User ManUal
Smart
W
eather SenSor WS10
Content
Content
Change log ................................................................................................................................... - 1 -
1 Read before commissioning ................................................................................................ - 2 -
1.1 Used symbols ........................................................................................................... - 2 -
2 Safety .................................................................................................................................... - 2 -
2.1 Safety notices ........................................................................................................... - 2 -
2.2 Warning signs .......................................................................................................... - 3 -
2.3 Warning signs on the device ................................................................................... - 3 -
2.4 Intended use ............................................................................................................. - 4 -
2.5 Incorrect use ............................................................................................................ - 4 -
3 Scope of delivery .................................................................................................................. - 4 -
3.1 Further documents and software ............................................................................ - 4 -
4 Device description ................................................................................................................ - 5 -
4.1 Overview ................................................................................................................... - 5 -
4.2 Air temperature and humidity .................................................................................. - 6 -
4.3 Air Pressure .............................................................................................................. - 6 -
4.4 Precipitation ............................................................................................................. - 6 -
4.5 Wind .......................................................................................................................... - 6 -
4.6 Global Radiation ....................................................................................................... - 6 -
4.7 Position of the sun ................................................................................................... - 6 -
4.8 Brightness ................................................................................................................ - 6 -
4.9 Twilight ..................................................................................................................... - 6 -
4.10 Compass ................................................................................................................... - 6 -
4.11 GPS (Global Positioning System) ............................................................................ - 6 -
4.12 UV-Index ................................................................................................................... - 7 -
5 Measurement Output ............................................................................................................ - 8 -
5.1 Air and Dewpoint Temperature ................................................................................ - 8 -
5.2 Humidity ................................................................................................................... - 8 -
5.3 Air pressure .............................................................................................................. - 8 -
5.4 Wind Speed .............................................................................................................. - 9 -
5.5 Wind Direction .......................................................................................................... - 9 -
5.6 Compass ................................................................................................................... - 9 -
5.7 Precipitation Quantity - Absolute .......................................................................... - 10 -
5.8 Precipitation Quantity - Daily ................................ ................................................. - 10 -
5.9 Precipitation Quantity - Differential ....................................................................... - 10 -
5.10 Precipitation Intensity ............................................................................................ - 11 -
5.11 Precipitation Type .................................................................................................. - 11 -
5.12 Global radiation ...................................................................................................... - 12 -
5.13 UV-Index ................................................................................................................. - 12 -
5.14 Brightness .............................................................................................................. - 12 -
5.15 Twilight ................................................................................................................... - 12 -
5.16 Position Of The Sun ............................................................................................... - 13 -
5.17 Position ................................................................................................................... - 13 -
5.18 Service Channels ................................................................................................... - 13 -
6 Montage .............................................................................................................................. - 14 -
6.1 Installation Sketch .................................................................................................. - 15 -
6.2 Connections ........................................................................................................... - 16 -
6.3 Fastening ................................................................................................................ - 17 -
7 Commissioning .................................................................................................................. - 18 -
7.1 Configuration.......................................................................................................... - 18 -
Change log - 2 -
7.1.1 Adjustment to the local time zone ........................................................................ - 19 -
7.1.2 Adjustment of location height .............................................................................. - 19 -
7.1.3 Manual adjustment to the north ........................................................................... - 20 -
7.1.4 Wind direction at calm winds ............................................................................... - 20 -
7.1.5 Manual activation of precipitation radar .............................................................. - 21 -
7.1.6 Reset into configuration mode ............................................................................. - 21 -
7.2 Communication through WLAN ............................................................................. - 21 -
7.3 Communication with Weather Underground......................................................... - 22 -
7.4 Communication through COM1 / RS485 ............................................................... - 23 -
7.5 Communication Protocols ..................................................................................... - 23 -
7.5.1 UMB binary ............................................................................................................ - 23 -
7.5.2 UMB-ASCII 2.0 ....................................................................................................... - 23 -
7.5.3 Modbus .................................................................................................................. - 23 -
7.6 Maintanance ........................................................................................................... - 30 -
8 Declaration of Conformity .................................................................................................. - 31 -
8.1 WS100 FCC Compliance Statement (US) .............................................................. - 31 -
8.2 WS100 IC Compliance Statement (CA) .................................................................. - 31 -
9 Disposal .............................................................................................................................. - 32 -
10 Error handling and Error Codes ........................................................................................ - 32 -
10.1 Error handling ........................................................................................................ - 32 -
10.2 Status LED .............................................................................................................. - 32 -
10.3 Error codes UMB .................................................................................................... - 32 -
11 Technical Data .................................................................................................................... - 33 -
11.1 Electrical Data ........................................................................................................ - 33 -
11.2 Measurements ........................................................................................................ - 33 -
11.3 Interfaces ................................................................................................................ - 34 -
11.4 Mechanical data ..................................................................................................... - 34 -
11.5 Environmental Conditions ..................................................................................... - 34 -
12 Appendix ............................................................................................................................. - 35 -
12.1 Approved Countries for precipitation radar .......................................................... - 35 -
13 Contact ................................................................................................................................ - 36 -
Change log - 1 -
Change log
Version
Date
Change
V1.0
2018/04/03
Fist version (pre-series)
V1.1
2018/07/23
• Manual alignment description of the WS10
• Various screenshoots for device settings added
• Modbus register description added and corrected
• Added new UMB channel descriptions (for example, daily rainfall)
• Description of configuration mode revised
• Added sketch for manual wind direction
• Inserting the manual setting option of the precipitation radar
• Adjustable behavior of the wind direction in calm conditions
documented
V1.2
2018/07/25
• Final review and minor corrections (typing and presentation)
Read before commissioning - 2 -
1 Read before commissioning
This manual is part of the device It must be stored close to the device, so
people in need find it quickly.
This manual must be read and understood by the people installing and
operating the device. This is valid especially for the chapter safety.
1.1 Used symbols
Important notice for correct operation of the device
Necessary step
Safety note
2 Safety
2.1 Safety notices
Installation and commissioning may only be carried out by adequately qualified
specialists.
Never measure or touch parts that are under voltage.
