LUDLUM MODEL 3005
DIGITAL SURVEY METER WITH INTERNAL DETECTOR
USER’S MANUAL
July 2017
Serial Number: 25009185 and Succeeding
Firmware: 49830n26 and Higher
LUDLUM MODEL 3005
DIGITAL SURVEY METER WITH INTERNAL DETECTOR
USER’S MANUAL
July 2017
Serial Number: 25009185 and Succeeding
Firmware: 49830n26 and Higher
Model 3005 Gamma Survey Meter User’s Manual
Model 3005 Gamma Survey Meter User’s Manual
STATEMENT OF WARRANTY
Ludlum Measurements, Inc. warrants the products covered in this manual to be free of
defects due to workmanship, material, and design for a period of twelve months from
the date of delivery. The calibration of a product is warranted to be within its
specified accuracy limits at the time of shipment. In the event of instrument failure,
notify Ludlum Measurements to determine if repair, recalibration, or replacement is
required.
This warranty excludes the replacement of photomultiplier tubes, GM and
proportional tubes, and scintillation crystals which are broken due to excessive
physical abuse or used for purposes other than intended.
There are no warranties, express or implied, including without limitation any implied
warranty of merchantability or fitness, which extend beyond the description of the
face there of. If the product does not perform as warranted herein, purchaser’s sole
remedy shall be repair or replacement, at the option of Ludlum Measurements. In no
event will Ludlum Measurements be liable for damages, lost revenue, lost wages, or
any other incidental or consequential damages, arising from the purchase, use, or
inability to use product.
RETURN OF GOODS TO MANUFACTURER
If equipment needs to be returned to Ludlum Measurements, Inc. for repair or calibration, please
send to the address below. All shipments should include documentation containing return shipping
address, customer name, telephone number, description of service requested, and all other necessary
information. Your cooperation will expedite the return of your equipment.
LUDLUM MEASUREMENTS, INC.
ATTN: REPAIR DEPARTMENT
501 OAK STREET
SWEETWATER, TX 79556
800-622-0828 325-235-5494
FAX 325-235-4672
Model 3005 Gamma Survey Meter User’s Manual
Table of Contents
Introduction 1
Getting Started 2
Unpacking and Repacking 2-1
Battery Installation 2-1
Instrument Operational Test 2-2
Detector Failure Diagnostic 2-5
Detector Over Range 2-5
Detector Overload 2-6
Instrument Use and Controls 2-6
RATE Mode Operation 2-8
MAX Mode Operation 2-9
COUNT Mode Operation 2-10
Specifications 3
Setup Mode 4
Setup Overview 4-1
Default Setup Values 4-2
Entering Setup Mode 4-3
Setup Mode Operation 4-5
Advanced Features 5
Dead Time Correction 5-1
Units 5-2
Software Calibration Tools 5-2
Instrument Calibration 5-3
Other Device Data 5-3
Real-Time Settings 5-3
Model 3005 Gamma Survey Meter User’s Manual
Datalogging 6
Datalogging Operation – Mode 1 6-2
Datalogging Operation – Mode 2 6-3
Datalogging Operation – Mode 3 6-4
Specifications 6-4
Software
Connecting to Software 7-1
Extended Features 7-2
Safety Considerations 8
Environmental Conditions for Normal Use 8-1
Warning Markings and Symbols 8-1
Cleaning and Maintenance Precautions 8-2
7
Revision History 9
Recycling 10
Options 11
Energy Response A
Model 3005 Gamma Survey Meter User’s Manual Section 1
Section
1
Introduction
The Model 3005 is an ergonomic, lightweight instrument with an
internal detector used for radiation survey. The instrument features a
large backlit LCD (liquid crystal display), a piercing audio warning, and
easy, intuitive use. The unit body is made of lightweight but durable
plastic. It is intended for outdoor use and can resist splashing water.
Versions: While the standard Model 3005 has an internal EnergyCompensated Geiger-Muller (ECGM) detector, other detectors are
possible:
3005: ECGM with range 0.1-5000 mR/hr or 0.001-50 mSv/h
3005/3: ECGM with range 0.1-25000 mR/hr or 0.001-250 mSv/h
3005/4: ECGM with range 1-50000 mR/hr or 0.001-500 mSv/h
Three modes of operation are available for the Model 3005 – RATE,
MAX, and COUNT. RATE mode operation will display the current
exposure, or dose rate. MAX mode is used to capture the highest
exposure or dose rate detected – useful for finding a peak rate when the
display is not visible. Two sets of units (primary and secondary) for
RATE and MAX modes can be chosen from among cps, cpm, Bq,
dpm, R/h, or Sv/h. The user can switch between these two units by
simply tapping the Units button. If not needed, the 2nd set of units can
be disabled. Also, the additional MAX and COUNT modes may also be
disabled, reducing the possible number of displays the user may
confront.
COUNT mode allows the user to perform a count for a predetermined
time. Depending on the count units chosen, the result can be a scaler
count (in counts or disintegrations), a time-averaged rate (cpm, dpm,
Bq, cps), a time-averaged exposure or dose (R/h, Sv/h), or an
integrated exposure or dose (R or Sv).
The display will be automatically backlit if light levels are low. The
display backlight can also be configured for “Continuous On”
Ludlum Measurements, Inc. Page 1-1 July 2017
operation. Radiation level alarm points can also be configured.
Model 3005 Gamma Survey Meter User’s Manual Section 1
Setup of the instrument is accomplished through the front-panel
buttons, or through the USB port with software available from Ludlum
Measurements. The advanced user or administrator can set:
Calibration Constant
Dead Time Correction 1
Dead Time Correction 2
Efficiency
High Voltage
Pulse Threshold
Detector Current Overload Threshold
Loss of Count Alarm Time
Primary and Secondary Units
Primary and Secondary Minimum and Maximum Displays
Primary and Secondary Unit Alarm Levels
Primary and Secondary Count Units
Primary and Secondary Count Units Minimum Displays
Primary and Secondary Count Alarm Levels
Response Time
Auto-Response Rate (Fast or Slow)
Available Operational Modes
Count Time
Auto Shutdown Time
Backlight Threshold
Sigma or Click Audio Mode
The Model 3005 comes with the ability to log measurements to memory
for later download. The optional Ludlum Lumic Datalog software is
needed to download this memory, however. The unit can log up to
1000 measurements, and it adds a date/time stamp to each
measurement.
Ludlum Measurements, Inc. Page 1-2 July 2017
Model 3005 Gamma Survey Meter User’s Manual Section 1
Front-panel setup can be disabled via the internal switch on the Model
3005 in order to protect settings from inadvertent changes.
The unit is operated with four alkaline AA batteries for operation from
-20 to 50 °C (-5 to 122 °F). Battery life is approximately 750 hours
under normal usage. A low-battery indicator on the LCD warns when
less than 16 hours of battery life remain.
Ludlum Measurements, Inc. Page 1-3 July 2017
Model 3005 Gamma Survey Meter User’s Manual Section 2
1. Turn the instrument over so that the bottom of
the instrument is facing up.
2. Use a straight medium-sized screwdriver to turn
the single screw on the battery cover one
quarter-turn counter-clockwise.
3. Release and remove the battery cover.
4. Replace four each AA batteries.
5. Replace the cover and turn screw one quarter-
turn clockwise to secure.
Section
2
Getting Started
Unpacking and Repacking
Remove the calibration certificate and place it in a secure location. Remove
the instrument and ensure that all of the items listed on the packing list are
in the carton. Check individual item serial numbers and ensure calibration
certificates match between instruments and detectors (if applicable). The
Model 3005 serial number is located on a label on the front side of the unit.
To return an instrument for repair or calibration, provide sufficient packing
material to prevent damage during shipment.
Every returned instrument must be accompanied by an Instrument
Return Form, which can be downloaded from the Ludlum website at
www.ludlums.com. Find the form by clicking the “Support” tab and
selecting “Repair and Calibration” from the drop-down menu. Then choose
the appropriate Repair and Calibration division where you will find a link to
the form.
Battery Installation
A low-battery indicator appears at the bottom of the LCD when less than
16 hours of battery life remain. When this indicator is present, follow these
steps to replace the four standard AA batteries:
Ludlum Measurements, Inc. Page 2-1 July 2017
Model 3005 Gamma Survey Meter User’s Manual Section 2
Instrument Operational Test
Turn the instrument ON by pressing the ON/ACK button for about a
second, and then releasing.
