Original operating instructions

BA-10010-02-V01

Solenoid-diaphragm dosing pump

MAGDOS LA / LD

Operating instructions

Read the operating manual!

The user is responsible for installation and operation related mistakes!

Table of Contents

BA-10010-02-V01

Solenoid-diaphragm dosing pump MAGDOS LA / LD Operating instructions

Table of Contents

1 Notes for the Reader ..........................................................4

1.1 General non-discrimination ...................................................... 4

1.2 Explanation of the signal words ................................................ 4

1.3 Explanation of the warning signs .............................................4

1.4 Identiﬁcation of warnings ......................................................... 4

1.5 Instruction for action identiﬁcation ...........................................5

2 Safety ................................................................................. 6

2.1 General warnings .....................................................................6

2.2 Hazards due to non-compliance with the safety instructions .....7

2.3 Working in a safety-conscious manner .....................................7

2.4 Personal protective equipment .................................................7

2.5 Personnel qualiﬁcation .............................................................7

3 Intended use ......................................................................9

3.1 Notes on product warranty .......................................................9

3.2 Intended purpose .....................................................................9

3.3 Device revision ........................................................................9

3.4 Principles ................................................................................9

3.5 Prohibited dosing media ...........................................................9

3.6 Foreseeable misuse .................................................................9

4 Product description .........................................................11

4.1 Properties ..............................................................................11

4.2 Scope of delivery ...................................................................11

4.3 Structure of the dosing pump .................................................11

4.4 Function description ..............................................................12

4.5 Rating plate ...........................................................................12

5 Technical data .................................................................. 13

5.1 Delivery capacity data ............................................................13

5.2 Operating conditions and limits ..............................................13

5.3 Approved media temperature .................................................14

5.4 Electrical speciﬁcations .........................................................14

5.5 Other data .............................................................................14

6 Dimensions ......................................................................15

6.1 MAGDOS with dosing head made of PVC, PP or PVDF ..............15

6.2 MAGDOS with dosing head made of stainless steel (1.4571) ...15

7 Installing the Dosing Pump .............................................. 16

7.1 Set up information .................................................................16

7.2 Installation examples .............................................................16

8 Hydraulic installations ..................................................... 17

8.1 Design of the system ..............................................................17

8.2 System piping ........................................................................17

8.3 Aligning the dosing head ........................................................18

8.4 Hydraulic connections ............................................................18

8.5 Connecting a leakage drain ....................................................19

8.6 Connecting the dosing head venting facility ............................19

8.7 Hydraulic accessories ............................................................20

9 Electrical installation ....................................................... 22

9.1 Principles ..............................................................................22

9.2 Description of connection sockets ..........................................23

10 Control .............................................................................. 25

10.1 Operator controls of the control unit ......................................25

10.2 Explanation of the menu icons ..............................................25

11 Operation ..........................................................................27

11.1 Commissioning the dosing pump..........................................27

11.2 Operating modes .................................................................28

11.3 External On / Off via Release input ........................................32

11.4 Decommissioning the dosing pump ......................................32

11.5 Shutting down in an emergency ...........................................32

11.6 Storage ...............................................................................32

11.7 Transportation......................................................................32

11.8 Disposal of old equipment ....................................................32

12 Maintenance ....................................................................33

12.1 Maintenance intervals ..........................................................33

12.2 Tighten up dosing head bolts ................................................33

12.3 Change the diaphragm .........................................................34

12.4 Clean suction and pressure valves ........................................34

13 Troubleshooting ............................................................... 35

13.1 Type of fault .........................................................................35

14 Spare parts ....................................................................... 37

14.1 Diaphragm spare parts kits ..................................................37

14.2 Dosing head spare parts kits including valves .......................37

15 Delivery characteristic curves ......................................... 38

16 EC Declaration of Conformity ........................................... 39

17 Declaration of no objection .............................................. 40

18 Warranty claim .................................................................41

19 Index .................................................................................42

Notes for the Reader

General non-discrimination

BA-10010-02-V01

Solenoid-diaphragm dosing pump MAGDOS LA / LD Operating instructions

1 Notes for the Reader

These Operating instructions contain information and behaviour rules for safe and designated operation of the dosing pump MAGDOS LA / LD.

Observe the following principles:

nRead the entire operating manual prior to starting-up the device. nEnsure that everyone who works with or on the dosing pump has read

the operating instructions and follows them.

nKeep the operating instructions for the entire service life of the dosing

pump.

nPass on the operating instructions to any subsequent owner of the

dosing pump.

1.1 General non-discrimination

In this operating manual, only the male gender is used where grammar allows gender allocation. The purpose of this is to make the text easy to read. Men and women are always referred to equally. We would like to ask female readers for understanding of this text simpliﬁcation.

1.2 Explanation of the signal words

Different signal words in combination with warning signs are used in this operating manual. Signal words illustrate the gravity of possible injuries if the risk is ignored:

Signal word Meaning

DANGER

Refers to imminent danger. Ignoring this sign may lead to death or the most serious injuries.

WARNING

Refers to a potentially hazardous situation. Failure to follow this instruction may lead to death or severe injuries.

CAUTION

Refers to a potentially hazardous situation. Failure to follow this instruction may lead to minor injury or damage to property.

NOTE

Refers to a danger which, if ignored, may lead to risk to the machine and its function.

Table 1: Explanation of the signal words

1.3 Explanation of the warning signs

Warning signs represent the type and source of a danger:

Warning sign Type of danger

Danger point

Danger from electrical voltage

Danger from corrosive substances

Danger from potentially-explosive substances

Danger from automatic startup

Danger from electromagnetic radiation

Danger of damage to machine or functional inﬂuences

Table 2: Explanation of the warning signs

1.4 Identiﬁcation of warnings

Warnings are intended to help you recognise risks and avoid negative consequences.

This is how warnings are identiﬁed:

Warning sign

SIGNAL WORD

Description of danger.

Consequences if ignored.

ðThe arrow signals a safety precaution to be taken to eliminate

the danger.

Notes for the Reader

Instruction for action identiﬁcation

BA-10010-02-V01

Solenoid-diaphragm dosing pump MAGDOS LA / LD Operating instructions

1.5 Instruction for action identiﬁcation

This is how pre-conditions for action are identiﬁed:

üPre-condition for action which must be met before taking action.

@A resource such as a tool or auxiliary materials required to perform

the operating instructions.

This is how instructions for action are identiﬁed:

èSeparate step with no follow-up action.

1. First step in a series of steps.

2. Second step in a series of steps.

4Result of the above action.

üAction completed, aim achieved.

Safety

General warnings

BA-10010-02-V01

Solenoid-diaphragm dosing pump MAGDOS LA / LD Operating instructions

2 Safety

2.1 General warnings

The following warnings are intended to help you to eliminate the dangers that can arise while handling the dosing pump. Risk prevention measures always apply regardless of any speciﬁc action.

Safety instructions warning against risks arising from speciﬁc activities or situations can be found in the respective sub-chapters.

DANGER

Mortal danger from electric shock!

Wrongly connected or located cables or damaged ones can injure you.

ðConnect the device only to a SCHUKO socket outlet protected by a

ground fault circuit interrupter (GFCI).

ðReplace damaged cables without delay. ðDo not use extension cables. ðDo not bury cables. ðSecure cables to avoid being damaged by other equipment.

DANGER

Danger to life through explosions!

The use of dosing pumps without ATEX certiﬁcation in a potentially explosive atmospheres can result in potentially-fatal explosions.

ðNever use the dosing pump in potentially explosive areas.

WARNING

Danger from unsuitable materials

The materials of the dosing pump and hydraulic parts of the system must be suitable for the dosing medium that is used. Should this not be the case, the dosing media may leak.

ðMake sure that the materials you are using are suitable for the

dosing medium.

ðMake sure that the lubricants, adhesives, sealants, etc. that you

use are suitable for the dosing medium.

WARNING

Caustic burns or other burns through dosing media!

While working on the dosing head, valves and connections, you may come into contact with dosing media.

ðUse sufﬁcient personal protective equipment. ðRinse the dosing pump with a liquid (e.g. water) which does not

pose any risk. Ensure that the liquid is compatible with the dosing medium.

ðRelease pressure in hydraulic parts. ðNever look into open ends of plugged pipelines and valves.

WARNING

Danger of automatic start up!

After connecting the mains supply, residual dosing media in the dosing head can spray out.

ðBefore connecting the mains supply, connect the dosing lines. ðCheck that all the screw connections have been tightened

correctly and are leak-proof.

WARNING

Danger from electromagnetic radiation!

Solenoid diaphragm dosing pumps In operation, solenoid diaphragm dosing pumps emit a stray magnetic ﬁeld. If you do not keep far enough away, the function of a pacemaker can be negatively affected.

ðPeople with pacemakers must always keep at least 50 cm away

from the dosing pump.

CAUTION

Danger when changing the dosing medium!

Changing the dosing media can provoke unexpected reactions, damage to property and injury.

ðClean the dosing pump and the system parts in contact with the

media thoroughly before changing the dosing medium.

Safety

Hazards due to non-compliance with the safety instructions

BA-10010-02-V01

Solenoid-diaphragm dosing pump MAGDOS LA / LD Operating instructions

CAUTION

Increased risk of accidents due to insufﬁcient qualiﬁcation of personnel!

Dosing pumps and their accessories may only be installed, operated and maintained by personnel with sufﬁcient qualiﬁcations. Insufﬁcient qualiﬁcation will increase the risk of accidents.

ðEnsure that all action is taken only by personnel with sufﬁcient and

corresponding qualiﬁcations.

ðPrevent access to the system for unauthorised persons.

2.2 Hazards due to non-compliance with the safety instructions

Failure to follow the safety instructions may endanger not only persons, but also the environment and the device.

The speciﬁc consequences can be:

nFailure of vital functions of the dosing pump and the system nFailure of required maintenance and repair methods nDanger for individuals through dangerous dosing media nDanger to the environment caused by substances leaking from the

system

2.3 Working in a safety-conscious manner

Besides the safety instructions speciﬁed in this operating manual, further safety rules apply and must be followed:

nAccident prevention regulations nSafety and operating provisions nSafety provisions for handling dangerous substances (mostly the

safety data sheets to dosing media)

nEnvironmental protection provisions nApplicable standards and legislation

2.4 Personal protective equipment

Based on the degree of risk posed by the dosing medium and the type of work you are carrying out, you must use corresponding protective equipment. Read the Accident Prevention Regulations and the Safety Data Sheets to the dosing media ﬁnd out what protective equipment you need.

You will require the minimum of the following personal protective equipment:

Personal protective equipment required

Protective goggles

Protective clothing

Protective gloves

Table 3: Personal protective equipment required

Wear the following personal protective equipment when performing the following tasks:

nCommissioning nWorking on the dosing pump while running nShutdown nMaintenance work nDisposal

2.5 Personnel qualiﬁcation

Any personnel who work on the dosing pump must have appropriate special knowledge and skills.

Anybody who works on the dosing pump must meet the conditions below:

nAttendance at all the training courses offered by the owner, npersonal suitability for the respective activity, nsufﬁcient qualiﬁcation for the respective activity, nTraining in handling of the dosing pump, nknowledge of safety equipment and the way this equipment functions, nknowledge of this operating manual, particularly of safety instructions

and sections relevant for the activity,

nknowledge of fundamental regulations regarding health and safety

and accident prevention.

All persons must generally have the following minimum qualiﬁcation:

nTraining as specialists to carry out work on the dosing pump

unsupervised,

nsufﬁcient training that they can work on the dosing pump under the

supervision and guidance of a trained specialist.

Safety

Personnel qualiﬁcation

BA-10010-02-V01

Solenoid-diaphragm dosing pump MAGDOS LA / LD Operating instructions

These operating instructions differentiate between these user groups:

2.5.1 Specialist staff

Thanks to their professional training, knowledge, experience and knowledge of the relevant speciﬁcations, specialist staff are able to perform the job allocated to them and recognise and/or eliminate any possible dangers by themselves.

2.5.2 Trained persons

Trained persons have received training from the operator about the tasks they are to perform and about the dangers stemming from improper behaviour.

In the table below you can check what qualiﬁcations are the pre-condition for the respective tasks. Only people with appropriate qualiﬁcations are allowed to perform these tasks!

