ULTRA SLIM UNIVERSAL
AC ADAPTOR
LS-PAB90S-2U
User Manual
Firstly thank you for purchasing our new 90W ultra slim product, which is
especially designed for charging and supplying power for notebooks and
netbooks. This product has acquired many patents and certificates already
and the max power can reach 90W. Also it adopts the widest output voltage
technology and switch voltage automatically. With ultra slim appearance
and fashion style, It will be one of the best choice for you and your family.
Product Feature:
1. Ultra slim housing with only 17mm and very competitive size with full
power 90W.
2. Charge or supply power to notebooks with more than different DC
connectors which cover almost brands in the markets.
3. 100% Automatic switch when different tips used, just plug & go, no fiddly
switch.
4. LED Light showing working status.
5. Adopt SCM computer controlling technique to make sure working
precision.
6. Adopt the newest ultra slim transformer technology and double panel
PCB used.
7. Adopt ABS+PC materials for the housing, being safe and environmental
friendly.
8. Automatic computer electrical overload test and high temperature
overload aging test before shipment to make more safe.
9. High efficiency: up to 91%.
10. Self-designing and produced with several applied patents.
11. AC Input 100-240V worldwide compatible.
12. Widest output voltage: 12V to 24V.
13. Multi protections: over temperature, over voltage, over current, short
circuit protection.
Product Diagram:
DC Joint
USB output
AC Input
DC Tips
Product Specification:
AC Input: 100~240V , 2.0A 50-60Hz
DC Output: 12~24V 6A 90W(MAX）
USB output: DC 5V 2.1A*2 (MAX）
Size: 114*70*17mm
Net Weight: 239g
Package Content:
1. Adaptor Body
2. AC power cord
3. 10 pcs standard Notebook tips as follows:
N04, N07, N09, N11, N18, N19, N23, N24, N35, N36.
4. User manual
AC cable
Notes：
your device's manual instruction. Please read this manual and its
caused by incorrect or reckless operation.
Operation Steps :
1. When you want to charge or supply power to laptop, connect the AC
plug into the wall socket (picture A). Choose the right tip for your laptop,
such as N04, join it with the DC output(picture B), connect the joint DC
tip to the laptop then it can be used. (picture C)
2. When you use the 5V USB output, connect the USB cable to digital
product, then it can be charged (as picture D and E)
Please check that the product’s feature, connector, and voltage will be
compatible with your laptop, camera and/or other devices; in accordance to
instructions carefully before use. We are not responsible for any damage
Important Safety Information:
This safety guideline is to help you operate your LVSUN power adapter
safely, to ensure your personal safety and reduce the risk of fire, electric
shock or injury.
1. Do not apply external force on the cord.
2. Do not unplug by pulling the cord.
3. Do not connect a binded cord to the power supply.
4. Do not place the cord or device near heating elements.
5. Do not bend the blade or pins of the plug.
6. If there is any strange sound, smoke or odor, pull of the cable
immediately.
7. Do not disassemble (It may cause fire or electric shock)
8. Do not put any sharp objects into the venting hole of the product (It
may cause fire or electric shock)
9. Ensure to plug the product firmly.
10. Ensure not to use a damaged cable. (It may cause fire or electric shock)
11. Do not place the product on a bed, bag or inside a closet that is not
good for ventilation.
12. Always wipe off the product with soft fabric, not water mop.( water
may cause electric shock)
13. Keep clean the power plug and the outlet (Dirt may cause a short circuit
and fire)
14. Keep the product out of reach of children.
15. Don't unplug the power cord with a wet hand. (It may cause electric
shock)
16. Unplug the power cord if you don't use the product for a long time. (It
may cause heat, fire and electric shock)
Notebook DC Connectors Specification:
No
N04
N07
N09
N11
N18
N19
N23
Output
Voltage
Range
Voltage
Connectors
Spec.
Replacement
HP/COMPAQ:18.5V/2.7A,18.5V/3.5A,18.5V/3.
19V 18.1-19.9V 4.8*1.7*10.7mm
8A,18.5V/4.9A; DELTA:19V/2.64A;
ASUS:19V/2.64A; NEC:19V/2.64A
IBM:19V/4.2A; DELL:19V/3.16A,19V/3.42A;
COMPAQ/HP:18.5V/4.9A,19V/4.9A; DELTA:
19V/2.64A.;
TOSHIBA:19V/3.16A,19V/3.42A,19V/4.74A;
19V 18.1-19.9V 5.5*2.5*10.7mm
ASUS:19V/4.74A.LENOVO:20V/2A;
LITEON:19V/3.16A,19V/3.42A,19V/3.95A,19V
/4.74A; NEC:19V/2.64A,19V/3.16A;
GATEWAY:19V/3.16A,19V/3.42A,19V/3.68A,1
9V/4.74A
SONY:
19.5V 18.5-20.4V 6.0*4.3*10.7mm
19.5V/2.7A,19.5V/3A,19.5V/4.1A,19.5V/4.7A;
FUJITSU: 19V/ 3.16A, 19V/3.69A, 19V/4.22A
19V 18.1-19.9V 5.5*1.7*10.7mm
TOSHIBA: 19V/3.95A; ACER: 19V/3.42A;
DELTA: 20V/3.5A
ACER:19V/3.16A,19V/3.42A,19V/4.74A;
19V 18.1-19.9V 5.5*2.1*10.7mm
LITEON:19V/3.16A,19V/3.42A;
NEC:19V/3.16A
19V 18.1-19.9V 5.5*3.0*10.7mm
SAMSUNG:
19V/3.16A,19V/3.75A,19V/4.22A,19V/4.74A
18.5V 17.6-19.4V 7.4*5.0*12.5mm HP/COMPAQ: 18.5V/3.5A, 18.5V4.9A et c.
N24
N35
N36
20V 19-21V 7.9*5.5*0.9mm IBM/LENOVO: 20V/4.5A,20V/3.25A etc.
20V 19-21V
11*5.6*11mm
square t ip
Lenovo: 20V2.25A,20V3.25A, 20V4.5A
19.5V 18.5-20.4V 4. 5*3.0 with pin HP:19.5V2.31A, 19.5V3.33A,19.5V4.62A
Notes: 1, All listing of brand names are registered trademarks of their respective
companies..
2, Not all connectors are available in the package, connectors may be different for
different market.
Hereby
LVSUN
Electr
Technology Co.,
onics
Ltd
declares that this
device is in complia nce w ith the r equir ements o f Direct iv e 2014/30/ E U
(EMC), Directive 2014/35/EU (LVD) and the Directive 2011/65/EU for
RoHS compliance. The complete declaration of conformity can be
requested by post under the below mentioned manufacturer address.
Warning:
This device is a class B product. This equipment may cause some
radio interference in living environment. In this case, the user can be
requested to undertake appropriate measures to prevent interference
www.enlvsun.com
LVSUN
E-mail:
Electr
mark
Technology Co.,
onics
et@enlvsu
n.com
Ltd
