Lynx 4TS852A User Manual

1 2 3 4 5

End of programme when ...

... the status indicator centrifugado (Spin) flashes and

§Ê appears in the display panel.

Interrupting the programme

Programmes at high temperatures: – Cool washing: Select aclarado/centrifugado (Rinse/

Spin).

– Select iinicio/pausa (Start/Pause). Programmes at lower temperatures: – aclarado/centrifugado (Rinse/Spin) (deactivate agua

extra (Extra Rinse)) or select vaciado (Empty).

– Select inicio/pausa (Start/Pause).

Changing the programme, if ...

... you have selected the wrong programme by mistake: – Reselect the programme. – Select inicio/pausa (Start/Pause). The new programme

starts from the beginning.

Correct installation according to the separate Installation instructions.

Checking the machine

– Never use a damaged machine. – Inform the after-sales service.

Connecting the mains plug

Make sure your hands are dry. Take hold of the plug only.

Turning the tap on

Compartment II: Detergent for the main wash, water softener,

bleach, stain remover

Sorting and loading laundry

Follow the manufacturer's care information.

According to the information on the care labels.

According to type, colour, soiling and temperature.

Do not exceed the maximum load –> page 7.

Observe the important information –> page 6.

Insert large and small items of laundry.

Close the washing machine door. Take care not to trap items of laundry

between the washing machine door and the rubber seal.

Add detergent and care products

Measure accordingly:

Amount of laundry, soiling, water hardness (ask your water supply

company) and manufacturer's instructions.

Pour liquid detergent into the appropriate dispenser and place in the drum.

Your washing machine

Congratulations ä You have opted for a modern, high-quality

domestic appliance manufactured by Lynx. The washing machine is distinguished by its economical energy consumption.

Each machine that leaves our factory has been inspected thoroughly to ensure that it functions properly and is in perfect condition.

Further information: http://www.actitud-lynx.com

Environmentally friendly waste disposal 

All packaging must be disposed of in accordance with environmental guidelines. This appliance is certified in accordance with European Directive 2002/96/EC on waste electrical and electronic equipment (WEEE). This directive provides the framework for the EU-wide collection and reuse of used appliances.

Intended use

Contents Page

ʋIntended use .......................................................................................1

ʋProgrammes .......................................................................................1

ʋSetting and adjusting the programme ...........................................3

ʋWashing ...........................................................................................3/4

ʋAfter washing ......................................................................................4

ʋIndividual settings ..........................................................................5/6

ʋImportant information ...................................................................... 6

ʋOverview of programmes ................................................................7

ʋSafety instructions .............................................................................8

ʋConsumption values .........................................................................8

ʋCare .....................................................................................................9

ʋInformation on the display panel ....................................................9

ʋMaintenance .................................................................................... 10

ʋWhat to do if... ..................................................................................11

Environmental protection/Conservation tips

– Always fill the washing machine with a maximum amount of

laundry for the relevant programme.

– Wash normally soiled laundry without a pre-wash. – Instead of algodón (Cottons) 90 °C, choose the programme

algodón (Cottons) + económico (economic) j 60 °C.

Comparable cleaning result with significantly lower energy consumption.

– Measure the detergent according to the manufacturer's

instructions and water hardness.

– If the laundry is then dried in the tumble dryer, select the spin

speed according to the instructions of the dryer manufacturer.

Preparation

Before washing for the first time

Wash once without any laundry –> page 9.

Programmes

Detailed overview of programmes –> page 7. Temperature and spin speed can be selected individually,

depending on the selected programme and programme progress.

algodón (Cottons)

Hard-wearing fabrics

+ rápido (quick) i

+ económico (economic) j

+ prelavado (Prewash)

antiarrugas (Anti-crease)

sintéticos (Easy-Care)

Easy-care fabrics

+ rápido (quick) i

+ económico (economic) j

+ prelavado (Prewash)

mix Different types of laundry

delicado (Delicate/Silk) Delicate washable fabrics

lana (Wool) ÿHand/machine-washable wool

15 minutos (Quick) Short programme

aclarado/centrifugado (Rinse/Spin)

Hand-wash laundry, agua extra (Extra Rinse) activated; if only using the spin cycle, deactivate the button

vaciado (Empty) Drain rinsing water for - - - -

Washing

Removing the washing

Open the washing machine door and remove the washing. If - - - - (without final spin) is active: Turn the programme

selector to vaciado (Empty) or select the spin speed. Select inicio/pausa (Start/Pause).

