HIGHLIGHTS
FULLY DIMMABLE
DAMP LOCATION RATED
HIGH CRI
LOW GLARE
SLEEK DESIGN
ENERGY STAR QUALIFIED
UL LISTED
LONG LIFE
Page 2
MODEL CASE BASE FLOOD LIFETIME
ALL 15 E26 40º 25000 120
MODEL DESCRIPTION WATT LUMENS COLOR TEMP MOL CRI DIMMABLE
RATED
LR31500 LED6.5PAR20/FL40/27K/DIM 6.5 460 2700K Warm White • • 3.18” 83 •
LR31501 LED6.5PAR20/FL40/30K/DIM 6.5 460 3000K Soft White • • 3.18” 84 •
LR31503 LED6.5PAR20/FL40/40K/DIM 6.5 460 4100K Cool White • • 3.18” 83 •
PAR 20
LR31504 LED6.5PAR20/FL40/50K/DIM 6.5 460 5000K Bright White • • 3.18” 86 •
LR31510 LED12PAR30L/FL40/27K/DIM 12 850 2700K Warm White • • 4.56” 83 •
LR31511 LED12PAR30L/FL40/30K/DIM 12 850 3000K Soft White • • 4.56” 83 •
LR31513 LED12PAR30L/FL40/40K/DIM 12 850 4100K Cool White • • 4.56” 84 •
PAR 30
LR31514 LED12PAR30L/FL40/50K/DIM 12 850 5000K Bright White • • 4.56” 85 •
LR31515 LED16.5PAR38/FL40/27K/DIM 16.5 1160 2700K Warm White • • 5.05” 84 •
LR31516 LED16.5PAR38/FL40/30K/DIM 16.5 1160 3000K Soft White • • 5.05” 83 •
LR31518 LED16.5PAR38/FL40/40K/DIM 16.5 1160 4100K Cool White • • 5.05” 84 •
PAR 38
LR31519 LED16.5PAR38/FL40/50K/DIM 16.5 1160 5000K Bright White • • 5.05” 85 •
VOLTS
CO L O R
T E M P E R AT U R E
5500 - 6000K
3500 - 4100K
Cool / Bright White
2700 - 3200K
Warm / Soft White
Daylight
9000 - 10000K
Shade or
Very Cloudy Sky
6000 - 8000K
Shade or Cloudy
5000 - 5500K
Flash
4000 - 5000K
Fluorescent
3000 - 4000K
Sunrise / Sunset
2500 - 3600K
Tungsten Lamp
1000 - 2000K
Candlelight
BEAM-SPREAD
CODES
NSP
Narrow Spot
SP
Spot
NFL
Narrow Flood
FL
Flood
WFL
Wide Flood
BEA M A NGL E
