Professional Weighing
Equipment
HRB Series intelligent weighing machine
HIGH RESOLUTION BALANCE
WITH COUNTING FUNCTION
HRB(-E) 3001 / 6001 / 10001 HRB(-E) 10001LP / 20001
Operating Manual
1
Mark applied
EU Directive
Standards
2004/108/EC
EN 61326-1: 2006
USA model
UK (Europe) model
HRB 3001
HRB-E 3001
HRB 6001
HRB-E 6001
HRB 10001
HRB-E 10001
HRB 10001LP
HRB-E 10001LP
HRB 20001
HRB-E 20001
Declaration of Conformity
Declaration of conformity for apparatus with CE mark
We hereby declare that the product to which this declaration refers conforms to the following
standards.
Electronic scale: HRB - High Resolution Balances
Date: 14. 11. 2012 Signature:
Boon Lim, R & D Manager
LW Measurements LLC, 3510 Industrial Drive, Unit H Santa Rosa, CA 95403
2
Identification
Customer Service
USA
LW Measurements LLC, 3510 Industrial Drive,
Unit H Santa Rosa, CA 95403
USA
Tel: (707) 542-2185
FAX: (707) 542-3285
EUROPE
LW Measurements Europe Ltd
Chalkwell Park House 700 London Road
Westcliff-on-Sea Essex SS0 9HQ
United Kingdom
Tel: 01702-476700
Fax: 01702-477380
ASIA
LW Measurements PTY Ltd
Block 1004, Toa Payoh North
#03-16 Singapore 318995
Tel: (65) 6458 3438
HP: (65) 8119 3401
http://lwmeasurements.com
Refer to our website for information about local customer service centers and details of their
addresses.
3
Introduction
What you should know about these Operating Instructions:
Tree® Professional Weighing Equipment products are simple to operate.
Nevertheless, you should read through these operating instructions in their entirety, so that you can make
optimum use of the full potential and the diverse possibilities of the weighing machine in your daily work.
These operating instructions contain guidance in the form of pictograms and keyboard diagrams, which
should help you in finding the required information:
For the labeling of potential hazards and advice, please see Safety below.
4
Contents
Section
Heading
1
Safety
1.1 Representation and symbols
1.2 Safety recommendations
2
Your weighing machine
2.1 Construction and functions
2.1.1 Construction of the weighing machine
2.1.2 Functions of the weighing machine
2.2 Application, conformity
2.2.1 Correct use of the weighing machine
2.2.2 Conformity
2.3 Data and parameters
2.3.1 Technical data
2.3.2 RS232 Data Interface
3
Getting started with your weighing machine
3.1 Unpacking the equipment
3.2 Scope of delivery
3.3 Assembling your weighing machine
3.4 Choice of a suitable location
3.5 Checking the mains voltage
3.6 Leveling the weighing machine
3.7 Calibrating the weighing machine
4
Working with the application menu using the intelligent keypad
4.1 Display messages and key functions
4.1.1 Display messages
4.1.2 Key functions
4.2 Program options
4.2.1 Interface setting
4.2.2 Parameter settings
4.2.2.1 Setting zero tracking range
4.2.2.2 Setting zero tracking time
4.2.2.3 Setting displaying zero range
4.2.2.4 Setting filter parameter
5
4.2.2.5 Setting Zero range when power on
4.2.2.6 Setting Zero range of ZERO key
4.2.2.7 Setting Zero range of TARE key
4.2.2.8 Setting overload range
4.2.2.9 Setting Beeper
4.2.2.10 Setting ZERO and TARE function merge function
4.2.2.11 Setting Auto Shut off
4.2.2.12 Setting Backlight
4.2.3 Pieces counting
5
Calibration using an external calibration weight
6
Maintenance and service
7
Transport and storage
7.1 Transportation and shipping
7.2 Storage
6
1 Safety
1.1 Representations and symbols
Important instructions, which involve safety, are highlighted with the appropriate mark:
1.2 Safety recommendations
When using the weighing equipment in surroundings with increased safety requirements, the
corresponding regulations must be observed.
The weighing machine may only be used with the power adapter supplied exclusively for use with the
weighing machine.
Before inserting the power adapter, the user must ensure that the operating voltage stated on the power
adapter agrees with the mains voltage.
If not, please contact Customer Service at the address above.
If the power adapter or its cable is damaged, the weighing machine must immediately be disconnected
from the electricity supply (pull out the power adapter).
The weighing machine may only be operated from mains electricity supply with a power adapter which is
in perfect condition.
