User Manual (ver.1.0)
Signature Turbo Force
Lumapower Multi-purpose Flashlight
Welcome to Lumapower
Please take a moment to register your product on our Web site at
http://www.Lumapower.com
(download the product registration form in the “ORDER page”)
It enables us to keep you posted on our latest advancements, and helps us to better
understand our customers and build products that meet their needs and Expectations.
This product has been designed and manufactured to the highest quality standards.
However, if something does go wrong with this product, Lumapower and its national
distributors warrant free of charge labour and replacement parts in any country served by
an official distributor.
Unpacking: Check the product carefully. If it has been damaged in transit, report the
damage immediately by calling your dealer and/or the shipping company that delivered it.
Read Instructions. All the safety and operating instructions should be read before the
product is operated.
Follow Instructions. All operating and use instructions should be followed.
Replacement Parts. When replacement parts are required, be sure the replacement parts
have the same characteristics as the original part. Unauthorized substitutions may cause
damage to the unit.
Introduction
The Lumapower “Signature” supports input voltage from 2.8V to 8.4V. The “Signature”
is fitted with pure white LED module driven by a constant current regulation circuitry to
achieve a consistent level of light output for the useable life of the batteries. Li-ion
rechargeable : LumaPower only recommends the use of PCB protected batteries.
Combination Battery Type Pcs
1 Rechargeable 18650 (3.7V)
1
2 Rechargeable 17670 (3.7V)
1
3 Rechargeable 17650 (3.7V)
1
4 Rechargeable 16340 (3.7V)
2
5 Primary 123A (3.0V) 2
The ”Signature“ features a forward clicky switch and multi-level SideKick control circuit
with memory functions. Half-press the tail switch to power ON ”Signature“ momentary,
full press to lock it for constant ON. Cycle press the SideKick to select output mode.
Convertible Design
Reflectors/LED engine module can be easily upgrade.
SideKick output control and Memory
Press to cycle the output from High, Medium, Low and Strobe (12Hz-14Hz).
The SideKick module works on Power ON which remains the selected output with your next
start.
Battery Installation
Unscrew the tail or battery tube and insert new batteries with positive (+) ends towards
LED assembly. Restore hand tighten. Depress tail cap pushbutton switch to test.
Note: Flashlight will not light if batteries are inserted in the wrong direction.
Damage may occur with reversed battery polarity.
CAUTION: ”Signature“ flashlights are high-output lighting devices. Due to
possible eye injury, DO NOT look directly into the reflector when the light is
switched on. Do not shine the ”Signature“ into the eyes of others. Safety is your
responsibility. External surface temperature will rise during prolonged operation; this is a
normal operating phenomenon.
Battery Replacement
If there is significant decrease in brightness of light output you should replace the batteries
with freshly charged batteries. Unscrew the LED-engine and remove the old battery.
Insert a new battery as mentioned in Battery Installation Guide
WARNING: Lithium batteries can explode or cause burns if disassembled, shorted,
recharged, exposed to water, fire, or high temperatures. Do not place loose batteries i n a
pocket, purse or other container containing metal objects or store with hazardous or
combustible materials. Store in cool, dry, ventilated area. Follow applicable laws and
regulations for disposal.
Never use mixed-battery types or brands. Do not mix charged and uncharged
batteries. Input voltage limited to 8.4V,. Power ON ”Signature“ at High-out
position unattended over 15 minutes may cause overheating and damage.
Maintenance
Clean and lubricate threads with a clean cloth and apply thin coat of silicon-based lubricant
to rubber O-rings. Note: Do not use petroleum-based lubrication on O-rings. After
prolonged exposure to moisture, the bezel and batteries should be removed, inspected,
and dried if necessary
.
WARNING: Lumapower reflectors are made with a hi ghly precise process. Do not
touch or clean the reflecting surface using any cloth which may cause damage to the
surface material affecting the illuminating performance.
Inactive Periods.
If ”Signature“ is left unused for long period, the installed batteries should be removed
from the unit.
Output & Runtime
Accurately specifying light output (lumens) and runtime is complicated for LED flashlights.
Installed batteries and operating temperature are the main factors affecting the light
output and runtime. Lumapower cannot guarantee its products can reach the specification
under the using condition of users.
Specification
LED : Cree XR-E
Reflector : SMO type (optional OP-textured type)
Output : 30 Lumens to 265 Lumens
Runtime : 150 minutes High-out to 50% with 1x18650 2200mAh
75 minutes High-out to 50% with 2 x 123A (Duracell Ultra).
Input Voltage : 2.5V to 8.4V
Batteries : primary 123A, rechargeable Li-ion (16340,18650…)
Length : 152mm
Bezel Diameter : 35mm
Body Diameter : 22.5mm
Tail cap Diame ter : 24.8mm
Reflector Diameter : 30mm
Weight : 95g (Full size without battery installed)
Material : T6 aircraft aluminum with Type III HA
Body color : Black
Accessories : spare o-rings (for battery tube), rubber switch cap, holster
Specifications: All product specifications/features are subject to change without no tification.
