Document #: 555-660-134
Comcode: 108196197
Issue 1, February 1998
MERLIN LEGEND
®
Communications System
MLX Direct-Line Consoles
Operator’s Guide
Contents
Your MERLIN LEGEND MLX Direct-Line Console ........................................................... 1
Describes phone buttons and screens
Understanding Your DSS ....................................................................................... 2
DSS Buttons, DSS Button Lights
Understanding Your Direct-Line Console ................................................................ 3–4
Line Buttons, Line Button Lights, Tones, Rings
Feature Finder ................................................................................................ 5–7
Use to choose the right feature for the activity you want to perform.
Headsets .......................................................................................................... 8
Call Handling ............................................................................................... 9–10
Answering Calls, Making Calls, Hold, Conference, Transfer
Messaging .................................................................................................. 11–14
Send/Remove Message, Reminders .................................................................... 12
Signaling & Notify, Receiving Messages .............................................................. 13
Leaving Messages, Posting Messages ................................................................. 14
Directories ..................................................................................................... 15
Extension & System Directory, Personal Directory
Using Features ................................................................................................ 16
Display-Only Features, Other Features, Feature Codes
Often-Used Features ..................................................................................... 17–24
Account Codes, Alarm, Alarm Clock & Timer ......................................................... 17
Authorization Codes, Auto Dial .......................................................................... 18
Barge-In, Callback & Line Request ..................................................................... 19
Call Waiting, Camp-On, Coverage ...................................................................... 20
Direct Voice Mail, Do Not Disturb, Extension Status (Hotel/Motel), Last Number Dial ....... 21
Forward & Follow Me, Night Service, Paging ........................................................ 22
Park, Park & Pickup ....................................................................................... 23
Pickup, Privacy, Saved Number Dial, System Speed Dial, Voice Announce .................... 24
Display Reference ........................................................................................ 25–26
Notes ............................................................................................................ 26
Use these forms to keep track of information about your phone and system.
Programming Buttons & Settings ...................................................................... 27–28
Display Programming, Code Programming ............................................................ 27
Programming Codes ....................................................................................... 28
Security Alert
Your Responsibility for Your System’s Security␣
Toll fraud, the unauthorized use of your telecommunications system by an unauthorized party (for example,
persons other than your company’s employees, agents, subcontractors, or persons working on your
company’s behalf) can result in substantial additional charges for your telecommunications services. You
are responsible for the security of your system. There may be a risk of toll fraud associated with your
telecommunications system. Your system administrator should read all installation, instruction, and
system administration documents provided with this product to fully understand the features that can
introduce the risk of toll fraud and the steps that can be taken to reduce that risk. Lucent Technologies
does not warrant that this product is immune from or will prevent unauthorized use of common-carrier
telecommunication services or facilities accessed through or connected to it. Lucent Tecnologies will not
be responsible for any charges that result from such unauthorized use.
Your MERLIN LEGEND MLX Direct-Line Console
Unlabeled Display Buttons
Press one to select the item next to or above it on the display.
Home
Menu
More
Inspct
7 Lines
24 Characters
Your Display Screen
Your telephone’s display is an alarm clock and timer (see p. 17), a
telephone directory (see p. 15), and a message center (see pp.
11–14). Read the button descriptions on this page to find out how
you can use your screen to locate and activate features or see who’s
calling you. If you have a 2-line display, abbreviations are used on
the screen. These are explained in Display Reference, pp.
25–26, as are the four display screens.
Volume
Press or to change the ringer loudness while the
phone is ringing, the handset volume while you’re using
the handset, or the speaker volume while you're using the
speakerphone.
Feature
Press to display the Feature screen and select features.
HFAI
(Hands Free Answer on Intercom) Press before calls come in to
answer voice-announced calls without lifting the handset.
Mute
Press to turn the speakerphone microphone on or off so
that you can or cannot be heard by the caller.
V
V
1
Home
Press to return to the Home
screen and exit the current
activity. The Home screen
gives calling and timekeeping information, and
prompts when you need help.
2 Lines / 24 Characters
Home Menu Inspct More
Volume
Feature Transfer
HFAI Conf
Mute Drop
Speaker Hold
User Card Tray
Pull out for quick reference.
Line Buttons
ABC DEF
123
JKLGHI MNO
456
PQRS WXYZ
TUV
789
OPER
0#
*
Hold
Press to put a call
on hold (see p. 10).
Speaker
Press to turn the speakerphone on/off
for hands-free conversation during a
call or when a call rings; or press to
hang up a speakerphone call.
TEL/OTHER Jack (underside) On MLX-10DP™, MLX-16DP™, MLX-20L®,
and MLX-28D® telephones is a connection for a Multi-function Module.
Menu Press to program the phone, view messages, or select features available only from the display. (See More below.)
DSS Jack (underside) Used on MLX-20L and
MLX-28D telephones for connecting a DSS or a
PassageWay™ Direct Connect Solution or
PassageWay Solution.
Inspct
Press Inspct and a line button to display information
about the current call or a ringing call or to see
what feature is programmed on that button.
More
The > appears on the screen when more information
exists. Press More to advance through additional
menus or to display more information about the
current call or a ringing call.
Line Buttons
Outside, SA, and ICOM buttons (see p. 3); blank line
buttons can be programmed with features (see p. 27).
• MLX-28D telephone (shown) has 28 line buttons
• MLX-20L telephone has 20 line buttons
Message
Message Light
The red light is lit to indicates a waiting message
(see pp. 11–14).
Transfer
Press to send a call to another phone
(see p. 10).
Conf
Press to add a person to a conference (see p. 10).
Drop
Press Drop and a line button to disconnect a
person from a conference call (see p. 10).
!
CAUTION:
To clean your phone, unplug it from the wall jack and
use a
slightly
damage, do not immerse the phone in water or other
liquid, and do not use liquid or aerosol cleaners directly
on the telephone.
dampened cloth. To prevent permanent
Understanding Your DSS
Fixed Page Buttons
Press the fixed Page buttons to change the
of telephone numbers accessible to your DSS. The
green light turns on next to the Page button that
is active. If you have one DSS, Page 1 accesses
the first 50 extensions, Page 2 accesses the
second 50 extensions, Page 3 accesses the third
50 extensions. If you have two DSSs, Page 1
accesses the first 100 extensions, Page 2
acccesses the second 100 extensions, Page 3
accesses the third 100 extensions.
Message Status Button
When Message Status is on, the red lights next to the
DSS buttons turn on for extensions with messages
from system operators. Messages from other sources
(such as co-workers and fax machines) do not cause
the red lights to turn on. The green light next to the
Message Status button turns on when the button is
pressed to tell you that the lights on the DSS are
showing Message Status. Pressing the button again
turns off Message Status and the green light.
page
2
DSS Buttons
Each DSS has 50 DSS buttons, arranged in five columns of 10 buttons each.
DSS buttons have numbers assigned in consecutive order, starting with the
top left corner button. Each button can have three numbers assigned to it, which
00
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
30
31
32
33
34
40
41
42
43
44
can correspond to the following:
• Extension numbers for transferring or making calls to co-workers (see
pp. 9–10)
• Paging numbers for paging co-workers over speakerphones or a
loudspeaker system (see p. 22)
• Numbers for parking calls to the system operator park zones (see p. 23)
• Pools and lines for monitoring the pools’ current status
25
26
27
28
29
35
36
37
38
39
45
46
47
48
49
Reserved buttons
These buttons are reserved for future use.
- DSS Button Lights -
Light Button/Meaning
Off Extensions. The phone is not in use and Do Not Disturb is off. With the Message
Status button, the Message light is off at the extension.
Pool. One or more lines in the pool are available.
Line. Not in use. (available)
Group Page, Page All, Park Zone. Not in use. (available)
Calling Group. The number of calls waiting for calling group are fewer than the
programmed maximum.
Steady Extensions. A co-worker is on phone, available on hold, or Do Not Disturb is on.
With the Message Status button, the Message light is on at the extension.
Pool. All lines in the pool are busy.
Line. In use. (not available)
Group Page, Page All. In use. (not available)
Calling Group. The number of calls waiting for the calling group is equal to or
more than the programmed maximum.
Fast flashing Extensions. A co-worker is calling you, or a parked call or call on hold is returning
to you.
