How To Order
seeTouch
™
Example: SG-2BN-WH-E01
1 2 3 4 5 6
---
WH2B NSG
E
01
1 2 3
Series Button Configurations/Features Non-Insert
or Insert
2B NSG
Three options
for GRAFIK Eye
lighting control
systems.
3000 AND
4000 SERIES
Choose the button configurations
and features required.
®
NON-INSERT (N) MODELS
Use NON-INSERT (N) Models
for a clean single-gang look.
Use INSERT (I) Models for
multigang applications.
N
SG
2BN 4BN 4SN 4SIRN 4MN 4PSN 4NRLN
INSERT (I) MODELS
Non-Insert for
single-gang use
I
Insert for
multigang use
5000 AND
6000 SERIES
2BI 4BI 4SI 4SIRI 4MI 4PSI
NON-INSERT (N) MODELS
4NRLI
N
SO
2BN 3BN 4BN 4SN 4SIRN 4NRLN
INSERT (I) MODELS
5BN 6BN 7BN
I
BUTTON AND
WALLPLATE
REPLACEMENT
KITS
SR
2BI 3BI 4BI 4SI 4SIRI 4NRLI
NON-INSERT (N) MODELS
Includes wallplate adapter,
button assembly, wallplate
INSERT (I) MODELS
Includes wallplate adapter,
button assembly, wallplate
Innovations in Lighting Control
5BI 6BI 7BI
TIP!
Use Button
Replacement Kits to:
N
◊ Change colors, button
configurations, and
engraving
◊ Change between Insert
and Non-Insert
◊ Order Non-Standard
I
Text Engraving
4 5 6
Colors/Finishes Language Engraving
Choices
WH
There are 19 Color/Finish options.
Insert a Color/Finish code into
the model number.
MATTE
†
GLOSS
†
Gloss available for
Insert models only.
BACKLIGHTING
Illuminated text
available for IV,
GR, BR, BL buttons.
Metals have black
buttons.
METAL
WH
BE
IV
GR
SPECIAL METAL
BR
BL
GWH
GLA
Illuminated buttons
available for WH,
BE, GWH, GLA,
colors/finishes.
Innovations in Lighting Control
SB
BB
BC
QB
QZ
SC
SN
BN
CLA
BLA
BRA
E
Standard Text Engraving
is available in 13 languages.
Insert a language code
into the model number.
Arabic
Chinese
Danish
Dutch
English
French
German
Italian
Japanese
Portuguese, Brazil
Portuguese, Europe
Spanish, Europe
Spanish, Americas
Note: Language is not
required for non-standard
text engraving ,
see below.
NON-STANDARD TEXT ENGRAVING ( ONLY)
NST
NST
Example: SR-2BN-WH-NST
---
There are 3 options
for ordering engraving.
Insert an engraving code
into the model number.
GENERAL
A
ENGRAVING
C
Add to model number.
D
Language code is required.
N
E
F
G
STANDARD TEXT
I
ENGRAVING
J
B
P
S
L
Offers customized button engraving to suit
particular needs. To order, contact Lutron
Customer Service. Add to model
number. No language code is required.
01 99
Available in a number
of choices, shown.
Language code and engraving
number is required.
See www.lutron.com/seetouch
for more choices.
NON-STANDARD TEXT
ENGRAVING ( ONLY)
See below.
WH2B NSR
01
GN
01
SR
SR
NST
NST
Page 3
seeTouch™Wallstations
Just a look and a touch
and the perfect light settings are recalled.
SEE.
◊
Easy to see
backlit buttons
◊
Easy to read
engraved buttons
◊
Matching buttons
TOUCH.
◊
Large buttons
◊
Rounded button
design
◊
2-7 buttons in
the same control
and faceplates
(matte and gloss finishes)
◊
Text angles up for
ease of viewing from
any mounting height
SG-4SN-WH-E01 shown
Specifications Multigang Ordering
POWER: Operating voltage: Class 2, 12-35VDC.
MOUNTING: Mounts in standard U.S. single gang
wallbox.
INSTALLATION: Front-accessible DIP switches
for ease of addressing and setting function.
Use Button Replacement Kits (SR-) to change
color, button configuration, or engraving. Button
Replacement Kits may also be used to convert
between non-insert (N) and insert (I) configurations.
World Headquarters
Lutron Electronics Co., Inc.
7200 Suter Road, Coopersburg, PA
18036-1299 U.S.A.
US/CAN: 800-523-9466
Int’l: 610-282-3800
Worldwide Offices
Berlin, Hong Ko ng,
London, Tokyo,
and Singapore
www.lutron.com
CONTROLS: Order Insert (I) models for
multigang installations. Non-Insert (N) models
cannot be multiganged.
WALLPLATES: Specify “R3” openings in Lutron
NovaTa
multigang FB Series (fins broken only) wallplates.
®
Note: seeTouch button assemblies are NOT provided with
multigang wallplates. Use the button assemblies provided
with Insert (I) Models/Button Replacement Kits.
MULTIGANG WALLPLATE EXAMPLES:
Wallplate for two seeTouch wallstations
Model Number: NT-R3R3-FB-
Wallplate for other Lutron controls
(shown: NTGRX-2B-SL-) and two
seeTouch wallstations
Model Number: NT-T8R3R3-FB-
Note: R3 openings ship without inserts.
©2002 Lutron Electronics Co., Inc.
Printed in U.S.A. 1/02 P/N 367-274
