M2TECH Evo Clock User Manual
M2TECH
E
VO
HIGH PERFORMANCE CLOCK GENERATOR
C
LOCK
USER MANUAL
REV. PRB – 12/2011
E
vo CLOCK
HIGH PERFORMANCE CLOCK GENERATOR
REVISION PrB – DECEMBER 2011
M2Tech
www.m2tech.biz
Warning!
Changes or modifications not authorized by the manufacturer can invalidate the
compliance to CE regulations and cause the unit to be no more suitable to use. The
manufacturer refuses every responsibility regarding damages to people or things
due to the use of a unit which has been subject to unauthorized modifications or to
misuse or to malfunction of a unit which has been subject to unauthorized
modifications.
This unit is compliant with the following CE regulations: CEI EN 55022:2009 Class B (Radiated Emissions),
CEI EN 55024:1999, CEI EN 55024:A2/2003, CEI EN 55024:IS1/2008 (Radio Frequency Electromagnetic
Fields, 50Hz Magnetic Field Immunity Test and Electrostatic Discharges – ESD).
Recycling
The label above, printed on the product case, indicates that the product, when no more usable, can’t be
treated as generic garbage, but must be disposed of at a collection point for recycling of electrical and
electronic equipment, in compliance with the WEEE regulation (Waste of Electrical and Electronic
Equipment).
By making sure that this unit is correctly recycled, you will help preventing potential damages to environment
and human health, which could be caused by a wrong treatment of this product as generic garbage.
Materials recycling helps saving natural resources. For more in-depth information about recycling this
product, please contact M2Tech Srl.
Copyright © 2011, M2Tech Srl
2
E
vo CLOCK
HIGH PERFORMANCE CLOCK GENERATOR
REVISION PrB – DECEMBER 2011
Dear customer,
thank you for purchasing Evo CLOCK. What you have is a high performance word clock
and master clock generator with many unique features conceived to obtain the best audio
performance in conjunction with the hiFace Evo as well as stand-alone.
E
vo CLOCK features two high precision, low phase noise temperature compensated
crystal oscillators, custom-made for M2Tech, low-noise regulators to avoid injecting jitter
by the supplies, transformer-coupled outputs and a wide range of frequencies. Two
outputs are available: one is specifically designed for the hiFace Evo, the other is for more
general usage with other market equipment which accept word clocks. 75 Ohms
impedance matching is an option for the word clock output.
An hiFace Evo fed by the very stable and clean clock from an Evo CLOCK delivers very
high performance, better than those allowed by the stock (and cheaper) oscillators inside
the hiFace Evo.
We feel that your expectations will be fulfilled by Evo CLOCK: you’ll hear your music in a
way like never before, prepare for a whole new experience!
To further increase the jitter performance from your Evo CLOCK, we suggest using an Evo
S
UPPLY to power it.
Nadia Marino, CEO
Please annotate here your Evo CLOCK serial number for future reference:
S/N: ____________________________________
Date of purchase: _________________________
M2Tech
www.m2tech.biz
Copyright © 2011, M2Tech Srl
3
