Lucent Technologies 8410D, 8411D, 8405D PLUS, 6408D PLUS, 6424D PLUS User Manual

...
USING THE NEW ABBREVIATED DIALING
PROGRAM FEATURE
For Users of the Following Display Telephones:
8405D, 8405D Plus, 8410D, 8411D, and 8434DX Voice Terminals AND 6408D Plus, 6416D Plus, and 6424D Plus Telephones
Connected to a DEFINITY® ECS and/or PROLOGIX™ Release 6.3 or later
555-233-705
Issue 2, June 1999

Introduction

Beginning with Release 6.3 of the DEFINITY® ECS and/or PROLOGIX™
software, the following enhancements have been made to the Abbreviated Dialing (AD) Program feature:
Messages appear on the display to step you through the programming procedure. When you program a softkey, you can also program a label of up to five characters that will appear on the display directly above it.
To be programmable for abbreviated dialing, a button, whether it is a softkey or a hardkey (feature button), must be administered for the Abbreviated Dialing feature. You can use the Button View feature to find the Abbreviated Dialing buttons on your set. (To do this, select BtnV u from the softkey menu; then press the button you want to check.)
NOTE: If the speaker on your set has been deactivated, this feature will not work as described below. See your system manager to activate your speaker.
Programming an Abbreviated Dialing button on Softkeys (the four buttons immediately below the display
CFrwd CPark Prog AD8
These are the four softkeys
NOTE: If you make a mistake while programming, you CANNOT move back a space to erase it. Instead, save whatever you have entered by pressing the “#” key and start over.
1. Enter Programming mode. (To do this, press the button labeled Prog, if your set has one, or select Prog from the softkey menu by pressing the Menu button, then the Nex t or Prev button, if necessary, until you see Prog on the display . Then press the softkey below Prog.)
Your telephone w il l go o ff-h ook, a nd the light next to will see the message,
NOTE: If you do not see this message once you have entered Programming mode, your telephone is probably NOT connected to a Release 6.3 switch. For help, contact your system manager.
2. Select the softkey/feature button you wan t to program. (To do this, press the Menu button again, then press Next or Prev, if necessary, until you see the label of the softkey you want on the display; then press the softkey below that label.)
You will see the message,
3. If you want to enter a new number or change an existing number , pr ess t he “1” key on the dial pad and continue with Step 3A. If you do not want to change the number, press the “2” key and skip to step 3B.
Press button to program
Change number? Yes=1 No=2
)
Spkr
will go on. You
on the display
on the display.
.
1
3A.
You will see the message
number you want that button to call. See the “Helpful Hints” section on the last page for information on the numbers you can enter.
When you have finished entering the number, press the “
Enter number:
on the display.
#” key.
Enter the
You will hear the confirmation tone (three beeps), and you will see the message
Change label? Yes=1 No=2. Skip to Step 4. — 3B.
Continue with Step 4.
4. If you want to change the label f or that sof t key, press the “1” key on the dial pad and continue with Step 4A. If you do not want to change the label, press the “2” key and skip to Step 4B.
4A. pad to enter the label you want, up to five characters. (Pressing a dial pad key once enters the first letter on the key; if you want a different letter or the number, press the key repeatedly until the character you want appears on the display .) If the next letter of the label is on the same dial pad key, press the “
When you have finished entering the label, press the “
Number saved
You will see the message
You will see the message
” key to advance to the next space.
*
for one second and then the message
Change label? Yes=1 No=2.
Enter label
on the display.
Use the dial
#” key.
You will hear the confirmation tone (three beeps), and you will see the message
update display program. If you want to program another button, go back to Step 2;
otherwise, skip to Step 5. NOTE: When you program a label, it does not appear on the display until
you hang up. — 4B.
program another button, go back to Step 2; otherwise, continue with Step 5.
5. To exit from Programming mode, hang up your telephone. (T o do t his, press the Speaker button or lift the handset and then put it back.)
Note: Pressing the Exit button does not exit you from Programming mode.
Label saved
You will see the message
for one second, then the message
for two seconds and then the message
Press button to program. If you want to
Hang up to
Press button to
Programming Abbreviated Dialing on hardkeys (feature buttons) (the buttons next to paper label strips such as )
NOTE: If you make a mistake while programming, you CANNOT move back a
space to erase it. Instead, save whatever you have entered by pressing the “#” key and start over.
1. Enter Programming mode. (To do this, press the button labeled Prog, if your set has one, or select Prog from the softkey menu by pressing the Menu button, then press Next or Prev, if necessary, until you see Prog on the display , and then press the softkey below Prog.)
Your set will go of f-hook, and the light next to the You will see the message
Press button to program
Jim x1234
Speaker
button will go on.
on the display.
2
NOTE: If you do not see this message once you have entered Programming m ode,
your telephone is probably NOT connected to a Release 6.3 switch. For help, contact your system manager.
2. Select the hardkey (feature button) you want to program. (To do this, press the button.)
3.
You will see the message
you want that button to call. See the “Helpful Hints” section below for information on the numbers you can enter.
When you have finished entering the number, press the “
Enter number:
on the display.
Enter the number
#” key.
You will hear the confirmation tone (three beeps), and you will see the message
ton to program. If you want to program another button, go back to Step 2; otherwise,
continue with Step 4. NOTE: When you have changed the number called by a hardkey, you may
want to change its label on the paper strip too.
4. T o exi t from Programming mode, hang up your telephone. (To do this, press the Speaker button, or lift the handset and then put it back.)
NOTE: Pressing the Exit button does not exit you from Programming mode.
Number Saved
for one second and then the message
Press but-

Helpful Hints

If the number you are entering for an Abbreviated Dialing button is an out­side number, be sure to include any applicable trunk codes, for example, a “9.”
Numbers programmed on softkeys may be up to 24 digits in length; numbers programmed on hardkeys (feature buttons) may be up to 16 digits if the hardkey will be used as an auto-dial button or up to 24 digits if associated with a list. If you need help. see your system manager.
Special functions such as Pause, Mark, and Wait, may be available on your softkey menu; if so, they can be inserted in the numbers you program. These functions may be accessed during programming by pressing the Menu button.
You can enter feature access codes on Abbreviated Dialing buttons instead of telephone numbers so that the button initiates a feature rather than placing a call.
Prepared by Copyright © 1999 BCS Product Publications Lucent Technologies
Middletown, NJ 07748-1998 Printed in USA