Line. A directed, parked, or held call is returning to you.
Slow flashing Extensions. A call directed to this extension is returning to you.
Line. A call is ringing on this line at your console or at a co-worker’s phone.
Understanding Your Direct-Line Console
␣Line Buttons␣
All Telephones
NNN-XXXX
Telephones with ICOM Buttons
ICOM Ring Make/receive inside calls
ICOM Voice Make inside voice-
ICOM Originate Make (not receive) inside
Only calls only.
Make/receive outside calls
only.
and receive inside voiceannounced calls.
announced calls and receive
inside ringing and voiceannounced calls.
Telephones with System Access (SA) Buttons
SA buttons give you access to inside or outside
lines for making and/or receiving calls. To make
an outside call on an SA button, first dial the
dial-out code (usually 9) that your system
manager supplies. No dial-out code is
necessary when you call another extension.
SA Ring Make/receive inside/outside
ringing calls and receive inside
voice-announced calls.
SA Voice Make/receive outside calls,
receive inside ringing and
voice-announced calls, make
inside voice-announced calls.
SA Originate Make (not receive) inside and
Only outside calls.
␣Line Button Lights␣
Light Meaning
Steady red The line you are using or will use when you lift the handset or
Steady green The line is in use, or the feature programmed onto the line
Flashing green An incoming call is ringing on this line button or a call you
press the Speaker button.
button is on.
transferred is returning to this line button (see p. 10).
Fast-flashing green You have put a call on hold on this line button.
Slow-flashing green Someone else has put a call on hold on this line button.
3
Understanding Your Direct-Line Console
␣Tones␣
Tone Meaning
Dial tone (steady) You can make a call.
Busy (slow repeating tone) The phone you are calling is busy.
Fast busy (fast repeating tone) No lines are available.
Error (alternating high-low tones) You dialed a number or used a feature incorrectly.
Confirmation (double break in You used a feature correctly.
dial tone followed by steady tone)
Callback (5 short beeps) This call is receiving Callback treatment (p. 19).
Call Waiting (1 or 2 beeps) You have an inside (1 beep) or an outside
␣Rings␣
The table below helps you identify the different types of ringing. You can also personalize ringing at
your telephone or adjust ring timing for the line buttons where calls arrive. Programming Buttons
& Settings, p. 27, tells you how to change the settings. Listed below are your options:
• Personalized Ring. Allows you to give calls ringing at your phone one of eight
distinctive rings.
• Abbreviated Ring. When you are on a call and another call arrives at your phone, you can use
this feature to give the second call a short ring.
• Immediate Ring. Calls ring immediately on line buttons set this way.
• Delay Ring. This setting causes calls to ring at your phone after a delay. If your calls are being
covered, this allows time for another person to answer a call before you do.
• No Ring. Calls do not ring (except for returning transferred and Callback calls). Calls on lines
set for No Ring do not receive Coverage (p. 20).
(2 beeps) call waiting (p. 20).
Ring Meaning
1 long ring Inside call
1 long ring and 1 short ring Outside call
1 long ring and 2 short rings Priority ring; outside call transferred to you or
1 long ring and 3 short rings Returning Callback call (p. 19)
returning camped-on call (p. 20)
4
Feature Finder
This table shows where to look for information about performing specific telephone activities. Any
features that do not have detailed instructions can be used by following the directions in Using
Features (p. 16) or programmed by following the instructions in Programming Buttons &
Settings (p. 27).
Calling
If you want to ... Then
Dial numbers with the touch of a button. See Auto Dial, p. 18.
Quickly dial numbers your company has programmed. See System Speed Dial, p. 24.
Make a voice-announced call to one or more See Line Buttons, p. 3, and Paging, p. 22.
co-workers.
Make a call after office hours. See Night Service, p. 22.
Make and answer calls with no hands. See HFAI button, p. 1, to answer inside calls
Automatically redial a number you dialed before. See Last Number Dial, p. 21, and Saved
Quickly dial numbers from your phone’s display. See Directories, p. 15.
Connect to an extension or outside line when it’s free. See Callback & Line Request, p. 19.
Enter an account code before or during a call. See Account Codes, p. 17.
Set up a conference with as many as four others. See Conference, p. 10.
Transfer a call. See Transfer, p. 10.
Put a call on hold. See Hold, p. 10.
Interrupt a co-worker’s call in an emergency. See Barge-In, p. 19.
Broadcast over the company’s loudspeaker system. See Paging, p. 22.
Put a call on hold and page a co-worker to pick it up See Park & Pickup, p. 23, and Paging, p. 22.
at another telephone.
Know if someone is calling you when all your other See Call Waiting, p. 20.
lines are in use.
Reach a voice mailbox without calling the person. See Direct Voice Mail, p. 21.
Make a call from another extension, using your own See Authorization Codes, p. 18.
calling privileges.
hands-free. For information about headsets,
see p. 8.
Number Dial, p. 24.
5
Feature Finder
Customizing Your Phone
If you want to ... Then
Program a feature on an unused line button. See Programming Buttons & Settings, p. 27.
Adjust volume of the speaker, handset, or ringer. Use the Volume button, p. 1.
Give your phone its own distinctive ring. See Rings, p. 4.
Delay or remove the ring from an outside, SA, or See Rings, p. 4, and Coverage, p. 20.
ICOM line button.
Change your phone’s display language. Use the Language feature. See Using Features,
p. 16.
Covering Calls
Have a co-worker answer your calls. See Coverage, p. 20, and Line Buttons, p. 3.
Answer all of a co-worker’s calls from your telephone.
Stop your calls from being covered by others.
Stop your outside calls from going to your company’s See Coverage, p. 20.
voice mail system (or send your calls to voice mail).
Forward your calls to another telephone. See Forward & Follow Me, p. 22.
Answer your calls from another extension.
Answer a call ringing at a co-worker’s extension. See Pickup, p. 24.
Answer a call on a line that’s not on your phone.
Put a call on hold at a busy extension untill your If your company does not have voice mail, see
co-worker is ready for it or complete a transfer Camp-On, p. 20.
to an extension that doesn’t answer.
Hold a call when you’re trying to transfer it and your See Park & Pickup, p. 23.
co-worker doesn’t answer; page your co-worker while
the caller waits.
Handling Console Basics
Monitor the status of other extensions in your system. See Extension Status, p. 21. If you supervise a
calling group, ask your system manager for the
Calling Group Supervisor’s Guide
.
Set up your system to cover outside calls after See Night Service, p. 22.
business hours.
Respond to a system alarm. See Alarm, p. 17.
Set a wake-up call. See Reminders, p. 12.
6
Feature Finder
Messaging
If you want to ... Then
Let a co-worker know you called. See Messaging, p. 11–14.
Find out if you have a voice mail message, fax, or
other message.
Signal a co-worker to contact you.
Choose a message to leave for co-workers who have
display phones.
Call or transfer a call directly to a co-worker's voice See Direct Voice Mail, p. 21.
mail.
Privacy
Prevent interruptions by blocking calls to your phone. See Do Not Disturb, p. 21.
Prevent co-workers from joining your calls. See Privacy, p. 24.
Prevent others on a call from hearing you speak to Try the Mute button, p. 1. If you have a headset,
someone in your office. use the Headset/Handset Mute feature, p. 8.
See who’s calling you while you’re on the phone. Use the Inspct button, p. 1.
Receive or not receive voice-announced calls. See Voice Announce, p. 24.
Timekeeping
Remind yourself or co-workers of meetings or See Alarm Clock & Timer, p. 17, and
appointments. Reminders, p. 12.
Keep track of the duration of calls or meetings.
Change the time, day, or date on your display.
7
Headsets
Headsets for MLX telephones allow one-touch
operation, hands-free. Headsets consist of a
headpiece and modular base unit. The base unit
plugs into the handset jack.
Touch a button to answer a call, then touch it
again to disconnect. Use the features below to
control headset operation.
A calling group agent using a headset must press
the Headset Hang Up button to complete a call
in order to update the supervisor’s Agent button.
␣Headpieces␣
®
Mirage
StarSet
Supra
Supra Monaural Noise-Canceling (NC). Same as above with noise-canceling microphone that
reduces background noise transmission by up to 75%.
Supra Binaural. Sound in both ears.