The instrument should activate all the LCD segments and the audio.
Observe the device during this time. If any LCD segments are missing, or
audio fails to work, the device is in need of repair. Please refer to Figure 1
below.
Figure 1: Startup display for Model 3005, with all LCD segments shown.
The instrument then displays the firmware version. Please refer to Figure 2
below.
Figure 2: Firmware version display.
Note: Firmware Versions with the Bq displayed support auxiliary
communication.
The instrument then displays the battery voltage. Please refer to Figure 3.
Ludlum Measurements, Inc. Page 2-2 July 2017
Model 3005 Gamma Survey Meter User’s Manual Section 2
Figure 3: Battery Voltage display
The instrument then displays the number of stored records if data logging is
enabled. Please refer to Figure 4 below.
Figure 4: Startup display for Optional Data Logging firmware, showing
155 stored records.
The instrument will then move to normal operation, displaying the current
rate for the Primary units (default: µR/hr).
If the Sigma Audio option is selected, the unit will display a countdown
from :08 to :01 (in seconds) as the unit measures background radiation
levels. Note that the Sigma Audio option is intended for scintillation
detectors and will generally not work well for the GM detectors used in the
Model 3005, 3005/3 and 3005/4.
The user may select the Secondary units (default: cpm) by tapping the Units
button.
Ludlum Measurements, Inc. Page 2-3 July 2017
Model 3005 Gamma Survey Meter User’s Manual Section 2
Ensure that the low-battery indicator is not present. If the low-battery
indicator is present, replace the batteries as soon as possible. Should the
instrument detect a battery voltage that is high enough to power on, but too
low to safely operate, the display will blank and the low-battery icon will
flash. Normal operation will not be available until the batteries have been
replaced. Under extreme low-battery conditions, be aware that the unit may
not even turn on or may turn itself off abruptly.
A reference reading with a check source, 1 µCi (37 kBq) of
137
Cs for
example, should be obtained at the time the instrument is received in the
field. Small check sources of radiation are available from Ludlum
Measurements. While exempt from many regulations because of their small
size, these sources are large enough to produce a response on this
instrument. If this procedure is done routinely with the same radiation
source, instrument malfunction may be detected when anomalous readings
are observed. If at any time the instrument fails to read within 20% of the
reference reading when using the same check source, it should be sent to a
calibration facility for recalibration and/or repair.
Example log reading:
Check Source # Rate Units
Once this procedure has been completed, the instrument is ready for use.
Ludlum Measurements, Inc. Page 2-4 July 2017
Model 3005 Gamma Survey Meter User’s Manual Section 2
Detector Failure Diagnostic
Note that the Model 3005 has its own diagnostic tests to ensure that the
detector is functioning correctly. The Model 3005 can detect when the
radiation detector is malfunctioning and will flash the display to indicate a
fault. If the detector stops detecting radiation for a settable number of
seconds, the Model 3005 will flash a zero reading for the currently selected
units. This indication is common if the unit is powered up without a
detector connected. If this indication is observed with a connected detector,
remove the unit from service and have it evaluated by a qualified repair and
calibration technician.
Figure 5: Detector Failure display (shown for cpm); will also flash.
Detector Over Range
If the detector is exposed to high levels of radiation or has an internal
malfunction that causes it to count high or excessively, the unit flashes the
maximum rate (999) for the currently selected units as a warning. The user
should ensure whether this is being caused by a high radiation field or by
internal malfunction. With some detectors, this display could be an indicator
of a light leak, possibly caused by a puncture or tear in the detector face. If a
Maximum Display parameter is set, then it is possible for the display to flash
the Maximum Display value under this condition.
Figure 6: Detector Over Range (shown for cpm); will also flash.
Ludlum Measurements, Inc. Page 2-5 July 2017
Model 3005 Gamma Survey Meter User’s Manual Section 2
Detector Overload
As another diagnostic test, the Model 3005 monitors the HV supply's
detector current. A current overload threshold can be set via Setup Mode.
(A setting of 0 disables this alarm.) In general, this alarm setting can be used
to detect when there is some detector failure, a cable failure, or a possible
high level of radiation. When this alarm is triggered, the LCD will display
OL and an alarm tone will sound. Once the detector current goes below the
threshold, the Model 3005 will return to normal operation.
Figure 7: Detector Overload Alarm; will also flash.
Instrument Use and Controls
With four front-panel buttons, the Ludlum Model 3005 is simple and easy
to use with minimal training required. Default operation is RATE mode,
and the display shows the current count rate using the Primary units.
Tapping the UNITS button will switch between Primary and Secondary
units. Long-pressing the MODE button will switch the instrument to MAX
mode, which will display the highest count rate detected. Long-pressing the
MODE button again will switch to COUNT mode, which will display the
COUNT timer. Note that either or both of the MAX and COUNT modes
can be locked out in the setup process.
See the Model 3005 drawing at the beginning of this manual to
reference the following controls:
There are two types of button presses for each button described below:
Short Press - pressing the button and releasing in under a half second. A
short press will be referred to as a tap throughout this document.
Long Press -pressing the button and holding for at least a half second
before releasing. A long press will be referred to as a press throughout this
document.
Ludlum Measurements, Inc. Page 2-6 July 2017
Model 3005 Gamma Survey Meter User’s Manual Section 2
ON/ACK button: Used to power the Model 3005 ON and OFF, reset MAX
mode, start/reset the COUNT Timer, and acknowledge audio alarms.
Power On: Press for approximately one second and release (all
LCD segments will activate, and firmware version will be shown).
Power Off: Press for approximately five seconds. The display will
show a 3, 2, 1 countdown for the final three seconds of shutdown.
Releasing the ON/ACK button during shutdown will return the
device to the previous state of operation. At completion of the
shutdown count, the LCD will go blank.
Short Press(Tap):
Will acknowledge/silence alarms in all modes of operation.
Change Log Location Selected Position (if data logging is enabled).
Will move selection position in the device menu.
Long Press(press):
Start/reset COUNT Timer in COUNT mode.
When Sigma Audio is enabled, pressing the ON/ACK button will
take a new background reading and update the Sigma Audio level
(in Rate Mode only).
Reset/Zero (if enabled): When in Rate mode, will reset/zero the
averaged rate. The minimum display will be shown before returning
to the exposure rate. When Sigma Audio is enabled, Rate Reset is
disabled.
Will reset MAX mode display.
UNITS button: Tap to switch between Primary and Secondary units in all
available modes.
AUDIO button: Tap to toggle the click/Sigma audio ON or OFF. Audio
defaults to ON when the unit is powered up. Count Mode audio is disabled
by default, but can be enabled through Lumic Software. Sigma audio is
disabled in Count Mode. While viewing the Detector Overload parameter in
the device menu, long-pressing the audio button will allow the user to view
the actual current level. Another long press will return the user to overload
setpoint.
MODE button: Tap to advance between the three operating modes, RATE,
MAX, and COUNT. Note that MAX and/or COUNT mode may be
disabled from use by the administrator or calibrator. While in the device
menu, tap to increment the selected digit/text to the next available option.
Ludlum Measurements, Inc. Page 2-7 July 2017
Model 3005 Gamma Survey Meter User’s Manual Section 2
RATE Mode Operation
In RATE mode, the current count rate will be displayed.
Long-pressing the ON/OFF button for at least a half second will reset the
averaged rate before releasing the button. The Reset feature must be
enabled through Lumic Calibration software (see parameter: RateResetBtn)
and will be disabled when Sigma Audio is enabled.
Tapping the UNITS button will switch the displayed value between the
Primary and Secondary Units.
Tapping the AUDIO button will turn the audio on/off.
If an alarm condition is present, tapping the ON/ACK button will
acknowledge and turn off the continuous tone alarm audio. Under an alarm
condition, the ALARM display indicator will remain on. Alarms are nonlatching in RATE mode.
If other operational modes are available, tapping the MODE button will
move to the next available operational mode.
Figure 8: RATE mode display showing typical background radiation rate
and the low-battery icon.