Qualiﬁcation Activities

Specialist staff nAssembly

nHydraulic installations nElectrical installation nMaintenance nRepairs nCommissioning nTaking out of operation nDisposal nFault rectiﬁcation

Trained persons nStorage

nTransportation nControl nFault rectiﬁcation

Table 4: Personnel qualiﬁcation

Intended use

Notes on product warranty

BA-10010-02-V01

Solenoid-diaphragm dosing pump MAGDOS LA / LD Operating instructions

3 Intended use

3.1 Notes on product warranty

Any non-designated use of the product can compromise its function or intended protection. This leads to invalidation of any warranty claims!

Please note that liability is on the side of the user in the following cases:

nThe dosing pump is operated in a manner which is not consistent with

these operating instructions, particularly safety instructions, handling instructions and the section "Intended Use".

nIf people operate the product who are not adequately qualiﬁed to carry

out their respective activities.

nNo original spare parts or accessories of Lutz-Jesco GmbH are used. nUnauthorised changes are made to the device by the user. nThe user uses different dosing media than those indicated in the

order.

nThe user does not use dosing media under the conditions agreed with

the manufacturer such as modiﬁed concentration, density, temperature, contamination, etc.

3.2 Intended purpose

The dosing pump MAGDOS LA / LD is intended for the following purpose: the conveying and dosing of liquids.

3.3 Device revision

This operating manual applies to the following devices:

Device Month / year of

manufacture

Firmware

MAGDOS LA 11/2016 onwards From 01:59

MAGDOS LD 11/2016 onwards From 01:59

Table 5: Device revision

3.4 Principles

nBefore delivery, the manufacturer inspected the dosing pump and

operated it under speciﬁc conditions (with a speciﬁc dosing medium with a speciﬁc density and temperature, with speciﬁc pipe dimensions, etc.) Since these conditions differ at every location of usage, the delivery capacity of the dosing pump should be measured by gauging it at the operating company's installation. For details on the approximate values and the capacity of the dosing pump, refer to the chapter 15 „Delivery characteristic curves“ on page38.

nComply with the information regarding the operating and environmen-

tal conditions (see chapter "Technical data").

nAny restrictions regarding the viscosity, temperature and density of

dosing media must be followed. You must only use dosing media at temperatures above freezing point or below the boiling point of the respective medium.

nThe materials of the dosing pump and hydraulic parts of the system

must be suitable for the dosing medium that is used. In this connection, note that the resistance of these components can change in dependence on the temperature of the media and the operating pressure.

Information on the suitability of materials combined with different dosing media can be found in the Compatibility Chart of Lutz-Jesco GmbH. The information in this resistance list is based on information from the material manufacturers and on expertise obtained by Lutz-Jesco from handling the materials. As the durability of the materials depends on many factors, this list only constitutes initial guidance on selecting material. In all cases, test the equipment with the chemicals you use under operating conditions.

nThe dosing pump is not intended for outdoor use unless appropriate

protective measures have been taken.

nAvoid leaks of liquids and dust into the casing and avoid direct

exposure to sunlight.

nYou must never operate dosing pumps in a potentially explosive

atmosphere if they do not have corresponding nameplates or an appropriate EC Declaration of Conformity for potentially explosive atmospheres.

3.5 Prohibited dosing media

The dosing pump must not be used for these media and substances:

nGaseous media, nradioactive media, nsolid substances, ncombustible media, nall other media that are not suitable for delivery using this dosing

pump.

3.6 Foreseeable misuse

Below, there is information about the applications of the dosing pump or associated equipment that are not considered to be intended use. This section is intended to allow you to detect possible misuse in advance and to avoid it.

Intended use

Foreseeable misuse

BA-10010-02-V01

Solenoid-diaphragm dosing pump MAGDOS LA / LD Operating instructions

Foreseeable misuse is assigned to the individual stages of the product lifetime:

3.6.1 Incorrect assembly

nUnstable or unsuitable bracket nDosing pump bolted wrongly or loosely

3.6.2 Incorrect hydraulic installation

nSuction and pressure lines dimensioned incorrectly nUnsuitable connection of the pipes due to wrong material or

unsuitable connections.

nSuction and pressure lines mixed-up nDamage to threads due to them being tightened too much nBending of pipelines nNo free return ﬂow of the pressure relief valve nExcessive demand due to the pressure differences between the

suction and pressure valves

nThrough-suction at installation without back-pressure valves nDamage due to undamped acceleration mass forces nExceeding the admissible pressure on the suction and discharge sides nUsing damaged parts

3.6.3 Incorrect electrical installation

nConnecting the mains voltage without a protective earth nUnsecured mains or one that does not conform to standards nNot possible to immediately or easily disconnect the power supply nWrong connecting cables for mains voltage nDosing pump accessories connected to wrong sockets nDiaphragm monitoring not connected or defective nProtective earth removed

3.6.4 Incorrect start-up

nStart-up with damaged system nShut-off valves closed at commissioning nClosed suction or pressure line, e.g. due to blockages nPersonnel was not informed before the start-up nSystem was recommissioned after maintenance without all the

protective equipment and ﬁxtures, etc. being reconnected.

nInadequate protective clothing or none at all

3.6.5 Incorrect operation

nProtective equipment not functioning correctly or dismantled nModiﬁcation of the dosing pump without authority nIgnoring operational disturbances nElimination of operational disturbances by personnel without

adequate qualiﬁcations

nDeposits in the dosing head due to inadequate purging, particularly

with suspensions

nBridging the external fuse nOperation made more difﬁcult due to inadequate lighting or machines

that are difﬁcult to access

nOperation not possible due to dirty or illegible display of the dosing

pump

nDelivery of dosing media for which the system is not designed nDelivery of particulate or contaminated dosing media nInadequate protective clothing or none at all

3.6.6 Incorrect maintenance

nCarrying out maintenance during ongoing operation nCarrying out work that is not described in the operating manual nNo adequate or regular inspection of correct functioning nNo replacement of damaged parts or cables with inadequate

insulation

nNo securing against reactivation during maintenance work nUsing cleaning materials that can cause reactions with the dosing

media

nInadequate cleaning of the system nUnsuitable purging medium nUnsuitable cleaning materials nDetergents left in system parts nUsing unsuitable cleaning equipment nUsing the wrong spares or lubricants nContaminating the dosing medium with lubricant nInstalling spare parts without following the instructions in the

operating manual

nBlocking venting oriﬁces nPulling off sections of the plant nContamination at installation without a dirt trap nMixing up the valves nMixing up the sensor lines nNot reconnecting all the lines nDamaging or not installing all the seals nNot renewing seals nNot paying attention to safety data sheets nInadequate protective clothing or none at all

3.6.7 Incorrect decommissioning

nNot completely removing the dosing medium nDismantling lines while the dosing pump is running nDevice not disconnected from the power supply nUsing the wrong dismantling tools nInadequate protective clothing or none at all

3.6.8 Incorrect disposal

nIncorrect disposal of dosing media, operating resources and other

materials

nNo labelling of hazardous substances

Product description

Properties

BA-10010-02-V01

Solenoid-diaphragm dosing pump MAGDOS LA / LD Operating instructions

4 Product description

4.1 Properties

The MAGDOS is a solenoid diaphragm dosing pump that is used when precise dosing results are required.

They are characterized by the following properties:

nOutput range from 0.5 to 15 l/h, up to 16 bar. nReproducible dosing precision of ± 2%. nIntegrated automatic dosing head venting facility (except with

stainless steel dosing heads (1.4571)).

nSuitable for highly aggressive or poisonous dosing media. nOperating modes: Manual mode, pulse input, analogue input (only LA). nGraphic display: 128 x 64 px, 1.5" , monochrome, illuminated. nMenu languages: English, German, French, Spanish, Portuguese,

Dutch, Polish.

nFour multifunction keys for operator inputs. nFloor- and wall-mounting options. nConnections: M12x1 plug, A-coded.

4.2 Scope of delivery

Please compare the delivery note with the scope of delivery. The following items are part of the scope of delivery:

nDosing pump MAGDOS LA / LD. nOne set each of hose clamping connections for the suction and

discharge sides for hoses with diameters of 4/6 mm, 6/9 mm and 6/12 mm (made of PVC, PP and PVDF).

nCovering caps electrical connections. n2 conductive rubber bands for electrical contacts (installed in

connection sockets 1 and 3).

nCable with M12x1 plug connector, A-coded, 2 m long, open cable end

4-pin.

nMains cable. nOperating instructions. nInspection report and test certiﬁcate (optional). nAccessory kit (optional).

4.3 Structure of the dosing pump

4.3.1 General Overview

Fig. 1:

Dosing pump overview MAGDOS LA / LD

No. Description

1 Dosing head

2 Drive unit

3 Control box

Table 6: General Overview

4.3.2 Dosing head

Fig. 2: Dosing head

No. Description

1 Valve and connection on the discharge side

2 Integrated dosing head ventilation

Arrow indicating the direction of throughﬂow of the dosing medium

4 Valve and connection on the suction side

Table 7: Dosing head

Product description

Function description

BA-10010-02-V01

Solenoid-diaphragm dosing pump MAGDOS LA / LD Operating instructions

4.3.3 Control elements

Fig. 3: Controller of dosing pump MAGDOS LA / LD

No. Description

1 Graphic display

2 Multifunction keys on the contol unit for operator inputs

3 Connection ports for external operation

4 Mains cable for power supply

Table 8: Designation of components

4.4 Function description

Dosing pumps are positive displacement pumps. They are used if precisely deﬁned delivery of a medium is necessary. A constant volume per stroke or time is delivered.

The system delivers or meters the dosing medium by means of a repeated sequence of suction strokes followed by pressure strokes. This results in a pulsing ﬂow.

If the dosing pump is in the suction stroke phase, the diaphragm is pulled into the rear ﬁnal position. Due to the resulting vacuum in the dosing head, the pressure valve closes, the suction valve opens and dosing medium ﬂows from the suction line into the dosing head.

If the dosing pump is in the pressure stroke phase, the diaphragm is moved into the front ﬁnal position. Due to the pressure in the dosing head, the suction valve closes and the dosing medium ﬂows through the pressure valve from the dosing head into the pressurised pipe.

4.5 Rating plate

There is information on the equipment about safety or the product's way of functioning. The information must stay legible for the duration of the service life of the product.

Material: Max. XXX l/h bei X bar Max. XXX l/h bei X bar IP XX, XXX V AC, XXXX Hz, XX W

XX/XXXX

S/N: XXXXXXXXXX

P/N:

Made in

Germany

*102A12345678*

*12345678012345*

MAGDOS LP

Lutz-Jesco GmbH 30900 Wedemark Am Bostelberge 19 Germany

Fig. 4: Rating plate MAGDOS LA / LD

No. Description

1 Product, type, nominal size

2 Material of the dosing head / seals

3 Maximum delivery capacity at average pressure

4 Maximum delivery capacity at maximum pressure

5 Protection class

6 Voltage supply

7 Label showing conformity with applicable European directives

8 WEEE label

9 Frequency

10 Power consumption

11 Serial number

12 Part number

13 Month / year of manufacture

Table 9: Rating plate

7 8 9 10

Technical data

Delivery capacity data

BA-10010-02-V01

Solenoid-diaphragm dosing pump MAGDOS LA / LD Operating instructions

5 Technical data

5.1 Delivery capacity data

Please note that some of this data only represents guide values. The actual capacity of a dosing pump depends on various factors. For approximate values of the delivery capacity at different pressures, refer to chapter 15 „Delivery characteristic curves“ on page38.

Information Value

MAGDOS LA / LD Size

05 1 2 4 6 10 15

Delivery capacity at max. backpressure

l/h 0.36 0.76 1.9 3.4 6.2 9.0 13

ml/stroke 0.05 0.05 0.2 0.32 0.57 0.83 0.87

Max. delivery pressure bar 16 8 6 3

Delivery capacity at average backpressure

l/h 0.54 1.1 2.3 3.8 6.8 10 15

ml/stroke 0.08 0.08 0.24 0.35 0.63 0.92 1

Average delivery pressure bar 8 4 3 1

Max. stroke frequency rpm 120 250 160 180 250

Suction height for non-gassing media (with a ﬁlled suction line)

mWS 5 3 2

Table 10: Output data

5.2 Operating conditions and limits

Information Value

MAGDOS LA / LD Size

05 – 15

Approved ambient temperature °C 5 – 45 (with PVC components 5 – 40)*

Relative humidity % max. 90

Max. sound pressure level (depressurised) dB(A) 68 – 75

Max. sound pressure level (at test pressure) dB(A) 65 – 70

Max. supply pressure mbar 800

Viscosity limits mPa∙s 300** / 1000***

Adjustable dosing range % 0 – 100

Table 11: Operating conditions and limits

* Use of the dosing pump at ambient temperatures below 5 °C must be checked individually. In such cases, please contact the manufacturer.