Disconnect the power before working on the device.
Do not open the device. Operate it only in working and undamaged condition.
If modified or converted, operating reliability and functionality can no longer be
guaranteed.
The electrical cables must be checked regularly for damage. Operation of the device with
defective or manipulated electrical components is prohibited.
In addition to these operating instructions, the generally applicable legal rules and other
binding guidelines for occupational safety, accident prevention and environmental
protection must be observed.
The device may only be operated within its specifications.
The device may only be used under the conditions and for the purpose for which it was
designed.
Please observe the warnings attached to the device (→ windmeter)
Observe technical data, storage and operating conditions.
Safety - 3 -
2.2 Warning signs
Symbol
Meaning
Important notice of possible risks to the user
Warning of hot surfaces
Warning of dangerous electrical voltage
Fall hazard
Warning of damaging the device
2.3 Warning signs on the device
Wind measurement dome:
Warning of hot surfaces
Scope of delivery - 4 -
2.4 Intended use
• This device shall be used to measure and transmit meteorological data.
• This device shall be operated within the specified technical data
• This device shall be used only for the intended use
• The safety and functionality of the device may be compromised by changes or
modifications
2.5 Incorrect use
If incorrectly installed
• the device may be operable to a limited extent or not at all
• the device may be permanently damaged
• there can be a risk of injury by the device falling from its mounting
If the device is not properly connected
• the device may fail to operate
• the device may be permanently damaged
• under some circumstances, there is a risk of electric shock
3 Scope of delivery
Weather station WS10
Connector
3.1 Further documents and software
You will find the following documents and software available to download online at
www.lufft.de:
• Manual this document
• UMB*-Protocol 1.0 Specification and description of the UMB (Binary) protocol
• UMB-ASCII 2.0 Communication protocol for meteorological sensors
• Firmware latest firmware for this device
• UMB ConfigTool.Net UMB-Configuration-Software** for UMB-Sensors
• UMB Config Tool Manual for UMB-Configuration-Software**
* UMB = Universal-Measurement-Bus
** PC-Software for Microsoft® Windows® Operating system
Device description - 5 -
4 Device description
The WS 10 weather station is a device to measure different meteorological data to be used
mainly but not exclusive for home automation.
4.1 Overview
1
Weather station WS10
4
Connector
2
Transparent glass
5
Mounting bracket
3
Wind measurement dome
Connection
1 5-pin connector
Device description - 6 -
4.2 Air temperature and humidity
The air temperature is measured by a high accuracy NTC-Resistor. The humidity is measured
by a capacitive humidity sensor. External influence on the measurement (like sun radiation) is
eliminated by a compensation algorithm.
4.3 Air Pressure
The absolute air pressure is measured by an integrated sensor (MEMS) within the device. The
barometric altitude formula is used to calculate the relative air pressure in relation to sea level
(NN) using the GPS altitude (the altitude that can be set by the user in the device).
4.4 Precipitation
Latest radar technology is used to measure precipitation. The precipitation sensor works with
a 24GHz Doppler radar, which measures the drop speed and calculates precipitation quantity
and type by correlating drop size and speed.
4.5 Wind
The wind meter uses a heated thermal element. Depending on the wind speed and direction
the temperature of the thermal element changes. This temperature change is used to calculate
the wind speed and direction.
4.6 Global Radiation
The global radiation is measured by a pyranometer mounted in the top cover of the WS10.
4.7 Position of the sun
The position of the sun is calculated by the geographical position of the weather station plus
the current date and time.
4.8 Brightness
The illuminance is measured from the visible light.
4.9 Twilight
Twilight illuminance is measured by the illuminance sensor driven with a different attenuation.
4.10 Compass
The integrated electronic compass can be used to check the north – south adjustment of the
sensor housing for wind direction measurement. It is also used to calculate the compass
corrected wind direction.
Therefore, it is not necessary to adjust the WS10 to the north.
If there are misdirections in the compass due to surrounding magnetic fields, the electronic
compass can be switched off and manual alignment can be specified instead. See
configuration
4.11 GPS (Global Positioning System)
An integrated GPS-Modul is used to measure the geographical position of the WS10, date and
time.
Device description - 7 -
4.12 UV-Index
The UV-Index is a standard measurement value of the strength of sunburn-producing
ultraviolet (UV) radiation. The UV radiation is measured with an integrates sensor and the UVIndex is calculated.
Note: The measured UV-Index must not be used for medical applications.
UV-Index
Risk
Schutz
0-2
low
A UV Index reading of 0 to 2 means low danger from the
sun's UV rays for the average person.
Wear sunglasses on bright days. If you burn easily, cover up
and use broad spectrum SPF 30+ sunscreen. Bright surfaces,
such as sand, water and snow, will increase UV exposure.
3-5
moderate
A UV Index reading of 3 to 5 means moderate risk of harm
from unprotected sun exposure.
Stay in shade near midday when the sun is strongest. If
outdoors, wear sun protective clothing, a wide-brimmed hat,
and UV-blocking sunglasses. Generously apply broad
spectrum SPF 30+ sunscreen every 2 hours, even on cloudy
days, and after swimming or sweating. Bright surfaces, such
as sand, water and snow, will increase UV exposure.
6-7
high
A UV Index reading of 6 to 7 means high risk of harm from
unprotected sun exposure. Protection against skin and eye
damage is needed.
Reduce time in the sun between 10 a.m. and 4 p.m. If
outdoors, seek shade and wear sun protective clothing, a
wide-brimmed hat, and UV-blocking sunglasses. Generously
apply broad spectrum SPF 30+ sunscreen every 2 hours,
even on cloudy days, and after swimming or sweating. Bright
surfaces, such sand, water and snow, will increase UV
exposure.
8-10
very high
A UV Index reading of 8 to 10 means very high risk of harm
from unprotected sun exposure. Take extra precautions
because unprotected skin and eyes will be damaged and can
burn quickly.
Minimize sun exposure between 10 a.m. and 4 p.m. If
outdoors, seek shade and wear sun protective clothing, a
wide-brimmed hat, and UV-blocking sunglasses. Generously
apply broad spectrum SPF 30+ sunscreen every 2 hours,
even on cloudy days, and after swimming or sweating. Bright
surfaces, such as sand, water and snow, will increase UV
exposure.
