Interface Technology · Microcompact Solid State Relay
DC Solid State Relay, 3 wire, plus switching
Switching element DC 30 V; 5 A; short circuit protection
Screw-/ Spring terminal
Description Part-No. Type PU
Screw terminal
Rated voltage DC 24 V 760103 OT 6-0103 DC 24 V 3
Spring terminal
Rated voltage DC 24 V 761103 OT 6-1103 DC 24 V 3
Input DC 24 V
Dimensions
PIN assignment
Derating
I (A)
L
5,0
4,9
4,8
4,7
4,6
4,5
4,4
4,3
50 52 54 56 58 60 62 64 66 68 70
Input voltage range
Rated current 7.0 mA
Interrupting voltage
Protection device Suppressor diode
Status indication
Rated frequency –
Output
Switching element Transistor, N/O contact
Min. switching voltage
Max. switching voltage DC 30 V
Min. switching current
Max. switching current DC 5 A (Derating)
Inrush current
Leakage current –
Switch-on delay
Switch-off delay 200 µs
Switching frequency
Clearance/creep. dist.
(contol/load side)
Protection device output
General
Housing material
IP rating IP 20
Field installation
Insulation voltage input/output 4 kVeff
Safe isolation
Operation temperature range -25 °C – 60 °C
Storage temperature range
Dimensions (w × h × d) 6.2 × 84.0 × 80.0 mm
Weight (kg/piece)
Approvals –
Termination
Screw-/spring terminal 0.25–2.5 mm2
Accesories Colour Article number Type Pkg.
Jumper comb 24pole, 26A
blue
Tag holder 4×11 mm white 681313 BZT 0411 100
Labels for laser printer A4 unpunched
Labels for laser printer 4.23 x 11 mm
(Sheet with 1056 labels)
T (°C)
U
10.0 – 30.0 V
<9 V
LED yellow, short circuit red
DC 10 V
DC 1 mA
–
220 µs
<2 kHz
>5.5 mm
Suppressor diode
PPE
rail TS 35 (EN 50022)
yes
-40 °C – 80 °C
0.030
760801
681031
BK 6-0801
LEB-A4
681034 LEB-0411 1
units
5
1
2.7