Ludlum Measurements, Inc. Page 2-8 July 2017
Model 3005 Gamma Survey Meter User’s Manual Section 2
MAX Mode Operation
While in MAX mode, the highest detected count rate (since the last reset) is
displayed. The word MAX will be displayed when in MAX mode.
Tapping the UNITS button will switch the displayed value between the
Primary and Secondary Units.
Tapping the AUDIO button will turn the audio on/off.
Under a non-alarm or alarm condition, long-pressing the ON/ACK button
will reset the display. When Sigma Audio is enabled, the Sigma Audio alarm
level cannot be reset in Max Mode.
If an alarm condition is present, tapping the ON/ACK button once will
acknowledge and turn off the continuous tone alarm audio. (The “click”
audio will remain as selected under non-alarm conditions.) Under an alarm
condition, the ALARM display indicator will remain on until the display is
reset. Alarms in MAX mode latch with the display.
If other operational modes are available, tapping the MODE button will
move to the next available operational mode.
Figure 9: MAX mode operation display with ALARM indicator.
Ludlum Measurements, Inc. Page 2-9 July 2017
Model 3005 Gamma Survey Meter User’s Manual Section 2
COUNT Mode Operation
When entering COUNT Mode from another operational mode, the
currently selected COUNT Units will be displayed for approximately one
second. The purpose of COUNT mode is to count for a predetermined
amount of time, and to display the results on the display. Note that the
predetermined count time can be from 1 second to 10 minutes, or can be set
to zero to enable continuous counting until stopped by the user.
Count mode operation is very flexible, depending on the units chosen. A
common choice is for the count mode to just perform a scaler count for a
specified time, with a resulting answer in counts (equaling detected radiation
events).
There are two different options for COUNT mode, which can be set
through software.
Go to “Device Count Display Mode” in the Device or Others tab
(depending on Software version). Enter/Select the desired option into the
“Value” field.
0 - will only show the count-down timer while timer is active
(default selection).
1 - will cycle between showing the count-down timer and the
current reading.
2 - will only show the current gathered reading.
Note:
If the Data Logging Option is installed, tapping the LOG
button will start a count and automatically log the result. A
long press of the LOG button during the count will toggle the
display between the timer and reading.
Count Mode Audio Mode will enable\disable click audio during a COUNT.
0 - Disabled -default selection (Mute icon will always be
illuminated in COUNT mode.)
1- Enabled
Ludlum Measurements, Inc. Page 2-10 July 2017
Model 3005 Gamma Survey Meter User’s Manual Section 2
Note:
Sigma audio is disabled in Count Mode. If Sigma Audio and
Count Mode Audio are enabled, click audio will be utilized in
Count Mode.
If a result in terms of activity is desired, the scaler count can also be in units
of "d" or disintegrations. But if the count units are chosen to be cpm or cps,
then the resulting answer is an averaged count rate over the time interval.
Similarly, if count units of Bq or dpm are chosen, the resulting answer is an
averaged disintegration rate.
Note:
If the user desires the instrument to show results in terms of
disintegrations/area (eg. dpm/100cm2 or Bq/cm2), then the
appropriate factor should be placed in the Efficiency
parameter.
Other choices are to have count mode units of R/h or Sv/h, in which case
the COUNT mode result is an averaged exposure or dose rate. But if count
mode units of R or Sv are chosen, the result is shown in accumulated
exposure or accumulated dose over the chosen count time. The following
tables lists the possibilities:
UNITS RESULT
c counts per count time
d disintegrations per count time
cpm, cps count rate averaged over the count time
dpm, Bq disintegration rate, averaged over the count time
R/h, Sv/h exposure or dose rate, averaged over the count time
R, Sv integrated exposure or dose over the count time
Ludlum Measurements, Inc. Page 2-11 July 2017
Model 3005 Gamma Survey Meter User’s Manual Section 2
In COUNT mode, operation depends on the current state of the Count
Timer.
When the Count Timer is Ready:
The display will show the Count Time.
Tapping the UNITS button will switch between the Primary and
Secondary Count Units. The newly selected Count Units will be
displayed for approximately one second, and the display will then
return to the Count Timer.
Long-pressing the ON/ACK button starts the Count Timer.
If other operational modes are available, tapping the MODE button
will move to the next available operational mode.
When the Count Timer is active:
The display will show either Count Time, both Count Time and
Counts, or just counts, depending on Count Display Mode.
Long-pressing the ON/ACK button will reset the Count Timer.
Tapping the UNITS button will switch between the Primary and
Secondary Count Units.
Click audio, if enabled, can be turned on and off by tapping the
Audio button.
If an alarm condition occurs, the ALARM display indicator will turn
on. Alarm audio will sound after the count is completed if the result
is over the alarm threshold. (If the count unit is an averaged rate, it is
possible for the ALARM icon to come on during the count, but if
the averaged rate falls below the alarm threshold by the end of the
count, no ALARM will be active.)
If other operational modes are available, tapping the MODE button
will cancel the current Count Timer and move to the next available
operational mode.
When the Count Timer has finished:
The display will show either the accumulated total for c, d, R, and
Sv, or the timed ratemeter average for cps, cpm, Bq, dpm, or the
average exposure or average dose in R/h and Sv/h.
Ludlum Measurements, Inc. Page 2-12 July 2017
Tapping the UNITS button will switch between the Primary and
Secondary Count Units.
Model 3005 Gamma Survey Meter User’s Manual Section 2
Long-pressing the ON/ACK button will reset the Count Timer.
If an alarm condition occurred during the Timed Count, a
continuous audio tone will sound, and the ALARM display indicator
will turn on. Tapping the ON/ACK button once will acknowledge
and turn off the continuous tone alarm audio. Long-pressing the
ON/ACK button will clear the alarm condition and reset the Count
Timer. Alarm audio will sound after the count is completed if the
result is over the alarm threshold. (If the count unit is an averaged
rate, it is possible for the ALARM icon to come on during the
count, but if the averaged rate falls below the alarm threshold by the
end of the count, no ALARM will be active.)
If other operational modes are available, tapping the MODE button
will move to the next available operational mode.
Figure 10: COUNT mode operation showing COUNT Timer of 5
minutes, 30 seconds.
Ludlum Measurements, Inc. Page 2-13 July 2017
Model 3005 Gamma Survey Meter User’s Manual Section 3
Section
3
Specifications
0
Detector: version dependent, internal energy-compensated GM for Models
3005, 3005/3, and 3005/4
HV: 550 Vdc
Threshold: negative 4-100 mVdc, typically set to -35 mVdc for GM detectors
Resolving Time: approximately 5 µsec as defined by IEC 60325
Alarms: alarm setpoints adjustable over the display range
Zero Protection: after a user-settable number of seconds of no pulses from
detector, unit will flash a zero reading and the alarm audio will be triggered
LCD Display: 3-digit LCD with large 20 mm (0.8 in.) digits, (k)cps, (k)cpm,
(k)Bq, (k)dpm, (µ)(m)R(/h), (µ)(m)Sv(/h), low-battery indicator, MAX,
ALARM, AUDIO
Detector Range: 1 µSv/h to 50 mSv/h (0.1 to 5000 mR/hr) (other ranges
available)
Backlight: built-in ambient light sensor automatically activates low-power
LED backlight, unless internal dip switch is set to continuous-on (will reduce
battery life)
User Controls:
ON/OFF/Quiet – long press to turn ON, tap to acknowledge alarms
and silence alarm tone, hold for OFF
MODE – alternates between RATE (count rate), MAX ( captures peak
rate), and COUNT ( user-selectable preset count time from 0 to 10
minutes)
AUDIO – turn “click” audio on/off
UNITS – changes the units from count rate (cpm, cps), to
dose/exposure (µSv/h, mR/h) or disintegration (dpm/Bq)
Response Time: user-selectable from 1 to 60 seconds, or auto-response rate
FAST or SLOW
Ludlum Measurements, Inc. Page 3-1 July 2017
Audio: click audio greater than 65 dB at 0.6 m (2 ft), alarm audio at greater than
72 dB, approximately 4.5 kHz
Power: four alkaline “AA” batteries
Battery Life: approximately 750 hours of operation (as low as 100 hours with
backlight configured for continuous-on), 16-hour low-battery warning
Maximum Current: 35 mAdc
Construction: high-impact plastic with water-resistant rubber seals and
separate battery compartment
Temperature Range: -20 to 50 ˚C (-5 to 122 ˚F), may be certified for
operation from -40 to 65 ˚C (-40 to 150 ˚F)
Environmental Rating: NEMA (National Electrical Manufacturers
Association) rating of 4x or IP (Ingress Protection) rating of 65
Size: 16.5 x 11.4 x 21.6 cm (6.5 x 4.5 x 8.5 in.) (H x W x L)
Weight: 1.06 kg (2.3 lb)
Section
4
Setup Mode
Warning!