≥11
extreme
A UV Index reading of 11 or more means extreme risk of
harm from unprotected sun exposure. Take all precautions
because unprotected skin and eyes can burn in minutes.
Try to avoid sun exposure between 10 a.m. and 4 p.m. If
outdoors, seek shade and wear sun protective clothing, a
wide-brimmed hat, and UV-blocking sunglasses. Generously
apply broad spectrum SPF 30+ sunscreen every 2 hours,
even on cloudy days, and after swimming or sweating. Bright
surfaces, such as sand, water and snow, will increase UV
exposure
Source: Wikipedia.org
Measurement Output - 8 -
5 Measurement Output
Measurements are transmitted in accordance with UMB binary protocol (Factory Settings).
It is recommended to set up and poll the station with ConfigTool.NET.
You can find an example of a measurement request in different protocols and a complete
summary of the list of channels in the Appendix.
The measurement range listed in the table is used for the UMB ASCII protocol.
5.1 Air and Dewpoint Temperature
Sampling rate 1 Minute
Units °C; °F
Request channels:
UMB Channel
Measuring range
act
Measurement variable (float32)
min
max
unit
100
Air temperature
-40
60
°C
105
Air temperature
-40
140
°F
110
Dewpoint temperature
-40
60
°C
115
Dewpoint temperature
-40
140
°F
5.2 Humidity
Sampling rate 1 Minute
Units %r.F.; g/m³
Request channels:
UMB Channel
Measuring range
act
Measurement variable (float32)
min
max
unit
200
Relative humidity
0
100 % 205
Absolute humidity
0
1000
g/m³
5.3 Air pressure
Sampling rate 1 Minute
Units hPa
Request channels:
UMB Channel
Measuring range
act
Measurement variable (float32)
min
max
unit
300
Absolute air pressure
300
1100
hPa
305
Relative air pressure
300
1100
hPa
Measurement Output - 9 -
5.4 Wind Speed
Sampling rate 1sec
Units m/s; km/h; mph; kts
Response threshold 0,1 m/s
Request channels:
UMB Channel
Measuring range
act
Measurement variable (float32)
min
max
unit
400
Wind speed
0
40
m/s
405
Wind speed
0
144
km/h
410
Wind speed
0
89,4775
mph
415
Wind speed
0
77,7538
kts
5.5 Wind Direction
Sampling rate 1sec
Units °
Response threshold 0,1 m/s
Request channels:
UMB Channel
Measuring range
act
Measurement variable (float32)
min
max
unit
500
Wind direction
0
359 ° 502
Wind direction, compass
0
359
°
Note: Ch. 500 the wind direction measured by the wind sensor adjusted by the value of the
manual adjustment to the north (see chapter Manual adjustment to the north).
Note: Ch. 502 wind direction is calculated from the wind direction measured by the wind
sensor and the heading measured by the compass.
Note: During calm wind situations the WS10 will keep the last measured wind direction. This
can be adjusted in the ConfigTool.NET (see chapter Wind direction at calm winds).
5.6 Compass
Sampling rate 1 sec (mean value over 16 measurements)
Units °
Request channels:
UMB Channel
Measuring range
act
Measurement variable (float32)
min
max
unit
510
Compass heading
0
360
°
Measurement Output - 10 -
5.7 Precipitation Quantity - Absolute
Sampling rate Event-dependent on reaching the response threshold
Units l/m²; mm; in; mil
Response threshold 0,01mm (Radar)
Request channels:
UMB Channel
Measuring range
act
Measurement variable (float32)
min
max
unit
600
Precipitation Quantity - Absolute
0
100000
l/m²
620
Precipitation Quantity - Absolute
0
100000
mm
640
Precipitation Quantity - Absolute
0
3937,008
inch
660
Precipitation Quantity - Absolute
0
3937008
mil
Note: This measurement indicates the accumulated precipitation quantity since the last device
reboot. The measurement is retained for the duration of a short power failure. To reset this
value, use the corresponding function in the UMB-Config-Tool or disconnect the device from
the power supply for at least one hour.
5.8 Precipitation Quantity - Daily
Sampling rate Event-dependent on reaching the response threshold
Units l/m²; mm; in; mil
Response threshold 0,01mm (Radar)
Request channels:
UMB Channel
Measuring range
act
Measurement variable (float32)
min
max
unit
601
Precipitation Quantity - Daily
0
100000
l/m²
621
Precipitation Quantity - Daily
0
100000
mm
641
Precipitation Quantity - Daily
0
3937,008
in
661
Precipitation Quantity - Daily
0
3937008
mil
5.9 Precipitation Quantity - Differential
Sampling rate Event-dependent on reaching the response threshold
Units l/m²; mm; in; mil
Response threshold 0,01mm (Radar)
Request channels:
UMB Channel
Measuring range
act
Measurement variable (float32)
min
max
unit
605
Precipitation Quantity - Differential
0
100
l/m²
625
Precipitation Quantity - Differential
0
100
mm
645
Precipitation Quantity - Differential
0
3,937
in
665
Precipitation Quantity - Differential
0
3937,008
mil
Note: Each request from a differential channel sets the accumulated quantity back to zero!
Measurement Output - 11 -
5.10 Precipitation Intensity
Sampling rate 1 Minute
Units l/m²/h; mm/h; in/h; mil/h; mm/min; in/min
Response threshold 0,1 mm/h
Request channels:
UMB Channel
Measuring range
act
Measurement variable (float32)
min
max
unit
800
Precipitation intensity
0
100
l/m²/h
820
Precipitation intensity
0
100
mm/h
825
Precipitation intensity
0
1,6667
mm/m
840
Precipitation intensity
0
3,937
in/h
845
Precipitation intensity
0
0,0656
in/m
860
Precipitation intensity
0
3937,008
mil/h
Note: The WS10 calculate the precipitation intensity from the accumulated precipitation
differences of the last 6 minutes before the measurement data request.