If there should be any reason to believe that it is no longer possible to operate the weighing machine
without danger, the weighing machine is to be immediately unplugged from the electricity supply (pull out
power adapter) and secured against inadvertent operation.
In carrying out maintenance work, it is essential to follow the recommendations in Chapter 6 Maintenance
and service.
The weighing machine must not be operated in an area subject to explosion risks.
Care must be taken when weighing liquids to ensure that no liquid is spilt into the inside of the weighing
machine or into connections on the rear of the equipment or the power adapter. If liquid is spilt on the
weighing machine, it must immediately be unplugged from the mains electricity supply (pull out power
adapter).
The weighing machine may only be operated again after it has first been re-checked by a service
technician.
These operating instructions must be read by each operator of the equipment and must be available at
the workplace at all times.
7
2 Your weighing machine
2
Figure 2.1 Your weighing machine
4
1 2 1
3
2.1 Construction and functions
2.1.1 Construction of the weighing machine
The weighing machine consists of the weighing machine body (1), the scale-pan (2), the hook for below
weighing - for model HRB(-E) 10001 only (3), the adapters (4), and this operating manual.
8
2.1.2 Functions of the weighing machine
Model number
Capacity
Graduation
Weighing pan Size
HRB(-E) 3001
3000g
0.1g
180mm x 170mm
HRB(-E) 6001
6000g
0.1g
180mm x 170mm
HRB(-E) 10001
10000g
0.1g
180mm x 170mm
HRB(-E) 10001LP
10000g
0.1g
215mm x 198mm
HRB(-E) 20001
20000g
0.1g
215mm x 198mm
Net/gross weight
HRB(-E) 3001 / 6001 / 10001: 1.4kg / 2.2kg
HRB(-E) 10001LP / 20001: 3.2kg / 3.9kg
Package
(Standard carton)
HRB(-E) 3001 / 6001 / 10001: 36 x 23 x 14 (cm3)
HRB(-E) 10001LP / 20001: 37 × 27 ×16 (cm3)
Package
(Master carton)
HRB(-E) 3001 / 6001 / 10001: 6 units in one box 54 x 35 x 40 (cm3)
HRB(-E) 10001LP / 20001: 4 units in one box 56 × 39 × 34 (cm3)
Operating Temp.
0-40℃ (32-104℉)
Power source
HRB(-E) 3001 / 6001 / 10001: 6 x AA dry cells(not included) or AC/DC
HRB(-E) 10001 LP / 20001: Rechargeable battery or AC/DC
Adapter: HRB(-E) 3001 / 6001 / 10001: 12V DC/150mA
HRB(-E) 10001LP / 20001: 10-12V DC/500mA
The HRB Series are high-quality electronic precision weighing machines with counting function and the
following specifications
9
FEATURES
Figure 2.2 Details of your weighing machine
Weighing pan
Battery
compartment cover
Bright back-lit display
Battery
compartment
(Dry cells not
included)
Bubble level
Mains power connection
Leveling feet
RS232 connection
Auto zero tracking
Low battery indication
Large bright backlit LCD
Large stainless steel pan
Stability indication
Auto calibration
Selectable auto back light
Selectable beeper
Selectable auto shut off
Unit switching: g, ct, oz, tola ... ...
1.3 million internal resolution
24 bit A/D processor
Less than 1s display setting time
Highest quality sensor used
Counting function
Below weighing - model HRB(-E) 10001 only
10
2.2 Application, conformity
2.2.1 Correct use of the weighing machine
The weighing machine may only be used for the weighing of solid-materials and of liquids filled into
secure containers.
The maximum allowable load of the weighing machine must never be exceeded, otherwise the weighing
machine may be damaged.
In using the weighing machine in combination with other appliances as well as with appliances produced
by other manufacturers, the appropriate regulations for the safe use of the relevant attachments and their
application in accordance with instructions must be observed.
2.2.2 Conformity
The weighing machine has been manufactured and tested in accordance with the standards and
recommendations set out in the declaration of conformity.
The power adapter produced for the operation of the weighing machine and intended exclusively for this
application, complies with the appropriate electrical protection class.
2.3 Data and parameters
2.3.1 Technical data
The following applies to HRB series
Power supply:
HRB(-E) 3001 / 6001 / 10001:
. Input: 110 or 230V AC (+/-15-20%); 50 to 60Hz
. Output: 10-12v DC 150mA
HRB(-E) 10001LP / 20001:
. Input: 110 or 230V AC (+/-15-20%); 50 to 60Hz
. Output: 10-12v DC 500mA
Allowable ambient conditions
Temperature: 5°C - 40°C
Relative humidity: 25% - 85%, non-condensing
If you have any questions on the technical data or require detailed technical information on your balance,
please contact your technical representative.