Only advanced users or administrators should consider changing
any of the parameters in the following section. Incorrect settings
could jeopardize the safety of users depending on this
instrument.
Setup Overview
Your instrument has been shipped from Ludlum Measurements only after
passing electronic checkout, a 24-hour burn-in process, and a careful calibration
process. Calibration papers are supplied with each instrument shipped from
Ludlum Measurements.
Recalibration should be accomplished after maintenance or adjustments have
been performed on the instrument. Recalibration is not normally required
following instrument cleaning or battery replacement. Recalibration does not
require any special tools or software to perform.
Ludlum Measurements offers a full-service repair and calibration department.
Not only do we repair and calibrate our own instruments, we also service most
other manufacturers’ instruments. Calibration procedures are available upon
request for customers who choose to calibrate their own instruments.
Note:
Ludlum Measurements, Inc. recommends recalibration at
intervals no greater than one year, assuming that regular
operational checks are performed. Check the appropriate local,
state, and federal regulations to determine required recalibration
intervals.
Ludlum Measurements, Inc. Page 4-1 July 2017
Model 3005 Gamma Survey Meter User’s Manual Section 4
Setup Parameter
3005
3005/3
3005/4
P1-1
Calibration Constant Mantissa
600
270
600
P1-2
Calibration Constant Exponent
05
5
4
P1-3
Dead Time Correction
80
45
45
P1-4
Dead Time Correction 2 Mantissa
varies
P1-5
Dead Time Correction 2 Exponent
varies
P1-6
Efficiency
15.0
P1-7
High Voltage Setpoint
550
P1-8
Pulser Threshold
35
P1-9
Detector Current Overload Threshold
100
P1-10
Loss of Count Alarm Time
60
60
300
P2-1
Primary Units and Minimum Display
0.00
mR/hr
00.0 mR/hr
P2-2
Primary Units Maximum Display
5.00 R/hr
25.0 R/hr
50.0 R/hr
P2-3
Primary Units RATE/ MAX Mode Alarm Point
5.00
mR/hr
50.0 mR/hr
P2-4
Primary Count Units and Minimum Display
000 µR
P2-5
Primary Count Alarm Point
000
P3-1
Secondary Units and Minimum Display
000 cpm
P3-2
Secondary Units and Maximum Display
999 kcpm
P3-3
Secondary Units RATE/ MAX Mode Alarm Point
5.00 kcpm
P3-4
Secondary Count Units and Minimum Display
000 c
P3-5
Secondary Count Alarm Point
000
P4-1
Response Time
0
P4-2
Auto-Response Rate
S
P4-3
Operational Modes
0
P4-4
Count Time
1:00
P4-5
Auto Shutdown Time
0
P4-6
Backlight Threshold
LO
P4-7
Sigma Audio
OFF
P5-1
Datalogging Mode
1
Default Setup Values
Ludlum Measurements, Inc. Page 4-2 July 2017
Model 3005 Gamma Survey Meter User’s Manual Section 4
P5-2
RTC Month
1
P5-3
RTC Day
7
P5-4
RTC Year
14
P5-5
RTC Hour
16
P5-6
RTC Minute
30
P5-7
RTC Second
00
Entering Setup Mode
To enter setup mode, power down the Model 3005, then turn the unit back
ON. Following the display of the Firmware version, when the instrument has
begun normal operation, press the MODE button three times (within four
seconds) to enter Setup mode.
Note:
This process is different if you are in Sigma Mode, rather than in
the “click” Mode. While trying to enter Setup Mode from Sigma
Mode, once the screen displays the firmware number and then
begins counting down, press the Mode button three times as soon
as the countdown begins. Do not wait until the countdown is
complete, which will prevent you from getting into the Setup
Mode. There is no countdown for the “click” Mode.
Entry to Setup mode can be confirmed when the numeric portion of the display
shows P-1, indicating the first setup page is selected. If you simply wish to view
the parameters, select the desired Setup Page by tapping the MODE button.
Tap the UNITS button to advance through the parameters available on the
selected Setup Page. To return to normal operation, advance back to the Setup
Page selection, by long-pressing the UNITS button. Long-pressing the UNITS
button again will exit the menu. Holding the UNITS button for approximately 5
seconds will also exit from anywhere in the menu.
Note:
If the menu is not exited properly, any changes made will not be
saved.
Ludlum Measurements, Inc. Page 4-3 July 2017
Model 3005 Gamma Survey Meter User’s Manual Section 4
SETUP PROTECT: The Model 3005 parameters can be protected from
unauthorized changes via the internal switch located on the Model 3005 circuit
board. To change the switch, open the battery compartment and remove the
batteries from the Model 3005. Next, loosen the six pan-head screws that fasten
the bottom cover.
Gently remove the bottom cover of the instrument. The DIP (dual in-line
position) switch should now be visible in the upper left-hand corner of the
circuit board.
To protect the Model 3005 from changes in Setup mode, slide DIP Switch 2
(the rightmost switch) to the ON (forward) position. If DIP Switch 2 is in the
OFF (back) position, changes are allowed in Setup mode. Once the DIP Switch
is set as desired, gently replace the back cover and the six pan-head screws.
Install the batteries, and replace the battery cover.
There are three different options for protect mode, which can be set through
Lumic Calibration Software. Locate the Parameter “Device Setup Prtct” in the
Others tab. Enter the desired option into the “Value” field.
- Normal: All Parameters are protected from change through the
device menu.
- Bypass Alarms: All Parameters except for Rate and Count Alarms
are protected from change through the device menu.
- Bypass Alarms Count: All Parameters except for Rate Alarms,
Count Alarms, and count time are protected from change through
the device menu.
Note that with the DIP Switch 2 in the ON position, Setup mode may be
entered and parameters viewed, but changes cannot be made.
DISPLAY BACKLIGHT ‘Continuous On’: The Model 3005 display
backlight can be set to remain on continuously during operation. Follow the
steps above for SETUP PROTECT, but use DIP Switch 1 for display
backlight selection. Setting DIP Switch 1 to the ON (forward) position will
configure the display backlight to remain on during operation. Set DIP Switch 1
to the OFF (back) position, and the display will be backlit only when light levels
are low.
Note:
Setting the display backlight for continuous-on operation can
result in reduced battery life. The backlight can be configured to
always be off as well through the device menu or Lumic
Calibration Software.
Ludlum Measurements, Inc. Page 4-4 July 2017
Model 3005 Gamma Survey Meter User’s Manual Section 4
Setup Mode Operation
Setup Page Selection: Once the Model 3005 is in Setup mode, the Setup Page
selection will be displayed on the LCD, and the Page number will be blinking,
indicating it as the selected item. The number of available parameters per Setup
Page will be displayed using the graph – the number of segments indicating the
number of parameters. Tap the MODE button to choose the Setup Page. Once
the desired Setup Page is shown, tap the UNITS button to move to the first
parameter of that Setup Page. Long-pressing the UNITS button will exit the
menu.
Figure 11: Setup Page Selection display (showing page 4).
Long-pressing the Mode button, no matter what parameter is shown, will first
return the user back to the Page Selection screen and then exit if held for
approximately 5 seconds in total. Exiting can also be accomplished by one or
two individual long presses of the UNITS button, depending on where the user
is in the menu. (If on the page selection, only one press will exit, but if viewing
an individual parameter, two presses will be required.
The list on the following page lists the four setup pages and the parameters, in
order, on each page.