Supra Binaural Noise-Canceling (NC). Same as above with noise-canceling microphone on
flexible boom; features windscreen and reduces background noise transmission by up to 75%.
. Receiver fits over either ear. Not for noisy environments.
®
. Eartip fits in ear canal.
®
Monaural. Adjustable headband and soft ear cushion.
Headpiece
Modular Base Unit
Handset Jack
Hom
e
V
o
l
u
m
e
F
e
a
t
u
r
e
T
r
a
n
s
f
e
r
H
F
A
I
1
A
B
C
o
C
n
f
M
2
u
G
t
e
H
I
4
J
D
K
r
o
L
p
S
p
e
a
5
P
k
Q
e
r
R
M
S
N
O
7
6
T
H
o
U
l
d
V
8
W
X
Y
Z
O
9
p
e
r
0
#
M
e
nu
Ins
pc
t
M
o
ve
D
E
F
M
e
s
s
3
a
g
e
␣Headset Features␣
Must be programmed on buttons. To program:
See Programming Buttons & Settings, p. 27.
There are four features used with headsets: Headset Hang Up, Headset Status, Headset Auto Answer,
and Headset/Handset Mute. All must be programmed on buttons. The Headset Hang Up button
(required) is programmed by your system manager and activates headset operation at your phone.
To use Headset Hang Up:
Press the programmed button to answer a call and press it again to disconnect, even if the caller
hangs up. Unless you have programmed a Headset Status button, headset operation is always on.
To use Headset Status:
Press the programmed button to switch between headset and handset operation; when headset
operation is on, the green light is on.
To use Headset Auto Answer:
Connects you automatically to ringing calls during headset operation. When you press the button to
activate the feature, the green light goes on; to turn off Headset Auto Answer operation, press the
button again.
To use Headset/Handset Mute:
Lets you turn off the microphone in the headset or handset, so that a caller cannot hear your
conversation. The red light goes on when the headset (during headset operation) or the handset
(during handset operation) microphone is off.
8
Call Handling
␣Answering Calls␣
You can answer a call using the handset,
headset, or speakerphone. Different calls have
distinctive ringing patterns. To identify calls by
their ringing patterns see Rings, p. 4.
To answer a ringing call:
Lift the handset, press the Speaker button, or
use the headset. If the red light is off next to
the line with the incoming call (flashing green
light), you must press the button next to the
flashing green light first.
To answer a voice-announced call:
If Mute is on (green light next to it is lit), press
the Mute button to turn Mute off. Lift the
handset or use the headset (see Headsets,
p. 8). If the HFAI button is on (the green light
next to it is lit), voice-announced calls are
answered automatically on the speakerphone.
␣Making Calls␣
Lifting the handset or pressing the Speaker
button connects you to a free line automatically.
When using a headset (see p. 8), select a line
button first.
To make an inside ringing call:
1. If the red light next to the SA Ring/ICOM
Ring button you want to use is not lit or if
you are using a headset, press the button.
2. Lift the handset, press the Speaker button,
or use the headset (see Headsets, p. 8).
3. Press a DSS or Auto Dial button, or dial
the number for the extension you want to
call.
To make an inside voice-announced call:
1. If the red light next to the SA Voice/ICOM
Voice button you want to use is not lit or if
using a headset, press the button.
2. Lift the handset, press the Speaker button,
or use the headset (see Headsets, p. 8).
3. Press a DSS or Auto Dial button, or dial
the number for the extension you want to
call. When you hear a beep, begin talking.
If you hear a busy tone, the person is
unavailable. If you hear ringing, the person
cannot receive a voice-announced call but
may be able to answer your call as a ringing
call.
To make an outside call:
1. If the red light next to the line button or
SA button you want to use is not lit or if you
are using a headset, press the button.
2. Lift the handset, press the Speaker button,
or use the headset (see Headsets, p. 8).
3. Listen for a dial tone and dial the telephone
number (include the dial-out code, if necessary), or press the outside Auto Dial
button.
4. If you are making the call for a co-worker,
transfer the call as described in Transfer,
p. 10.
Note:
For more information about programming
Auto Dial buttons, see p. 18.
9
Call Handling
␣Hold␣
When you have a call or conference on hold,
your phone beeps once each minute and the
display briefly shows
1. Press the Hold button to put a call on hold.
not
press the Drop button to end a
Do
conference while the call is on hold.
2. To return to the call or conference, press the
flashing ICOM, SA, or line button that is
holding the call.
Call on Hold
.
␣Conference␣
A conference call can have up to three inside
participants, including yourself, and up to two
outside participants.
1. Dial the first outside number or extension.
Announce the call.
2. Press the Conf button to put the call on
hold.
3. Select an ICOM, SA, or numbered line
button.
4. Dial the next number or extension.
5. Announce the call and press the Conf
button.
6. Repeat Steps 2–5 for each participant.
• Press the Drop button and line button to
drop any participant added.
• Press the Hold button to temporarily
leave the conference. Then press any
participant’s line to rejoin the conference.
7. To end the conference, hang up.
␣Transfer␣
Ask your system manager whether your system
is programmed for one-touch transfer with
automatic completion. For information about
Auto Dial buttons, see p. 18. If your
co-worker is unavailable, consider using
Barge-In (p. 19), Paging (p. 22), Park (p. 23),
or Camp-On (p. 20).
To transfer a call with one-touch transfer and
automatic completion:
Press the DSS or Auto Dial button for the
co-worker to receive the call. You do not
announce the call.
To transfer a call with one-touch transfer
without automatic completion:
1. Press the DSS or Auto Dial button for the
co-worker to receive the call.
2. Announce the call and hang up.
To transfer a call without one-touch transfer or
automatic completion:
1. Press the Transfer button.
2. Press the DSS or Auto Dial button or dial
the extension for the co-worker to receive
the call.
3. Announce the call and hang up.
!
SECURITY ALERT:
If the system selects an SA Voice button
when you add a conference participant, you
hear a beep instead of ringing after you dial
the extension. If the call is not answered and
you press the Conf button to complete the
call, your conversation with other conference
participants is broadcast on that extension’s
speakerphone. To prevent this, be sure to
drop an unanswered extension that you’ve
called on an SA Voice button.
10
Messaging
Your phone system has several features that allow you to leave messages for others in your office. If you
use Leave Message or Posted Messages, the person(s) for whom you are leaving a message must have a
display phone. If you wish to leave a message for a person who does not have a display telephone, use
voice mail and the Direct Voice Mail feature, if available, or Send/Remove Message. Here are some
guidelines for different messaging features:
•Leave Message. This feature simply lets a co-worker know you have called. The message shows
your name and the date and time of your call. If you leave one message and then another, the second
message replaces the first.
•Posted Messages. If you post a message at your telephone, inside callers with display phones see
the posted message you have selected. As many as 20 messages may be available for posting.
When a message is waiting for you, your red Message light is lit. The descriptions below explain how to
read, cancel, and delete messages you have sent or received.
If your company has voice mail, ask your system manager for details about using the voice mail system.
For information about having your phone covered by the voice mail system, see Coverage, p. 20.
If you frequently communicate with a small number of people (for example, as a receptionist for a few
co-workers), there are two features you can use, both of which require programming a button. These are
Signaling and Notify, described on p. 13.
␣Messaging Features Table␣
If you want to ... Then
Let a co-worker with a display phone know you called. See Leaving Messages, p. 14.
Let a co-worker with a nondisplay phone know that See Send/Remove Message, p. 12.
he or she should call you to pick up a message.
Turn off a co-worker’s Message light.
Find out if you have a voice mail message, fax, or See Receiving Messages, p. 13.
other message.
Signal a co-worker to contact you. See Signaling & Notify, p. 13.
Choose a message to leave for co-workers who have See Posting Messages, p. 14.
display phones.
Call or transfer a call directly to a co-worker’s See Direct Voice Mail, p. 21.
voice mail.
Automatically place a ringing call to a phone at a See Reminders, p. 12.
preset time.
11
Messaging
␣Send/Remove Message␣
To program:
See Programming Buttons & Settings, p. 27.
You can turn the Message light at a co-worker’s
extension on or off using a programmed Send/
Remove Message button. This is the only
way you can indicate a waiting message on a
co-worker's nondisplay telephone. Before
using this feature, check to make sure another
operator has not already turned the light on. If
you have a programmed Auto Dial button for
the extension, its red light is on when the
Message light is on. If you have a DSS, see p. 2.
