SONOMA SMOKER USER MANUAL
WARNINGS
WARNING
• Never use dented, rusty or damaged propane cylinders. Never store additional or empty propane cylinders
in the smoker cabinet or in the vicinity of this or any other appliance. Do not store propane cylinders indoors
or on their sides.
• Children should never be left alone or unattended in an area where a smoker is located. Place your smoker
well away from areas where children play. Do not store items that may interest children in or around the
smoker, in the cart, or in the masonry enclosure.
• Never move the smoker when hot. When in use, portions of the smoker are hot enough to cause severe
burns.
• Always maintain the required clearances from combustibles as detailed. The smoker is designed for outdoor
use only. Never use in a garage, building, shed, breezeway, or other enclosed area. Do not use this smoker
under any unprotected overhead combustible construction.
• Gas smokers are not designed or certified for and are not to be installed in or on recreational vehicles, portable trailers, boats or any other moving installation.
• Always have an ABC Fire Extinguisher accessible — never attempt to extinguish a grease fire with water or
other liquids.
• Storing your smoker: Store your smoker in a well-ventilated area. If stored indoors, detach and leave L.P.
cylinder outdoors in a well-ventilated area away from heat and away from where children may tamper with it.
• Keep any electrical supply cord and the fuel supply hose away from any heated surfaces. Electrical cords
should be placed away from walkways to avoid tripping hazard.
• Do not repair or replace any part of the smoker unless specifically recommended in this manual. Other service should be performed by a qualified technician.
• If the smoker is installed by a professional installer or technician, be sure that he/she shows you where your
gas supply shut-off is located. All gas lines must have a shut-off that is readily and easily accessible. If you
smell gas, check for gas leaks immediately. Check only with a soap and water solution. (See INDEX: “Leak
Testing” for further details.) Never check for gas leaks with an open flame.
• Inspect the L.P. gas supply hose prior to each use of the smoker. If there is evidence of excessive abrasion or
wear, or the hose is cut, it must be replaced before using the smoker.
• Never remove the grounding prong from the plug or use this product with an ungrounded, 2-prong adapter.
• Never block the flow of combustion and ventilation air.
THIS MANUAL MUST REMAIN WITH THE PRODUCT OWNER FOR FUTURE REFERENCE.
This product complies with ANSI standard Z21.89-2013/
CSA 1.18 2013, UL 62368-1 Issue: 2014/12/01 Ed:2 and
has been tested and approved by Intertek.
To obtain replacement parts or service contact:
Lynx Grills
7300 Flores Street
Downey, CA 90242
888-289-5969
CARE & USE/INSTALLATION
3
|
WARNINGS
WARNING
READ THIS MANUAL CAREFULLY and completely before using your smoker to reduce the risk of:
1. Fire
2. Burn hazard, personal injury or property damage
3. Ruined steaks or other unpleasant cooking experiences
4. Unapproved installation or servicing.
THIS PRODUCT IS DESIGNED FOR OUTDOOR USE ONLY. Improper installation, adjustment, alteration, service
or maintenance can cause property damage, injury or death.
Read this manual thoroughly before installation, use, or servicing of this product.
DANGER
IF YOU SMELL GAS:
1. Shut off all gas supply lines to the smoker.
2. Extinguish any open flames.
3. Carefully open the lid. Remember, it may be
extremely hot!
4. If odor continues, keep everyone away from the
smoker and immediately call your gas supplier
or your fire department.
WARNING
1. DO NOT store or use gasoline or other
flammable vapors and liquids in the vicinity of
this or any other appliance.
2. An LP cylinder not connected for use shall
not be stored in the vicinity of this or any
other appliance.
DANGER
S’IL Y A UNE ODEUR DE GAZ:
1. Coupez l’admission de gaz de l’appariel.
2. Éteindre toute flamme nue.
3. Ouvrir le couvercle.
4. Si l’odeur persiste, éloignez-vous de
l’appareil et appelez immédiatement le
fournisseur de gaz ou le service d’incendie.
AVERTISSMENT
1. Ne pas entreposer ni utiliser de l’essence ni
d’autres vapeurs ou liquides inflammables
dans le voisinage de l’appareil, ni de tout
autre appareil.
2. Une bouteille de propane qui n’est pas raccordée en vue de son utilisation, ne doit pas
être entreposée dans le voisinage de cet
appareil ou de tout autre appareil.