11
2.3.2 RS232 Data interface
1~2 3 4~13
14~18
19
20
‘W: ’ P DATA
UNIT
CR
LF
1. Connector: DB9
BALANCE PC
2 2
3 3
5 5
2. Transmissions Settings
Mode: Simplex Asynchronous Serial Baud Rate: 9600
Data Bit: 8 Parity Bit: None
Stop Bit: 1 Data Format: ASCII
3. Transmission Information Format： 20 Byte ，blank=20H
W: Start of Data Transmission=57H+3AH
P : Polarity ‘+’ = 2BH = Positive ‘-’ = 2DH =Negative
DATA: ‘ 12.345’= 20H+20H+20H+20H+31H+32H+2EH+33H+34H+35H
UNIT: ‘g’ =67H+20H+20H+20H+20H
‘oz ’ =6FH+7AH+20H+20H+20H
‘lb’ =6CH+62H+20H+20H+20H
‘dwt’ =64H+77H+74H+20H+20H
‘ozt ’ =6FH+7AH+74H+20H+20H
‘ct ’ =63H+74H+20H+20H+20H
‘tl.T’ =74H+6CH+2EH+54H+20H
‘tl.H’ =74H+6CH+2EH+48H+20H
‘tl.J ’ =74H+6CH+2EH+4AH+20H
‘GN’ =47H+4EH+20H+20H+20H
‘dr’ =64H+72H+20H+20H+20H
‘MM’ =4DH+4DH+20H+20H+20H
‘tola’ =74H+6FH+6CH+61H+20H
‘gsm’ =67H+73H+6DH+20H+20H
‘T/A/R’ =54H+2FH+41H+2FH+52H
‘T/M/R’ =54H+2FH+4DH+2FH+52H
‘pcs’ =50H+43H+53H+20H+20H
CR: = 0DH
LF: = 0AH
12
3 Getting started with your weighing machine
Component delivered present yes / no
Weighing unit body
Weighing pan
Power adapter
Operating manual
3.1 Unpacking the equipment
The machine is delivered in an environmentally-friendly carton, specifically developed for this precision
instrument, which provides optimum protection for the balance during transportation.
We suggest that you retain the original packaging in order to avoid transportation damage if re-shipping
or transporting the balance and to allow the unit to be stored in the best conditions if it is out of operation
for an extended period.
In order to avoid damage, attention must be given to the following points when unpacking the balance:
Unpack the weighing machine carefully. It is a precision instrument.
When outside temperatures are very low, the balance should first be stored for some hours in the
unopened transport package in a dry room at normal temperature, so that no condensation settles on the
unit when unpacking.
Check the weighing machine immediately after unpacking for externally visible damage. If you should find
transport damage, please inform your service representative immediately.
If the unit is not to be used immediately after purchase but only at a later time, it should be stored in a dry
place where fluctuations in temperature are as small as possible (see Chapter 7 .Transport, storage.).
Read through these operating instructions, even if you already have prior experience with weighing
equipment, before you work with the unit and pay attention to the Safety recommendations (see Chapter
1 .Safety).
3.2 Scope of delivery
Inspect delivery for completeness immediately on unpacking all components.
Checklist for complete delivery
13
3.3 Assembling your weighing machine
The weighing machine is delivered in partly dismantled condition. Assemble the individual components in
the following sequence:
Place the unit holder in position and add the weighing pan
Insert the power adapter cable plug into the socket at the rear of the balance.
3.4 Choice of a suitable location
The environment in which your weighing machine is used is very important. Air movement, temperature
changes, vibrations, direct sunlight, etc. all influence the performance of high precision weighing
machines. Therefore, place your weighing machine on a solid, sturdy surface that is free of air currents,
vibration and not in direct sunlight. The surface should not be magnetic and should be located away from
doors, windows, heaters, air conditioners and fans.
To summarize:
Put the weighing machine on a solid, firm and preferably vibration-proof, horizontal base
Make sure that the weighing machine cannot be shaken or knocked over
Protect from direct solar radiation
Avoid drafts and excessive temperature fluctuations
3.5 Checking the mains voltage
The following Safety recommendations must be observed when connecting the balance to the mains:
The balance may only be operated with the power adapter supplied.
Check before connecting the power adapter to the mains supply, that the operating voltage stated on the
power adapter agrees with the local mains voltage.