To turn a co-worker’s Message light on or off:
1. Press the Message Status button.
2. Press the programmed Send/Remove
Message button, OR
Press the Feature button and dial 38.
3. Press the DSS or Auto Dial button or dial
the extension for the co-worker with the
message.
4. Press the Message Status button to
return to normal call handling.
␣Reminders␣
To program:
See Programming Buttons & Settings, p. 27.
Use the Reminder feature to automatically place
ringing calls to phones in the system at preset
times.
To set a reminder:
1. Press the programmed Reminder Set
button,
OR
Press the Feature button and dial 81.
2. Press the DSS or Auto Dial button or dial
the number for the extension.
3. Dial a 4-digit time from 0100 to 1259.
4. Dial 2 (A) for a.m. or 7 (P) for p.m.
5. Repeat Steps 2–4 for each additional
extension.
To read reminder messages on a display:
1. Press the programmed Reminder Set
button,
OR
Press the Feature button and dial 81.
2. Press the DSS or Auto Dial button for the
extension, or dial the extension.
3. The display appears as follows:
• Answered reminder call: extension:
time (AM or PM)
• Missed reminder call: extension: X time
(
AM
or PM)
• Reminder set: extension: time (AM or
PM
)
To cancel set and answered reminders:
1. Press the programmed Reminder Cancel
button,
OR
Press the Feature button and dial ✻81.
2. Press the DSS or Auto Dial button for the
extension, or dial the extension.
A Missed Reminder button can be
programmed on your DLC. When you press
the Missed Reminder button, your display
identifies the name and extension of the missed
reminder call, along with the time set for the
reminder. After the messages have been read,
you can use Reminder to resend a reminder
call to an extension. You can clear the missed
reminder by pressing the programmed Missed
Reminder and Reminder Cancel buttons.
A
12
Messaging
␣Signaling & Notify␣
To program:
See Programming Buttons & Settings, p. 27.
Signaling. Program a button that will cause
a co-worker’s phone to beep. The other
person can then call you in response to the
beep. You must program a different line
button for each extension you wish to contact.
To beep the recipient’s phone, just press the
button, and the other phone beeps for as long
as you hold down the button. A programmed
Signaling button also acts as an Auto Dial
button (see p. 18). To dial the extension, lift
the handset or press the Speaker button;
then press the Signaling button.
Notify. This feature simply lights a line
button on the recipient’s phone, providing a
silent message light that alerts the other party
to call you. To use this feature, you must
program a Notify Send button (labeled, for
example, Notify Mary) on your phone
and the recipient must program a Notify
Receive button (labeled, for example, Call
Jim) on his or her phone. Communication
is one-way only, and buttons must be
programmed for each extension you notify.
␣Receiving Messages␣
When your red Message light is on, you have
a message from a co-worker. Messages are
identified by the name or extension of the
caller, along with the time and date the person
called. Depending on how your system is set
up, you may also have a voice mail message
or a fax. A message may be identified in these
ways:
ATT You have a message from another
system operator.
FAX You have a fax.
VMS You have a voice mail message.
EXT Indicates the extension number of the
person who called.
✻ Marks a new message.
To read and respond to messages on your
display:
1. Press the Menu button.
2. Select
3. Choose from:
Messages [Msgs
•
Return Call [Call
or voice mail while reading the message.
•
Next Msg [Next
Delete Msg [Dlete
•
You can have up 10 messages; if there
are 10, no more are accepted.
].
] to call your co-worker
] to see the next message.
] to delete the message.
13
Messaging
These features can be used to send messages to users with display telephones only.
␣Leaving Messages␣
To program:
See Programming Buttons & Settings, p. 27.
To leave a message at a busy or unanswered
extension you are calling:
•Press the Leave Message button you
have programmed,
OR
Press the Feature button; then select
Leave Msg [LvMsg
•To leave a voice mail message (if your
company has such a system), press the
Feature button and dial 56 (see Direct
Voice Mail, p. 21, for details).
A screen display confirms that the message
has been sent, or it alerts you that the message
box is full or the message can’t be sent (for
example, because the called person has no
phone display).
To leave a message without calling:
1.Press the Feature button and dial 53.
2.Dial the extension.
To cancel a message:
1.Press the Feature button and dial ✻53.
2.Dial the extension.
] or dial 25.
␣Posting Messages␣
A posted message appears on the display of
any inside caller who tries to reach you as
long as that person has a display phone.
(You also see the message posted at your
own phone as a reminder.) There may be as
many as 20 messages available to you for
posting. Message 1 is always
DISTURB
choices as:
A MEETING
manager has programmed them.
*; the others may include such
OUT TO LUNCH,OUT SICK, IN
, depending on how your system
To post a message:
1.Press the Menu button.
2.Select
3.Select the message you want to post.
4.Select
5.Press the Home button.
Posted Msg [Post
Depending upon your phone, you can
choose
Next, Prev
button to see more messages.
Post
, or press the More
.
To cancel a posted message:
1.Press the Menu button.
2.Select
3.Select
4.Press the Home button.
*
Posted Msg [Post
Cancel [Cancl
If you use the Do Not Disturb feature (p. 21),
the appropriate message is posted. When you
turn off the Do Not Disturb feature, the posted
message is canceled. However, posting or
canceling the message does not activate or
deactivate the feature.
DO NOT
].
].
].
14
Directories
␣Extension & System Directory␣
Check with your system manager to find out
whether these directories have been programmed. The System Directory dials outside
numbers that people in your company call
often. The Extension Directory dials inside
numbers.
1. Press the Menu button.
2. Select
3. For the Extension Directory, select
4. Select the entry.
5. Press the Home button to exit.
Directory [Dir
].
Ext Dir
[
ExtDir
],
OR
For the System Directory, select
[
SysDir
].
•
On MLX-20L telephones:
a) Select the range of letters that includes
the first letter of the listing you want. If
there are no listings available for the
range, you hear a beep.
b) View other listings by selecting either
Prev Page
c) If you want to check the number, select
Show Number
next to the listing. Select
Number
numbers.
d) To dial a number, press the button next
to the listing.
•
On MLX-28D telephones:
a) Use the dialpad to spell the name and
then select
b) View other entries that match what you
entered by selecting either
Next
c) To call the number, select
d) Select
the dialpad to spell the name and then
select
or
Next Page.
and press the button
again to stop viewing
Enter
.
.
New
to find another entry. Use
Enter
.
System Dir
Show
Prev
Dial
.
or
␣Personal Directory␣
On MLX-20L telephones only, this feature
stores up to 50 phone numbers (as well as
account codes, area codes, and access codes),
then dials those numbers when you wish. You
can enter, change, select, dial, and delete
listings from the display. You can place oftenused listings on the Home screen.
When entering or changing names, use the
screen to select letters A–F; use the line
buttons, as labeled on the faceplate, to enter
G–Z. Select
punctuation marks. You may need to use
special characters (see outside back cover)
when entering dialing sequences. Include
dial-out codes, if needed.
The screen guides you through Personal
Directory activities, so the steps are summarized here. Press Home to stop the activity.
Bold type shows the button you press;
indicate a screen selection.
To enter a listing:
Menu→
New
number→
To assign a listing to the Home screen:
Menu→
Home
Select location on the Home screen→Home
To dial a listing on the Home screen:
Home→Press a line or SA button→Select
listing
To dial a listing not on the Home screen:
Home→
range→Press a line or SA button→Select
listing
To verify a stored phone number, use the steps
above to display the letter range, and:
Show Number
To delete a listing:
Menu→
Entry
Delete
To change a listing:
Menu→
Entry
listing→Select part of listing to change→Enter
new information→
Punctuation
to use the displayed
Directory→Personal Dir→Enter
→ Type name→
Enter→Yes
Enter
→Type
or
No→Enter
→Home
Directory→Personal Dir→Put on
→Select letter range→Select listing→
Next Page→Next Page
→Select listing→
→Select letter
Show Number
Directory→Personal Dir→Delete
→Select letter range→Select listing→
→Home
Directory→Personal Dir→Edit
→ Select letter range→Select
Enter→Exit
→Home
italics
15
Using Features
There are two ways to use a feature:
• Directly, as explained below
• By pressing a line button you programmed with the feature (see Programming Buttons &
Settings, p. 27)
␣Display-Only Features␣
To use a Directory of numbers, Messages and
Posted Messages, display screen contrast setting
(MLX-28D telephone), Alarm Clock, or Timer:
1. Press the Menu button.
2. If you see > at the right of the display, there
are more options. Press More to see them.