** With a viscosity of ~300 mPa∙s and above, you must use spring-loaded valves.

*** If the viscosity is above 1000 mPa∙s, this must be checked individually and the stroke frequency must be between 50 and 100 strokes/min.

Technical data

Approved media temperature

BA-10010-02-V01

Solenoid-diaphragm dosing pump MAGDOS LA / LD Operating instructions

5.3 Approved media temperature

Information Value MAGDOS LA / LD (all sizes)

Dosing head made of PVC °C 0 – 35

Dosing head made of PP °C 0 – 60

Dosing head made of PVDF °C 0 – 80

Dosing head made of stainless steel (1.4571) °C 0 – 80

Table 12: Approved media temperature

5.4 Electrical speciﬁcations

Information Value

MAGDOS LA / LD Size

05 1 2 4 6 10 15

Voltage supply 230 V AC ± 10 %, 50/60 Hz or

115 V AC ± 10 %, 50/60 Hz (see rating plate)

Power consumption W 10 15 21 27 28 29 26

Max. current consumption during dosing stroke A 2.0 3.0 3.7 3.8 4.1 3.6

Table 13: Electrical speciﬁcations

5.5 Other data

Information

Value

MAGDOS LA / LD Size

05 1 2 4 6 10 15

Weight (dosing head made of PVC, PP, PVDF)

kg 3.2 approx.

Weight (dosing head made of stainless steel (1.4571))

kg 4.3 approx.

Diameter of diaphragm mm 24 33 39

Electrical cable m 1.8 m (with mains plug)

Protection class IP65 (with covering caps on the connections)

Insulation class F

Valve connection G 5/8 male

Valve size DN3 DN4

Table 14: Other data

Dimensions

MAGDOS with dosing head made of PVC, PP or PVDF

BA-10010-02-V01

Solenoid-diaphragm dosing pump MAGDOS LA / LD Operating instructions

6 Dimensions

6.1 MAGDOS with dosing head made of PVC, PP or PVDF

Fig. 5:



 







 









 

Dimensioned drawing of MAGDOS LA / LD with dosing head made of PVC, PP or PVDF (all dimensions in mm)

Connection Material Scale Nominal width L

Hose clamp connector PVC / PP / PVDF

4/6 mm DN4 31

1/4" x 3/8" 1/4" 34

6/9 mm

DN6

6/12 mm DN6 15

6.2 MAGDOS with dosing head made of stainless steel (1.4571)

Fig. 6:



 





 



 

















 











 

Dimensioned drawing of MAGDOS LA / LD with dosing head made of stainless steel 1.4571 (all dimensions in mm)

Connection Material Scale Nominal width L

Hose clamp connector Stainless steel

(1.4571) / PVDF

4/6 mm DN4 50

Hose clamp connector Stainless steel

(1.4571) / PVDF

6/9 mm DN6 54

Installing the Dosing Pump

Set up information

BA-10010-02-V01

Solenoid-diaphragm dosing pump MAGDOS LA / LD Operating instructions

7 Installing the Dosing Pump

DANGER

Mortal danger from electric shock!

Electrically conductive liquid can enter pump housings, cable screw connections and mains connectors.

ðMake sure that all protective measures comply at least with the

requirements of protection class IP65.

ðAlways set up the dosing pump such that water cannot enter the

housing.

CAUTION

Danger of personal injury and material damage!

A dosing pump that is difﬁcult to access represents a danger due to incorrect operation and faulty maintenance.

ðInstall the dosing pump such that it is accessible at all times.

7.1 Set up information

When installing, follow the basic principles below:

nThe valves must be vertical: Pressure valve at top, suction valve at

bottom. in this connection, pay attention to the arrow on the dosing head. The dosing head must be aligned such that the arrow points vertically upwards.

nYou should install the dosing pump at a convenient height for

operation.

nIt must not be installed under the ceiling. nThe frame of foundation for ﬁxing the dosing pump must not be

subjected to jolts. The pump must be vibration-free and stable.

nThere must be enough free space in the area of the dosing head and

the suction and pressure valves for these parts to be easily dismantled if required. The entire space requirement for installation and maintenance is approximately 1 m².

nThe distance from the sides of the dosing pump to the wall or other

dosing pumps or equipment must be at least 3 cm. There must be a guaranteed ﬂow of circulating air.

nThe maximum ambient temperature must be complied with, see

chapter 5.2 „Operating conditions and limits“ on page13. If necessary, radiant heat from surrounding equipment must be screened.

nAvoid exposure to direct sunlight. nThe dosing pump is not intended for use out of doors unless

appropriate protective measures have been taken to prevent dust and water from entering the housing.

nFor the dimensions of the fastening holes, refer to chapter 6

„Dimensions“ on page15.

nThe tightening torque for the fastening bolts is 1.5 – 2 Nm.

7.2 Installation examples

7.2.1 Installation on a wall console

Fig. 7: Installation on a wall console

To reduce the structure-borne noise, the dosing pump is bolted to the wall bracket using rubber elements. The materials necessary for this are included with the wall bracket.

7.2.2 Installation on the wall

Fig. 8: Installation on the wall

The dosing pump can be mounted to the ﬂoor or directly to the wall without the need for additional elements. Turn the dosing head appropriately to ensure the ﬂow direction of the medium through the dosing head.

Hydraulic installations

Design of the system

BA-10010-02-V01

Solenoid-diaphragm dosing pump MAGDOS LA / LD Operating instructions

8 Hydraulic installations

In this chapter, you will ﬁnd information about the hydraulic parts of a system that you should install or that can install additionally. In many cases, you must install hydraulic accessories to be able to use all the functions that the dosing pump offers, to guarantee functional safety or to achieve a high level of dosing precision.

WARNING

Caustic burns or other burns through dosing media!

A diaphragm rupture, blocked pressure lines or the use of material not suitable for the dosing medium can result in the discharge of dosing medium. Depending on the type and hazardousness of the dosing medium, this can result in injury.

ðWear the recommended personal protective equipment. ðMake sure that the materials you are using are suitable for the

dosing medium.

ðMake sure that the lubricants, adhesives, sealants, etc. that you

use are suitable for the dosing medium.

ðInstall a leakage drain. ðInstall pressure relief valves.

CAUTION

Danger of personal injury and material damage!

High peak pressures can lead to piping vibrating and cause them to snap. This can result in injury from piping or escaping dosing media.

ðInstall pulsation dampeners.

NOTE

Damage to drives due to overloading

The pressure conditions between the suction and discharge sides must be balanced; otherwise, overloading can result. This can lead to uncontrolled dosing processes, damage to the piping and to the dosing pump.

ðEnsure that the pressure on the discharge side is at least 1 bar

than on the suction side.

NOTE

Locking of threads

Stainless steel and plastic parts (particularly those made of PVC) that are bolted together in a detachable connection (e.g. the dosing head and the valves) can lock. This makes them difﬁcult to release.

ðBefore bolting, grease the corresponding parts with a lubricant

(e.g. PTFE spray). Ensure that the lubricant is compatible with the dosing medium.

8.1 Design of the system

nThe dosing pump s technical data must be taken into account and the

plant s layout must be set up appropriately (e.g. pressure loss when rating the lines with regard to their nominal diameter and length).

nThe entire system and its integrated dosing pump must be designed

in such a way that an escaping dosing medium (due to the failure of wearing parts such as the diaphragm, or burst hoses) does not lead to permanent damage to system parts or the premises.

nThe leakage opening of the dosing head must be visible so that you

can detect a diaphragm rupture. It must be possible for the outﬂow from the leakage drain to be on a free downwards gradient.

nIf you use hazardous dosing media, the installation must be designed

such that no disproportionately high consequential damages arise due to dosing media escaping.

nTo avoid dosing errors after the end of the process, the dosing pump

must be locked hydraulically.

nTo allow you to easily inspect the pressure conditions in the system,

you should provide connections for pressure gauges close to the suction and pressure valves.

8.2 System piping

nThe system piping must not exert any force on the connections and

valves of the dosing pump.

nThis means that steel piping should be connected to the dosing pump

by means of ﬂexible pipe sections.

nThe nominal diameters of the pipework and the installed ﬁttings

should be rated the same as or greater than the nominal diameters of the dosing pump's suction and pressure valves.

nThe suction line should be kept as short as possible. nYou should avoid intertwined hoses. nAvoid loops, since air bubbles can collect.

Hydraulic installations

Aligning the dosing head

BA-10010-02-V01

Solenoid-diaphragm dosing pump MAGDOS LA / LD Operating instructions

8.3 Aligning the dosing head

Fig. 9: Aligning the dosing head

When connecting the dosing lines to the dosing pump, you must observe the direction of through-ﬂow (see arrow 2). The dosing head must be aligned vertically. The alignment can be changed in 90° intervals.

The suction valve (3) must always point downwards. Accordingly, arrow (2) and pressure valve (1) always point upwards. This is irrespective of the positioning of the dosing head to the drive.

8.4 Hydraulic connections

8.4.1 Connecting hose clips

Choose the hose connection according to the condition of the hose (material, inner diameter, wall thickness) in order to ensure maximum pressure resistance.

8.4.1.1 Size 4/6 and 6/9

4/6

6/9

Fig. 10: Hose clips 4/6 and 6/9 (internal and external diameters in mm)

Perform the following working steps:

1. Cut the hose (1) to the appropriate length neatly and at an exact right angle.

2. Place a gasket that is suitable for the dosing medium between the connection (5) and the valve.

3. Screw the connecting piece e to the dosing pump's valve using the (2).

4. Thread the union nut (3) and the clamping ring (4) onto the hose.

5. Plug the hose all the way in to the grommet of connection piece.

6. Push the clamping ring onto the grommet of connection piece and

screw it to the union nut.

7. Carry out the same procedure with the connection to the dosing pump's other valve.

üHose clip connected.

8.4.1.2 Size 6/12

Fig. 11: Hose clip 6/12 (internal and external diameter in mm)

Size 6/12 hose clips only have a union nut. It clamps the hose onto the grommet of the connection piece and at the same time fastens on the dosing pump's valve.

Perform the following working steps:

1. Cut the hose (1) to the appropriate length neatly and at an exact right angle.

2. Place a gasket that is suitable for the dosing medium between the connection (4) and the valve.

3. Push the union nut (2) and the cutting ring (3) over the hose.

4. Press the end of the hose onto the grommet of connection piece. You

can do this more easily by moistening the end of the hose on the inside or applying some lubricant to the grommet in the cone area. You should push at least two thirds of the hose onto the grommet of the connection piece.

5. Push the cutting ring over the hose into the cone area on the grommet of connection piece.

6. Screw the union nut onto the valve of the dosing pump.

üHose clip connected.

Hydraulic installations

Connecting a leakage drain

BA-10010-02-V01

Solenoid-diaphragm dosing pump MAGDOS LA / LD Operating instructions

8.4.2 Making the glue-in connection

Fig. 12: Glue-in connection

Perform the following working steps:

1. Cut the PVC tube to length.

2. Push the union nut (1) onto the tube.

3. Stick the bonded coupling sleeve (2) to the tube (follow the

instructions of the adhesive manufacturer).

4. Screw the union nut onto the valve of the dosing pump. Use a gasket that is suitable for the dosing medium.

üGlue-in connection made.

8.4.3 Making the cemented connection

Fig. 13: Cemented connection

Perform the following working steps:

1. Cut the tube to length.

2. Cut the thread (2) onto the end of the tube.

3. Push the union nut (1) onto the tube.

4. Seal the thread. When choosing your sealing material, take into

account its resistance to material, temperature and pressure.

5. Screw the union nut onto the valve of the dosing pump. Use a gasket that is suitable for the dosing medium.

üCemented connection made.

Under normal conditions, you only need to screw the hydraulic connections ﬁnger-tight. However, due to the material settling, the pre-tension of the screw connection can slacken. This means that you must re-tighten the screw connection before carrying out commissioning.