5.11 Precipitation Type
Sampling rate Event-dependent on reaching the response threshold
Response threshold 0,002mm (Radar)
Follow-up time 2 minutes
Request channels:
UMB Channel
Measurement Value (uint8)
Coding
700
Precipitation type
0 = no precipitation
60 = liquid precipitation, e.g. rain
70 = solid precipitation, e.g. snow
67: freezing rain
69: sleet
90: hail
Note: A detected precipitation type remains valid for 2 minutes after the end of the
precipitation event. In order to record precipitation types which only occur for a short period
(e.g. short-term rain), the request interval should be 1 minute or shorter.
Measurement Output - 12 -
5.12 Global radiation
Sampling rate 1 sec
Unit W/m²
Request channels:
UMB Channel
Measuring range
act
Measurement variable (float32)
min
max
unit
900
Global radiation
0
1500
W/m²
5.13 UV-Index
Sampling rate 1 sec
Unit digits
Request channels:
UMB Channel
Measuring range
act
Measurement variable (uint8)
min
max
unit
902
UV-Index
0
20
digits
5.14 Brightness
Sampling rate 5 sec
Unit klx
Request channels:
UMB Channel
Measuring range
act
Measurement variable (float32)
min
max
unit
903
Brightness
0
160
klx
5.15 Twilight
Sampling rate 5 sec
Unit lx
Request channels:
UMB Channel
Measuring range
act
Measurement variable (float32)
min
max
unit
904
Twilight
0
500
lx
Measurement Output - 13 -
5.16 Position Of The Sun
Sampling rate 10 sec
Unit °
Request channels:
UMB Channel
Measuring range
act
Measurement variable (float32)
min
max
unit
910
Position of the sun - azimuth
0
360
°
911
Position of the sun - elevation
0
90
°
5.17 Position
Sampling rate 10 sec
Request channels:
UMB Channel
Measuring range
act
Measurement variable (float32)
min
max
unit
3900
Position longitude
-180
180
°
3901
Position latitude
-90
90
°
3902
Position height
-1000
10000
m
3903
UTC timestamp (uint32)
0
4294967295
s
4071
GPS number of satellites (uint8)
0
255
digits
4072
GPS Position locked (uint8)
0
255
digits
5.18 Service Channels
Request channels:
UMB Channel
Measuring range
act
Measurement variable (float32)
min
max
unit
4060
Wi-Fi status (uint16)
0
65535
digits
4061
Wi-Fi signal strength (sint16)
-32767
32767
digits
4700
Device runtime (uint32)
0
4294967295
s
4701
Attended time (uint32)
0
4294967295
s
4702
Number boot cycles (uint32)
0
4294967295
digits
4703
UTC timestamp (uint32)
0
4294967295
s
4704
Local timestamp (uint32)
0
4294967295
s
10000
Supply voltage (float32)
0
50
V
Montage - 14 -
6 Montage
Caution
Fall hazard while working in heights
For installation, only approved and tested aids (ladder, steps, etc.) may
be used.
All applicable regulations for work in heights must be observed.
Caution
Hazard of falling objects.
Make sure the device is mounted correctly and save.
During installation make sure no objects can fall down.
Important notices for installing
Installation and commissioning may only be carried out by adequately qualified
specialists .
Never measure or touch parts that are under voltage.
Observe technical data, storage and operating conditions.
The intended location is outdoors. The device must not be operated in closed rooms.
The building-side holding device must be sufficiently dimensioned and firmly anchored.
The device must be secured in such a way that there are no objects, trees or other
objects in the immediate vicinity that could affect the acquisition of the measured data.
The direct measuring range in front of the device must be kept clear of all obstacles in
any case.
All work must be carried out when the device is de-energized. Only connect the power
supply to the mains once all assembly work has been completed correctly.
The cables to and from the device must be fastened in such a way that no tension is
exerted on the plug connection during operation.
Lay the cables so that they can not be damaged.
Lay the cables so that nobody can trip over them.
To ensure a reliable rain radar measurement, the WS10 must be at least 8 m apart.
The following tools are required for installation:
• fork or ring spanner SW10
Montage - 15 -
6.1 Installation Sketch
1
Tube (Ø 35 mm)
a
Proposed height 2000 mm
2
WS10
b
Proposed distance 500 mm
c Free surrounding >1000 mm
To achieve a correct measurement of global radiation, make sure the WS 10 is in all
directions horizontally aligned.
Montage - 16 -
To ensure the correct functionality of the WS10 the notes below concerning the place
of installation must be followed:
• Free sight to the sky – for the correct function of the GPS module and the
precipitation measurement the WS10 must have a free sight to the sky.
• To ensure correct measurements of any kind of sun imposed radiation make sure
that there is never shade on the WS10.
• To ensure correct wind measurements there should be no bigger obstacle (tree,
building, etc.) within 5m around the WS10.
Not following the above mentioned notes may lead to wrong measurements.
6.2 Connections
The WS 10 is to be supplied with a direct voltage of typ. 24 VDC (9-36VDC). The power
supply unit used must be approved for the operation of devices with protection class III
(SELV).
The power supply must serve at least 35W @ 24V. The power connection must be fused by a
2.5A (slow-blow) fuse.
The connecting cable must be resistant to UV radiation. The cable must have an external
diameter of 4-6mm and a wire gauge of at least 0,3mm².
Pin assignment
PIN
Usage
Cable color
1
+Vin
2
GND
3
RS 485 A (+)
4
RS 485 B (-)
5
Configuration
(pos)
Only used for Wi-Fi AP mode
The device has a half-duplex, 2-wire RS485 interface for configuration, measured value query
and firmware update.
Positive voltage (+Vin 9..36V) at the configuration pin forces the WS10 into Wi-fi access point
mode. This is independent of any other setting within the WS10 configuration.
Montage - 17 -
6.3 Fastening
1
Connector
5
Tube
2
Connection
6
Screw
3
WS10
7
Mounting bracket
4
Cable
The WS10 is mounted on a tube in horizontal position. Make sure the tube is mounted safely
at a fixed mounting point (e.g. mast, building, etc.)