(Press More to use the alarm clock or timer
on an MLX-28D telephone.)
3. Respond to display prompts, if necessary.
4. Press the Home button to exit at any time.
Feature Codes
Account Code Entry 82 + code + #
Authorization Code Entry 80 + code + #
Callback 55
Call Waiting
■
pick up call waiting call
Camp-On 57
Direct Voice Mail 56
Extension Status
ES Off 760 + extension
ES1 761 + extension
ES2 762 + extension
Follow Me 34 + extension
Forward
inside 33 + extension
outside 33 + dial-out code
Forward and Follow Me
cancel from all extensions
cancel from one extension ■✻ 34 + extension
cancel from your phone 33 + your extension
Language
▼
English 790
French 791
Spanish 792
87
+ number + #
■
✻ 34 ✻
␣Other Features␣
To use a feature from the
1. Press the Feature button.
2. Select the feature from the display,
OR
Dial the feature code from the Feature
Codes list.
Note: Some features can only be used by
entering a code (see the Feature Codes
list).
3. Press the Home button to exit at any time.
Last Number Dial 84
Messaging
cancel message
leave message 25
leave message without
■
calling
send/remove message 38 + extension
Night Service 39
Paging loudspeaker 9 + line number
Pickup
group 88
inside 9 + extension
outside 9 + line number
Privacy
off ✻ 31
on 31
Recall 775
Reminders
set reminder
▼
cancel reminder ✻ 81 + extension
System Speed Dial code (600–729)
■
Feature Codes
✻ 53 + extension
53 + extension
+ zone
81 + extension
+ time + 2 or 7
list:
■
Available only by using feature code.
▼
For time functions, English operates on 12-hour clock (2 or 7). French and Spanish operate on 24-hour clock.
16
Often-Used Features
␣Account Codes␣
To program:
See Programming Buttons & Settings, p. 27.
In some companies, you enter an account code
before or during a call to indicate client billing
information. You may be
account code for all outside calls, or an
account code may be optional for incoming
and outgoing calls. Check with your system
manager for account code operation and
account codes.
You can program a button for this feature and
label it Acct. See also Auto Dial (p. 18) to
program an account code on an outside
Auto Dial button.
To enter an account code:
1. Press the button you have programmed,
OR
Press the Feature button and dial 82 or
select
Account Code [Acct
2. Dial the account code and #.
3. Lift the handset or press the Speaker
button to make a call. (If necessary, press an
outside line or SA button.)
4. Dial the outside number (including dial-out
code, if required).
To enter or change an account code during a
call (the other party cannot hear your entry),
follow Steps 1 and 2. If you enter an account
code for an incoming call before it arrives, you
cannot change that code during the call.
required
to enter an
] from the display.
␣Alarm␣
To program:
See Programming Buttons & Settings, p. 27.
If there is something wrong with the system,
the red light next to your console’s programmed Alarm button goes on. Report the alarm immediately to your system manager. Press the Alarm button, then the Inspct button, to see how many problems the system is reporting.
The red light stays on until the problem is
cleared by your system manager.
␣Alarm Clock & Timer␣
The Alarm Clock and Timer features are only
available from the display and cannot be
activated with a feature code. Alarm Clock
causes your phone to beep at a certain time;
you can set only one alarm. Until canceled,
the display shows a bell reminding you that
the alarm is on, and the alarm sounds each
day at the same time. Timer times calls or
other activities for up to 59 minutes, 59
seconds, displaying the elapsed time on your
screen. You must turn Timer off when timing
is over; it does not turn off automatically at
the end of a call.
To set an alarm:
1. Press the Menu button.
2. Select
3. If your display is English, dial a 4-digit time
4. Select On.
5. Press the Home button. The display shows
To cancel the alarm:
1. Repeat Steps 1 and 2 above.
2. Select
3. Press the Home button. The display no
To time a call or other activity or to turn Timer
off:
1. Press the Menu button.
2. Select
Alarm Clock [AlClk
from 0100 to 1259 and select
switch between AM and PM.
If your display is French or Spanish, dial a
4-digit time between 0000 and 2359.
If you make an error, select
a bell to remind you that an alarm is on.
Off
.
longer shows a bell.
Timer
.
].
Reset
a.m/p.m.
and redial.
to
17
Often-Used Features
␣Authorization Codes␣
To program:
See Programming Buttons & Settings, p. 27.
This feature is useful at companies where there
are telephones in public areas that are resricted
from making some calls.
If your system manager has given you an
authorization code, you can pick up someone
else’s telephone, enter your authorization code,
and make an outside call with your own calling
privileges. You must activate the feature and
enter your code for each call you make, even
when you are adding people to a conference.
It is not necessary to use your authorization
code for inside calls. Using an authorization
code does not affect the button assignments on
your own phone or the phone where you enter
the code.
Security Alert
Compromise of authorization codes
could lead to toll fraud or unauthorized
charges.
Memorize your authorization code, and do not
share it with anyone.
The way you activate the Authorization Code
feature depends upon the type of telephone you
are using to make the call.
•
If the telephone has a programmed
Authorization Code
The system selects a line and automatically activates the Speaker button (an
available line button is selected for you);
then continue with Step 3 below.
•
On an MLX display telephone
Feature button, then select
[
Auth
] from the display or dial 80; then
continue with Step 3 below.
To enter an authorization code at any type of
phone (except a QCC):
1.Lift the handset or press the Speaker
button. (You may first select an ICOM, SA,
or SSA button.)
2.Dial #80.
3.Dial your authorization code, followed by #.
4.Dial the dial-out code (usually a 9) for an
outside call and then dial the phone number.
5.To make another call, repeat Steps 1–4.
button
, press it.
, press the
AuthCode
␣Auto Dial␣
This feature must be programmed on a line
button; it dials an inside or outside number.
Use inside Auto Dial buttons to:
•Dial other extensions or groups, including
park zones.
•Page groups (see Paging, p. 22).
Use outside Auto Dial buttons to:
•Dial outside phone numbers (with dial-out
codes but without account codes).
•Enter account codes automatically (when
programming, include # at the end).
•Dial long-distance access codes.
•Dial emergency contact numbers.
Note that you can also use other features to
automate dialing: Directories (p. 15), Last
Number Dial (p. 21), Saved Number Dial
(p. 24), and System Speed Dial (p. 24). When
programming Auto Dial, use the Special
Characters table on the outside back cover,
if necessary. Include the complete dialing
sequence for the call.
To program on a button:
1.Label a button.
2.Press the Menu button.
3.Select
4.Press the button to be programmed.
5.Select
6.Select
7.Dial the group paging number, extension, or
8.Repeat Steps 1 and 4–7 to program
9.Press the Home button.
To use an
1.To make a ringing call to an inside or outside
2.The call is dialed automatically. If it’s a
Ext Program [Prog]
ListFeature [List]
[
AutoD
]. For a paging group, select
Feature
[
List
go to Step 7.
outside number and select
additional numbers.
number, press the programmed Auto Dial
button,
OR
To make an inside voice-announced call,
press an ICOM Voice or SA Voice button
and then press the inside Auto Dial button.
voice-announced call, talk after the beep.
] and
Inside [In
Auto Dial
] or
and
Start
and
Auto Dial
GroupPage [GrpPg
Outside [Out]
Enter.
button:
.
List
and
] and
Enter.
18
Often-Used Features
Barge-In␣
If you use this feature often, ask your system manager to program a Barge-In button on your console.
If a co-worker is on the phone or using Do Not
Disturb, use Barge-In to reach that person in an
emergency or if you have special instructions
to interrupt. When the extension is busy, you
hear a tone and Barge-In connects you to the
call; if your co-worker is using Do Not Disturb,
his or her telephone rings.
You cannot use Barge-In on the following:
• A conference call, if the conference already
has the maximum number of participants.
(You hear a fast busy signal.)
