Technical data sheet
Mounting Accessories · Component mounting
Side supports
Identification
Type CST 7 Set
Part-No. 346364.0010
Product version
Datasheet version 00
Description
Description The depth of the wiring space is increased with CST standoffs. CST standoffs
are used to increase or decrease the depth of the wiring space of the
mounting rails.
Technical data
Cross-section surface 167.14 mm²
Tensile strength 250 N/mm²
General
Material AL Mg Si 0.5 F25
Surface polished, electrically conductive
Operation temperature range -5 °C . . . +80 °C
Storage temperature range -30 °C . . . +90 °C
Conductance 24 S
PU (units) 10