Ludlum Measurements, Inc. Page 4-5 July 2017
Model 3005 Gamma Survey Meter User’s Manual Section 4
Model 3005 List of Parameters (in order)
Page 1 (P-1)
Calibration Constant Mantissa
Calibration Constant Exponent
Dead Time Correction 1
Dead Time Correction 2 Mantissa
Dead Time Correction 2 Exponent
Efficiency
High Voltage Setting
Pulse Threshold
Detector Current Overload Threshold
Loss of Count Alarm Time
Page 2 (P-2)
Primary Units and Minimum Display
Primary Units Maximum Display
Primary Units RATE/MAX Mode Alarm Point
Primary COUNT Units and Minimum Display
Primary COUNT Units Alarm Point
Page 3 (P-3)
Secondary Units and Minimum Display
Secondary Units Maximum Display
Secondary Units RATE/MAX Mode Alarm Point
Secondary COUNT Units and Minimum Display
Secondary COUNT Units Alarm Point
Page 4 (P-4)
Response Time
Auto Response Rate
Operational Modes
Count Time
Auto Shutdown Time
Backlight Threshold
Sigma Audio
Ludlum Measurements, Inc. Page 4-6 July 2017
Model 3005 Gamma Survey Meter User’s Manual Section 4
Setup Parameter Adjustment: Use the MODE button to adjust the value for
the selected item. When the appropriate value is selected for that item, long
press the ON/ACK button to move to the next item. When the desired value is
displayed, long press the UNITS button to advance to the next parameter. The
graph will display the total number of parameters available on the current Setup
Page, and the current parameter’s position will be blinking. When the Model
3005 is in PROTECT mode (dipswitch setting), the Setup parameters will
cycle through to display the set values, but changes are not possible.
The order of Setup parameters for the Model 3005 is as follows:
Setup Page 1
Calibration Constant Mantissa (Default 110) - Tap ON/ACK to select the
value to adjust, and MODE to adjust the value. Value is used with Calibration
Constant Exponent to express counts per R. Available values are:
Ones Place (0-9)
Tens Place (0-9)
Hundreds Place (1-9)
Calibration Constant Exponent (Default 8) - Tap ON/ACK to select the
value to adjust, and MODE to adjust the value. Value is used with Calibration
Constant Mantissa to express counts per R. Available values are:
Ones Place (0-9)
Tens Place (0-1)
Dead Time Correction 1 (Default 0) - Tap ON/ACK to select the value to
adjust, and MODE to adjust the value. Value is in microseconds. Available
values are:
Ones Place (0-9)
Tens Place (0-9)
Hundreds Place (0-9)
Dead Time Correction 2 Mantissa (Default 0) - Tap ON/ACK to select the
value to adjust, and MODE to adjust the value. Available values are:
Ones Place (0-9)
Tens Place (0-9)
Ludlum Measurements, Inc. Page 4-7 July 2017
Hundreds Place (1-9)
Model 3005 Gamma Survey Meter User’s Manual Section 4
Dead Time Correction 2 Exponent (Default 0) - Tap MODE button to
adjust the value. Available values are:
Value between (-6 to -12)
Efficiency (Default 15.0%) - Tap ON/ACK to select the value to adjust, and
MODE to adjust the value. Available values are:
Ones Place (0-9)
Tens Place (0-9)
Hundreds Place (0-9)
Number of Decimal Places (0 or 1)
Normally the efficiency is used on a per detector basis or 4pi basis, i.e. the
efficiency of the detector is calculated by dividing the count rate received from a
source by the total disintegration rate of the source. When either dpm or Bq
units are chosen, the use of the 4pi efficiency allows the display of the source
size or activity on the Model 3005 display.
But if the user desires to have the Model 3005 show results in terms of
dpm/100 cm2, the user could manipulate the efficiency to produce this result by
multiplying the efficiency times the ratio of the detector area to 100 cm2. For
example, using a detector with an area of 15 cm2, if we start with 10% efficiency
to measure in dpm, then the parameter could be changed to 1.5% to measure in
dpm/100 cm2.
Or likewise for Bq/cm2, efficiency could be calculated as: efficiency = count
rate/disintegration rate*detector area (in cm2). For example, with the same
detector as above with an area of 15 cm2, and starting with an efficiency value of
15%, then the parameter could be changed to 225% to measure in Bq/cm2.
High Voltage (Default 800 Volts) - Tap ON/ACK to select the value to
adjust, and MODE to adjust the value. Value is in Volts. Available values are:
Ones Place (0-9)
Tens Place (0-9)
Hundreds Place (0-9)
k Multiplier (on/off)
Note: k multiplier also activates left-most decimal point. If k multiplier is used,
Hundreds Place value is limited to 0 and 1.
Ludlum Measurements, Inc. Page 4-8 July 2017
Model 3005 Gamma Survey Meter User’s Manual Section 4
Pulser Threshold (Default 35 millivolts) - Tap ON/ACK to select the
value to adjust, and MODE to adjust the value. Available values are:
Ones Place (0-9)
Tens Place (0-9)
Hundreds Place (0-9)
Multiplier (m or leftmost decimal)
Note: multiplier m signifies a value in millivolts. If the multiplier is the left-most
decimal, value is in Volts.
Detector Current Overload Threshold (Default 100) - Tap ON/ACK to
select the value to adjust, and MODE to adjust the value. Setting the Detector
Current Overload Threshold to 0 disables the Current Overload Alarm.
Available values are:
Ones Place (0-9)
Tens Place (0-9)
Hundreds Place (0-9)
Long-pressing the AUDIO button will cause the display to show the actual live
current reading. Repeating this process will return you back to the overload
threshold setpoint.
Loss of Count Alarm Time (Default 60 seconds) - Tap ON/ACK to select
the value to adjust, and MODE to adjust the value. Setting the Loss of Count
Alarm Time to 0 disables the alarm. Value is in seconds. Available values are:
Ones Place (0-9)
Tens Place (0-9)
Hundreds Place (0-9)
Ludlum Measurements, Inc. Page 4-9 July 2017
Model 3005 Gamma Survey Meter User’s Manual Section 4
cpm
kcpm
cps
kcps
dpm
kdpm
Bq
kBq
µR/h
mR/h
R/h
µSv/h
mSv/h
Sv/h
Setup Page 2
Primary RATE/MAX Units and Minimum Display (Default 0.00 µR/h) -
Tap ON/ACK to select the value to adjust, and MODE to adjust the value.
Available values are:
Number of Decimal Places (0, 1, or 2)
Minimum Units – See List Below
Primary Units RATE/MAX Maximum Display (Default 9.99 R/h) - Tap
ON/ACK to select the value to adjust, and MODE to adjust the value. Units
will be the same as selected earlier with Primary Units. Available values are:
Ones Place (0-9)
Tens Place (0-9)
Hundreds Place (0-9)
Number of Decimal Places (0, 1, or 2)
Range (k on or off – cpm, cps, dpm, Bq; µ, m or none for R/h and Sv/h)
Primary Units RATE/MAX Mode Alarm Point (Default 000) - Tap
ON/ACK to select the value to adjust, and MODE to adjust the value. Units
will be the same as selected earlier with Primary Units. The ALARM LCD
Segment will be on to indicate an Alarm parameter. Set this Alarm Point to 000
to disable. Available values are:
Ones Place (0-9)
Tens Place (0-9)
Hundreds Place (0-9)
Number of Decimal Places (0, 1, or 2)
Range (k on or off – cpm, cps, dpm, Bq; µ, m or none for R/h and Sv/h)
Note: If the Primary Units has changed to a value other than that used to
previously set this Alarm Point, the Alarm Point will be reset to 000.
Ludlum Measurements, Inc. Page 4-10 July 2017
Model 3005 Gamma Survey Meter User’s Manual Section 4
Primary
Units
Primary
Count
Units
Available
Primary
Units
Primary
Count
Units
Available
cps
kcps
cps
c
µR/h
mR/h
R/h
µR/h µR
mR/h mR
R/h R
cpm
kcpm
cpm c Bq
kBq
Bq
d
µSv/h
mSv/h
Sv/h
µSv/h µSv
mSv/h mSv
Sv/h Sv
dpm
kdpm
dpm
d
Primary Count Units and Minimum Display (Default 0.00 µR) - Tap
ON/ACK to select the value to adjust, and MODE to adjust the value.