• Telephones that have forwarded calls by
using Coverage, Forward, or Follow Me.
(You hear ringing at the extension you are
calling.)
• Telephones that have Privacy in use. (You
hear a fast busy signal.)
• Telephones that are being programmed.
(You hear ringing at the extension you are
calling.)
• Telephones in the process of dialing. (You
hear a fast busy signal.)
To use:
Press the programmed Barge-In button,
OR
Press the Feature button and select
[
Barge
].
Barge In
Callback & Line Request␣
Your system has two features that you can use
when an outside line or extension is busy.
These features give you access to the line or
extension when it becomes available.
On phones with SA buttons, use Callback to
reach:
• Busy outside lines on SA buttons, when
you dial the dial-out code and hear the
fast busy signal.
• Busy extensions, when you dial and hear
the busy signal.
On phones with ICOM buttons, use:
• Line Request to reach a busy outside line
when you lift the handset or press the
Speaker button and do not hear dial
tone.
• Callback for busy extensions.
To use Callback when you hear the busy
(extension) or fast busy (outside line) signal:
1. Press the programmed Callback button,
OR
Press the Feature button and dial 55.
2. If you are trying to reach an outside line,
dial the outside telephone number.
3. After you hear five short beeps, hang up.
When the line or extension is free, you hear
a long ring and three short rings.
4. Lift the handset or press the Speaker
button. You hear dial tone, and the system
dials the call.
To cancel a Callback request:
1. Press the same line button you pressed
when you tried to make the call. (The line
will have a flashing green light.)
2. Lift the handset and press the Drop button.
3. Press the same line button again.
To use Line Request:
1. When outside lines are busy, hang up and
press the line button you want to use. Do
not lift the handset or press the Speaker
button.
2. When a line is available, the phone beeps.
Lift the handset or press the Speaker
button.
3. Dial the outside number.
19
Often-Used Features
␣Call Waiting␣
If Call Waiting is on, you hear a call-waiting
tone when a call comes in and all your lines
are in use. This feature works only on SA and
ICOM buttons, not on line buttons labeled
with phone numbers.
When a call is waiting, you hear a single beep
(inside call) or two beeps (outside call).
To complete a call and answer a waiting call:
1. When you hear the call-waiting tone, hang
up.
2. When the phone rings, lift the handset or
press the Speaker button.
To put a call on hold and pick up a waiting call:
1. Press the Hold button.
2. Press an ICOM Originate Only or SA
Originate Only button. (You must have
one of these buttons available to pick up
the call.)
3. Press the Feature button and dial 87.
4. To return to the call on hold, press the
button with the fast-flashing green light.
To turn Call Waiting on or off:
1. Press the Menu button and select
Program
[
Prog
].
2. Select
3. Select
4. Select
5. Select
Start
and press any line button.
ListFeature [List
CallWaiting [CWait
On
or
Off.
Enter
exit programming.
and press the Home button to
].
Ext
] and then select
␣Camp-On␣
To program:
See Programming Buttons & Settings, p. 27.
Use this feature to hold a call at a busy
extension; the call rings when the extension is
available.
To camp on a busy extension so the call will
ring at the extension when available:
1. Press the Home button.
2. Select
Note: Do not use Camp-On if your system is
equipped with a voice mail system.
CampOn [Camp
].
␣Coverage␣
To program:
See Programming Buttons & Settings, p. 27.
Coverage allows to your extension to ring
elsewhere, so that they can be handled by
someone else. If your system has voice mail,
your calls can also be covered that way. There
are three types of coverage:
• Primary Coverage. If your calls are
covered this way, they ring immediately at
the covering phone.
• Secondary Coverage. The covering
phone rings after a delay of 2 rings, giving
you a chance to answer first.
• Group Coverage. Calls for a group of
people (coverage group) may be covered
by one or more people. Your system
manager can tell you how this works at
your office..
Covering phones are programmed with Cover
buttons used to answer calls for others. Delay
Ring on the covering phone can add a longer
delay before your calls ring there. If line
buttons on your phone are set to No Ring,
however, calls on those lines are not covered
(see Rings, p. 4).
To control coverage of inside calls, use these
programmable settings: Coverage Inside On
allows your inside calls to ring elsewhere;
Coverage Inside Off turns inside coverage off.
You can also program buttons for these
Coverage features:
• Use a Coverage VMS button to prevent
or allow coverage of your outside calls by
a voice mail system. These calls may still
be covered by a person at another
extension.
• Use a Coverage Off button to turn off or
on all coverage of your calls.
20
Often-Used Features
␣Direct Voice Mail␣
To program:
See Programming Buttons & Settings, p. 27.
Direct Voice Mail allows an inside caller to call
directly or transfer a call directly to another
user’s voice mail. You can also use the feature
after
you have dialed the extension; just do
Step 1 below.
To call directly to another user’s voice mail or
transfer a call directly to another user’s voice
mail:
1. Press the programmed Direct Voice Mail button,
OR
Press the Feature button and select
VM
[
DrcVM
] or dial 56.
2. Press an Auto Dial or DSS button, select a
Directory listing, or dial the number of the
extension whose voice mail you want to call
or transfer a call to.
Note: If you are transferring a call to an
extension that does not have voice mail, you
hear an error tone and the call returns to you
after the transfer return interval.
␣Do Not Disturb␣
Must be programmed on a button. To program:
See Programming Buttons & Settings, p. 27.
This feature prevents calls from ringing at your
extension, although outside calls cause the
green lights at line buttons to flash. If you have
coverage, your calls are covered. Inside callers
with display phones see
they attempt to call you. A system operator or
the person providing individual coverage for
you can still call you. Callback calls and
returning transfers ring at your phone.
To use:
Press the programmed button to turn on or off.
When the feature is on, the green light is on.
Do Not Disturb
DIrect
when
␣Extension Status (Hotel/Motel)␣
To program:
See Programming Buttons & Settings, p. 27.
Extension Status lets you monitor telephone
status in your system. You can change status
either at your console or at the extension, using
either a programmed line button or a feature
code. You can monitor status only from a
console. Extension Status must be
programmed systemwide and assigned to the
console. Consult your system manager to find
out how your company uses each status feature
and line button on the console.
The programmed buttons in the Hotel/Motel
mode are labeled:
ES Off. The light next to that extension is off.
The room is occupied, and telephone is in
regular call-handling status.
ES1. The light next to that extension is flashing.
The room is unoccupied and ready for cleaning;
outside calls cannot be made from the
telephone.
ES2. The light next to that extension is on.
The room is vacant, and outside calls cannot
be made from the telephone.
To change the status from your console:
1. Press the programmed ES Off, ES1, or ES2
button, OR
Press the Feature button and dial:
760 for ES Off
761 for ES1
762 for ES2
2. Press a DSS or Auto Dial button or dial the
number for the extension you want to change.
␣Last Number Dial␣
To program:
See Programming Buttons & Settings, p. 27.
This feature redials the last number you called. You
should program Last Number Dial on a button.
To use:
1. Press the same type of line button used to place
the first call (for example, ICOM or SA).
2. Press the programmed Last Number Dial
button, OR
Press the Feature button and dial 84.
21
Often-Used Features
␣Forward & Follow Me␣
To program:
See Programming Buttons & Settings, p. 27.
Forward and Follow Me both send your calls to
another phone when you are busy and need
your calls covered or you are not working at
your own desk. Turn either off from your
extension or the one you are visiting.
• If you want your calls handled at another
extension or at an outside number, turn on
Forward from your extension.
• If you are working away from your phone,
turn on Follow Me where you are.
If Delayed Call Forwarding is turned on
through centralized telephone programming,
calls ring at the forwarding extension for the
programmed number of rings (0–9) before
being forwarded. To change the Delayed Call
Forwarding setting, contact your system
manager.
To forward calls to another extension:
1. Press the button you have programmed, OR
Press the Feature button and dial 33.
2. Dial the extension.
To forward calls to an outside number (if enabled):
1. Press the button you have programmed, OR
Press the Feature button and dial 33.
2. Dial the dial-out code, outside number,
and #.
To set up Follow Me and receive calls at
another extension:
1. Press the Feature button and dial 34.
2. Dial your extension.
To cancel Forward and Follow Me:
• To cancel forwarding or following of your
own calls: at your extension, press the
Feature button, dial 33 and your extension.