Put the connector (1) of the connecting cable into the connector (2) of the WS10 (3).
Pull the connecting cable (4) through the tube (5).
Loosen the screw (6) at the bracket (7).
Push the tube (5).into the WS10 bracket until the very end.
Make sure you do not damage the connecting cable.
Tighten the screw (6) at the bracket (7).
Commissioning - 18 -
7 Commissioning
Caution
Warning of hot surfaces.
Do not touch the wind measurement dome.
7.1 Configuration
After connecting the supply voltage the WS10 will start automatically.
If there is no WiFi configured, the WS10 starts in WiFi access point mode. By using the UMB-
ConfigTool.NET you can now configure the WS10.
Be aware, that the configuration mode is limited to 30 min.
Configuration mode will be indicated by LED blinking green
To ensure a stable WiFi connection you should be within 10m around the WS10 with
your device running the UMB-ConfigTool.NET.
To configure the WS10 you need a WiFi capable device running Windows
®
-PC Software
or Android® operating system and theLufft ConfigTool.NET. The Lufft ConfigTool.NET
can be downloaded on the Lufft internet web site or
installed directly from the Android® Playstore.
Connect your device with the WS10 WiFi access point
SSID: WS10_Wifi-<serial number>
Password: <serial number> (to be found on the label)
Note: During the connection to the WS10 there is no
connection to the Internet possible.
Start the Lufft UMB-ConfigTool.NET
Please check the Windows
®
firewall configuration to allow connections to a public
network.
In the Lufft UMB-ConfigTool.NET please select “Add device” > “WSX-UMB”
Configure the WiFi login credentials of the WLAN which the WS10 should use.
Through the Button you get to the configuration menu.
Insert your WiFi SSID and WiFi key.
With “Save” the configuration will be written to the WS10 and the WS10 will automatically
restart with the new parameters.
Connect your device to the local WiFi you configured the WS10 for.
Commissioning - 19 -
Now you should be able to connect to the WS10 through your local WiFi and continue the
configuration of the WS10 if needed.
If you do not need the Wifi connection, please disable the WiFi in the configuration
menu of the ConfigTool.NET. Under WiFi – WiFi you can disable the WiFi.
Due to the integrated electrical compass a manually north alignment is not necessary
and therefore must not be configured.
The complete functionality of the ConfigTool .NET is described in a seperate documentation to
be found on the Lufft internet web site.
7.1.1 Adjustment to the local time zone
The system time (UTC) of the WS10 is adjusted automatically by the GPS-Modul. To adjust
the WS10 to the local time zone where the WS10 is installed, you need to enter the respective
offset value.
Please be aware – the offset value may change with the change of summer- and
wintertime (daylight saving time).
E.g. For central Europe the time zone is UTC +1h (wintertime) and UTC +2h
(summertime). The respective offset would be 3600s or 7200s.
Through the Button in the ConfigTool.NET you get to the configuration menu. Under GPS
– UTC local time offset you may adjust your desired time offset in seconds.
7.1.2 Adjustment of location height
Through the Button in the ConfigTool.NET you get to the configuration menu.
Under GPS – Location height you can select between Manual and Auto configuration. Using
Auto (GPS) mode, WS10 will retrieve the altitude from its internal GPS sensor. In Manuel
mode you can specify your location height manually.
Commissioning - 20 -
7.1.3 Manual adjustment to the north
In rare occasions there is a need to manually adjust the WS10 to the north. This could be the
case if the WS10 is mounted close to a strong magnetic field or large steel constructions.
To manually adjust the WS10 to the north, you must enter the difference in degree between
the WS10 connector and the magnetic north.
Through the Button in the ConfigTool.NET you get to the configuration menu.
Under Wind – Manual angle alignment in degrees you can enter the direction of the WS10.
7.1.4 Wind direction at calm winds
The WS10 offers two ways to report wind direction at calm winds.
1. Freeze – means the WS10 reports the last measured wind direction
2. North – means the WS10 reports 0° as wind direction
Through the Button in the ConfigTool.NET you get to the configuration menu.
Under Wind – Wind direction at inactivity you can make your choice what should be reports
at calm winds.
Commissioning - 21 -
7.1.5 Manual activation of precipitation radar
Because of country individual regulation the precipitation radar is switched of automatically by
a geofencing algorithm in countries where there is no approval.
If you want to manually switch on the precipitation radar, you can use the ConfigTool.NET to
do so.
Through the Button in the ConfigTool.NET you get to the configuration menu.
Under Radar rain sensor – Radio regulations you need to select Manual
and under Manual setting you need to choose the country standard you want to comply to.
Caution
The operation of precipitation radar outside the approved countries is not permitted
by law. The operator acts at his own risk and is responsible for a possible criminal
liability itself. Lufft rejects any liability for the operation of precipitation radar outside
the countries approved by Lufft.
7.1.6 Reset into configuration mode
If the WS10 is due to miss configuration not accessible anymore through the WLAN, you can
reset the WS10 to the configuration mode in two ways.
1. Position a magnet close to the housing where you can read ‘Reed’ on the housing.
2. Connect B+ to Pin 5 of the WS10 connector
Switching to the configuration mode is indicated by a short blue flashing of the status LED.
As long as the WS10 is in configuration mode, this is indicated by a green flashing every 10s
of the status LED.
Please note that configuration mode is only active for 30min.
7.2 Communication through WLAN
The WLAN module is automatically activated and is sending measurement data.
Commissioning - 22 -
7.3 Communication with Weather Underground
In ordert o see the WS10 measurement values online in the public internet a Weather
Underground connection is necessary.
Call the Weather Underground site https://www.wunderground.com
Choose “More” and “Add Weather Station”
“Step 1: Register Your Station choose ”Join”
Enter your email-Address and choose a password
Read the ‚Terms of Service‘ and agree to them by checking the respective box
Click the button ‘Sign up for free’ to finalize the registration
After a successful registration you can register your weather station in some additional simple
steps
Step 1:
Push the red point to the geographical location of your WS10 weather station
If the WS10 weather station is close to a house with a postal address, you can also find
your location by adding this address
The coordinates and the height above sea level is automatically generated by the map
Step 2:
On the next page, please add additional information. The only thing necessary is an entry
in ‚neighborhood‘
‚Station hardware‘ has to be set to ‚other‘
After a successful registration of your WS10 weather station, Weather Underground will send
you a Station ID and a Station Password.
