Lumens Ladibug PC User Manual

TM

Ladibug

2.0

Visual Presenter Image Software

User Manual - English

Table of Contents

1. Introduction .......................................................................................................... 2

2. System Requirements .......................................................................................... 2

3. Install Ladibug™ ................................................................................................... 3

4. Connection to the Hardware ................................................................................. 5

5. Start to Use Ladibug™ ......................................................................................... 5

6. Operation Interface Description ............................................................................ 6

6.1 Software screen introduction .............................................................................................. 6

6.2 Thumbnail (Saved image window) ..................................................................................... 7

6.3 Main menu .......................................................................................................................... 8

6.4 Annotation Tools ................................................................................................................. 9

6.5 Camera Settings ............................................................................................................... 11

6.6 Options ............................................................................................................................. 12

6.7 Time Lapse (Burst Settings) ............................................................................................. 13

7. Function Descriptions ......................................................................................... 14

7.1 Turn on/off the Visual Presenter ....................................................................................... 14

7.2 I would like to display a live image ................................................................................... 14

7.3 I would like to capture images .......................................................................................... 14

7.4 I would like to capture images continuously ..................................................................... 14

7.5 I would like to freeze the live image .................................................................................. 14

7.6 I would like to annotate the displayed image .................................................................... 15

7.7 I would like to add textual annotation to images ............................................................... 16

7.8 I would like to adjust the drawing object ........................................................................... 17

7.9 I would like to record videos ............................................................................................. 17

7.10 I would like to use the mask mode ................................................................................... 17

7.11 I would like to use the spotlight mode ............................................................................... 18

7.12 I would like to manage saved image files ......................................................................... 18

8. Troubleshooting .................................................................................................. 19

1

1. Introduction

After installing the Ladibug™ application, you can use the software to:

 Control the Visual Presenter.

 Capture and record images.

 Annotate the image, highlight important details and save it.

 Support the full screen function.

2. System Requirements

Windows XP

 Min CPU: Intel Core 2 Duo 2GHz and above
 Min Memory: 1GB RAM
 Supporting Direct X 9
 Min Screen Resolution: 1024 x 768
 Min Hard Drive Space: 1GB
 Windows XP SP2 and above

Windows Vista / 7 / 8

 Min CPU: Intel Core 2 Duo 2GHz and above
 Min Memory: 1 GB (32-bits)/2 GB (64-bits) RAM
 Supporting Direct X 9 (with WDDM 1.0 or higher)
 Min Resolution: 1024 x 768
 Min Hard Drive Space: 1GB

2

3. Install Ladibug™

1. Please download Ladibug software at Lumens website.

2. Extract the file downloaded and then click [Ladibug] to install.

3. The installation wizard will guide you through the process. Please follow the on-screen
instructions and press [Next] for the next step.

3

Yes

No

4. Press [Yes] to create Ladibug™ shortcut on your desktop.

5. Once the installation is completed, press [Finish] to restart the computer.

4

AC Outlet

<Very Important> To ensure successful installation, please follow each of the
following steps.

4. Connection to the Hardware

4.1. Connect the power cord of the Visual Presenter.

<Note> Appearance may vary depending on country/region.

4.2. Connect USB cable to the Visual Presenter and your computer.

5. Start to Use Ladibug™

5.1. Double-click the [Ladibug] icon on the desktop to launch Ladibug™.

5.2. Click [POWER] icon to power on.

5.3. Click [PREVIEW] icon to start to use.

5
