Technical data sheet
Wiring Accessories · Wire management
Edge protection for RG 035
Identification
Type KHS 035 200 RG
Part-No. 380093.0010
Product version
Datasheet version 00
Description
Description
Edge protection of the RG 035 (adapter rail) to prevent injuries on cables
or contact with any potential sharp edges when wiring. Sliding nuts can be
inserted through the recess in the edge protector.
General
Dimensions (w × h × d) 35.0 mm × 20.0 mm × 10.0 mm
Material PA 6.6
Surface smooth
Halogen free according to VDE 0472-815
Flammability rating UL 94 V0
PU (units) 10
United Kingdom: LÜTZE Ltd.
Unit 3, Sandy Hill Park
Sandy Way, Amington • GB-Tamworth, Staffs B77 4DU
Tel. +44 (0)1827 31333-0 • Fax +44 (0)1827 31333-2
www.lutze.com • [email protected]
Germany: Friedrich Lütze GmbH
Postfach 12 24 (PLZ 71366) • Bruckwiesenstraße 17-19 • D-71384 Weinstadt
Tel. +49 (0)7151 6053-0 • Fax +49 (0)7151 6053-277(-288)
www.luetze.de • [email protected]
13.04.2021 • Subject to technical modification
Part-No. 380093.0010 • Datasheet version: 00 page 1 of 2
Page 2
Technical data sheet
Wiring Accessories · Wire management
Dimensions
13.04.2021 – Subject to technical modification
Part-No. 380093.0010 • Datasheet version: 00 page 2 of 2