8.5 Connecting a leakage drain

Lutz-Jesco GmbH dosing pumps are produced to the highest of quality standards with a long service life. However, some parts are subject to operational wear. This is the case particularly with the diaphragms that are continuously subjected to forces during the suction and discharge strokes and to the effects of the dosing medium.

If a diaphragm ruptures, the dosing medium starts to leak. This leakage is drained via the leakage opening. On the ﬂange of the dosing head, there are three openings for this purpose. Depending on the alignment of the dosing pump, the leakage is drained via the downward opening.

Fig. 14: Openings of the leakage drain

NOTE

Damage to drives due to effervescent media

If a hose is connected to the leakage drain and it is routed back into the dosing tank, effervescent media can enter the drive and damage it.

ðCollect the leakage in a collecting pan. ðAs an alternative, you can route the leakage back to to the dosing

tank using a funnel. You should install the funnel at an adequate distance from the leakage opening.

8.6 Connecting the dosing head venting facility

MAGDOS LA / LD dosing heads have an integrated dosing head venting facility (except for dosing heads made of stainless steel).

For the procedure when venting, refer to chapter 11.1.1 „Venting the dosing pump“ on page27.

Fig. 15: Dosing head venting facility with hose connection

Hydraulic installations

Hydraulic accessories

BA-10010-02-V01

Solenoid-diaphragm dosing pump MAGDOS LA / LD Operating instructions

Perform the following working steps:

1. Connect a 4/6 hose to the dosing head venting facility.

2. Route the other end of the hose into the dosing tank or a collecting

tank.

üDosing head venting facility connected.

8.7 Hydraulic accessories

The following chapter is intended to give you an overview of installation options.

Please note that these operating instructions are no substitute for the instructions supplied with the accessories in each case. The corresponding documentation supplied with the product applies to safety information and provides exact instructions on assembly.

8.7.1 Injection nozzle

If the pressure line enters a main line, it is advisable to install an injection nozzle.

Injection nozzles have three main functions:

nDosing the medium into a main line, nPreventing ﬂowback into the pressure line through a non-return valve.

Notes on assembly:

nDouble-ball injection nozzles must be installed into the main line

vertically from the bottom. You can install hose and spring-loaded injection nozzles any way you like.

nWith dosing media that tend to crystallize, it is advisable to carry out

installation into the main line from the bottom. This prevents air bubbles from being trapped.

nMany dosing media tend to contaminate the injection nozzles, which

can lead to blockages. In cases like this, it is advisable to install an injection nozzle that is easy to dismantle and block off.

8.7.2 Contact-type water meter

The contact-type water meter measures the throughﬂow in a pipe and sends a pulse to the dosing pump, which then starts dosing. This means that ideal proportional dosing is also possible with large throughﬂow ﬂuctuations.

The contact water meter is connected to connection port 2 (see chapter

9.2.2 „Connection socket 3“ on page24).

8.7.3 Pressure-relief valve

Pressure relief valves have an important safety function for protecting the dosing pump and the associated pipes and ﬁttings. The dosing pump can generate a pressure that is many times the rated one. A blocked pressure line can lead to dosing medium escaping.

An improperly high pressure can occur if:

nthe shut-off valves are closed even though the dosing pump is

running,

npipes block.

At an appropriate pressure, a pressure relief valve opens a bypass line and protects the system in this way from damage caused by over-pressure.

Notes on assembly:

nThe line for returning dosing medium from the pressure relief valve

must be routed to the dosing tank or to a collecting pan.

nThe pressure in the dosing tank must not be too high so that it is

possible to accommodate the returned dosing medium.

nAs an alternative, the system can return dosing medium into the

suction line in front of the dosing pump. In this case, there must not be a non-return valve or a foot valve in the suction line.

nYou should install the pressure relief valve as close as possible to the

dosing head.

8.7.4 Back-pressure valve

Back-pressure control valves are necessary if:

nthere are considerably ﬂuctuating system pressures, nthe pressure on the suction side is higher than on the discharge side

or if you intend to carry out dosing into depressurized lines.

In cases like this, if you do not use a back-pressure valve, imprecise dosing results will occur or overloading will result. The back-pressure valve solves these problems by generating a deﬁned, constant backpressure.

In some circumstances, a back-pressure valve is unnecessary if you use a hose injection nozzle and if the backpressure that it generates is adequate.

8.7.5 Pulsation dampener

Pulsation dampeners have the following functions:

nDamping pulsating delivery ﬂows for processes that require

low-pulsation dosing,

nReducing the throughﬂow resistance with long pipelines.

When installed on the suction side:

nDamping of acceleration mass forces and with this reduction of wear

on the dosing pump.

nPreventing cavitation (pull-off of the liquid column) due to too high

acceleration.

However, pulsation dampeners also have important safety functions, since they prevent pressure peaks from arising that lead to piping vibrating and cause them to snap.

This problem can occur:

nwith the high amplitudes of the vibrations, nwhen using long pipes (the severity of the pulsation increases with the

length of the pipe),

nwhen using rigid piping instead of elastic hoses.

Notes on assembly:

nYou should carry out assembly in the direct vicinity of the location

where you want to damp the pressure peaks (directly in front of the suction valve or directly behind the pressure valve).

nPulsation dampeners should be installed with throttle valves or

back-pressure valves installed directly behind them. By setting the valves appropriately, you can further-optimise damping of the

Hydraulic installations

Hydraulic accessories

BA-10010-02-V01

Solenoid-diaphragm dosing pump MAGDOS LA / LD Operating instructions

pulsations.

nTo prevent unnecessary pipe friction losses, you should lay the

connecting line straight and in accordance with the rated width of the pulsation dampener.

nYou must separately fasten relatively large pulsation dampeners and

ones with hose connections.

nPipelines must not transfer any mechanical tensions onto the

pulsation dampener.

8.7.6 Priming aid

Priming aids are particularly advisable:

nin the case of dosing pumps with small volumetric displacements per

stroke or with low stroke length settings,

nwith high suction hights, nwith highly dense dosing media, nat priming for the ﬁrst time due to dry valves and air in the suction line

and the dosing head,

nin dosing systems with frequent downtimes.

Further advantages resulting from priming aids:

npreventing cavitation in the suction line, ngas removal, noptical dosing control with small amounts, nsmoothing of the suction ﬂow.

8.7.7 Level monitoring

Level monitoring of suction-side feeding of the dosing medium to prevent the tank being sucked dry and to ensure that it can be topped up again in good time.

8.7.8 Dosing of suspensions

When dosing suspensions, the dosing head must be rinsed regularly to prevent depositing. To do this, you install a feed line for the rinsing medium (water) in the suction side installation.

8.7.9 Suction pressure regulator

A suction pressure regulator may be necessary if the suction-side installation of the system demonstrates a varying suction pressure or supply pressure:

nDosing pumps that are installed above dosing tanks deliver less as the

tank empties, since the suction head increases.

nDosing pumps that are installed below dosing tanks deliver less as the

tank empties, since the positive delivery pressure reduces.

Further problems that can occur:

nGreater wear on the dosing pump, e.g. diaphragm rupture due to the

effects of heavy forces with particularly high tanks and high-density dosing media.

nIdling of the dosing tank in the case of a diaphragm rupture or pipe

breakage.

nImpermissibly high forces in the pump transmission that occur when

dosing pumps receive the dosing medium directly from the pressure line.

nReduced performance or destruction of ﬁttings due to cavitation with

long suction lines.

Installing a suction pressure regulator is a remedy for the problems above. The suction pressure regulator is opened by the dosing pump's suction pressure. This ensures that no dosing medium can ﬂow if the dosing pump is not running or no vacuum can be generated following a pipe fracture.

Electrical installation

Principles

BA-10010-02-V01

Solenoid-diaphragm dosing pump MAGDOS LA / LD Operating instructions

9 Electrical installation

DANGER

Mortal danger from electric shock!

If there is an electrical accident, you must disconnect the dosing pump from the mains as quickly as possible.

ðInstall an emergency stop switch or integrate the dosing pump

into the plant safety concept.

CAUTION

Danger of automatic start up!

The dosing pump does not have an ON/OFF switch and may start to pump as soon as it is connected to the mains supply. This means that dosing medium can escape. Depending on the type and hazardousness of the dosing medium, this can result in damage to property or to injury.

ðInstall an emergency stop switch or integrate the dosing pump

into the plant safety concept.

NOTE

Damage due to incorrect mains voltage

The dosing pump can be damaged if you connect it to the wrong mains voltage.

ðObserve the information on the mains supply that is given on

the rating plate.

NOTE

Insufﬁcient electromagnetic compatibility

When you connect the dosing pump to a socket without an attached protective earth, it is not possible to guarantee the interference radiation and interference immunity according to EMC regulations.

ðOnly connect the dosing pump to sockets with an attached

protective earth.

9.1 Principles

nThe dosing pump is ﬁtted with a 115 V AC or 230 V AC (50 / 60 Hz)

power supply unit.

nThe electrical connection comply with local regulations. nThe dosing pump must be plugged into a grounded power outlet. nTo avoid dosing errors at the end of the process, the dosing pump

must be locked electrically.

nThe dosing pump must not be operated by switching the mains

voltage on or off.

nSignal cables must not be laid parallel to high-voltage current lines or

mains cables. You must route supply and signal lines in separate channels. An angle of 90° is required at line crossings.

NOTE

Conducting rubber hoses with versions LA and LD

The MAGDOS LA and LD are delivered with two conductive rubber hoses installed in connection sockets 1 and 3. These conduct electricity and ensure that the contacts in the connection sockets remain closed when no cables are connected. If the conductive rubber bands in connection sockets 1 and 3 are missing or not correctly installed and there are no cables connected to the sockets, it is not possible to start the dosing pump.

ðInsert the conductive rubber bands in connection sockets 1 and

3 if there are no cables connected to the connection sockets.

ðEnsure that the conductive rubber band is installed on the

correct contacts (see instructions in following chapters).

ðRetain the conductive rubber hoses so that you can change the

assignment of the connection ports later.

Fig. 16: Conductive rubber hoses in the connections 1 and 3 of the MAGDOS LA/LD

Electrical installation

Description of connection sockets

BA-10010-02-V01

Solenoid-diaphragm dosing pump MAGDOS LA / LD Operating instructions

9.2 Description of connection sockets

Not all versions of the dosing pump provide all the features described here. Every section heading includes the versions which apply to the section.

Fig. 17: Connection sockets 1 – 3

Inputs Connection socket

Clearance signal input 1

Analogue or pulse signal input 2

Level signal input 3

Table 15: Inputs of the control unit

9.2.1 Connection socket 1

9.2.1.1 Release input

Using the Release input, it is possible to start or stop the dosing pump externally.

To set the function, see section10.2.3 „Release input“ on page25.

nPotential-free contact nConnection M12x1 cable with plug connector, A-coded nAssignment of pin 3, 4

Pin M12x1

(A-coded)

Assignments Connection Cable colour

1 -

Brown BN

2 -

White WH

3 Ground (GND)

Blue BU

4 External On/Off Black BK

Table 16: Connection socket 1

* Applies to cable colours of cables from Lutz-Jesco GmbH. No liability is accepted for cables from other manufacturers.

Removing the conductive rubber band

Fig. 18: Conductive rubber band in connection socket 1

Remove the conductive rubber band before inserting the cable in the connection socket.

After the cable has been removed, the conductive rubber band must be reinserted in the connection socket. Insert it between pins 1+2 and 3+4 as shown in Fig. 18.

Connection socket 2

9.2.1.2 Analogue input (only LA)

The analog input makes it possible to control the delivery capacity by means of a 0/4 – 20 mA signal. The delivery capacity is regulated via the stroke frequency.

n0/4 – 20 mA Signal nInvertible nCurrent range variable nWorking resistance: 200 Ohm (because of the electronic fuse), not

potential-free

Pin M12x1

(A-coded)

Assignments Connection Cable colour

- - Brown BN

2 (+) 0/4 – 20 mA

White WH

3 Ground (GND) Blue BU

4 - - - Black BK

Table 17: Connection port 2 - analogue input

* Applies to cable colours of cables from Lutz-Jesco GmbH. No liability is accepted for cables from other manufacturers.