If the operating voltage is not the same as the mains voltage, the power adapter must on no account be
connected to the mains supply. Contact customer service.
14
3.6 Leveling the weighing machine
*** Not applied to model HRB(-E) 3001 / 6001 / 10001
To function properly, the balance must be precisely horizontal. The balance is fitted with one bubble level.
and adjustable feet for level-control, with the aid of which it is possible to compensate for small height
differences and / or any unevenness in the surface on which the balance is positioned.
The screw feet must be adjusted so that the air bubble is precisely in the center of the sight glass of the
bubble level (see Fig. 1)
Place the scale horizontally and keep the bubble inside the bubble level aligned with the red circle (See
Fig.1). In order to get exact measurements, the balance must again be carefully leveled after each
relocation.
Fig. 1 Correct leveling with the aid of the bubble level
ER
3.7 Calibration of the weighing machine
Since the Earth’s gravity is not the same everywhere, each balance must be adjusted to compensate for
the gravity differences at each location in accordance with the underlying physical weighing principles.
This adjustment process, known as calibration and must be carried out on initial installation and after
each subsequent relocation.
In order to ensure exact measurements, it is recommended that the balance should be calibrated
regularly using a known external calibration weight (see Section 5 below).
15
4 Working with the application menu using the Intelligent
Low battery indicator
Negative value indicator
Stable indicator
Tare indicator
Weighing units
Zero indicator
Key-Pad
4.1 Display messages and key functions
4.1.1 Display messages:
4.1.2 Key Functions:
1. The On/Off key is to turn the Balance On or Off (Note: it has an On/Off hard switch at the bottom)
2. The ZERO key allows the user to subtract the container value multiple times within the capacity
weight, and is used to set or re-adjust the weighing machine in correct zero position.
3. The Print key is to send data to external device through RS232 connector.
4. The UNIT key is to toggle between different weighing units.
5. The PCS key is for piece counting.
16
4.2 Program options
Please see our web-site at http://lwmeasurements.com for practical demonstrations of application
usage.
4.2.1 Interface Settings
Press [ON/OFF] to turn on the scale, when instrument displays --------
Press [PRINT], the display will show b xxx BAU value
Press [UNIT] to select among (1200,2400,4800,9600), default setting is 9600
Press [ZERO] to enter Parity mode, the display will show P xxx PAR
Press [UNIT] to select odd, even or none ( odd stands for 7 data bits with odd parity, even stands
for 7 data bits with even parity, none stands for 8 data bit without parity), default setting is none
Press [ZERO] to enter Print mode, the display will show n xxx mod
Press [UNIT] to select CON,OFF, KEY, STB
a) OFF stands for serial data output disabled
b) KEY stands for manual mode by pressing [PRINT]
c) STB stands for automatic print when scale is stable
d) CON stands for continuous print
Default setting is KEY
Press [ZERO] again to return to weighing mode.
4.2.2 Parameter settings
4.2.2.1 Setting zero tracking range
Press ON/OFF key, and when “- - - - - - “ shows, press PCS key, display will show “Zrd x.x”, press UNIT
key to select, factory default setting is 0.8
4.2.2.2 Setting zero tracking time
Press ON/OFF key , and when “- - - - - - “ shows, press PCS key, and then press ZERO key till display
shows “Zrt x.x”, press UNIT key to select, factory default setting is 2.0
17
4.2.2.3 Setting displaying zero range
Press ON/OFF key, and when“- - - - - - “ shows, press PCS key, and then press ZERO key multiple times
till display shows “rzd x.x”, press UNIT key to select, factory default setting is 0.8
4.2.2.4 Setting filter parameter
Press ON/OFF key, and when “- - - - - - “shows, press PCS key, and then press ZERO key multiple times
till display shows “FIL.x”, press UNIT key to select, factory default setting is 2
4.2.2.5 Setting Zero range when power on
Press ON/OFF key, and when“- - - - - - “shows, press PCS key, and then press ZERO key multiple times
till display shows “Pzr xx”, press UNIT key to select, factory default setting is 20
4.2.2.6 Setting Zero range of ZERO key
Press ON/OFF key, and when“- - - - - - “shows, press PCS key, and then press ZERO key multiple times
till display shows “Kzr xx”, press UNIT key to select, factory default setting is 4
4.2.2.7 Setting Zero range of TARE key
Press ON/OFF key, and when“- - - - - - “shows, press PCS key, and then press ZERO key multiple times
till display shows “Ktr xxx”, press UNIT key to select, factory default setting is 100
4.2.2.8 Setting overload range
Press ON/OFF key, and when“- - - - - - “shows, press PCS key, and then press ZERO key multiple times
till display shows “Ovr xx”, press UNIT key to select, factory default setting is 9d
4.2.2.9 Setting Beeper
Press ON/OFF key, and when“- - - - - - “shows, press PCS key, and then press ZERO key multiple times
till display shows “b2 ON” or “b2 OFF”, press UNIT key to switch it ON or OFF.