Available values are:
Number of Decimal Places (0, 1, or 2)
Minimum Units depend on the selected Primary Units– See List Below
Primary Count Alarm Point (Default 000) - Tap ON/ACK to select the
value to adjust, and MODE to adjust the value. Units will be the same as
selected earlier with Primary Count Units. Primary Count Units of c or d will
not be displayed, but mR or µSv will. The ALARM LCD Segment will be on to
indicate an Alarm parameter. Set this Alarm Point to 000 to disable. Available
values are:
Ones Place (0-9)
Tens Place (0-9)
Hundreds Place (0-9)
Number of Decimal Places (0, 1, or 2)
Range (k on or off – cpm, cps, dpm, Bq; µ, m or none for R/h and Sv/h)
Note: If the Primary Count Units has changed to a value other than that used
to previously set this Alarm Point, the Alarm Point will be reset to 000.
Ludlum Measurements, Inc. Page 4-11 July 2017
Model 3005 Gamma Survey Meter User’s Manual Section 4
cpm
kcpm
cps
kcps
dpm
kdpm
Bq
kBq
µR/h
mR/h
R/h
µSv/h
mSv/h
Sv/h
Setup Page 3
Secondary RATE/MAX Units and Minimum Display (Default 0 cpm) -
Tap ON/ACK to select the value to adjust, and MODE to adjust the value. Set
to OFF to disable Secondary RATE/MAX Units. Available values are:
Number of Decimal Places (0, 1, or 2)
Minimum Units – See List Below
Secondary Units RATE/MAX Maximum Display (Default 999 kcpm) -
Tap ON/ACK to select the value to adjust, and MODE to adjust the value. If
the Secondary Units is off, this parameter will be skipped. Units will be the same
as selected earlier with Secondary Units. Available values are:
Ones Place (0-9)
Tens Place (0-9)
Hundreds Place (0-9)
Number of Decimal Places (0, 1, or 2)
Range (k on or off – cpm, cps, dpm, Bq; µ, m or none for R/h and Sv/h)
Secondary Units RATE/MAX Mode Alarm Point (Default 000) - Tap
ON/ACK to select the value to adjust, and MODE to adjust the value. If the
Secondary Units is off, this parameter will be skipped. Otherwise, units will be
the same as selected earlier with Secondary Units. The ALARM LCD Segment
will be on to indicate an Alarm parameter. Set this Alarm Point to 000 to
disable. Available values are:
Ones Place (0-9)
Tens Place (0-9)
Hundreds Place (0-9)
Number of Decimal Places (0, 1, or 2)
Note: If the Secondary Units has changed to a value other than that used to
previously set this Alarm Point, the Alarm Point will be reset to 000.
Ludlum Measurements, Inc. Page 4-12 July 2017
Range (k on or off – cpm, cps, dpm, Bq; µ, m or none for R/h and Sv/h)
Model 3005 Gamma Survey Meter User’s Manual Section 4
Primary
Units
Primary
Count
Units
Available
Primary
Units
Primary
Count
Units
Available
cps
kcps
cps
c off
µR/h
mR/h
R/h
µR/h µR
mR/h mR
R/h R
off
cpm
kcpm
cpm
c off
Bq
kBq
Bq
d off
µSv/h
mSv/h
Sv/h
µSv/h µSv
mSv/h mSv
Sv/h Sv
off
dpm
kdpm
dpm
d off
Secondary Count Units and Minimum Display (Default 0 c) - Tap
ON/ACK to select the value to adjust, and MODE to adjust the value. If the
Secondary Units is off, this parameter will be skipped. Available values are:
Number of Decimal Places (0, 1, or 2)
Minimum Units depend on the selected Primary Units. See list below:
Secondary Count Alarm Point (Default 000) - Tap ON/ACK to select the
value to adjust, and MODE to adjust the value. If the Secondary Units is off,
this parameter will be skipped. Otherwise, units will be the same as selected
earlier with Secondary Count Units. The ALARM LCD Segment will be on to
indicate an Alarm parameter. Set this Alarm Point to 000 to disable. Available
values are:
Note: If the Secondary Count Units has changed to a value other than that used
to previously set this Alarm Point, the Alarm Point will be reset to 000.
Ludlum Measurements, Inc. Page 4-13 July 2017
Ones Place (0-9)
Tens Place (0-9)
Hundreds Place (0-9)
Number of Decimal Places (0, 1, or 2)
Range (k on or off – cpm, cps, dpm, Bq; µ, m or none for R/h and Sv/h)
Model 3005 Gamma Survey Meter User’s Manual Section 4
Count Rate
Auto Response
Time – Fast
(Seconds)
Auto Response
Time – Slow
(Seconds)
Less than 3 kcpm (50 cps)
10.5
21
Between 3 kcpm and 4 kcpm (67 cps)
8.4
16.8
Between 4 kcpm and 6 kcpm (100 cps)
6.3
12.6
Between 6 kcpm and 12 kcpm (200 cps)
4.2
8.4
More than 12 kcpm
2.1
4.2
Setup Page 4
Response Time (Default 0 - auto) – Tap ON/ACK to select the value to be
adjusted and MODE to adjust the value. Setting the Response Time to a fixed
value is useful primarily when performing surveys to a fixed MDA (Minimum
Detectable Activity) level. Setting the Response Time to 0 will enable the AutoResponse mode for the Model 3005 (see the next parameter). Available values
for the Response Time (in seconds) are:
Ones Place (0-9)
Tens Place (0-6, 6 forces max Response Time of 60)
Auto-Response Rate (Default S) - Tap MODE to select Fast (F) or Slow (S).
When operating in Auto-Response mode, the Model 3005 will vary the
Response Time based on the Auto-Response Rate selected (Fast or Slow) and
the current Count Rate. The following table shows the response time for
different count rates when these auto response modes are chosen:
The Model 3005 also utilizes a Step function in Auto Response mode, which
enables faster response to a significant increase or decrease in Count Rate.
When the instrument detects a sudden change in count rate from the detector,
the response time is reduced to 1 second to quickly show the new value.
Operational Modes (Default 0 - All modes available) - Tap MODE to
adjust the value. Available values are:
Ludlum Measurements, Inc. Page 4-14 July 2017
0 – RATE, MAX, and COUNT Modes
1 – RATE and MAX Modes only
2 – RATE and COUNT Modes only
3 – RATE Mode only
Model 3005 Gamma Survey Meter User’s Manual Section 4
Count Time (Default 1 minute) - Tap ON/ACK to select the value to
adjust, and MODE to adjust the value. Setting Count Time to 0 enables
continuous count until reset. If 9 minutes is selected, then the maximum
seconds value is 60; otherwise, the maximum seconds value is 59. Available
values are:
Ones Place (0-9)
Tens Place (0-6, 6 only available if minutes value is 9)
Hundreds Place (0-9)
NOTE: The UNITS button can be used to advance to the next parameter. To
end Setup mode and save the current setting, press and hold the UNITS button
for approximately 5 seconds, or press the UNITS button for at least a half
second two times.
Auto Shutdown Time (Default 0 - off) - Tap MODE to adjust the value in
hours. If non-zero, unit will automatically power down after so many hours
since the last button press. Setting Auto Shutdown Time to 0 disables Auto
Shutdown. Available values are:
Ones Place (0-9) hours
Backlight Threshold (Default LO –most sensitive) - Tap MODE to adjust
the value. Available values are:
LO – Backlight comes on at a higher ambient light level
There are two different options for Backlight Threshold LOW,
which can be set through software. Locate the Parameters in the Others
tab. Enter the desired number into the “Value” field.
- Low Light Turn On: The backlight will turn on at the threshold
set by this value. (This should be lower than the Turn Off value.)
- Low Light Turn Off: The backlight will turn on at the threshold
set by this value. (This should be higher than the Turn On value.)
HI – Backlight comes on at a lower ambient light level
There are two different options for Backlight Threshold HIGH, which
can be set through software. Locate the Parameters in the Others tab.
Enter the desired number into the “Value” field.
Ludlum Measurements, Inc. Page 4-15 July 2017
- High Light Turn On: The backlight will turn on at the threshold
set by this value. (This should be lower than the Turn Off value.)
Model 3005 Gamma Survey Meter User’s Manual Section 4
- High Light Turn Off: The backlight will turn on at the threshold
set by this value. (This should be higher than the Turn On value.)