• To cancel all extensions forwarded or
followed to yours: at your extension, press
the Feature button, dial ✻34✻.
• To cancel one extension forwarded or
followed to yours: at your extension, press
the Feature button, dial ✻34 and that
extension.
␣Night Service␣
Your company may use Night Service to treat calls differently after hours. You may be responsible for turning Night Service on or off at a Night Service button programmed on your console. If Night Service is on, you may not be able to make outside calls, or you may need a password to do so. See your system manager for a password and/or emergency numbers you can dial without a password.
To make an outside call and override Night
Service, press the Hold button and dial the
password. Then make the call as you would
normally. (See Making Calls, p. 9).
␣Paging␣
To program:
See Programming Buttons & Settings, p. 27.
You can page an individual at his or her phone
by using an ICOM Voice or SA Voice button
(see Line Buttons, p. 3). Or you may be able to
page all speakerphones or groups of speakerphones, depending upon how your system is set
up. If your company has a loudspeaker paging
system, use it to page the whole company or just
people in a certain paging zone.
To program or use Speakerphone Paging, check
with your system manager for Group Paging or
Page All numbers, then:
1. Press any ICOM or SA button and lift the handset.
2. Dial the Group Paging or Page All number, OR
Press the button you programmed for Group
Paging or Page All.
3. After the beep, make the announcement and
hang up.
Ask your system manager whether Loudspeaker
Paging is available and if there is a list of paging
zones. To use:
1. Press any ICOM or SA button and lift the handset.
2. Press the Feature button.
3. Select
Loudspkr Pg [LdsPg
if necessary.
4. Make the announcement and hang up.
To use when a button is programmed:
1. Lift the handset, press the programmed button,
and dial the zone, if necessary.
2. Make the announcement and hang up.
] and dial the zone,
22
Often-Used Features
␣Park␣
Park puts a call on a special type of hold so that it can be picked up from any phone in the system. A user can park a call and then pick it up at another telephone or can use Paging to announce the call so that another person can pick it up. Pick up a parked call by using the Pickup feature. See Park & Pickup.
To park a call at your own extension on the
button that the call arrived on:
• Press the programmed Park button,
OR
• Press the Transfer button, dial your
extension, and press Transfer again,
OR
• Press the Feature button and select
You can also park calls at park zones. The
factory setting of the system is to have eight
extensions (881–888) for operator park zones.
Ask your system manager if these park zones
are available. If they are, you can use a DSS
button or program an Auto Dial button (p. 18)
with a park zone extension.
To park at a park zone:
Press the DSS button for a park zone,
OR
Press the Transfer button and dial a park zone
(factory setting: 881–888).
If the parked call is not picked up within the
park return interval (factory setting: 3 minutes),
the call rings back at your telephone.
Park
␣Park & Pickup␣
To program:
See Programming Buttons & Settings, p. 27.
While a call is parked, use Paging to summon
the co-worker who should answer. The person
picks up the call using Pickup (p. 24) and
dialing your extension.
To use Park and Paging:
1. Park the call.
• Press the programmed Park button,
OR
• Press the Transfer button, dial your
extension, and press Transfer again,
OR
.
• Press the Feature button and select
Park
,
OR
• Press the Transfer button and dial the
park zone.
2. Set up the page.
•
For Speakerphone Paging:
a) Press the appropriate Group Page or
Page All button,
OR
Press any ICOM or SA button and dial
the Group Page or Page All extension.
b) Announce the call and give your
extension or park zone.
•
For Loudspeaker Paging:
a) Press the programmed Loudspeaker
Paging button,
OR
Press the Feature button and select
LoudspkrPg [LdsPg
the zone.
b) Announce the call and extension where
the call is parked.
3. Hang up.
To pick up a parked call:
1. Lift the handset.
2. Press the programmed Pickup button,
OR
Press the Feature button and dial 9.
3. Dial the extension where the call is parked
or use the DSS button.
]. If necessary, dial
23
Often-Used Features
␣Pickup␣
Pickup lets you pick up calls that are not ringing at your phone. Using Pickup, you can answer a parked call (see Park & Pickup, p. 23), a call ringing at a specific extension, or a call ringing on a specific line. If you are part of a Pickup group, you can pick up a call ringing anywhere in the group. Program a general Pickup button that activates the feature or a specific Pickup button to take a call for a group (example: Pickup
Sales) or at a specific line or extension (example:
Pickup Maria). Ask your manager if you are a
member of a Pickup group and get the Pickup
group number.
To program:
1. Label a button.
2. Press the Menu button.
3. Select
4. Select
5. Press the button to be programmed.
6. Select
7. Select
8. Select
9. Select
10. Press the Home button.
To use:
Ext Program [Prog
Start
.
ListFeature [List
Pickup [Pkup
General [Genrl]
extension; select
specific extension or line; select
group of extensions.
Enter
screen; select
• Press the programmed button. For a line or
an extension that is not programmed, also
dial the extension or line number.
• You can also use Group Pickup by pressing
the Feature button and selecting
PickupGrp [PkupG
dialing 88.
and follow the prompts on
Enter
].
].
].
for any line or
Extension [Ext
again when you’re done.
] from the display or
] or
Group
Line
for a
for a
␣Saved Number Dial␣
Must be programmed on a button. To program:
See Programming Buttons & Settings, p. 27.
Use this feature to redial a busy or unavailable
number that you want to try later.
To use:
1. Before hanging up, press the programmed
Save Number Dial button.
2. Press the same type of button used to place
the call (for example, ICOM, Pool, or SA).
3. To redial, press the programmed Saved
Number Dial button.
␣System Speed Dial␣
To program:
See Programming Buttons & Settings, p. 27.
You can program 3-digit System Speed Dial
codes on a button. These are the same
numbers that are available from the System
Directory (see p. 15). Dial these directly by
pressing the Feature button and dialing the
code (600–729).
␣Voice Announce␣
To program:
See Programming Buttons & Settings, p. 27.
Make voice-announced calls from ICOM
Voice or SA Voice buttons on your phone
(see Line Buttons, p. 3) or use Paging (p. 22).
The Voice Announce feature allows you to
prevent voice announcements and paging calls
from interrupting you. Instead, the calls ring.
Voice Announce is a setting that you can turn
on or off without programming a button for it.
␣Privacy␣
To program:
See Programming Buttons & Settings, p. 27.
Privacy prevents co-workers who share a line
with you from joining your calls. Turn the
feature on before or during a call; it remains on
until you turn it off. A call on hold is not protected by Privacy. You should program Privacy
on a button so that you will have a green light
to remind you when the feature is on.
24
Display Reference
MLX-28D telephones have a 2-line screen, 24 characters wide. MLX-20L telephones have a 7-line screen, 24
characters wide. Whatever the model of your phone, it has four basic displays, described below.
The display is controlled by the Home, Menu, Feature, and Inspct buttons, which bring up the four basic
screens. (See p. 1 for a picture of the Feature and Inspct buttons.) The Home, Menu, and Inspct buttons
are located either below or next to your screen, as is the More button. The More button is available when a
> appears next to or above it on the screen; the > means that you can press the More button to see additional
choices or information. Unlabeled display buttons are positioned next to or below your choices. Press one to
select an item from the screen.
Note: If your company has Caller ID services and Caller ID is supported in a caller’s area, an outside
caller’s phone number may appear on your display when an outside call comes in or is transferred to you.
When caller information is not available because of the caller’s local phone company or because the caller
has blocked the service, you may see
No Caller ID, Out of Area
, or
Private
.
Home Screen
The Home screen is displayed when you have not chosen another screen or when you press the Home button.
The screen contains different information, depending upon your activity. In general, during a calling activity
Lines 1 and 2 of the Home screen show prompts and give feedback to guide you.
When phone is idle, shows a
posted message, if any.
When a call comes in or is
made, shows the number
called, name or number of
caller, or other call-handling
information.
MLX-20L telephone users
can assign up to 16
Personal Directory
(p. 15) listings to this
screen.
This line shows Directory
and navigational options.