Electrical installation

Description of connection sockets

BA-10010-02-V01

Solenoid-diaphragm dosing pump MAGDOS LA / LD Operating instructions

9.2.1.3 Pulse input (only LD)

The pulse input makes it possible to control the delivery capacity by means of pulses. The system regulates the delivery capacity by means of the dosing pump's stroke frequency and number of strokes in dependence on the number of pulses and the pulse spacing.

nProvided potential-free contact nFor potential-free NO contact, e.g. a contact-type water meter n5 V DC supply voltage (current across all connections limited to a total

maximum of 50 mA)

nPulse length min. 4 ms

Pin M12x1

(A-coded)

Assignments Connection Cable colour

1 Pulses

Brown BN

3 Ground (GND) Blue BU

4 - - - Black BK

Table 18: Connection port 2 - pulse input

* Applies to cable colours of cables from Lutz-Jesco GmbH. No liability is accepted for cables from other manufacturers.

9.2.2 Connection socket 3

Level input

Connection port 3 serves the level monitoring of a dosing tank (e.g. a suction line with a level switch).

n5 V DC supply voltage (current across all connections limited to a total

maximum of 50 mA)

nAlert and main alarm nPotential-free contact nProgrammable NC or NO contact

A matching connection cable with A-coded plug connector is integrated in the suction lines / level monitoring systems of Lutz-Jesco GmbH. An adapter is required if using older suction lines with a 3.5 mm jack plug. You can ﬁnd this adapter and additional cables in the Lutz-Jesco GmbH price list.

Pin M12x1

(A-coded)

Assignments Connection Cable colour

1 Low level alert

Brown BN

2 Main alarm White WH

3 Ground (GND) Blue BU

4 - - - Black BK

Table 19: Connection socket 3

* Applies to cable colours of cables from Lutz-Jesco GmbH. No liability is accepted for cables from other manufacturers.

Removing the conductive rubber band

Fig. 19: Conductive rubber band in connection socket 3

Remove the conductive rubber band before inserting the cable in the connection socket.

After the cable has been removed, the conductive rubber band must be reinserted in the connection socket. Insert it between pins 1+2 and 3+4 as shown in Fig. 19.

Control

Operator controls of the control unit

BA-10010-02-V01

Solenoid-diaphragm dosing pump MAGDOS LA / LD Operating instructions

10 Control

10.1 Operator controls of the control unit

Fig. 20: Operator controls of the control unit

No. Explanation

1 Graphic display

2 Four multifunction keys

Table 20: Operator controls of the control unit

You operate the dosing pump using the four keys below the display. The system shows the respective functions of the keys at the bottom of the display.

The + and - selection keys as well as the and keys have a repeat function, i.e. if you keep them pressed down, the system automatically repeats the key function.

The display brightness reduces 45 seconds after your last input.

The dosing pump does not have an ON/OFF switch. After being disconnected from the power supply, the dosing pump starts in the operating mode and conﬁguration that you selected last.

10.2 Explanation of the menu icons

10.2.1 Level monitoring

Symbol Meaning

Dosing tank full

Dosing tank at minimum (alert)

Dosing tank empty (main alarm)

Table 21: Explanation of the menu symbols – Level monitoring

10.2.2 Operating modes

Symbol Meaning

Manual mode

Analogue input (only LA)

Pulse input (only LD)

Table 22: Explanation of the menu symbols – Operating modes

10.2.3 Release input

Symbol Meaning

Contact open

Contact closed

Table 23: Explanation of the menu symbols – Release input

10.2.4 Release code

Symbol Meaning

Release code active

Table 24: Explanation of the menu symbols – release code

10.2.5 Activating the password protection

If password protection is activated, the dosing pump is protected against unauthorized access. You can only perform settings after entry of the correct password.

WARNING

Caustic burns or other burns through dosing media!

If the password protection is activated, operation of the dosing pump is blocked. The only way to stop a dosing pump without entry of the password is via the power supply. In unfavourable cases, if the password protection has been inadvertently activated or the user has forgotten the password, the dosing pump cannot be stopped in time. This can result in injury.

ðInstall an emergency stop switch or integrate the dosing pump into

the plant safety concept.

You can set any password you like from 0001 to 9999.

1. Press + and - simultaneously.

4The dosing pump displays the password protection menu.

Fig. 21:

4 3 2 1

OK - +



Release code

Control

Explanation of the menu icons

BA-10010-02-V01

Solenoid-diaphragm dosing pump MAGDOS LA / LD Operating instructions

2. Use the+ and - keys to set a value from 0 to 9 for the ﬁrst digit of the

code and then press →.

3. Proceed as described under point 2 for the other digits.

4. Choose the last point and press +.

5. Press OK.

4The dosing pump now displays the corresponding symbol:

Fig. 22: Start screen with activated password protection

üPassword protection activated.

10.2.5.1 Entering the password

Once you press any key, you must enter the password. If you enter the code correctly, you have 120 seconds in which to operate the dosing pump. When the 120 seconds have elapsed, you must re-enter the code, even if you are in the middle of making another entry (this does not include settings in the menus).

Fig. 23:

4 3 2 1

OK - +



Entering the Release code

1. Use the+ and - keys to set a value from 0 to 9 for the ﬁrst digit of the

code and then press →.

2. Proceed as described under point 1 for the other digits.

3. After entering all the digits, press OK.

4If your input is correct, the dosing pump displays the start screen.

If you have forgotten the code, please contact Lutz-Jesco GmbH.

üEnter the code.

10.2.5.2 Deactivating the password protection

1. Press + and - simultaneously.

2. Press → until is selected.

3. Press -.

4. Press OK.

üPassword protection deactivated.

Operation

Commissioning the dosing pump

BA-10010-02-V01

Solenoid-diaphragm dosing pump MAGDOS LA / LD Operating instructions

11 Operation

WARNING

Caustic burns or other burns through dosing media!

After connecting the mains supply, residual dosing media in the dosing head can spray out.

ðBefore connecting the mains supply, connect the dosing lines. ðCheck that all the screw connections have been tightened

correctly and are leak-proof.

CAUTION

Danger of automatic start up!

ðStop the dosing pump before disconnecting it from the mains

supply.

ðEnsure that the dosing pump has been installed correctly before

connecting it to the mains supply.

11.1 Commissioning the dosing pump

Precondition for action:

üThe dosing pump was ﬁtted and installed in accordance with the sec-

tions “Fitting the dosing pump”, “Hydraulic installation” and “Electrical installation”.

üAll the mechanical fastenings have been inspected to ensure

adequate load-bearing capacity.

üThe dosing head screws have been tightened with the correct torque. üAll the hydraulic sections have been inspected to ensure they are

adequately leak-proof and that the through ﬂow direction is correct.

For initial commissioning, it is advisable to use water as the dosing medium to check that the system is leak-proof and that the dosing pump is functioning correctly. Check ﬁrst whether undesirable reactions could occur between the actual dosing medium and the water.

Perform the following working steps:

1. Open the shut-off valves on the suction and discharge sides if present.

2. Plug in the dosing pump's mains plug to the power supply.

3. If the dosing head is ﬁtted with a vent screw, vent the dosing pump

(see section 11.1.1 „Venting the dosing pump“ on page27).

4. Select an operating mode and start the dosing pump in accordance with the instructions in the chapter 11.2 „Operating modes“ on page28.

4The dosing pump primes. If it does not prime enough, use a priming

aid (see chapter 8.7.6 „Priming aid“ on page21).

At initial commissioning, it is advisable to prime the pump without backpressure. For this purpose, we recommend installing a relief valve on the discharge side of the dosing pump.

üThe dosing pump is commissioned.

11.1.1 Venting the dosing pump

Plastic dosing heads are ﬁtted with a vent screw. Gas bubbles can be removed from the dosing head using vent screws, in order to improve the performance of the pump. Whether venting is helpful depends on the dosing medium and the size of the pump.

CAUTION

Danger of personal injury and material damage!

Dosing medium can escape if you loosen connections on the dosing head (e.g. for venting) during operation.

ðUse sufﬁcient personal protective equipment. ðFollow the safety data sheet of the dosing medium. ðClean the dosing pump if dosing medium escapes. ðDispose of the dosing medium correctly.

Fig. 24: Dosing head venting facility with vent screw

Precondition for action:

üThe dosing head venting facility connected has been connected in

accordance with the chapter 8.6 „Connecting the dosing head venting facility“ on page19.

Perform the following working steps:

1. Select the Internal.operating mode.

2. Press Stop.

3. Keep + depressed until 100% delivery capacity is achieved.

Operation

Operating modes

BA-10010-02-V01

Solenoid-diaphragm dosing pump MAGDOS LA / LD Operating instructions

4. Open the vent screw by one complete turn (looking onto the dosing head, anti-clockwise).

5. Press Start.

4The dosing pump starts delivery at the highest stroke frequency.

6. Press Stop, as soon as there is a continuous throughﬂow from the dosing head venting facility with no air bubbles.

4The dosing pump stops delivery.

7. Close the vent screw.

üThe dosing pump is vented.

If you are using strongly effervescent dosing media, allow them to ﬂow out continuously. Open the vent screw such that about one drop per 1 – 3 strokes escapes, then close the discharge.

11.2 Operating modes

The dosing pump offers the following operating modes:

nInternal - Manual setting of the delivery capacity, nExternal - Controlling the stroke frequency and number of strokes in

dependence on the number of pulses and the pulse spacing (LD) or the analogue signal (LA).

11.2.1 Internal operation

11.2.1.1 Selecting the operating mode

èPress Int.

4The dosing pump displays the start screen of Intern mode.

Fig. 25:

Ext Start - +

Start screen of Manual operation

11.2.1.2 Starting the dosing pump

1. Use the + and - keys to set the desired stroke frequency.

2. Press Start.

üDosing pump has started.

11.2.1.3 Stopping the dosing pump

èPress Stop.

4The system displays the "Stop" signal and Stop changes to

Start.

üDosing pump has stopped.

11.2.2 External operation

In External mode, the frequency and number of strokes issued by the MAGDOS LD dosing pump is controlled in dependence on the pulse frequency and number of pulses applied at the pulse input (see section

9.2.1.3 „Pulse input (only LD)“ on page24).

The MAGDOS LA is controlled via an analogue signal.

11.2.2.1 Selecting the operating mode

èPress Ext to select the operating mode.

4The dosing pump shows the start display of the operating mode

External.

Fig. 26:

Int Start - +

100%

Parameters of the operating mode

11.2.2.2 Setting the current value for 0% and 100% delivery capacity (only LA)

Perform the following working steps:

1. Press the key to navigate to the settings menu.

4The dosing pump displays the current conﬁguration of the

parameters.

0% = 4.00 mA 100% = 20.00 mA

6.04 mA

OK → - +

→

Fig. 27: Conﬁguring the parameters

2. Either select the limit value 0% or 100% using the → button.

3. Use the + and - keys to set the desired current value for 0% / 100 %.

A value between 0.00 - 20.00 mA is permissible. The symbol shows the current value currently set.

4. Press OK.

4The dosing pump displays the start screen of the operating mode

External (analogue input).

üThe current value for 0% and 100 % delivery capacity is set.

11.2.2.3 Setting the transmission and reduction

The transmission and reduction factors can be set in 1% intervals of 1% to 1000%. A set value of 100% means that the dosing pump executes one dosing stroke per incoming pulse signal. For values above 100%, the dosing pump executes more dosing strokes per pulse signal accordingly.

For values below 100%, the dosing pump executes less than one dosing stroke per pulse signal, meaning that several pulse signals are required before a dosing stroke is executed.

Operation

Operating modes

BA-10010-02-V01

Solenoid-diaphragm dosing pump MAGDOS LA / LD Operating instructions

The number of pulse signals required for a dosing stroke is displayed on the dosing pump display for values below 100%.

Fig. 28:

Int Start - +

50% (2)

Number of pulse signals required (here: 2)

Examples for transmission / reduction

Number of pulses Setting Dosing strokes

4 25% 1

2 50% 1

1 100% 1

2 100% 2

4 125% 5

1 1000% 10

Table 25: Examples for transmission / reduction of pulse signals

With sequences consisting of successive pulses, it is necessary to ensure that given speciﬁc settings, the pulses are not always followed by the number of dosing strokes which correspond to the pulses. This is due to the circumstance that only one whole dosing stroke is performed, and not e.g. half or a quarter of a dosing stroke. Depending on the transmission or reduction factor and the number of pulses, however, there is a possibility of uneven results with "pending" pulse signals. In theses cases, the required number of dosing strokes is only achieved after a number of pulse cycles.