OFF – Disables backlight
Sigma Audio (Default ON) - Tap MODE to adjust the value. Available
values are:
ON – Sigma Audio Enabled (not recommended for Model 3005, 3005/3,
and 3005/4)
OFF – Sigma Audio Disabled (Normal ‘Click’ Audio active)
Note:
The Sigma Mode may not work properly until the 8-second
background is complete. If the 8-second background count is too
low or too high, the device will continually beep until an
acceptable background count rate (500 cpm-200 kcpm) is
obtained. Sigma Audio is disabled in Count Mode. If Count audio
and Sigma Audio are enabled, Count audio will be click audio.
Ludlum Measurements, Inc. Page 4-16 July 2017
Model 3005 Gamma Survey Meter User’s Manual Section 5
Section
5
Advanced Features
Dead Time Correction
All pulse counting detectors have a “dead time” in which the detector is unable
to register another event. In relatively low fields this is not an issue. However, as
the field strength approaches the high end of the detector’s range, dead time
causes the pulse rate to become non-linear with respect to the real radiation
field. Dead time correction is used to linearize the measurements, allowing a
wider linear response range for a given detector.
This instrument uses a second order dead time correction using the equation
where and are the dead time correction coefficients, is the
measured count rate, and is the corrected rate.
Dead time correction coefficients are configured through the device setup menu
or through Lumic Calibration software. Lumic Calibration software also includes a
wizard that will automate finding and setting the correct coefficients.
is represented in micro seconds (µs) on the device setup menu and in the
software. The equation must be calculated in terms of seconds (s) and must be
scaled appropriately. has more complex units and are not shown.
However, the representation of the coefficient on the setup menu and in
software do not require scaling.
Note:
Setting the to zero will disable the second order
correction, while setting to zero will disable both,
regardless of the value of .
Ludlum Measurements, Inc. Page 5-1 July 2017
Model 3005 Gamma Survey Meter User’s Manual Section 5
Table 1: Features that modify different units
Unit
Feature
cpm
cps
counts
Dead time correct
Bq
dpm
disintegrations
Dead time correction
Efficiency
R/h
R
Dead time correction
Calibration constant
Sv/h
Sv
Dead time correction
Calibration constant
R to Sv conversion
These apply to all modes.
Units
Depending on the chosen display units, different features will affect value of the
reading. The following table lists the features that apply to each of the display
units.
R to Sv Conversion
The R to Sv conversion is a setting available in Lumic Calibration software. It
defines the conversion factor between R and Sv. Since the calibration
constant is directly tied to R (counts per R), calibrating Sv requires a correct
setting of both calibration constant and R to Sv conversion.
Example: A R to Sv conversion factor of 0.0106 will cause a reading of 10.6
mSv/h while in a 1 R/h field.
Software Calibration Tools
Lumic Calibration software includes wizards that will assist in calibrating and
plateauing detectors. After configuring the wizard for a specific detector, the
wizard will automate much of the data collection and calculation required for
calibration.
Ludlum Measurements, Inc. Page 5-2 July 2017
Model 3005 Gamma Survey Meter User’s Manual Section 5
Instrument Calibration
This instrument provides the ability to digitally enter a voltage for both high
voltage and threshold. As such, the instrument itself needs to be calibrated. This
happens at the factory when the instrument is built and should not require recalibration. However, if calibration is required (due to board rework, etc.), the
calibration settings are available in Lumic Calibration software.
Other Device Data
The following parameters on the instrument allow recording important device
information within the device:
Firmware Version: This is a read-only representation of the firmware version.
With a version of 4983XNyy.zzzz, the Xyy will show up on the device screen
during the power-on sequence and signifies the released version.
Device – Model Name: This should match the model name on the front face
of the instrument.
Device – Serial Number: This should match the serial number of the
instrument.
Detector – Model: This can store the model of the detector the instrument
was calibrated for.
Detector – Serial Number: This can store the serial number of the detector
the instrument was calibrated for.
Real-time Streaming
Lumic Calibration software and this instrument have the ability to stream data
from the instrument to a computer. The data can be viewed live inside software
or can be recorded to a file.
Multiple user-selected parameters can be streamed simultaneously including:
Remote display of the screen
All unit values
Device status
Live HV current measurement
Ludlum Measurements, Inc. Page 5-3 July 2017
Model 3005 Gamma Survey Meter User’s Manual Section 6
Section
6
Datalogging
The datalogging feature of the Model 3005 allows the user to log radiation
readings with the use of a handle-mounted LOG button. Data can be
logged in any of the Model 3005’s operational modes (RATE, MAX, and
COUNT). Up to 1000 data points can be taken and stored internally.
Depending on the chosen Datalogging Mode, the user can quickly save
logged data using a single Location ID, or select from up to 250 stored
Location IDs. A Real Time Clock (RTC) is utilized to time and date stamp
each datalog entry.
The saved log data and stored location IDs can be viewed, downloaded, and
erased using the LMI Lumic software kit, which includes a USB cable.
Editing of datalogging parameters and RTC via setup mode on the
instrument is disabled.
Setup of the datalogging parameters is also done through the LMI Lumic
software. The advanced user or administrator can set:
Datalogging Mode
Real Time Clock (RTC) Values
Location IDs
Ludlum Measurements, Inc. Page 6-1 July 2017
Model 3005 Gamma Survey Meter User’s Manual Section 6
Datalogging Operation – Mode 1
Datalogging Mode 1 will store the logged data using only the first Location ID
in the Location ID table.
When the LOG button is pressed, the current radiation reading and
other log data is saved along with the first Location ID in the format
specified in the Specifications at the end of this section.
In COUNT Mode:
o With a set count time, the LOG button is disabled until completion
of a Scaler count.
o For a continuous Scaler count (Scaler time is 0), the LOG button is
enabled at all times.
For approximately 2 seconds, the LCD will display the Datalog Table
index for the newly saved log data.
Figure 12: Display showing a Datalog Table index of 12.
After displaying the Datalog Table index, the instrument will return to
the previous mode of operation.
The Datalog Table is linear; once the table is full, no further writes will
be allowed until the Datalog Table is erased.
If an attempt is made to write to a full Datalog Table, a beep will sound
and the maximum Datalog Table index (1.00 k) will be displayed for
about 2 seconds. The instrument will then return to the previous mode
of operation.
Ludlum Measurements, Inc. Page 6-2 July 2017
Model 3005 Gamma Survey Meter User’s Manual Section 6
Datalogging Operation – Mode 2
Datalogging Mode 2 will allow the user to choose the Location ID (by Location
ID Table index) to store with the logged data.
When the LOG button is pressed, the current radiation readings and
other log data are temporarily stored.
In COUNT Mode: (Datalogging Mode 1 is always utilized in COUNT
Mode.)
o With a set count time, the LOG button is disabled until completion
of a Scaler count.
o For a continuous Scaler count (Scaler time is 0), the LOG button is
enabled at all times.
The LCD display will show a possible Location ID Table index for the
user. The index will be auto-incremented from the previously used
index.
Figure 13: Display showing a Location ID Table index of 36.
The ones digit of the index will be blinking, indicating a changeable
value. The user may then enter the preferred Location ID Table index
by tapping the ON/OFF (to select the digit) and MODE (to change
the value) buttons as in Setup mode.
Once the user has the preferred Location ID Table index entered, tap
the LOG button to save the log data.
For approximately 2 seconds, the LCD will display the Datalog Table
index for the newly saved log data (See Figure 12).
After displaying the Datalog Table index, the instrument will return to
the previous mode of operation.
The Datalog Table is linear; once the table is full, no further writes will
be allowed until the Datalog Table is erased.
Ludlum Measurements, Inc. Page 6-3 July 2017
Model 3005 Gamma Survey Meter User’s Manual Section 6
Datalogging Operation – Mode 3
Data Logging Mode 3 will automatically record data log records using the
current location with the user settable auto log interval (settable to record every
1 to 1800 seconds).
When the Device is turned on and in RATE or MAX mode, the current
radiation reading and other log data is recorded at the set interval.
In SCALER Mode:
o Auto log will be paused and will only log at the completion of each
count.
o For a continuous Scaler count (Scaler time is 0), logs will be
recorded at auto log interval.
The Data Log Table is linear; once the table is full, no further writes will be
allowed until the Data Log Table is erased.
Note:
Tapping the LOG button will start a count and automatically log
the result. Long-pressing the LOG button during the count will
toggle the display between the timer and reading.