WARNING! CALIFORNIA PROPOSITION 65
1. The burning of gas cooking fuel generates some by-products which are on the list of substances which are
known by the State of California to cause cancer or reproductive harm.
2. California law requires businesses to warn customers of potential exposure to such substances. To minimize
exposure to the substances, always operate this unit according to the use and care instructions found in this
manual. Be certain to provide adequate ventilation when cooking.
4
CARE & USE/INSTALLATION
|
WARNINGS
WARNING
1. Always maintain the required clearances from combustible construction as detailed. The smoker is designed
for outdoor use only. Never use in a garage, building, shed, breezeway or other enclosed area. This smoker
shall not be used under any unprotected overhead combustible construction.
2. Gas smokers are not design certified for and are not to be installed in or on recreational vehicles, portable
trailers, boats or any other moving installation.
3. Keep any electrical supply cord and the fuel supply hose away from any heated surfaces. Electrical cords
should be placed away from walkways to avoid creating a tripping hazard.
4. Do not repair or replace any part of the smoker unless specifically recommended in this manual. Do not
open the touch pad containment box as there are no user-serviceable parts inside, and doing so will void all
warranties. All other service should be performed by a qualified technician.
5. All gas lines must have a shut-off that is readily and easily accessible. Be sure the owner knows where the
shut-off is located. If you smell gas, check for gas leaks immediately. Check only with a soap and water
solution. Never check for gas leaks with an open flame. (See INDEX: “Leak Testing” for further details.)
WARNING
1. The outdoor cooking gas appliance and its individual shutoff valve must be disconnected from the gas supply
piping system during any pressure testing of that system at test pressures in excess of 0.5 psi (3.5 kPa).
2. The outdoor cooking gas appliance must be isolated from the gas supply piping system by closing its
individual manual shutoff valve during any pressure testing of the gas supply piping system at test pressures
equal to or less than 1/2 psi (3.5 kPa).
STATE OF MASSACHUSETTS
1. Massachusetts requires all gas be installed using a plumber or gas fitter carrying the appropriate
Massachusetts license.
2. All permanently-installed natural gas or propane installations require a “T” handle type manual gas valve be
installed in the gas supply line to this appliance.
3. This does not apply to portable propane installations using a 20 pound cylinder.
CARE & USE/INSTALLATION
5
|
TABLE OF CONTENTS
USE & CARE GUIDELINES 6
LYNX SMOKER MODELS 6
A MESSAGE FROM LYNX 6
BEFORE YOU START 7
If Shipment Arrives Damaged 7
Important Notes 7
Clearance to Combustibles 8
SPECIFICATIONS & INSTALLATION 10
UNPACKING & ASSEMBLY 14
GAS CONNECTIONS 16
Natural Gas 16
LP Gas 17
Gas Conversion Kits 18
ELECTRICAL CONNECTIONS 20
FINAL CHECKS 21
Leak Testing 21
IMPORTANT SAFETY PRECAUTIONS 24
CHECKLIST BEFORE EACH USE 25
USING YOUR LYNX SMOKER 26
CLEANING YOUR LYNX SMOKER (Required Maintenance) 28
TROUBLESHOOTING YOUR LYNX SMOKER 30
Potential Problems 30
Contacting Lynx Customer Care 32
The Lynx Story 32
LYNX LIMITED WARRANTY 33
LYNX PROFESSIONAL SMOKERS EXPLODED PARTS VIEW 34-36
MODEL-SPECIFIC BTU OUTPUTS & MAX. RUNS FOR APPLIANCES 37
INDEX 38
6
CARE & USE/INSTALLATION
|
SONOMA SMOKER BY LYNX™ MODELS
USE & CARE GUIDELINES
This use & care manual covers the Sonoma Smoker by Lynx™ models listed below. Some features and options will
vary based upon the model that you purchased.
BUILT-IN FREESTANDING
LSMK LSMKF
LSMKM
SONOMA BLEND SMOKER CHIPS
LSCA Apple
LSCH Hickory
LSCM Mesquite
LSCP Pecan
LSCF 4 Pack
A MESSAGE FROM LYNX
Thank you for your purchase of a Sonoma Smoker by
Lynx™. You’ve just entered the future of smoking, a world
of amateur and professional chefs who are taking the
world of outdoor cooking to new levels through
technology.
Your Sonoma Smoker by Lynx™ has been designed to
the same exacting standards and meticulous attention
to detail every Lynx product enjoys. In addition to that,
You’re about to enjoy a high-performance stainless
steel Smoker that incorporates patented MyChef™
technology, an interactive, innovative and chef-friendly
system designed to elevate your cooking to new heights.