– Remove any foreign objects - risk of rusting. – Leave the washing machine door and detergent

drawer open so that any residual water can evaporate.

Turning the tap off

Not required for AquaStop models –> Refer to installation instructions

Switching off

Turn the programme selector to paro ](stop).

Washing

Detergent drawer with

compartments I, II, ~

Washing machine door

Compartment ~: Fabric softener, starch

Compartment I: Detergent for pre-wash

ʋfor domestic use only,

ʋfor machine-washable fabrics and hand-washable wool

in detergent solution,

ʋto be operated with cold drinking water and commer-

cially available detergents and care products which are suitable for use in washing machines.

– Do not leave children unattended near the

washing machine.

– The washing machine is not to be used by

children or persons not familiar with the operating instructions.

– Keep pets away from the washing machine.

Dilute thick fabric softener and fabric conditioner with water. This prevents blockages.

Individual settings

Option buttons

The spin speed and temperature can be changed before and during the selected programme runs. The effects depend on the programme progress.

centrifugado (Spin speed)

You can change the displayed spin speed. The maximum selectable spin speed depends on the model and on which programme is currently selected.

temperatura (Temperature)

You can change the displayed washing temperature. The maximum washing temperature that can be selected depends on the programme that has been set.

tiempo diferido (Finished in)

When you select the programme, the relevant programme duration is displayed. You can delay the start of the programme before it begins. The "finished in" time can be set in increments of one hour up to a maximum of 24 hours. Press the tiempo diferido (finished in) button repeatedly until the required number of hours is displayed (h = hour). Select inicio/

pausa(Start/Pause).

Additional function –> and overview of programmes, see page 7

agua extra

(Extra Rinse)

Additional rinse cycle. For areas with very soft water or for further enhancing the washing result.

Childproof lock

#

Childproof lock/ Appliance lock

You can lock the washing machine to prevent the functions you have set from being changed inadvertently.

ON/OFF: Press and hold the inicio/pausa (Start/Pause) button for approx. 5 seconds after the start/end of the programme.

Note: The childproof lock can remain activated until you wish to start the next programme, even after switching off the machine.

Then you can deactivate the childproof lock before the start of the programme and activate it again as necessary once the programme has started.

inicio/pausa (Start/Pause)

For starting or interrupting the programme.

Important information

Protecting the laundry and the machine

– Empty pockets. – Look out for metal items (paperclips, etc.). – Wash delicates in a laundry bag (tights, curtains, underwired bras). – Fasten zips, do up any buttons. – Brush sand out of pockets and collars. – Remove curtain fittings or place in the laundry bag.

Laundry with varying degrees of soiling

Wash new items of clothing separately.

light Do not pre-wash. If required, choose the + rápido (quick) i

programme. Pre-treat any stains as necessary.

heavy Do not load as much laundry. Select the program with prewash.

Soaking Load laundry of the same colour

Pour soaking agent/detergent into compartment II in accordance with the manufacturer's instructions. Turn the programme selector to algodón (Cottons) 30 °C and select inicio/ pausa (Start/Pause). After approx. 10 minutes, press inicio/pausa (Start/Pause) to pause the programme. Once the required soaking time has elapsed, select inicio/pausa (Start/Pause) again to continue the programme, or select a different programme.

Starching Laundry must not be treated with fabric softener

Starching is possible in all wash programmes if liquid starch is used. Pour the starch in

accordance with the manufacturer's instructions into fabric softener compartment ~ (rinse first

if necessary).

Dyeing/bleaching

Dye should only be used in normal household quantities. Salt may damage stainless steel. Always follow the dye manufacturer's instructions! Do not use the washing machine for bleaching clothes!

Drum

Control panel

Service flap

---- - 1200* centrifugado

(spin speed)

Select the spin speed (* depending on the model) or - - - - (no final spin, laundry soaks in the last rinsing water, display panel - - - -)

ª¥Ê - 90 temperatura

(temperature)

Selecting the temperature

1 - 24h tiempo diferido

(finished in)

Programme end after

Childproof lock –> page 5

Setting** and adjusting programmes

Display panel/

option buttons

Programme selectorStart/

Pause

Programme selector for switching the machine on and off and for selecting the programme. Can be turned in either direction.

