User Manual
Welcome to Lumapower
Please take a moment to register your product on our Web site at
http://www.Lumapower.com. It enables us to keep you posted on our latest advancements,
and helps us to better understand our customers and build products that meet their needs
and Expectations.
This product has been designed and manufactured to the highest quality standards. However ,
if something does go wrong with this product, Lumapower and its national distributors
warrant free of charge labour and replacement parts in any country served by an official
distributor.
Unpacking: Check the product carefully. If it has been damaged in transit, report the
damage immediately by calling your dealer and/or the shipping company that delivered it.
Read Instructions. All the safety and operating instructions should be read before the
product is operated.
Follow Instructions. All operating and use instructions should be followed.
Replacement Parts. When replacement parts are required, be sure the replacement parts
have the same characteristics as the original part. Unauthorized substitutions may cause
damage to the unit.
Introduction
Lumapower EncoRE supports input voltage from 2.4V to 8.5V. It is powered by 1 x CR123A,
1 x RCR123A or 1 x 18650 batteries. EncoRE is fitted with pure white LED module driven by
current regulation circuitry to achieve a consistent level of light output for the useable life of
the batteries.
EncoRE features a forward clicky switch and multi-level digital output control circuit with
memory functions.
Half-press the tail switch to power on EncoRE momentary, full press to lock it for constant on.
Another full press to release the lock (power off)
Digital output control and Memory
Half press to cycle the output from High, Medium and Low.
At each output level, with a full press to lock it.
During slelected level po wer on within 1
st
second, you can change the output by power off and
on. As the selected level powered over 1 second will activate the memory-IC to store the
status and remains the same output with your next start.
The memory-IC retains last mode for easy usage.
Battery Installation
Unscrew the LED-engine and insert new batteries with positive ends towards LED assembly.
Replace bezel and hand tighten. Depress tailcap pushbutton switch to test.
Note: It would not light if battery is inserted in wrong direction.
Damage will occur with wrong battery insertion.
CAUTION: EncoRE flashlights are high-output lighting devices. Due to possibl e eye
injury, DO NOT look directly into the reflector when the light is switched on. Safety is
your responsibility, too.
External surface temperature will rise during prolonged operation; this is a normal operating
phenomenon.
Battery Replacement
If there is significant decrease in brightness of light output you should replace the battery.
Unscrew the LED-engine and remove the old battery. Insert a new battery as mentioned in
Battery Installation Guide
WARNING: Lithium batteries can expl ode or cause burns if disassembl ed, shorted,
recharged, exposed to water, fire, or high temperatures. Do not place loose batteries i n a
pocket, purse or other container containing metal objects or store with hazardous or
combustible materials. Store in cool, dry, ventilated area. Follow applicable laws and
regulations for disposal.
Maintenance
Clean and lubricate threads with a clean cloth and apply thin coat of silicon-based lubricant to
rubber O-rings. Note: Do not use petroleum-based lubrication on O-rings. After prol onged
exposure to moisture, the bezel and batteries should be removed, inspected, and dried i f
necessary
.
WARNING: Lumapower reflector is made with high precision process. Do not touch
or clean the reflecting surface using any cloth which may cause damage to the surface
material affecting the illuminating performance.
Non-use Periods.
If EncoRE is left unused for long period, the installed battery should be removed from the
unit.
Output & Runtime
Accurately specifying light output (lumens) and runtime is complicated for LED flashlights.
Installed batteries and operating temperature are the main factors affecting the light output
and runtime. Lumapower doesn’t guarantee its products can reach the specification under the
using condition of users.
Specification
LED : Cree XR-E Q5
Reflector : OP textured type
Output : 5 Lumens to 180 Lumens
Runtime : 150 minutes at High, 4200 minutes at Low (18650 @ 2200mAh)
Batteries : Primary 123A, rechargeable Li-ion RCR123A, 18650
Length : 115mm
Bezel Diameter : 21mm
Weight : 41g (without battery installed)
Material : T6061 aircraft aluminium
Body color : Black (Type III HA)
Accessories : spare o-rings
Specifications: All product specifications/features are subject to change without notification.