To get the maximum performance out of your Smoker, we
recommend carefully reading through this entire
manual before your first smoking. It contains important
information on how to properly set up your
Web: http://www.lynxgrills.com/
Facebook: https://www.facebook.com/LynxProfessionalGrills
Instagram: @lynxgrills
Twitter: @LynxGrills
Sonoma Smoker by Lynx™ and utilize the MyChef™
technology along with important safety tips and hints and
tricks that will enhance your Smoking experience. Keep it
handy for easy reference and should your Lynx Sonoma
Smoker by Lynx™ change
ownership, please make sure
the new owner receives this
manual. With proper use
and care, your Lynx Sonoma
Smoker by Lynx™ will provide years of trouble-free
service.
Thank you again for joining the community of Lynx
chefs. We love hearing about your experiences with our
products. Please check us out on the Web and social
media to let us know how you and your Sonoma Smoker
by Lynx™ are doing.
We wish you many years of happy smoking!
-The Lynx grills Team
CARE & USE/INSTALLATION
7
|
BEFORE YOU START
IMPORTANT NOTES
WHERE’S THE WIND?
When selecting a suitable location, consider important
factors such as exposure to the wind and foot-traffic
patterns.
If you have a freestanding smoker, position it so the prevail-
ing wind blows into the front control panel (at your back
when smoking), supporting the proper front-to-rear airflow.
Built-in smokers located in areas with prevailing winds
should be protected by a wind barrier.
Winds hitting the back of the smoker directly may cause
problems, as well as wind blowing along the hood gap.
HOW LONG IS YOUR RUN?
Keep all gas supply lines as short as possible because gas
lines lose pressure over distance and with each elbow and
tee that is added. This drop in pressure affects smoker
performance. (See INDEX: “Gas Supply Line Runs” for
further details.)
ARE YOU “ON-THE-LEVEL”?
Proper leveling during installation is critical. A smoker that
is out of level will cause erratic burner combustion and
inefficient, uneven heating. A carpenter’s spirit level
should be used to level the smoker both front-to-back and
side-to-side.
If the floor is uneven or has a decided slope, re-leveling
may be required each time you move a freestanding unit.
WARNING
• Never locate the smoker under a roof or overhang, in a building, garage, shed or other such enclosed area.
• Never locate the smoker under unprotected combustible construction.
• Installation must conform with local codes or, in the absence of local codes, with either the National Fuel Gas
Code, ANSI Z223.1/NFPA 54, Natural Gas and propane Installation Code, CSA B149.1, or Propane Storage and
Handling Code, B149.2, in Canada.
IF SHIPMENT ARRIVES DAMAGED
VISIBLE LOSS OR DAMAGE
Be certain any visible damage to the carton is noted on
freight bill or express receipt and signed by the person
making delivery.
FILE CLAIM FOR DAMAGES IMMEDIATELY, regardless of
extent of damage.
CONCEALED LOSS OR DAMAGE
If damage is unnoticed until the smoker is unpacked, notify
the transportation company or carrier immediately and file
a “concealed damage” claim with them. This should be
done within (5) days of the date delivery is made to you. Be
sure to hold on to the container for inspection. We cannot
assume responsibility for damage or loss incurred in transit.
(See INDEX: “Obtaining Service from Lynx” for further
details.)
Be sure wind doesn’t blow into the hood gap.
8
CARE & USE/INSTALLATION
|
BUILT-IN INSTALLATIONS
BEFORE YOU START ...continued
SMOKER TRAY CLEARANCE
The Lynx Built-In Smoker is designed for easy installation
into masonry enclosures.
NOTE: Lynx built-in smokers are intended either for
installation in a built-in enclosure constructed of
non-combustible materials or for an installation in a built in
enclosure constructed of combustible material when
clearance guidelines are followed.
For non-combustible applications, the smoker drops into
the opening shown in the cutout detail drawing (See INDEX:
“cut out dimensions”) and hangs from its counter-top trim.
A deck is not required to support it from the bottom.
(See INDEX: “Gas Requirements”) Pay special attention to
the provisions shown for gas line hook-up.
The enclosure should have ventilation holes to prevent gas
build-up in the event of a leak. The deck ledges and counter
should be flat and level. (refer to ANSI Z21.58 Standard for
Outdoor Cooking Gas Appliances, Section 1.7 Enclosures
For Self Contained LP-Gas Supply Systems)
This smoker requires that a 120 volt, 60 hertz, 15 amp GFI
certified outlet be installed by a qualified electrician.
