Blood Pressure
Monitor
Instruction
Manual
2
Model Number 1098
ID # =
Requires 2 “AAA” Alkaline Batteries
YEAR
LIMITED WARRANTY
TABLE OF CONTENTS
Identification of Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Battery Installation/Replacement . . . . . . . . . . . . . . . . . . . . . . . . 4
Attaching the Wrist Cuff and Posture During . . . . . . . . . . . . . . . 4
Measurement
Measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Subsequent Measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Automatic Power-off Function . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Memory Recall . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Memory Clear Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Description of Display Marks . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Identification of Parts
3
2 "AAA" type battery
Wrist Cuff
Memory Key
LCD Display
ON/OFF Key
Battery Cover
LCD Display
4
Battery
Installation/Replacement
• To use the unit, you must install
batteries.
• Open battery cover as illustrated.
Install or replace two new batteries, making
sure the polarities (+ and -) on the battery
match the polarities on the case.
• Replace battery cover.
• If the Low Battery indicator “ “ appears on
the display, both batteries must be replaced.
• “AAA” alkaline batteries or equivalent are suitable for this blood pressure meter.
Attaching the Wrist Cuff
and Posture During
Measurement
• The blood pressure is measured at the wrist.
Therefore, rolling up the sleeve is no longer
necessary.
• Wrap the wrist cuff around your left wrist with
the display panel on the inside of the wrist.
• Pull the wrist cuff to fit wrist size and fasten
velcro.
Wrist circumference: 5.4-9in.
Rest left elbow on a table so that the cuff is at
heart level. Relax the lower arm across the table
and remain still.
Perform measurements in either a seated or
reclining posture with the left palm turned
upward. The hard carry case should be used as
an arm rest, with rubber grips facing down
against the table.
1/2 inch
Carry Case
2 "AAA" type battery
Measurement
NOTE: Unit measures on inflation.
• To start the measurement
Press the “ON/OFF” switch.
• Initial display.
• Pumping.
• Measuring and Beeping sounds.
• Once the blood-pressure measurement has stabilized, pressurization is discontinued and the air in
the cuff is automatically let out.
• The buzzer sounds for about 2 seconds, and the
high and low blood pressure are respectively displayed one above the other.
• Unless an error is generated, the measurement
results are automatically stored in memory (Up to
42 sets of results can be stored ). When there are
already 42 sets of results in memory, the oldest one
is automatically erased and overwritten with the
newest.
5
6
• Blood pressure values and pulse rate are
alternately displayed. The unit will continue
to display the measurement until power
is turned off.
• Turn Power off
Press the “ON/OFF” switch to turn off.
NOTE:
To discontinue a measurement for any reason, press the “Power/Start”
switch. This causes the “wrist cuff” to rapidly deflate.
Subsequent Measurement
When a measurement needs to be made again,
the time between 2 measurements must be at least 10 minutes.
Automatic Power OFF Function
If the unit is left on after measurement, an “Automatic Power
OFF Function” turns the power off after approximately
3 minutes. To continue with another measurement press
the “ON/OFF” switch to turn the unit on.
7
Setting the Clock
Enter the setting mode by pressing and holding the MEMORY key for over three seconds.
The display will show a blinking year. Press
the ON/OFF key to adjust the year when it is
blinking. Then press and release the MEMORY key again, the month will apear and blink
to be adjusted, then the date, hour and minute
will follow up as you press and release the
MEMORY key again.
Adjust the clock by pressing the MEMORY
key to adjust the values of the month, date,
hour, and minute when they are blinking.
Memory Recall
• You can recall stored data by pressing the
“Memory Recall” switch at any time, EXCEPT while
taking a measurement.
• Up to 42 sets of measurement results can be
stored in memory. Memory cell No. 1 is always
used to store the newest set of results.
• When pressing the “Memory Recall” switch, the
memory cell number is displayed. The stored
measurement results (systolic/diastolic blood pressure) are then displayed. The display will show the
memorized pressure and pulse value switching
back and forth.
• If the “Memory Recall” switch is pressed again, the
prior measurements are displayed in the order they
were taken.
Memory Clear Function
You may erase one or all records in the memory.
•Press and release MEMORY key to choose the
record that you wish to delete.
•Press and hold the ON/OFF key until the display
shows dEL.
•Delete one record: Press and release the power
key. After three beeps are heard, the record is
completely deleted.
