Interface Technology · Microcompact Solid State Relay
AC/DC Solid State Relay, 3 wire, plus switching
Switching element DC 30 V; 3 A; short circuit protection, wide range input
Screw-/ Spring terminal
Description Part-No. Type PU
Screw terminal
Rated voltage AC/DC 77–250 V 760705 OT 6-0705 AC/DC 24 V 3
Spring terminal
Rated voltage AC/DC 77–250 V 761705 OT 6-1705 AC/DC 24 V 3
Input AC/DC 77–250 V
Dimensions
PIN assignment
A1
A2
Derating
Input voltage range
Rated current 3.0 mA
Interrupting voltage
Protection device Suppressor diode
Status indication
Rated frequency 50–60 Hz
Output
Switching element Transistor, N/O contact
Min. switching voltage
Max. switching voltage DC 30 V
Min. switching current
Max. switching current DC 3 A (Derating)
Inrush current
Leakage current –
Switch-on delay
Switch-off delay 60 ms
Switching frequency
Clearance/creep. dist.
(contol/load side)
Protection device output
General
Housing material
IP rating IP 20
+13
Field installation
Insulation voltage input/output 0,5 kVeff
Safe isolation
14
Operation temperature range -25 °C – 70 °C
Storage temperature range
0 V
Dimensions (w × h × d) 6.2 × 84.0 × 80.0 mm
Weight (kg/piece)
Approvals cULus
Termination
Accesories Colour Article number Type Pkg.
Jumper comb 24pole, 26A
Tag holder 4×11 mm white 681313 BZT 0411 100
Labels for laser printer A4 unpunched
Labels for laser printer 4.23 x 11 mm
(Sheet with 1056 labels)
blue
Screw-/spring terminal 0.25–2.5 mm
77.0–250.0V
<25 V
LED yellow
DC 10 V
DC 1 mA
DC 5 A ( 1 s)
7 ms
<10 Hz
>5.5 mm
Suppressor diode
PPE
rail TS 35 (EN 50022)
yes
-40 °C – 80 °C
0.029
2
760801
681031
681034 LEB-0411 1
BK 6-0801
LEB-A4
units
5
1
2.6
