Interface Technology · Solid State Relay
80
116
12,7
86 ––
90
5,4
4,5
output
input
input
DC Solid State Relay, 2 wire
Switching element AC 6600 V; 25 A; Zero crossing switch
Screw terminal
Description Part-No. Type PU
Screw terminal
Rated voltage DC 24 V / 25 A 716080 OT-6080 DC 24 V 1
Input DC 24 V / 25 A
Input voltage range
Rated current 10.0 mA
Interrupting voltage
Protection device –
Status indication
Rated frequency –
Output
Switching element Thyristor, N/O contact
Min. switching voltage
Max. switching voltage AC 660 V
Dimensions
input
output
input
12,7
PIN assignment
80
86
90
Min. switching current
Max. switching current AC 25 A (Derating)
Inrush current
Leakage current <1 mA
Switch-on delay
Switch-off delay 10 ms
116
Switching frequency
Clearance/creep. dist.
(contol/load side)
Protection device output
General
4,5
Housing material
5,4
IP rating IP 20
Plastic, flame resistant according to UL-94-V0
Field installation
Insulation voltage input/output 4 kVeff
Safe isolation
Operation temperature range -25 °C – 70 °C
Storage temperature range
Dimensions (w × h × d) 22.5 × 116.0 × 80.0 mm
Weight (kg/piece)
Approvals –
Termination
4.0–32.0V
2 V
LED green
AC 48 V
AC 100 mA
AC 250 A ( 10 ms)
10 ms
<10 Hz
–
Varistor
rail TS 35 (EN 50022)
yes
-40 °C – 80 °C
0.260
Screw terminal: 0.25–4.0 mm
2
Derating
2.15