4.2.2.10 Setting ZERO and TARE function merge function
Press ON/OFF key, and when“- - - - - - “shows, press PCS key, and then press ZERO key multiple times
till display shows “Zt ON” or “Zt OFF”, press UNIT key to switch it ON or OFF, in these models, it has to
be set ON
4.2.2.11 Setting Auto Shut off
Press ON/OFF key, and when“- - - - - - “shows, press PCS key, and then press ZERO key multiple times
18
till display shows “A ON” or “A OFF”, Press UNIT key to select Auto shut off mode “ON” or “OFF”.
4.2.2.12 Setting Backlight
Press ON/OFF key, and when“- - - - - - “shows, press PCS key, and then press ZERO key multiple times
till display shows “L ON”, “L OFF” or “ L AU”, Press UNIT key to select backlight to be “On”, “Off” or “Auto”.
4.2.3 Pieces counting
Press [ON/OFF] to turn on the Balance, wait for “0” to appear on the display
If necessary, press [ZERO] key to set the display to “0”
Press [PCS] key to enter PCS mode, display will show P = XX
Press [UNIT] key to select XX value ( 10, 20, 50 or 100)
Place a given number of samples of one item on the pan, the sample size should be 10, 20, 50 or
100 pieces.
Press [PCS] key to confirm sample quantity
Start counting by adding weight on the Balance
Press [PCS] key to return to the weighing mode
19
5 Calibration - Using an External Calibration Weight
Calibration is required when the weighing machine is initially installed or if the Balance is moved to a
substantial distance from the original location. 30 minutes of warming up of the Balance is always
needed before weighing and calibration.
Turn the Balance on and when display shows “--------”, press ZERO key
The display will show “CAL”
Press ZERO key again, the display will show “X0000 CAL”, “X” is the flashing digit
Press UNIT key, the flashing digit will move to right
Press PCS key to increase the value of the flashing digit(“X” is the calibration weight can be set
according to users’ requirements, we recommend a minimum weight of at least 50% of the
Balance capacity)
Place the corresponding test weight on the center of the pan
Press ZERO key to confirm and the display shows the weight value
Now the calibration is completed
Turn off the power, then turn on the power again, place a known weight on the platform to verify if
it is accurate.
If not, repeat above steps.
20
6 Maintenance and service
The weighing machine must be treated carefully and cleaned regularly. It is a precision instrument.
For maintenance-work, the balance must be separated from the power supply (remove power adapter
plug from socket). Also ensure that the balance cannot be reconnected to the power
supply during the work by a third party.
Take care during cleaning that no liquid penetrates into the appliance. If liquid is spilt on the balance, the
latter must immediately be disconnected from the electricity supply. The balance may
only be used again after it has first been checked by a service engineer.
The connections on the rear of the appliance and the power adapter may not come into contact with
liquids.
Regularly dismantle the weighing pan and the weighing pan holder and remove any dirt or dust from
under the weighing pan and on the weighing machine housing with a soft brush or a soft, lint-free cloth,
moistened with a mild soap solution. The scale and the holder can be cleaned under running water. Take
care that both parts are completely dry before they are re-installed on the scale.
Never use solvents, acids, alkalis, paint thinners, scouring powders or other aggressive or corrosive
chemicals for cleaning, since these substances attack the surfaces of the scale housing and
can cause damage.
21
7 Transport, storage
7.1 Transportation and shipping of the weighing machine
Your weighing machine is a precision instrument. Treat it carefully. Avoid shaking, severe impacts and
vibration during the transportation.
Take care that there are no marked temperature fluctuations during the transportation and that the
weighing machine does not become damp (condensation).
7.2 Storage of the weighing machine
If you would like to take the weighing machine out of service for an extended period, disconnect it from
the electricity supply, clean it thoroughly (see Section 6 .Maintenance and servicing.) and store it in a
place which meets the following conditions:
No violent shaking, no vibrations
Minimum temperature fluctuations
No direct solar radiation
Minimum moisture
The weighing machine should preferably be dispatched and transported in the original packaging to avoid
transportation damage.
The weighing machine should preferably be stored in the original packaging, since this provides optimal
protection for the weighing machine.
22
Loading...