For your convenience and later use, you can note it here:
Station ID
Station Password
Station ID and Station Password will be needed for the WS10 configuration.
Commissioning - 23 -
7.4 Communication through COM1 / RS485
For the communication to the weather station WS10 you’ll need the UMB-ConfigTool.Net
software tool from Lufft.
The functionality and configuration of the UMB-ConfigTool.Net software tool is described in the
online help of the tool. The online help can be used without internet connection.
With the UMB-ConfigTool.NET software tool you can completely configure the WS10.
7.5 Communication Protocols
The command “PRT=<value>” reads/sets the used communication protocol based on the
values shown in the table below:
<value>
protocol
0*)
UMB-binary
5
MODBUS-RTU
6
MODBUS-ASCII
9
UMB-ASCII 2.0
*) factory setting
The change to another communication protocol will need a restart of the WS10 to take
effect.
7.5.1 UMB binary
UMB binary is the standard protocol used for configuration of the WS10 with the
ConfigTool.NET.
You’ll find to documentation for download on the Lufft internet web site www.Lufft.com.
7.5.2 UMB-ASCII 2.0
The messages of the UMB-ASCII 2.0 protocol is highly customizable. Therefore you can
change your messages to fit most of the data logger hardware.
auto sending
Send a message automatically in the configured interval
interval
Time in seconds between the automated sending of messages
start character
ASCII-char used as start sequence for a message
Factory setting: 2 / 02h (STX)
end character
ASCII-char used as end sequence for a message
Factory setting: 4 / 04h (EOT)
decimal separator
Char used as decimal separator
Factory setting: Point 46 / 2 Eh (“.”)
parameter separator
Char used as parameter separator
Factory setting: Semicolon 58 / 3 Bh (“;”)
block separator
Char used as block separator
Factory setting: Colon 58 / 3Ah (“:”)
line end
Char used for line end
Factory setting: CRLF (0Dh, 0Ah)
alternative CR (0Dh) or LF (0Ah)
7.5.3 Modbus
For a simpler integration of WS family Smart Weather Sensors into a PLC environment the
Modbus communication protocol has been made available.
Commissioning - 24 -
Measurement values are mapped to Modbus Input Registers. The range of values available is
basically the same as for the UMB protocol, including different unit systems.
In the interest of simple and safe integration the use of register pairs for floating point values
or 32 bit integers, which is not part of the Modbus standard, has not been applied. All
measurement values are mapped to 16bit integers using suitable scaling factors.
Modbus communication parameter
The Smart Weather Sensor can be configured for MODBUS-RTU or for MODBUS-ASCII.
The base configuration must be done using the UMB Config Tool.
When selecting MODBUS RTU or MODBUS-ASCII with the UMB Config Tool, communication
parameters 19200 Bd, even parity, will be preselected.
Modbus operating modes: MODBUS-RTU, MODBUS-ASCII
Baud rate: 19200 (9600, 4800 or lower)
Interface Setting 8E1, 8N1, 8N2
The Modbus communication has been tested for a poll rate of 1 sec. The proper function
of the Smart Weather Sensor with higher Modbus poll rates has not been tested.
We suggest to set the poll rate to 10 sec or slower, as, with the exception of the channels
„wind speed / wind directions fast“, which are provided for special purposes, the update rate of
the data is >= 10sec. However, for most of the weather data, significant changes should be
expected in the range of minutes.
Addressing
The Modbus address is deducted from the UMB device ID.
A device with UMB device ID 1 also has the UMB address 1, etc..
The valid address range of Modbus from 1 to 247 is smaller than that of the UMB device IDs.
If a UMB device ID > 247 has been selected, the Modbus address will be set to 247.
Modbus functions
The functions of conformance class 0 and 1 have been implemented as far as they are
applicable for the Smart Weather Sensor, i.e. all functions operating on register level.
Conformance Class 0
0x03
Read Holding Registers
Selected configuration settings
0x16
Write Multiple Registers
Selected configuration settings
Conformance Class 1
0x04
Read Input Registers
Measurement values and status information
0x06
Write Single Register
Selected configuration settings
0x07
Read Exception Status
Currently not used
Diagnostics
0x11
Report Slave ID
(responds also to broadcast address)
Commissioning - 25 -
Function 0x03 Read Holding Register
The Holding Registers are used to make a selected set of adjustable parameters available for
Modbus access. As for the measurement values the parameters are mapped to 16bit integers.
Reg.
No.
Reg.
Addr
Function
Values
Scale
1 0 Local Altitude
Altitude in m, for calculation of relative air
pressure
Value range -100 … 5000
1.0
2 1 Deviation
Local deviation for the correction of compass
heading.
Value range -3599 … 3599
(equalling -359.9° … +359.9°)
10.0
8 7 Reset rainfall
Function only when writing to the register,
reading will give 0 always
-
9 8 Device reset
Function only when writing to the register,
reading will give 0 always
-
Function 0x06 Write Holding Register, 0x10 Write Multiple Registers
By writing into the holding registers selected parameters of the Smart Weather Sensor can be
adjusted through Modbus.
Register assignment see 7.5.3.4
Local altitude, compass deviation and averaging intervals are set by writing the new values
into the related registers. Depending on the selected register the value must be scaled by the
factor given in the table:
Example: for compass deviation, the table shows a scaling factor of 10.0. If the deviation is
4.8° a value of 48 shall be written into register 2 (reg.addr. 1).
The transmitted values will be checked for plausibility. Illegal values will not be accepted and
cause a Modbus exception.
When writing the value 0x3247 (12871d) to register no. 8 (reg. addr. 7) the stored absolute
rain amount will be set to 0. Subsequently a device reset will be initiated.
When writing the value 0x3247 (12871d) to register no. 9 (reg. addr. 8) a device reset will be
initiated.