**If the #symbol flashes in the

display panel, the childproof lock is active –> deactivate, page 5.

Additional function and options buttons –> Individual settings, page 5.

Select inicio/pausa

(start/pause)

Additional

function

Status

indicators

If the buttons are held for longer, the appliance automatically runs through the setting options.

Overview of programmes –> Refer to the table of consumption values on page 8 and notes on page 6.

Programmes °C max.

Type of laundry

Additional functions; information

algodón (Cottons) ª¥Ê - 90 °C

7 kg/

4 kg*

Hard-wearing fabrics, heat-resistant fabrics made

of cotton or linen

agua extra (Extra Rinse)

+ rápido (quick) i* ª¥Ê - 90 °C agua extra(Extra Rinse); shorter programme

+ económico (economic) jª¥Ê - 90 °C agua extra(Extra Rinse); energy-saving programme

+ prelavado (Prewash) ª¥Ê - 90 °C agua extra(Extra Rinse); prewash at 30 °C

antiarrugas]

(Anti-crease)

ª¥Ê - 60 °C

agua extra(Extra Rinse); special spin sequence with

subsequent fluffing.

sintéticos (Easy-Care) ª¥Ê - 60 °C

3 kg

Easy-care fabrics made of cotton, linen, synthetic

fibres or blended fabrics

agua extra(Extra Rinse)

+ rápido (quick) iª¥Ê - 60 °C agua extra(Extra Rinse); shorter programme

+ económico (economic) jª¥Ê - 60 °C agua extra(Extra Rinse); energy-saving programme

+ prelavado (Prewash) ª¥Ê - 60 °C agua extra(Extra Rinse); prewash at 30 °C

mix ª¥Ê - 40 °C Fabrics made of cotton or easy-care fabrics

agua extra(Extra Rinse);

different types of laundry can be washed together

delicado

(Delicate/Silk)

ª¥Ê - 40 °C

2 kg

For delicate, washable fabrics, e.g. made of silk,

satin, synthetic fibres or blended fabrics (e.g. cur-

tains)

agua extra(Extra Rinse);

no spin between rinse cycles

lana (Wool) ÿüª¥Ê - 40 °C

Handä or machine-washable fabrics made of wool

or containing wool

Particularly gentle wash programme to prevent shrinkage of laundry.

Longer programme breaks (fabrics rest in the detergent solution)

15 minutos (Quick) ª¥Ê - 40 °C

Easy-care fabrics made of cotton, linen, synthetic

fibres or blended fabrics

Short programme, approx. 15 minutes,

suitable for lightly soiled laundry

Additional programmes aclarado/centrifugado (Rinse/ Spin), vaciado (Empty)

* reduced load



As a short programme, mix 40 °C, with the maximum spin speed is ideal.

Programmes without pre-wash - add detergent to compartment II, programmes with pre-wash - distribute the detergent between compartments I and II.

8908 / 9000414483

9000414483

4TS863A /...

Lynx Electrogeräte GmbH

CarläWery Str. 34

81739 München / Germany

Safety instructions

– Read the instruction manual and installation instructions and all other information enclosed

with the washing machine and act accordingly.

– Retain the documents for subsequent use.

Risk of electric shock – Never pull the cable to disconnect the mains plug.

– Never insert/disconnect the mains plug with damp hands.

Danger to life For worn-out appliances:

– Disconnect the mains plug. – Sever the mains cable and discard along with the plug. – Destroy the lock on the washing machine door. This will prevent

children from locking themselves in and risking their lives.

Danger of suffocation – Keep packaging, film and packaging parts out of the reach of

children.

Risk of poisoning – Keep detergents and care products out of the reach of children.

Risk of explosion – Items of laundry pretreated with cleaning agents containing

solvents, e.g. stain remover/cleaning solvent may cause an explosion after being loaded into the washing machine. Rinse items of laundry thoroughly by hand beforehand.

Risk of injury – The washing machine door can become very hot.

– Be careful when draining hot detergent solution. – Do not climb onto the washing machine. – Do not lean on the open washing machine door. – Do not reach into the drum if it is still rotating. – Be careful when opening the detergent drawer while the machine

is in operation.