On the right side 24” clearance is required to allow the
smoker chip tray to be removed.
24” Clearance
CLEARANCE TO COMBUSTIBLE MATERIALS
Combustible materials may make direct contact with the
edges of the firebox body up to the top surface of the
firebox. Above the counter top a minimum clearance of 6”
to rear combustibles, and 5” on the left side of the smoker.
CLEARANCE TO NON-COMBUSTIBLE MATERIALS
For non-combustible installations a 4” clearance is required
immediately behind the smoker to allow the front hood to
open. The smoker exhausts combustion products and
cooking greases to the back of the unit.
Never locate the smoker where this
residue will be difficult to clean.
Below the counter top surface the
non-combustibles should not encroach
on the cutout dimensions defined in this
manual for both fit, access to service and
airflow.
4” Min.
OVERHEAD PROTECTION AND EXHAUST REMOVAL
If installed under any combustible contruction the
cooking area over the smoker must be covered with an
exhaust hood. The hood must provide 3-6 inches of
overhang on all exposed sides. The exhaust hood shall
provide no less than 1,200 CFM for proper exhaust
ventilation. The hood must be approved for outdoor
installation and provided with a dedicated GFCI protected
branch circuit.
CARE & USE/INSTALLATION
9
|
CUTOUT SPECIFICATIONS
SHIPPING WT: 125#
NET WT: 108#
SHIPPING WT: 125#
NET WT: 108#
10
CARE & USE/INSTALLATION
|
The guides, measurements and dimensions detailed below are designed to assist you with planning your outdoor kitchen.
SPECIFICATIONS & INSTALLATION
NOTE: Due to continuing product innovation, specifications are subject to change without notice.
IMPORTANT: Please reference the Care & Use / Installation manual for details on gas plumbing requirements, electrical specifications and the
proper installation of your Lynx outdoor kitchen equipment. This manual can be downloaded from the Lynx website at www.lynxgrills.com
CUT OUT DIMENSIONS
12” minimum clearance
between accessories
3”minimum clearance
12” minimum clearance
between accessories
D
H
2 ½”minimum clearance between accessories.
H
W
D
W
GRILLS
MODEL
L27 26.00 10.88 22.00
L30 29.00 10.88 24.50
L36 35.00 10.88 22.00
L42 41.00 10.88 24.50
L54 53.00 10.88 24.50
W (Width)
H (Height) D (Depth)
INSULATED JACKET
MODEL
LIJ27 33.00 11.63 23.75
LIJ30 36.00 11.63 26.50
LIJ36 42.00 11.63 23.75
LIJ42 48.00 11.63 25.50
LIJ54 60.00 11.63 26.50
W (Width)
H (Height) D (Depth)
12” minimum clearance
between accessories (both sides)
H
W
D
NAPOLI OVEN/SMOKER/ASADO
MODEL
LPZA 29.00 4.00 24.50
LSMK 29.00 4.00 24.50
L30AG 29.00 10.88 24.50
2 ½”minimum clearance
3 ¼”minimum clearance
W (Width)
H
H (Height) D (Depth)
12” minimum clearance
between accessories (both sides)
W
CARE & USE/INSTALLATION
D
11
|
SPECIFICATIONS & INSTALLATION...
continued
3”
min.
D
W
H
2 ½”minimum clearance
betwee accessories.
SIDE BURNERS
MODEL
LSB1-3 12.13 10.63 12.50
LSB2-2 12.13 10.63 24.50
LSB2PC-1 24.25 10.63 24.50
LPB 19.00 10.63 22.00
W (Width)
H (Height) D (Depth)
WARMING DRAWERS
MODEL
L30WD-1 28.50 10.00 20.50
L42CC-1 40.25 19.38 24.50
W (Width)
H (Height) D (Depth)
H
D
W
COCKTAIL PRO/SINKS
MODEL
LCS30 29.00 10.50 22.00
LSK18 17.00 10.50 22.00
LSK24 23.00 10.50 22.00
LSK30 29.00 10.50 22.00
D
H
W
W (Width) H (Height) D (Depth)
UNCONVENTIONAL ISLAND INSTALLS
If building an island that does not conform to the standard properties listed in the following pages, please contact Lynx
Grills at 888-259-5969 to verify all safety requirements regarding installation have been met.
12
CARE & USE/INSTALLATION
|
Loading...