•Delete all records:
1. Press and release the MEMORY key then
the display shows dEL ALL.
2. Press and release the ON/OFF key. After
three beeps are heard, the unit erases all
records.
3. Remove one or both batteries while the
unit is on.
8
9
Description of Display Marks
DISPLAY MARK CONDITION/CAUSE
CORRECTIVE ACTION
Pumping error.
The pressure measured
was less than 20 mmHg.
The pressure measured
was higher than
300mmHg.
Please measure
again.
The pumping pressure
is higher than
300mmHg.
Batteries are weak.
There is a problem with
the device.
Please measure
again.
Please check the cuff and
try again.
Please measure
again.
Replace the batteries.
Return to Lumiscope
service Department.
HI
or no display
10
Switch
Inflation
Exhaust
Rated Voltage
Power Source
Power Consumption
Battery Life
Automatic Power-Off
Memory Function
Dimension
Weight
LCD
LCD
Indication
Accuracy
Operating
Environment
Storage
Environment
Temperature
Humidity
Temperature
Humidity
Measurement
Range
Measuring Principle
Measurement Localization
Cuff
Wrist Circumference Range
Model No.
1098
View Size
Digit Size
Marks
Systolic blood pressure: 3 digits
Diastolic blood pressure: 3 digits
Pulse rate: 3 digits
Measuring ❤
Battery
1.44(H) x .904(W)in (36(H) x 22.6(W)mm)
.44(H) x .22(W)in (11(H) x 5.5(W)mm)
ON/OFF switch, Memory recall switch
Automatic Inflation by Internal Pump
Deflation Valve
3 VDC
2 “AAA” Size Batteries
1.0W
Approx. 250 measurements
After 2 minutes, or 30 sec. of non use
42 Memories Function, plus date & time
80mm(W) x 80mm(D) x 30mm(H)
Approx. 130g including batteries
50 to 104°F
(10 to 40°C)
30 to 85%RH
14 to 140°F
(-10 to 50°C)
Less than 85%RH
Pressure
Pulse
Pressure
Pulse
Pressure
Pulse Rate
Full Fuzzy Auto, Oscillometric Method
Left Wrist
Soft Cuff
5.4 to 7.8 in.
(13.5 to 19.5cm)
20 to 300 mmHg
40 to 200 Pulses/min.
±3 mmHg
±5% of reading
Alternatively
Specifications
CAUTION:
1. Measurement of blood pressure may not be possible for someone with a weak pulse or cardiac
arrhythmia.
2. This product is not intended to be used in the diagnosis or treatment of disease.
3. If you have high blood pressure and/or other cardiovascular conditions or diseases, this device
should be used in consultation with your doctor.
4. Consult your doctor if you have questions about your blood pressure or pulse.
5. Specifications are subject to change without notice due to improvements in performance.
Two Year Limited Warranty
The Lumiscope Company, Inc., guarantees this product free from defects
in material and workmanship for a period of two years from the date of
purchase, except as noted below:
This Lumiscope product warranty does not cover damage caused by
misuse or abuse; the attachment of any unauthorized accessory; alteration to
the product; or any other conditions whatsoever that are beyond the control of
the Lumiscope Company, Inc. Lumiscope shall not be
responsible for any type of incidental, consequential, or special damage. All
implied warranties, including, but not limited to those implied warranties of fitness and merchantability, are limited in the total duration of two years from the
original date of purchase.
To obtain warranty service on your Lumiscope Blood Pressure Meter either
hand deliver or mail the entire unit and your dated sales receipt (as proof
of purchase), postpaid, along with a certified check or money order in
the amount of $15.00 payable to The Lumiscope Company, Inc., to
cover handling.
Upon receipt Lumiscope will repair or replace, as appropriate, Blood
Pressure Meter, and return to you. Warranty is solely through Lumiscope
Repair Department. Service of this product by anyone other than
Lumiscope Repair Department voids warranty.
In the event that Lumiscope does not abide the terms of this warranty the consumer may seek breach of contract remedies in the New York State Federal
courts of law. This warranty gives you specific legal rights and you may also
have other rights, which vary from state to state.
Some states do not allow the exclusion or limitation of incidental or
consequential damages, so the above limitation may not apply to you.
2
YEAR
LIMITED WARRANTY
The Lumiscope Company, Inc. Service Dept.
122 Tices Lane
East Brunswick, N.J. 08816
tel: 732-254-3800
www.lumiscope.net