Consumption values

Programme

Additional

function

Load

Electricity consumption

(cold)

***

Water***

Programme duration

***

algodón (Cottons) cold

7 kg 0.25 kWh 60 l 2:36 h

algodón (Cottons) 40 °C**

7 kg 0.69 kWh 60 l 2:36 h

algodón (Cottons) 60 °C**

7 kg 1.33 kWh 60 l 2:39 h

algodón (Cottons) 60 °C*

+ económico

(economic) j

7 kg 1.05 kWh 47 l 3:08 h

algodón (Cottons) 90 °C

7 kg 2.00 kWh 64 l 2:47 h

sintéticos (Easy-Care) 40 °C**

3 kg 0.55 kWh 55 l 1:17 h

mix 30 °C 3 kg 0.24 kWh 32 l 1:03 h

delicado (Delicate/Silk) cold

2 kg 0.06 kWh 31 l 0:41 h

delicado (Delicate/Silk) 30 °C

2 kg 0.21 kWh 31 l 0:41 h

lana (Wool) cold

2 kg 0.10 kWh 39 l 0:40 h

lana (Wool) 30 °C

2 kg 0.19 kWh 39 l 0:40 h

* Programme setting for testing and energy labelling in accordance with EU directive 92/75/EEC. ** Programme setting for testing in accordance with valid standard EN60456.

Note on comparative tests: For testing the test programmes, wash the specified load using the maximum spin speed. As a short programme for coloureds, select the programme mix 40 °C with the maximum spin speed.

*** The values deviate from the indicated values depending on water pressure, hardness, and inlet temperature, ambient

temperature, type, amount and soiling of the laundry, detergent used, fluctuations in the power supply and selected additional functions.

Care

Before washing for the first time

Do not put any laundry in the machine. Turn on the tap, add approximately 1 litre of water and then ½ a measuring cup of detergent into compartment II. Turn the programme selector to sintéticos (Easy-Care) 60 °C and select inicio/pausa (Start/Pause). At the end of the

programme, turn the programme selector to paro

 (stop).

Machine housing, control panel

– Wipe with a soft, damp cloth. – Do not use any abrasive cloths, scourers or cleaning agents (stainless steel cleaners). – Remove detergent and cleaning agent residue immediately. – Do not clean with a jet of water.

Cleaning the detergent drawer ...

... if it contains detergent or fabric softener residues.

1. Pull out, press insert down, remove drawer completely.

2. To remove the insert: press the insert upwards from below with your

finger.

3. Clean the detergent dispenser tray and insert with water and a brush and

dry it.

4. Attach the insert and engage (connect the cylinder to the guide pin).

5. Push in the detergent drawer.

Leave the detergent drawer open so that any residual water can evaporate.

Drum

Leave the washing machine door open so that the drum can dry out. Rust stains - use chlorine-free cleaning agent, not steel wool.

Descaling Ensure there is no laundry in the machine

Descale the appliance according to the descaler manufacturer's instructions. This should not be necessary if the correct dosage of detergent is used.

Information on the display panel depending on model

E3 Close the washing machine door properly; laundry may be caught. E5 Open the tap completely, supply hose kinked or trapped;

Clean the filter –> page 10, Water pressure too low.

E6 Detergent solution pump blocked; Clean the detergent solution pump –> page 10.

Drainage hose/waste pipe blocked; Clean the drainage hose at the siphon –> page 10.

E2 Motor fault. Call the after-sales service.

– Risk of electric shock.

Disconnect the mains plug.

– Risk of explosion. No solvents.

Maintenance

Detergent solution pump

Turn the programme selector to paro  (stop) and disconnect the

mains plug.

1. Open and remove the service flap.

2. For models with a drainage hose: Remove the drainage hose from the

retainer and pull it from the housing. Remove the container. Remove the sealing cap, allow the detergent solution to flow out. Replace the sealing cap and place the drainage hose in the retainer.

2* For models without a drainage hose: Carefully unscrew the pump cover

until the detergent solution begins to flow out. When the service flap is half full, close the pump cover and empty the service flap. Repeat the above steps until all the detergent solution has completely drained out.

3. Carefully unscrew the pump cover (residual water).

4. Clean the interior, pump cover thread and pump housing (the impeller in

the detergent solution pump must rotate).