Function 0x04 Read Input Registers
The input registers are containing the measurement values of the Smart Weather Sensor and
the related status information.
The measurement values are mapped to the 16bit registers using scaling factors (0 … max.
65530 for unsigned values, -32762 … 32762 for signed values).
Values 65535 (0xffff) resp. 32767 are used for the indication of erroneous or not available
measurement values. A more detailed specification of the error can be evaluated from the
status registers.
The assignment of values to the available register addresses (0 … 124) has been arranged in
a way so that the user can read the most frequently used data with few (ideally only one)
register block requests
Following blocks have been defined:
• Status information
• Frequently used values which are independent of the unit system (met./ imp.) in use
• Frequently used values in metric units
• Frequently used values in imperial units
• Other measurement values
Commissioning - 26 -
When using the metric unit system, the first three blocks can the supply all data usually
required with one request.
There is no difference in the register assignment between the sub types of the WS family. If,
dependent on the type, some value is not available, this will be indicated by setting the register
to the error value.
For detailed information about measurement ranges, units etc. please refer to the related
description of the UMB.
Modbus register
7.5.3.7.1 Measurement values - Status
Reg.
Nr.
Reg.
Adr.
Value (UMB Channel)
Range
Scaling
signed/unsigned, Remarks
1 0 Identification
1 unsigned
2 1 Device status (low)
0..65535
1
unsigned
3 2 Device status (high)
0..65535
1
unsigned
4
3
Sensor status
Temperature
0..255
1
5 4 Sensor status Humidity
0..255
1
unsigned
6
5
Sensor status Air
pressure
0..255
1
unsigned
7 6 Sensor status Wind
0..255
1
unsigned
8
7
Sensor status
Precipitation
0..255
1
unsigned
9
8
Sensor status Global
radiation
0..255
1
unsigned
10 9 Sensor status UV-Index
0..255
1
unsigned
11
10
Sensor status
Brightness
0..255
1
unsigned
15
14
Status Wifi
0..255
1
unsigned
16
15
GPS Position erfasst
0..255
1
unsigned
17
16
UTC Time (low)
0..65535
1
[s], unsigned
18
17
UTC Time (high)
0..65535
1
[s*65535], unsigned
19
18
Run time
0..65535
10
[s], unsigned
Commissioning - 27 -
7.5.3.7.2 Measurement values - Metric
Reg.
Nr.
Reg.
Adr.
Value (UMB Channel)
Range
Scaling
signed/unsigned, Remarks
20
19
Air Temperature
-40..60 °C
10
signed
24
23
Dewpoint Temperature
-40..60 °C
10
signed
30
29
Relative Humidity
0..100 %
10
unsigned
32
31
Absolute Humidity
0..100 g/m³
10
unsigned
38
37
Absolute Air Pressure
300..1100 hPa
10
unsigned
40
39
Relative Air Pressure
300..1100 hPa
10
unsigned
46
45
Wind Speed
0..40 m/s
10
unsigned
50
49
Wind Speed
0..144 km/h
10
unsigned
54
53
Wind Direction
0..360°
10
unsigned
55
54
Wind Direction
(compass correction)
0..360°
10
unsigned
56
55
Compass Direction
0..360°
10
unsigned
60
59
Precipitation
0..655,3 mm
100
unsigned
61
60
Precipitation diff.
0..100 mm
100
unsigned
62
61
Precipitation Type
0..255
1
unsigned
63
62
Precipitation Intensity
0..100 mm/h
100
unsigned
64
63
Precipitation Intensity
0..1,6667
mm/min
10000
unsigned
69
68
Global Radiation
0..1500 W/m²
10
unsigned
Commissioning - 28 -
Reg.
Nr.
Reg.
Adr.
Value (UMB Channel)
Range
Scaling
signed/unsigned, Remarks
71
70
Position of the sun
Azimuth
0..360 °
10
Unsigned
72
71
Position of the sun
Elevation
0..90 °
10
Unsigned
75
74
UV-Index
0..20
1
unsigned
76
75
Brightness
0..160 klx
10
unsigned
77
76
Twilight
0..500 lx
10
unsigned
7.5.3.7.3 Measurement values - Imperial
Reg.
Nr.
Reg.
Adr.
Value (UMB Channel)
Range
Scaling
signed/unsigned, Remarks
80
79
Air Temperature
-40..140 °F
10
signed
84
83
Dewpoint Temperature
-40..140 °F
10
signed
90
28
Relative Humidity
0..100 %
10
unsigned
92
91
Absolute Humidity
0..100 g/m³
10
unsigned
98
97
Absolute Air Pressure
300..1100 hPa
10
unsigned
100
99
Relative Air Pressure
300..1100 hPa
10
unsigned
106
105
Wind Speed
0..89,4775 mph
10
unsigned
110
109
Wind Speed
0..77,7538 kts
10
unsigned
114
113
Wind Direction
0..360°
10
unsigned
115
114
Wind Direction
(compass correction)
0..360°
10
unsigned
116
115
Compass Direction
0..360°
10
unsigned
Commissioning - 29 -
Reg.
Nr.
Reg.
Adr.
Value (UMB Channel)
Range
Scaling
signed/unsigned, Remarks
120
119
Precipitation
0..65,53 in
1000
unsigned
121
120
Precipitation diff.
0..3,973 in
10000
unsigned
123
122
Precipitation Intensity
0..3,973 in/h
10000
unsigned
124
123
Precipitation Intensity
0..0,06561
in/min
100000
unsigned
129
128
Global Radiation
0..1500 W/m²
10
unsigned
131
130
Position of the sun
Azimuth
0..360 °
10
Unsigned
132
131
Position of the sun
Elevation
0..90 °
10
Unsigned
135
134
UV-Index
0..20
1
unsigned
136
135
Brightness
0..160 klx
10
unsigned
137
136
Twilight
0..500 lx
10
unsigned
7.5.3.7.4 Measurement values - Service
Reg.
Nr.
Reg.
Adr.