Examples:

The dosing pump receives pulses with a reduction factor of 30%. For the ﬁrst stroke, it requires 4 pulses in this setting (4x30% = 120%), as 3 pulses (3 x 30% = 90%) are insufﬁcient for one dosing stroke (= 100%). However, the second dosing stroke is executed after just 3 more pulses, as the stroke buffer of the dosing pump still has 20% pending from the ﬁrst 4 pulses (120% - 100% = 20%) and this is added to the 3 pulses (90% + 20% = 110%). The third dosing stroke also only requires 3 additional pulses (90% + 10% = 100%). A further 4 pulses are then required for the fourth dosing stroke.

If pulses are transferred to the dosing pump with a transmission factor of 125%, a dosing stroke is executed for each of the ﬁrst 3 pulses. With the 4th pulse, it executes 2 dosing strokes (3x 25% pending from the ﬁrst 3 pulses + 125% = 200%).

The dosing pump has a dynamic stroke buffer which includes the interval between the pulses in the calculation and adjusts the distribution of the dosing strokes accordingly.

11.2.2.4 Calculating the transmission factor

The dosing pump MAGDOS LD has a deﬁned stroke volume per dosing stroke. If a certain dosing quantity is required per pulse, the corresponding transmission factor can be calculated for the external operating mode.

You can ﬁnd a simple means of performing the necessary calculations on the Lutz-Jesco GmbH homepage. To do so, click on the following link or enter it in your browser: http://www.lutz-jesco.com/en/online-help

If you have no Internet connection, you can also perform the calculation yourself.

The following parameters are required for this:

nrequired dosing quantity in ml/pulse ndelivery capacity of the dosing pump in ml/stroke

The delivery capacity of the dosing pump can be taken from in the technical data and the delivery characteristic curves (see “delivery capacity data” on page 13 and “delivery characteristic curves” on page

46). Intermediate values can be interpolated.

Calculate the value using the following formula:

required dosing quantity per pulse x 100%

delivery capacity per stroke

Example: With a MAGDOS LD 6, 1 ml should be proportionally dosed per pulse. The stroke volume at 4 bar is 0.63 ml.

The factor to be set is calculated as follows:

required dosing quantity per pulse x 100%

delivery capacity per stroke

1 ml/pulse x 100

0,63 ml/stroke

= 159 %

In this example, the pump would execute 159 strokes for 100 incoming pulses.

Note that the stroke frequency of the dosing pump is restricted. For the MAGDOS LD 6, the max. stroke frequency is approx. 180 strokes/min. Any additional incoming strokes are not processed. For this example, this means that the dosing pump can process a maximum of 113 pulses/min (180/1.59).

11.2.2.5 Starting the dosing pump

Precondition for action:

üThe dosing pump has been connected in accordance with the

chapter “Pulse input (only LD)” on page 24.

1. Press Start.

2. Supply pulses to the pulse input of the dosing pump.

üDosing pump has started.

11.2.2.6 Stopping the dosing pump

èStop the incoming pulses or press Stop.

üDosing pump has stopped.

Operation

Operating modes

BA-10010-02-V01

Solenoid-diaphragm dosing pump MAGDOS LA / LD Operating instructions

11.2.2.7 Operation with contact water meter (only LD)

The dosing pump MAGDOS LD is prepared for operation with a contact-type water meter. The contact sequence of the water meter and the size of the dosing pump must be matched to each other (calibrated).

You can ﬁnd a simple means of performing the necessary calculations on the Lutz-Jesco GmbH homepage. Visit us under: http://www.lutz-jesco.com/online-helfer

If you have no Internet connection, you can also perform the calculation yourself.

Preselection of the dosing pump size

You can use the following diagram to determine the necessary size of the dosing pump depending on the intended dosing quantity and the existing or selected pulse sequence of the contact-type water meter. Comparison with the technical data of the dosing pump with regards to the operating pressure is also necessary (see “Technical data” on page 13). ).

0.7

0.5

0.4

0.3

0.2

0.1

0.07

0.05

0.04

0.03

0.02

0.01

ml/stroke of dosing pump

0.1 0.2 0.3 0.5 0.7 1 2 3 4 5 7 10 20 30 50 70 100

l/pulse (water meter)

MAGDOS 10, 15

MAGDOS 6

MAGDOS 4

MAGDOS 2

MAGDOS 05, 1

Dosing quantity: 1000 ml/m³

Operation

Operating modes

BA-10010-02-V01

Solenoid-diaphragm dosing pump MAGDOS LA / LD Operating instructions

Calculating the transmission factor

The ﬁrst calculation phase is used to determine the transmission factor which is set in the display of the MAGDOS LD.

The following parameters are required for this:

nDosing quantity per cubic metre of water in ml/m3 nPulse sequence of water meter in l/lmp nDelivery capacity per stroke of the dosing pump in ml/stroke

Calculate the factor using the following formula:

required dosing quantity per pulse x 100%

delivery capacity per stroke

1 ml/pulse x 100

0,63 ml/stroke

= 159 %

required dosing quantity x pulse sequence of water meter

delivery capacity per stroke x 10

Example:

1000 ml of a dosing medium should be dosed per m3 of water in a water line at 4 bar. The contact-type water meter has an pulse sequence of 1 l/ pulse. The selection table (see 30) can be used to select a MAGDOS LD 6 with 0.63 ml/stroke at 4 bar. A MAGDOS LD 10 would also come into consideration as it doses 0.88 ml/stroke. A MAGDOS LD 15 is not suitable as it can only work at 3 bar.

The factor to be set is calculated as follows:

1 ml/pulse x 100

0,63 ml/stroke

= 159 %

1000 x 1

0,63 x 10

= 159 %

Calculating the necessary stroke frequency

The second calculation phase checks the size of the contact-type water meter and the maximum stroke frequency of the MAGDOS LD by comparing the required stroke frequency and the maximum stroke frequency of the dosing pump.

The following additional parameter is required for this:

nThe nominal size of the contact-type water meter in cubic metres per

hour [m³/h]

Calculate the necessary stroke frequency using the following formula:

required dosing quantity per pulse x 100%

delivery capacity per stroke

1 ml/pulse x 100

0,63 ml/stroke

= 159 %

required dosing quantity x pulse sequence of water meter

delivery capacity per stroke x 10

1000 x 1

0,63 x 10

= 159 %

dosing quantity in ml/m³ x nominal size of the water meter in m³/h

delivery capacity per stroke in ml/stroke

Example:

For the dosing speciﬁed above, a contact-type water meter with the nominal size of m³/h should be used.

The necessary stroke frequency is calculated with:

required dosing quantity per pulse x 100%

delivery capacity per stroke

1 ml/pulse x 100

0,63 ml/stroke

= 159 %

delivery capacity per stroke x 10

1000 x 1

0,63 x 10

= 159 %

delivery capacity per stroke in ml/stroke

1000 ml/m³ x 5 m³/h

0,63 ml/stroke

= 7937 strokes/h

This value is compared with the maximum possible stroke frequency of the dosing pump. The MAGDOS LD 6 achieves a maximum of 10800 strokes/hour.

Result:

The required stroke frequency must be smaller than the maximum stroke frequency of the dosing pump, which is the case here.

If the maximum stroke frequency is higher, the dosing pump cannot continue up to the water meter's maximum ﬂow rate. In this case, the following versions are possible:

nUse of a higher dosing pump model, e.g., MAGDOS LD 10 instead of

MAGDOS LD 6

nReduction of the dosing quantity via higher concentration of the

dosing medium

nIncrease of the pulse sequence of the contact-type water meter, e.g.,

0.5 l/pulse instead of 1 l/pulse

Operation

External On / Off via Release input

BA-10010-02-V01

Solenoid-diaphragm dosing pump MAGDOS LA / LD Operating instructions

11.3 External On / Off via Release input

Regardless of the selected operating mode, you can start or stop the dosing pump by means of the closed switching contact on the Release input.

Fig. 29:

Int Start - +

100%

Start screen of external operation with symbol for closed contact in centre

11.3.1 Starting the dosing pump

èClose the switching contact on the Release input.

üDosing pump has started.

11.3.2 Stopping the dosing pump

èOpen the switching contact on the Release input.

üDosing pump has stopped.

No alarm follows the external switch-off of the dosing pump.

11.4 Decommissioning the dosing pump

Perform the following working steps:

1. Stop the dosing pump in accordance with the selected operating mode.

2. Unplug the dosing pump's mains plug from the power supply.

3. Disconnect all electrical connections.

4. Depressurize all the hydraulic parts in the system.

5. Unplug all the hydraulic connections on the dosing pump.

6. Empty the dosing head.

7. Remove any residual dosing medium from the dosing head by

ﬂushing the system with a washing agent. Ensure that the washing agent is compatible with the dosing medium.

üDosing pump is decommissioned.

11.5 Shutting down in an emergency

nIn an emergency, you must immediately disconnect the dosing pump

from the mains supply or activate the Emergency Stop switch installed in the system.

nDepending on the type of incident, you must depressurized the

hydraulic connections or locked to prevent dosing medium from escaping.

nYou must follow the safety data sheet of the dosing medium.

11.6 Storage

Storing the dosing pump correctly extends its service life. You should avoid negative inﬂuences such as extreme temperatures, high humidity, dust, chemicals, etc.

Ensure ideal storage conditions where possible:

nthe storage place must be cold, dry, dust-free and generously

ventilated,

nTemperatures between + 2°C and + 40°C (for PP and PVDF dosing

heads, between + 2°C and + 60°C),

nRelative air humidity must not exceed 90%.

11.7 Transportation

Perform the following working steps:

nThe unit should be thoroughly cleaned. Any dangerous dosing media

must be additionally neutralised and decontaminated.

nAll accessories should be dismantled. nAll openings should be closed, so that no foreign objects can get into

the system.

nThe dosing pump must be suitably packed, preferably in the original

packing, for transportation.

If the device is sent back to the manufacturer, please follow chapters 17 „Declaration of no objection“ on page40 and 18 „Warranty claim“ on page41.

11.8 Disposal of old equipment

nThe waste unit must be thoroughly cleaned. Any dangerous dosing

media must be additionally neutralised and decontaminated.

nAny residual dosing media must be removed in a professional manner. nThe dosing pump must be disposed of in accordance with applicable

local laws and regulations. The device does not belong to household waste!

nAs the disposal regulations may differ from country to country in the

European Union, please consult your supplier if necessary. In Germany, the manufacturer must provide free-of-charge disposal provided the unit has been sent in a safe manner.

Maintenance

Maintenance intervals

BA-10010-02-V01

Solenoid-diaphragm dosing pump MAGDOS LA / LD Operating instructions

12 Maintenance

The products are produced to the highest quality standards and have a long service life. Nevertheless, some of their parts are subject to wear due to operation (e.g. diaphragms, valve seats, valve balls). This means that regular visual inspections are necessary to ensure a long operating life. Regular maintenance will protect the dosing pump from operation interruptions.

DANGER

Mortal danger from electric shock!

Live parts can inﬂict fatal injuries.

ðBefore carrying out any maintenance work, always disconnect

the dosing pump from the power supply.

ðSecure the dosing pump from accidental power-up.

WARNING

Caustic burns or other burns through dosing media!

While working on the dosing head, valves and connections, you may come into contact with dosing media.

ðUse sufﬁcient personal protective equipment. ðRinse the dosing pump with a medium (e.g. water) which does

not pose any risk.

ðRelease pressure in hydraulic parts. ðNever look into open ends of plugged pipelines and valves.

WARNING

Danger of automatic start up!

The dosing pump does not have an ON/OFF switch and may start to pump as soon as it is connected to the mains supply.

After connecting the mains supply, residual dosing media in the dosing head can spray out.

ðBefore connecting the mains supply, connect the dosing lines. ðCheck that all the screw connections have been tightened

correctly and are leak-proof.

CAUTION

Danger of personal injury and material damage!

The dosing pump can generate a pressure that is many times the rated one. The dosing medium can escape in the case of material failure or wear on the dosing head, the connection pipe or the seals that are used.

ðCarry out maintenance work at the recommended intervals.

12.1 Maintenance intervals

This table gives you an overview of maintenance work and the intervals at which you must carry it out. The next few sections contain instructions for carrying out this work.