Specifications
Handle mounted LOG button
Real Time Clock (RTC)
Internal Storage of up to 250 32-byte Location IDs
Internal Storage of up to 1000 64-byte Datalog records
Datalog format:
Format Version (1 Byte)
Month (1 Byte)
Year (2 Bytes)
Day (1 Byte)
Hour (1 Byte)
Minutes (1 Byte)
Seconds (1 Byte)
Logged Value (4 Bytes)
Range (1 Byte)
Units (1 Byte)
Ludlum Measurements, Inc. Page 6-4 July 2017
Model 3005 Gamma Survey Meter User’s Manual Section 6
Mode (1 Byte)
Detector Number (1 Byte)
Status (1 Byte)
Reserved (2 Bytes)
Elapsed Count Time in seconds (4 Bytes)
Scaler Count Time in seconds (4 Bytes)
Location ID (32 Bytes)
Ludlum Measurements, Inc. Page 6-5 July 2017
Model 3005 Gamma Survey Meter User’s Manual Section 7
Section
7
Software
Connecting to Software
Most Model 3005 instruments are sent with a standard 2-meter cable. (A 5meter cable can be provided if requested. However, any cable above 2 meters
may have issues with some USB-hubs/computers.)
In order to connect an instrument to the computer, please connect one end of
the USB cable to the instrument first, then the other end to the computer. Do
not connect both ends to the computer.
Please allow Windows® a moment to install the proper HID drivers for the
instrument before trying to use any software.
Note:
We recommend that you plug the USB cable into the back of your
PC that connects to your motherboard instead of a USB hub.
Note:
Some parameters may only be edited in software, such as the
backlight thresholds, COUNT Display Mode, COUNT Audio
Mode, and Setup prtct.
Ludlum Measurements, Inc. Page 7-1 July 2017
Model 3005 Gamma Survey Meter User’s Manual Section 7
Extended Features
This section describes features that have been added to the firmware since the
last software release. If the version of your Lumic Calibration Software is higher
than 1.1.0.4, these parameters may have been moved to the Device tab.
Device Count DisplayMode
0 - timer active only (default selection).
1 – toggle between timer and the current reading.
2 - current reading only.
Device Count AudioMode will enable\disable click audio during a COUNT.
0 – Disabled (Mute icon will always be illuminated in COUNT
mode.)
1 – Enabled
Device RateResetBtn
0 disabled
1 enabled
Device Setup Prtct
Normal
Bypass Alarms
Bypass Alarms Count
Ludlum Measurements, Inc. Page 7-2 July 2017
Model 3005 Gamma Survey Meter User’s Manual Section 8
Section
8
Safety Considerations
Environmental Conditions for Normal Use
Indoor or outdoor use (While rain resistant, user is cautioned to avoid
getting water through detector opening.)
No maximum altitude
Temperature range of -40 to 65 °C (-40 to 150 °F)
Maximum relative humidity of less than 95% (non-condensing)
Pollution Degree 3 (as defined by IEC 664): (Occurs when conductive
pollution or dry nonconductive pollution becomes conductive due to
condensation. This is typical of industrial or construction sites.)
Not certified for use in an explosive atmosphere
Warning Markings and Symbols
Caution!
The operator or responsible body is cautioned that the
protection provided by the equipment may be impaired if the
equipment is used in a manner not specified by Ludlum
Measurements, Inc.
The Model 3005 Background Survey Meter is marked with the
following symbols:
CAUTION (per ISO 3864, No. B.3.1): designates hazardous live voltage
and risk of electric shock. During normal use, internal components are
hazardous live. This instrument must be isolated or disconnected from the
hazardous live voltage before accessing the internal components. This
symbol appears on the side panel. Be sure to take the precautions noted in
the next section whenever necessary.
Ludlum Measurements, Inc. Page 8-1 July 2017
Model 3005 Gamma Survey Meter User’s Manual Section 8
The “crossed-out wheelie bin” symbol notifies the consumer that the
product is not to be mixed with unsorted municipal waste when discarding.
Each material must be separated. The symbol is placed on the label located
on the side panel. See section 9, “Recycling,” for further information.
The “CE” mark is used to identify this instrument as being acceptable for
use within the European Union.
Cleaning and Maintenance Precautions
The Model 3005 may be cleaned externally with a damp cloth, using only
water as the wetting agent. Observe the following precautions when
cleaning or performing maintenance on the instrument:
1. Turn the instrument OFF and remove the batteries.
2. Allow the instrument to sit for one minute before cleaning the
exterior or accessing any internal components for maintenance.
Ludlum Measurements, Inc. Page 8-2 July 2017
Model 3005 Gamma Survey Meter User’s Manual Section 9
Section
9
Revision History
NOTE: This section of the manual will be updated with each revision of the Model
3005 in order to document changes over time. Ludlum Measurements’ policy is to
provide free software upgrades to instruments for the life of the instrument.
July 2017: Deleted Loss of Count Alarm Protection in Specs on page 3-1
because Zero Protection covers the same thing in more detail, added 3005/3
and 3005/4 values to table on page 4-2, added Advanced Features section as
Section 5.
June 2017: Added the Model 3005/3, Updated Section 6 to include Extended
Features, added Section 10 Options.
April 2017: Updated response times in table on page 4-14.
February 2017: New manual.
December 2016: Draft manual.
Ludlum Measurements, Inc. Page 9-1 July 2017
Model 3005 Gamma Survey Meter User’s Manual Section 10
Section
10
Recycling
Ludlum Measurements, Inc. supports the recycling of the
electronics products it produces for the purpose of protecting the
environment and to comply with all regional, national, and international
agencies that promote economically and environmentally sustainable
recycling systems. To this end, Ludlum Measurements, Inc. strives to supply
the consumer of its goods with information regarding reuse and recycling of
the many different types of materials used in its products. With many
different agencies – public and private – involved in this pursuit, it becomes
evident that a myriad of methods can be used in the process of recycling.
Therefore, Ludlum Measurements, Inc. does not suggest one particular
method over another, but simply desires to inform its consumers of the range
of recyclable materials present in its products, so that the user will have
flexibility in following all local and federal laws.
The following types of recyclable materials are present in Ludlum
Measurements, Inc. electronics products, and should be recycled separately.
The list is not all-inclusive, nor does it suggest that all materials are present in
each piece of equipment:
Batteries Glass Aluminum and Stainless Steel
Circuit Boards Plastics Liquid Crystal Display (LCD)
Ludlum Measurements, Inc. products that have been placed on the market
after August 13, 2005, have been labeled with a symbol recognized
internationally as the “crossed-out wheelie bin,” which notifies the consumer
that the product is not to be mixed with unsorted municipal waste when
discarding. Each material must be separated. On the Model 3005, the symbol
will be placed on the serial number label located on the side of the
instrument.
The symbol appears as such:
Ludlum Measurements, Inc. Page 10-1 July 2017
Model 3005 Gamma Survey Meter User’s Manual Section 11
Section
11
Options
Lumic Calibration Kit (part # 4498-1018): The kit includes calibration software plus the
cable required for calibration. The software allows users to collect data and read, print, and
save device parameters. It allows administrators to adjust device parameters from one device
to another.
Lumic Datalogging Kit (part # 4498-1019): The kit includes datalogging software plus the
required cable. The software allows users to collect data and read, print, and save device
parameters. It allows administrators to adjust device parameters from one device to another.
Headphone Option (part # 4498-555): This provides the Model 3000 series of
instruments with a jack and circuitry required for a standard headphone plug. Ludlum
Measurements also offers mono/stereo headphones with volume control.
Shoulder Strap (part # 4498-868): This adjustable, padded strap comes with a kit to attach
it to a Model 3000 series instrument.
Protective Storage/Transport Case (part # 2312958): This is a medium-sized, foampadded, rugged case that can be secured with a padlock. It is fitted with a manual pressure
relieve valve for air transport, providing water and dust-proof protection for sensitive
instruments.
Ludlum Measurements, Inc. Page 11-1 July 2017
Model 3005 Gamma Survey Meter User’s Manual Appendix A
•
0.1
1
10
10 100 1000 10000
Normalized to Cs-137
Gamma Energy (keV)
Energy Response for
LMI Model 3005 Relative to Cs-137
Cs-137
Appendix
A
Energy Response
Ludlum Measurements, Inc. Page A-1 July 2017
Loading...
