Luxor|H.Wilson WTPS72E User Manual
WTPS70 Series Cart Instructions
06/21/13
www.luxorfurn.com
www.hwilson.com
NOTICE:
Leg lengths may
vary by model
E x8 F x4
1
NOTICE:
Use wrench to
tighten bolt Q &
locking nut S
B
Q
x12
Parts List
T x1
A x1
T2 x1
Tools Required
- Rubber Mallet
- Wrench
A2 x1
C x1
C2 x1
B x1
Optional î›…uted
legs for units with
cabinet pack
R
S
B2
2 3
D2
D2 x2 Q x12 R x12 S x12
D1
D1 x4
B2 x1
Install optional cabinet pack /
pullout shelf / locking drawer
assembly after step 2
E
E
E
C
A
C2
A2
B2
B
4 5 6
F
C
F
E
B2
C2
C2
B
C
A2
A
T
T2
A2
A
WT-D Pullout Drawer Instructions
01/30/13
www.luxorfurn.com
www.hwilson.com
With a Phillips Screwdriver, attach
1
the drawer assembly to the top
shelf with the 4 screws.
Parts List
H
G x1
H
Tools Required
- Phillips Screwdriver
K x2 H x4
H
H
G
K
A