Maintenance work to be carried out Frequency

Check that piping is seated ﬁrmly Regularly

Check that suction and pressure valves are seated ﬁrmly

Regularly

Clean suction and pressure valves Regularly

Check that electrical connections are not damaged

Regularly

Tighten up dosing head bolts nRegularly

nBefore initial commission-

ing

nAfter each diaphragm

change

Check diaphragm for leakage due to rupture

Regularly (as long as no leak monitoring system is installed)

Check that the installed accessories are functioning correctly

Regularly

Check the dosing pump for unusual noises during operation, unusual temperatures or smells

Regularly

Replace parts that are subject to wear (diaphragms, valves, seals, etc.)

When unacceptable levels of wear are detected

Rinse out and clean the dosing pump nBefore changing

diaphragms

nBefore taking out of

service for a long period of time

nAfter feeding aggressive,

sticky, crystallising or contaminated liquids

Table 26: Maintenance information and maintenance intervals

12.2 Tighten up dosing head bolts

èTighten the dosing head bolts in diagonally opposite sequence with a

torque wrench.

The necessary torque is 180 Ncm.

Maintenance

Change the diaphragm

BA-10010-02-V01

Solenoid-diaphragm dosing pump MAGDOS LA / LD Operating instructions

12.3 Change the diaphragm

Fig. 30:

Exploded view of the diaphragm and dosing head

12.3.1 Remove the old diaphragm

Precondition for action:

üYou have disconnected the dosing pump from the mains supply. üYou have depressurised the hydraulic sections of the plant. üYou have rinsed the dosing pump using a safe medium (e.g. water).

Perform the following working steps:

1. Screw out the four screws (5) on the dosing head using a suitable tool (SW 3 Allen key) and take off the dosing head (4).

2. Use pliers to bend the edge of the diaphragm (3) slightly upwards and screw it out counter-clockwise.

12.3.2 Install a new diaphragm

Precondition for action:

üYou have thoroughly cleaned the diaphragm rod (2) and the

diaphragm ﬂange (1) so that the new diaphragm is not affected by dosing medium residues.

üThe diaphragm (3) thread was lightly greased (e.g. Molycote

Longterm W2).

1. Screw the diaphragm manually (3) in the clockwise direction until it safely contacts into the diaphragm rod.

2. Bring the dosing head into position and insert the screws. First tighten the screws ﬁnger-tight. After this, tighten the bolts on the diagonal, e.g. top left – bottom right – top right – bottom left.

NOTE

Damage to the dosing head/diaphragm leaks

If you tighten the screws too much, this can lead to the dosing head being damaged. However, not tightening the screws enough leads to the diaphragm being leaky and correct functioning being affected.

ðTighten the screws to a torque of 180 Ncm.

üDiaphragm change ﬁnished.

12.4 Clean suction and pressure valves

Contaminated valves affect the dosing preceision and this means that you should clean the valves on a regular basis.

With dosing heads made of plastic, when replacing a valve you must replace the complete dosing head (see chapter 14 „Spare parts“ on page37).

Troubleshooting

Type of fault

BA-10010-02-V01

Solenoid-diaphragm dosing pump MAGDOS LA / LD Operating instructions

13 Troubleshooting

See below for information about how to rectify faults on the device or the system. If you cannot eliminate the fault, please consult with the manufacturer on further measures or return the dosing pump for repair.

13.1 Type of fault

13.1.1 Dosing pump not delivering or output too low

Possible cause Remedy

Wrong type of dosing pump selected

èCheck the dosing pump's

technical data and if necessary select a type with a higher delivery capacity.

Valve leaking or blocked èClean the valve and vent the

dosing pump.

èTighten the screw connections.

Valve installed incorrectly èReassemble the valve. Ensure

that the valve balls are located above the valve seats.

Valve damaged (e.g. valve balls)

èRemove the damaged parts or

install a new valve.

Suction line is leaking èSeal the leak locations or replace

the parts.

Suction line is blocked (e.g. screen in foot valve)

èClean the suction line.

Shut-off valves closed èOpen the shut-off valves. Inspect

the dosing pump for possible damage.

Suction head too high èSet the dosing pump to feed or

reduce the suction head.

èInstall a priming aid.

Viscosity too high èPossibly reduce the concentration

of the dosing medium or increase the temperature.

èInstall spring-loaded valves.

èIncrease the pipe diameter.

Current supply interrupted èReconnect the current supply

The dosing pump's electrical data does not match that of the mains supply

èCheck the electrical installation.

System backpressure too high (measured at discharge connection of dosing pump)

èClean blocked injection nozzle.

èInstall pulsation dampeners to

reduce pressure peaks if pipes are too long.

èCheck function of safety valves.

Table 27: Type of fault: Dosing pump not delivering or output too low

Possible cause Remedy

Conductive rubber bands not inserted in connection sockets or not inserted correctly

èInsert conductive rubber bands

correctly

Table 27: Type of fault: Dosing pump not delivering or output too low

13.1.2 Dosing pump does not prime

Possible cause Remedy

Valve leaking or blocked èClean the valve and vent the

dosing pump.

èTighten the screw connections.

Valve installed incorrectly èReassemble the valve. Ensure

that the valve balls are located above the valve seats.

Valve damaged (e.g. valve balls)

èRemove the damaged parts or

install a new valve.

Suction line is leaking èSeal the leak locations or replace

the parts.

Suction line is blocked (e.g. screen in foot valve)

èClean the suction line.

Shut-off valves closed èOpen the shut-off valves. Inspect

the dosing pump for possible damage.

Suction head too high èSet the dosing pump to feed or

reduce the suction head.

èInstall a priming aid.

Viscosity too high èPossibly reduce the concentration

of the dosing medium or increase the temperature.

èInstall spring-loaded valves.

èIncrease the pipe diameter.

Current supply interrupted èReconnect the current supply

Dry the valves èDampen the dosing head and the

valves

èVent the dosing head.

Air in the suction line with simultaneous pressure on the pressure valve

èVent the dosing head or the lines.

Table 28: Type of fault: Dosing pump does not prime

Troubleshooting

Type of fault

BA-10010-02-V01

Solenoid-diaphragm dosing pump MAGDOS LA / LD Operating instructions

13.1.3 Delivery rate varies

Possible cause Remedy

Valve leaking or blocked èClean the valve and vent the

dosing pump.

èTighten the screw connections.

Valve damaged (e.g. valve balls)

èRemove the damaged parts or

install a new valve.

Suction line is leaking èSeal the leak locations or replace

the parts.

Suction line is blocked (e.g. screen in foot valve)

èClean the suction line.

Viscosity too high èPossibly reduce the concentration

of the dosing medium or increase the temperature.

èInstall spring-loaded valves.

èIncrease the pipe diameter.

The dosing pump's electrical data does not match that of the mains supply

èCheck the electrical installation.

Suction side pressure too high (pump siphoning)

èInstall a back-pressure valve in

the pressure line.

Pressure peaks due to acceleration with long suction lines

èInstall a suction pressure

regulator.

Imprecise dosing due to changeable positive and negative suction heads.

èInstall a suction pressure

regulator.

System backpressure too high (measured at discharge connection of dosing pump)

èClean blocked injection nozzle.

èInstall pulsation dampeners to

reduce pressure peaks if pipes are too long.

èCheck function of safety valves.

Table 29: Type of fault: Delivery rate varies

13.1.4 No stroke movement observed

Possible cause Remedy

Diaphragm return spring broken.

èContact the manufacturer.

Current supply interrupted èReconnect the current supply

The dosing pump's electrical data does not match that of the mains supply

èCheck the electrical installation.

Pressure peaks due to acceleration with long suction lines

èInstall a suction pressure

regulator.

Table 30: Type of fault: No stroke movement observed

Possible cause Remedy

System backpressure too high (measured at discharge connection of dosing pump)

èClean blocked injection nozzle.

èInstall pulsation dampeners to

reduce pressure peaks if pipes are too long.

èCheck function of safety valves.

Table 30: Type of fault: No stroke movement observed

13.1.5 Dosing pump delivery rate too high

Possible cause Remedy

Suction side pressure too high (pump siphoning)

èInstall a back-pressure valve in

the pressure line.

Pressure peaks due to acceleration with long suction lines

èInstall a suction pressure

regulator.

Table 31: Type of fault: Dosing pump delivery rate too high

13.1.6 Diaphragm is torn or tears too often

Possible cause Remedy

Shut-off valves closed èOpen the shut-off valves. Inspect

the dosing pump for possible damage.

Pressure peaks due to acceleration with long suction lines

èInstall a suction pressure

regulator.

The materials are not suitable for the dosing medium being used

èCheck the resistance of the

materials.

Diaphragm not screwed up to the end stop on the diaphragm rod

èScrew a new diaphragm up to the

end stop.

System backpressure too high (measured at discharge connection of dosing pump)

èClean blocked injection nozzle.

èInstall pulsation dampeners to

reduce pressure peaks if pipes are too long.

èCheck function of safety valves.

Media sediment in dosing head

èClean the dosing head.

Table 32: Type of fault: Diaphragm is torn or tears too often

13.1.7 Loud noises on the dosing pump

Possible cause Remedy

The drive magnet's stop damper is worn-out

èContact the manufacturer.

Table 33: Type of fault: Loud noises on the dosing pump

Spare parts

Diaphragm spare parts kits

BA-10010-02-V01

Solenoid-diaphragm dosing pump MAGDOS LA / LD Operating instructions

14 Spare parts

Fig. 31: Spare parts set

Required sets for a complete service:

n1 diaphragm spare parts kit, n1 dosing head spare parts set including valves.

14.1 Diaphragm spare parts kits

Diaphragm spare parts set containing:

n1 Diaphragm (item 1) n1 set of dosing head screws (item 3),

Diaphragm kit Type Part No.

05, 1 39121

2, 4 39122

6, 10, 15 39123

14.2 Dosing head spare parts kits including valves

Spare parts set: dosing head including screws consisting of:

nDosing head (item 2), nValves, n1 set of dosing head screws (item 3),

PVC Type Part No.

Ceramic/PVDF/FPM (ball/seat/seals)

05, 1 38981

2, 4 38982

6, 10, 15 38983

PP Type Part No.

Ceramic/PVDF/FPM (ball/seat/seals)

05, 1 38978

2, 4 38979

6, 10, 15 38980

PVDF Type Part No.

PTFE/PVDF/FPM (ball/seat/seals)

05, 1 38984

2, 4 38985

6, 10, 15 38986

Further sets in numerous material combinations can be found in the manufacturer’s current price list.

Other spare parts

PVC Part No.

Set of conductive rubber bands (2 pcs) 40036

Set of covering caps M12x1 (3 pcs) 40319

Delivery characteristic curves

Dosing head spare parts kits including valves

BA-10010-02-V01

Solenoid-diaphragm dosing pump MAGDOS LA / LD Operating instructions

15 Delivery characteristic curves

This Chapter is intended to give you an idea of the delivery capacity that the dosing pump can achieve at speciﬁc back pressures. These delivery capacities were determined on the manufacturer's test stands. They apply at 20 °C (68 °F) for water, at 100% stroke frequency. The delivery capacity depends on the medium (density and viscosity) and temperature. Since these conditions vary at every installation location, you should calibrate the dosing pump.

Fig. 32:

0 2 4 6 8 10 12 14 16

Delivery capacity [l/h]

Pressure [bar]

Delivery characteristic curves MAGDOS LA / LD 05 – 4

Fig. 33:

0 2 4 6 8

Delivery capacity [l/h]

Pressure [bar]

Delivery characteristic curves MAGDOS LA / LD 6 – 15

EC Declaration of Conformity

BA-10010-02-V01

Solenoid-diaphragm dosing pump MAGDOS LA / LD Operating instructions

16 EC Declaration of Conformity

(DE) EU-Konformitätserklärung

Hiermit erklären wir, dass das nachfolgend bezeichnete Gerät aufgrund seiner Konzipierung und Bauart sowie in der von uns in Verkehr gebrachten Ausführung den einschlägigen grundlegenden Sicherheits- und Gesundheitsanforderungen der aufgeführten EG-Richtlinien entspricht. Bei einer nicht mit uns abgestimmten Änderung am Gerät verliert diese Erklärung ihre Gültigkeit.

(NL) EU-overeenstemmingsverklaring

Ondergetekende Lutz-Jesco GmbH, bevestigt, dat het volgende genoemde apparaat in de door ons in de handel gebrachte uitvoering voldoet aan de eis van, en in overeenstemming is met de EU-richtlijnen, de EU-veiligheidsstandaard en de voor het product speciﬁeke standaard. Bij een niet met ons afgestemde verandering aan het apparaat verliest deze verklaring haar geldigheid.