5. Replace the pump cover and screw it tightly.

6. Place the service flap back on and close.

To prevent unused detergent from flowing straight into the drain during the next wash: Pour 1 litre of water into compartment II and start the vaciado (Empty) programme.

Drainage hose at the siphon

Turn the programme selector to

paro  (stop)

and disconnect the mains

plug.

1. Loosen the hose clamp, carefully remove the drainage hose

(residual water).

2. Clean the drainage hose and siphon connecting piece.

3. Reattach the drainage hose and secure the connection with the hose clamp.

Filter in the water supply

Risk of electric shock

Do not immerse the AquaStop safety device in water (contains an electric valve).

Reduce the water pressure in the supply hose:

1. Turn off the tap.

2. Select any programme (except aclarado/centrifugado/vaciado (Rinse/ Spin/Empty)).

3. Select inicio/pausa (Start/Pause). Let the programme run for

approximately 40 seconds.

4. Turn the programme selector to paro

 (stop). Disconnect the mains

plug. Clean the filter:

1. Depending on model: Disconnect the hose from the tap. Clean the filter using a small brush. and/or for Standard and AquaStop models: Remove the hose on the rear of the appliance, Remove the filter with pliers and clean.

2. Connect the hose and check for leaks.

– Risk of scalding. Allow the

detergent solution to cool down.

– Turn off the tap.

What to do if ...

Water is leaking out. – Attach/replace the drainage hose correctly.

– Tighten the screw connection of the supply hose.

No water supply. Detergent not dispensed.

– inicio/pausa (Start/Pause) not selected? – Tap not turned on? – Filter blocked? Clean the filter –> page 10. – Supply hose kinked or trapped?

Washing machine door cannot be opened.

– Safety function active. Wait approx. 2 minutes. – - - - - (without final spin) selected? –> page 3, 4.

Programme does not start.

– inicio/pausa(Start/Pause) or tiempo diferido (finished in-time)

selected?

– Washing machine door closed? – Childproof lock active? Deactivate –> page 5.

Detergent solution is not drained.

– - - - - (without final spin) selected? –> page 3, 4. – Clean the detergent solution pump –> page 10. – Clean the waste pipe and/or drainage hose.

Water not visible in the drum.

– Not a fault - water below the visible area.

Spin result not satisfactory.

– Distribute large and small items of laundry evenly in the drum. – Programme antiarrugas (Anti-crease) selected? –> page 7. – Speed selected too low? –> page 5.

Spin cycle performed several times.

– Not a fault - unbalanced load detection system adjusts the

imbalance.

Residual water in the compartment for care products.

– Not a fault - the action of the care product is not affected. – Clean the insert if necessary –> page 9.

Odour formation in the washing machine.

– Run programme algodón (Cottons) 90 °C without laundry. Use

standard detergent.

Foam escaping from the detergent drawer.

– Too much detergent used?

If foam is escaping from the detergent drawer: Mix 1 tablespoon of fabric softener with ½ litre of water and pour into compartment II (not with outdoor or down fabrics).

– Reduce the detergent dosage for the next wash cycle.

Intense noise formation, vibrations and “wandering” during the spin cycle.

– Are the appliance feet fixed?

Secure the appliance feet –> Installation instructions.

– Transportation safety devices removed?

Remove the transportation safety devices –> Installation instructions.

Display panel/indicator lamps do not function during operation.

– Power cut? – Fuses triggered? Reset/change the fuses. – If the fault occurs repeatedly, call the after-sales service.

Programme sequence longer than usual.

– Not a fault - unbalanced load detection system adjusts

imbalance by repeatedly distributing the laundry.

– Not a fault - foam detection system active - adds an additional

rinse cycle.

Detergent residues on the laundry.

– Occasionally, phosphate-free detergents contain water-insoluble

residues.

– Select aclarado/centrifugado (Rinse/Spin) or brush the laundry

after washing.

If you cannot correct a fault yourself (switching on/off) or a repair is required:

– Turn the programme selector to paro  (stop) and remove the mains plug from the

socket.

– Turn off the water supply and call the after-sales service –> Installation instructions.

Instruction manual

Washing machine

Observe the safety instructions on page 8.

Read these instructions and the separate installation instructions before operating the washing machine.

1 2