Value (UMB Channel)
Range
Scaling
signed/unsigned, Remarks
140
139
Supply Voltage
0..50 V
10
unsigned
141
140
Run Time (overall)
0..3931800 s
1/60
unsigned
143
142
Position Longitude
-180..180 °
100
signed
144
143
Position Latitude
-90..90 °
10
signed
145
144
Position Height Above
Sea Level
-1000..10000 m
1
signed
148
147
GPS satellites received
0..255
1
unsigned
149
148
GPS Position locked
0..255
1
unsigned
Commissioning - 30 -
7.6 Maintanance
There is no need to regularly service the WS10.
However, if there is an accumulation of dirt on the WS10 surface, especially on the glass you
should clean the surface.
To clean the glass you must only use water and dishwashing detergent. Don’t use
any other detergent containing alcohol or any other acid.
Declaration of Conformity - 31 -
8 Declaration of Conformity
8.1 WS100 FCC Compliance Statement (US)
Product: Smart Weather Sensor
Type: WS10 (Order No.: 8368.WS10P)
This device contains FCCID: UF9WS010.
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
Changes and modifications not expressly approved by manufacturer could void the user’s
authority to operate the equipment.
8.2 WS100 IC Compliance Statement (CA)
Product: Smart Weather Sensor
Type: WS10 (Order No.: 8368.WS10P)
This equipment contains equipment certified under ICID: 6650A-WS010.
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions:
(1) This device may not cause interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicable aux appareils radio
exempts de licence.
L’exploration est autorisée aux deux conditions suivantes:
(1) l’appareil ne doit pas produire de brouillage, et
(2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le
bouillage est susceptible d’en compromettre le fonctionnement.
Disposal - 32 -
9 Disposal
The disposal of this device has to be according to the European Union directive 2012/19/EU.
The disposal through household waste is applicable. The device should be recycled according
to the electronic waste guidelines of the respective country.
10 Error handling and Error Codes
10.1 Error handling
Error
Action
Device does not start up
Check if you connected the device according to the
specification.
Check pinout and polarity of your supply voltage.
10.2 Status LED
LED
Meaning
Red – Green – Blue - White
Normal start up
Red slowly blinking
Hardware defect
→ Send the device to the manufacturer
White slowly blinking
Configuration error
→ Check the device configuration
Green short blink every 10 sec
WS10 in Wi-Fi access mode
Blue - Green short blink every 10 sec
WS10 in Wi-Fi access mode forced through configuration pin
10.3 Error codes UMB
Status
Definition
Description
00h
OK
No Error
20h
LESE_ERR
Reading Error
23h
UNGLTG_ADRESS
Invalid Address
…
…
…
A detailed UMB documentation can be found on the internet under www.Lufft.com
Technical Data - 33 -
11 Technical Data
11.1 Electrical Data
Supply Voltage
9…36 V DC
Current Consumption
850 mA bei 9 V / 230 mA bei 24 V
Fuse supply Voltage
2,5 A (slow blow)
Protection Class
IP 67
11.2 Measurements
Air Temperature
Range
- 40 … 60 °C
Accuracy
±1,0 °C (+5 … +60 °C),
otherwise < ±2,0 °C
Relative Humidity
Range
0 … 100 %
Accuracy
±5% (@ 20°C and < 80% rH)
Air Pressure
Range
300 … 1100 hPa
Accuracy
±0,5 hPa (at room temperature 25 °C)
Wind Speed
Range
0 … 40 m/s
Accuracy
±1 m/s or 5 %, the larger value is valid
Wind Direction
Range
0 … 359°
Accuracy
± 10°
Precipitation
Range
0 … 100 mm/h
Accuracy
20 % under laboratory environment
Precipitation Type
Range
Rain, Snow, Sleet, Freezing Rain, Hail
Global Radiation
Range
0 … 1500 W/m2
Accuracy
10% or ±120 W/m², larger value is valid
UV-Index
Range
1 … 15
Brightness
Range
0 … 167 klx
Accuracy
±5 % of measured value
Twilight
Range
0 … 500 lx
Accuracy
±10 lx
Technical Data - 34 -
11.3 Interfaces
Wired
RS485 2-wire, 5 V
Baud rate
9600…115200 Baud (Standard 19200 Baud)
WLAN
802.11:b/g/n
WLAN Security
WPA2/WPA Personal, WPA2 WPA Enterprise und WEP
11.4 Mechanical data
Dimensions (L x B x H)
227 mm x 145 mm x 130 mm
Weight
0,5 kg
Tube size (D)
35 mm
11.5 Environmental Conditions
Operating Conditions
-40 °C…+60 °C
Storage Conditions
-60 °C…+85 °C
Humidity
0…100 % rH (non condensing)
Appendix - 35 -
12 Appendix
12.1 Approved Countries for precipitation radar
EU all members of the European Union
Swiss
Island
Norway
USA
Canada
Contact - 36 -
13 Contact
For warranty and repair, please contact:
G. Lufft Mess- und Regeltechnik GmbH
Gutenbergstraße 20
D-70736 Fellbach
Tel: +49(0)711-51822-0
Fax: +49(0)711-51822-41
Mail: info@lufft.de
www.lufft.de
Subject to Technical Modifications
G. LUFFT Mess- und
Regeltechnik GmbH
Lufft Germany:
Fellbach Headquarter:
Gutenbergstr. 20
70736 Fellbach
GERMANY
Phone: +49 711/51822-0
Fax: +49 711/51822-41
info@lufft.com
www.lufft.com
Berlin:
G. Lufft GmbH
Carl-Scheele-Straße 16
12489 Berlin
GERMANY
Phone: +49 711 51822-831
Fax: +49 711 51822-944
info@lufft.com
www.lufft.com
Lufft Noth America:
Lufft USA, Inc.
1110 Eugenia Pl Unit B
Carpinteria, CA 93013
USA
Phone: +1 888 519 8443
Fax: +1 805-220-6409
sales@lufftusainc.com
www.lufft.com
Lufft China:
Lufft Shanghai Measurement and
Control Technology Co., Ltd.
2F, Building No.1
518 North FuQuan Road
Shanghai 200335
CHINA
Phone: +86 21 2350 5000 ext. 3057
china@lufft.com
www.lufft.com
Loading...