(FR) Déclaration de conformité UE

Nous déclarons sous notre propre responsabilité que le produit ci-dessous mentionné répond aux exigences essentielles de sécurité et de santé des directives CE énumérées aussi bien sur le plan de sa conception et de son type de construction que du modèle que nous avons mis en circulation. Cette déclaration perdra sa validité en cas d’une modiﬁcation effectuée sur le produit sans notre accord explicite.

(PT) Declaração de conformidade UE

Declaramos pelo presente documento que o equipamento a seguir descrito, devido à sua concepção e ao tipo de construção daí resultante, bem como a versão por nós lançada no mercado, cumpre as exigências básicas aplicáveis de segurança e de saúde das directivas CE indicadas. A presente declaração perde a sua validade em caso de alteração ao equipamento não autorizada por nós.

(EN) EC Declaration of Conformity

We hereby certify that the device described in the following complies with the relevant fundamental safety and sanitary requirements and the listed EC regulations due to the concept and design of the version sold by us. If the device is modiﬁed without our consent, this declaration loses its validity.

(ES) Declaración de conformidad UE

Por la presente declaramos que, dados la concepción y los aspectos constructivos del modelo puesto por nosotros en circulación, el aparato mencionado a continuación cumple con los requisitos sanitarios y de seguridad vigentes de las directivas de la U.E. citadas a continuación. Esta declaración será invalidad por cambios en el aparato realizados sin nuestro consentimiento.

2006/42/EG, 2014/30/EU

Die Schutzziele der Niederspannungsrichtlinie 2014/35/EU wurden gemäß Anhang I, Nr. 1.5.1 der Maschinenrichtlinie 2006/42/EG eingehalten.

The protective aims of the Low Voltage Directive 2014/35/EU were adhered to in accordance with Annex I, No. 1.5.1 of the Machinery Directive 2006/42/EC.

EG-Richtlinien: EC directives:

DIN EN ISO 12100:2011-03, DIN EN 809:2012-10 DIN EN 61000-6-2:2005, DIN EN 61000-6-3:2007 + A1:2011

Harmonisierte Normen: Harmonized standards:

Lutz-Jesco GmbH

Dokumentationsbevollmächtigter: Authorized person for documentation:

Bezeichnung des Gerätes:

Descripción de la mercancía:

Description of the unit:

Omschrijving van het apparaat:

Désignation du matériel:

Designação do aparelho:

Magnet-Membrandosierpumpe

Bomba dosiﬁcadora magnética de membrana

Solenoid diaphragm dosing pump

Magneet Membraandoseerpomp

Pompe doseuse à membrane magnétique

Bomba doseadora de membrana magnética

MAGDOS LA 05 – 15 MAGDOS LD 05 – 15

Typ: Type:

Heinz Lutz Geschäftsführer / Chief Executive Ofﬁcer Lutz-Jesco GmbH Wedemark, 01.01.2017

Lutz-Jesco GmbH Am Bostelberge 19 30900 Wedemark Germany

Declaration of no objection

BA-10010-02-V01

Solenoid-diaphragm dosing pump MAGDOS LA / LD Operating instructions

17 Declaration of no objection

Please copy the declaration, stick it to the outside of the packaging and return it with the device.

Declaration of no objection

Please fill out a separate form for each appliance!

We forward the following device for repairs:

Device and device type: ................................................................ Part-no.:...................................................................................

Order No.:..................................................................................... Date of delivery: .......................................................................

Reason for repair: ......................................................................................................................................................................................

..................................................................................................................................................................................................................

Dosing medium

Description: .................................................................................. Irritating:

Yes No

Properties: .................................................................................... Corrosive:

Yes No

We hereby certify, that the product has been cleaned thoroughly inside and outside before returning, that it is free from hazardous material (i.e. chemical, biological, toxic, flammable, and radioactive material) and that the lubricant has been drained.

If the manufacturer finds it necessary to carry out further cleaning work, we accept the charge will be made to us.

We assure that the aforementioned information is correct and complete and that the unit is dispatched according to the legal requirements.

Company / address:...................................................................... Phone:......................................................................................

..................................................................................................... Fax:..........................................................................................

..................................................................................................... Email:.......................................................................................

Customer No.:............................................................................... Contact person: ........................................................................

Date, Signature:............................................................................

Warranty claim

BA-10010-02-V01

Solenoid-diaphragm dosing pump MAGDOS LA / LD Operating instructions

18 Warranty claim

Warranty claim

Please copy and send it back with the unit!

If the device breaks down within the period of warranty, please return it in a cleaned condition with the complete warranty claim.

Sender

Company: ............................................................................................................... Phone: .................................. Date: ..........................

Address: ....................................................................................................................................................................................................

Contact person: .........................................................................................................................................................................................

Manufacturer order no.: .......................................................................................... Date of delivery: .........................................................

Device type: ............................................................................................................ Serial number: ...........................................................

Nominal capacity / nominal pressure: .........................................................................................................................................................

Description of fault:.....................................................................................................................................................................................

Service conditions of the device

Point of use / system designation:...............................................................................................................................................................

Accessories used (suction line etc.):............................................................................................................................................................

Commissioning (date): ................................................................................................................................................................................

Duty period (approx. operating hours): ........................................................................................................................................................

Please describe the specific installation and enclose a simple drawing or picture of the chemical feed system, showing materials of construction, diameters, lengths and heights of suction and discharge lines.

Index

BA-10010-02-V01

Solenoid-diaphragm dosing pump MAGDOS LA / LD Operating instructions

19 Index

Accessories .....................................................................................20

Analog input

Connection .................................................................................23

Approved media temperature ...........................................................14

Back-pressure valve ........................................................................20

Cemented connection ......................................................................19

Clean suction and pressure valves ...................................................34

Commissioning the dosing pump .....................................................27

Connection sockets ..........................................................................23

Contact water meter ........................................................................20

Control .............................................................................................25

Control elements .............................................................................12

Decommissioning the dosing pump .................................................32

Delivery capacity data ......................................................................13

Delivery characteristic curves .......................................................... 38

Design of the system .......................................................................17

Device revision ..................................................................................9

Diaphragms

Replace ......................................................................................34

Spare parts set ...........................................................................37

Dimensioned drawings ....................................................................15

Dimensions ......................................................................................15

Disposal of old equipment ................................................................32

Dosing head

Alignment ...................................................................................18

Design ........................................................................................11

Spare parts .................................................................................37

Dosing head venting facility .............................................................19

Dosing media

Approved media temperature .....................................................14

Prohibited dosing media ...............................................................9

EC Declaration of Conformity ...........................................................39

Electrical speciﬁcations ...................................................................14

External On / Off via Release input ...................................................32

Foreseeable misuse ...........................................................................9

Function description ........................................................................12

General warnings ...............................................................................6

Glue-in connection ...........................................................................19

Handling instructions

Marking ........................................................................................5

Hazards due to non-compliance with the safety instructions ..............7

Hydraulic accessories ......................................................................20

Hydraulic connections ......................................................................18

Hydraulic installations ......................................................................17

Injection nozzle ................................................................................20

Inputs of the control unit ..................................................................23

Installation .......................................................................................16

hydraulic ....................................................................................17

Installing the Dosing Pump ..............................................................16

Intended purpose ...............................................................................9

Intended use ......................................................................................9

Leakage drain ..................................................................................19

Level monitoring ..............................................................................21

Maintenance .............................................................................. 33, 37

Maintenance intervals ......................................................................33

Notes for the Reader ..........................................................................4

Operating conditions and limits ........................................................13

Operating modes .............................................................................28

Explanation of the icons ..............................................................25

Operation ...................................................................................27, 33

Operator controls of the control unit .................................................25

Personnel qualiﬁcation .......................................................................7

Pressure-relief valve ........................................................................20

Priming aid ......................................................................................21

Product description ..........................................................................11

Product warranty ...............................................................................9

Prohibited dosing media ....................................................................9

Pulsation dampener .........................................................................20

Pulse input

Connection .................................................................................24

Rating plate .....................................................................................12

Release code ...................................................................................25

Release input ...................................................................................23

Index

BA-10010-02-V01

Solenoid-diaphragm dosing pump MAGDOS LA / LD Operating instructions

Safety ................................................................................................6

Scope of delivery .............................................................................11

Set up information ...........................................................................16

Shutdown .................................................................................. 32, 33

Shutting down in an emergency .......................................................32

Signal words

Explanation ...................................................................................4

Spare parts ......................................................................................37

Specialist staff ...................................................................................8

Start-up ..................................................................................... 22, 27

Storage ............................................................................................32

Structure of the dosing pump ...........................................................11

Suction pressure regulator ...............................................................21

Suspensions ....................................................................................21

System piping ..................................................................................17

Technical data .................................................................................13

Temperatures

Approved ambient temperature ..................................................13

Approved media temperature .....................................................14

Tighten up dosing head bolts ...........................................................33

Transportation ..................................................................................32

Troubleshooting ...............................................................................35

Venting ............................................................................................27

Venting the dosing pump .................................................................27

Wall bracket ....................................................................................16

Wall mounting ..................................................................................16

Warnings

General warnings .........................................................................6

Marking ........................................................................................4

Warning sign

Explanation ...................................................................................4

Warranty claim ................................................................................41

Water meter .....................................................................................20

Working in a safety-conscious manner ..............................................7

Headquarters

Lutz-Jesco GmbH

Am Bostelberge 19 30900 Wedemark Germany

Tel.: +49 5130 5802-0 Fax: +49 5130 580268

E-mail: info@lutz-jesco.com Website: www.lutz-jesco.com

Netherlands

Lutz-Jesco Nederland B.V.

Nijverheidstraat 14 C 2984 AH Ridderkerk Netherlands

Tel.: +31 180 499460 Fax: +31 180 497516

E-mail: info@lutz-jesco.nl Website: www.lutz-jesco.nl

Hungary

Lutz-Jesco Üzletág

Vasvári P. u. 9. 9024 Györ Hungary

Tel.: +36 96 419813 Fax: +36 96 419814

E-mail: info@lutz-jesco.hu Website: www.lutz-jesco.hu

USA

Lutz-JESCO America Corp.

55 Bermar Park Rochester, N.Y. 14624 USA

Tel.: +1 585 426-0990 Fax: +1 585 426-4025

E-mail: mail@jescoamerica.com Website: www.lutzjescoamerica.com

East Asia

Lutz-Jesco East Asia Sdn Bhd

6 Jalan Saudagar U1/16 Hicom Glenmarie Industrial Park 40150 Shah Alam/ Selangor Malaysia

Tel.: +603 55692322 Fax: +603 55691322

E-mail: info@lutz-jescoasia.com Website: www.lutz-jescoasia.com

Austria

Lutz-Jesco GmbH

Aredstraße 7/2 2544 Leobersdorf Austria

Tel.: +43 2256 62180 Fax: +43 2256 6218062

E-mail: info@lutz-jesco.at Website: www.lutz-jesco.at

Middle East

Lutz-Jesco Middle East FZE

P.O. Box 9614 SAIF-Free Zone Center Sharjah UAE

Tel.: +971 6 5572205 Fax: +971 6 5572230

E-mail: info@jescome.com Website: www.jescome.com

Great Britiain

Lutz-Jesco (GB) Ltd.

Gateway Estate West Midlands Freeport Birmingham B26 3QD Great Britain

Tel.: +44 121 782 2662 Fax: +44 121 782 2680

E-mail: info@lutz-jesco.co.uk Website: www.lutz-jesco.co.uk

Product Range Lutz Pumpen GmbH

P.O. Box 1462 • D-97864 Wertheim www.lutz-pumpen.com

Product Range Lutz-Jesco GmbH

P.O. Box 100164 • D-30891 Wedemark www.lutz-jesco.com

Centrifugal Pumps

Products for the disinfection of swimming pool water based on salt water electrolysis and domestic water technology

The Lutz-Jesco App for iPads and iPhones is available from the iTunes App Store. Additional information can be found at www.lutz-jesco.com

Barrel and Container Pumps

Dosing Pumps

Measuring and Control Equipment

Double Diaphragm Pumps

System and Process Technology

Chemical Centrifugal Pumps

Flow Meters

Chlorinators Disinfection

Lutz-Jesco MAGDOS LA, MAGDOS LD Operating Instructions Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