IN CONFERENCE
Home Menu Inspct More
Home
Menu
IN CONFERENCE
HOME
SCHOOL
TRAVEL AGNT
BANK
SHOW NUMBER
APR 18 12:43
APR 18 12:43
BROOKS
GARCIA
CHENG
COFFEE SHOP
NEXT PAGE
When phone is idle, shows
the date and time. Displays
Alarm Clock and Timer
(p. 17) if either is set.
More
Inspct
Menu Screen
Press the Menu button to list features available only from the display and to program your phone or line
buttons. MLX-28D telephone users can display additional choices by pressing the More button.
Home
Press to exit.
Press for access to
System, Extension,
and Personal
Directories (p. 15).
Press to view or post
messages (pp. 11–14).
Press to use Alarm
Clock or Timer (p. 17).
MENU MODE: Select Feature
Dir Post
Home Menu Inspct More
Home
Menu
MENU MODE: Select Feature
Press HOME to Exit
Directory
Messages
Posted Msg
Alarm Clock
Timer
Msgs
Ctrst>
Ext Program
More
Press to select from
Alarm Clock and
Timer (p. 17) and
programming (p. 27).
More
Inspct
Press to program your
phone (p. 27).
Feature Screen
This screen provides rapid access to often-used features; press the Feature button to display it. Available
features vary according to your calling activity and how your phone is programmed. The picture below
shows the Feature screen when you have just selected an ICOM or SA button, or when you are not on a
call. The table below shows the sets of features available on each of the other three Feature screens. (If you
have an MLX-28D telephone, you may need to press the More button to see all of the features in a set.)
The
MLX-28D telephone display abbreviations are shown in [].
Select a Feature:
Last# Pkup
Home
Press to exit.
Press to redial the
last number you
dialed (p. 22).
Press to pick up a
call ringing at another
extension or at a line
for which you have no
button (p. 24).
Press to enter an account
code before or during a
call (p. 17).
Home
Menu
Home Menu Inspct More
Select a Feature
Press HOME to Exit
LastNumDial
Pickup Grp
Pickup
Loudspkr Pg
AccountCode
DrcVMPkupG
Follow Me
Auth Code
Direct VM
See
Direct VM
>
More
Press to access Account Code
(p. 17), Authorization Codes
(p. 18), and Follow Me (p. 22)
features.
More
Inspct
below.
Press to send calls
from another
extension to this
extension (p. 22).
Press to enter your
authorization code
for a call (p. 18).
Press to call a voice
mailbox (p. 12).
Feature Screen Options
When you: These options are available:
Have reached a busy extension
Have made a call to an extension and it is ringing or you are
on an inside call
Are connected to an outside line
Do not use if your company has a voice mail system.
*
Barge-In [Barge
]
Leave Msg [LvMsg
Cback Sel [CbckS]Camp On [Camp
Leave Msg [LvMsg]Camp On [Camp
Park [Park
]
Direct VM [DrcVM
LastNumDial [Last#]AccountCode [Acct
Park [Park
Camp On [Camp
]
Follow Me [FlwMe
]*
Direct VM [DrcVM
]
]*
]*
]
]
]
]
Inspect Screens
An Inspect Screen appears when you press the Inspct button and then press a line button.
• If you are on a call, you see calling information. If you are on a call and another call comes in, press the
Inspct button and then the line button with the ringing call to display information about the new call
without interrupting your current activity.
• If you are not on a call, the line or feature programmed on the button is displayed. If the button is
programmed with Last Number Dial or Saved Number Dial, the last or saved number appears on the screen.
To exit from the Inspect screen, press the Home button.
25
3
Display Reference
Notes
Feature Name
Account Code Entry
Alarm
Alarm Clock
Authorization Codes
Auto Dial
inside (extension)
outside
Barge-In
Callback
Call Waiting
Camp-On
Conference
Contrast
Coverage
Coverage VMS
group
primary individual
secondary individual
inside only
off
Directory
extension
personal –
system
Direct Voice Mail
Do Not Disturb
Drop
Extension Programming
Extension Status (Hotel/Motel)
ES Off
ES 1
ES 2
Follow Me
Forward
Group Calling
Headset/Handset
Headset Auto Answer
Headset/Handset Mute
Headset Status
Last Number Dial
Line Preference
Messaging
delete message
leave message
return call
next message
posted message
send/remove message
Night Service
2-Line Display
Abbreviation
Acct
Alarm
AlClk
Auth
AutoD
In
Out
Barge
CbckS
CWait
Camp
Conf
Ctrst
Cover
CvVMS
Group
Prmry
Secnd
CvIns
CvOff
Dir
ExtDir
SysDir
DrcVM
DND
Drop
Prog
ES
ESOff
ES1
ES2
FlwMe
Forwd
GrpCl
Hdset
Auto
Mute
Stat
Last#
LnPref
Msgs
Dlete
LvMsg
Call
Next
Post
Msgs, SdMsg
Night
Feature Name
Notify
notify receive
notify send
Paging
group paging
loudspeaker paging
Park
Park Zone
Personalized Ring
Pickup
general
group pickup
inside (extension)
outside (line)
Privacy
Recall
Reminder
cancel
set
missed reminder
Ringing Options
all lines
one line
delayed ring
immediate ring
no ring
abbreviated ring
Saved Number Dial
Signaling
System Speed Dial
Timer
Transfer
Voice Announce
place calls
receive calls
ringing calls
voice-announced calls
2-Line Display
Abbreviation
Ntfy
Recv
Send
GrpPg
LdsPg
Park
PrkZn
PRing
Pkup
Genrl
PkupG
Ext
Line
Prvcy
Recll
Rmind
Cancl
Set
Rmind,Missd
RngOp
AllLn
1Line
Delay
Immed
No
Abbrv
Save#
Signl
SpdDl
Timer
Trans
Voice
Place
Recv
Ring
Voice
PAGING NUMBERS
Paging Group(s) No. Loudspeaker Paging No.
Line Number
Zone 1
Zone 2
Zone 3
Zone 4Page All
COVERAGE/PICKUP/CALLING GROUPS
Group Name Group NameNo.
No.
ADDITIONAL NUMBERS
Name NameNo. No.
26
Programming Buttons & Settings
If you use a feature often, you can program it onto an unused line button for easy access. If you use a
feature occasionally, see Using Features, p. 16. Keep these facts in mind when setting up your
telephone:
• Some features
with a ♦ on the Programming Codes list.)
• Other features (marked with • on the Programming Codes list) are settings that affect the way your
phone works. Some settings, such as Personalized Ring, affect all the lines on your phone. During
programming, you still have to select a line button, but it can be
Others, such as Delay Ring for a single line, are settings that affect a specific line and require you to
press it during programming (these features are noted on the Programming Codes list). Settings
remain active until you program them again.
To see whether a feature is programmed on a line button, press the Inspct button and then the line
button. Read the display and press the Home button to exit.
While programming, either make a selection from the display (press the button next to or below the
item) or use codes. Using codes takes fewer steps, but requires the Programming Codes list. As you
program, your phone beeps.
␣ Display Programming␣
must
be programmed on a button or they can’t be used. (These features are marked
any
line button the feature affects.
To program using the display:
1. If programming a feature on a button, label
the button.
2. Press the Menu button and select
3. Select
4. Press the line button you are programming.
[
Prog
Start
].
.
Program
If a feature is already programmed, its name
appears on the display. If you are programming a setting, either press the line button
affected or press any line button.
Ext
␣ Code Programming ␣
To program using programming codes:
1. If programming a feature on a button, label
the button.
2. Press the Feature button and dial 00.
3. Press the line button you are programming.
If a feature is already programmed, its name
appears on the display. If you are programming a setting, either press the line button
affected or press any line button.
5. Select
6. Select the feature. If additional numbers
7. Press
8. Press the Home button to exit at any time.
4. Select the code from the Programming
5. Press
6. To exit, press the Feature button and dial
ListFeature [List
feature name using
you see > on the screen, press the More
button to see more feature names. (Consult
the Display Reference, p. 26, if you need
help with abbreviations.)
(such as an extension number) are needed,
dial them.
Enter
wish to program another button, begin again
with Step 4. (Label the buttons first.)
Codes list and dial it. If additional numbers
(such as an extension number) are needed,
dial them.
wish to program another button, begin again
with Step 3. (Label the buttons first.)
✻00.
to finish programming. If you
Enter
to finish programming. If you
] and search for the
FindFeature [Find
]. If
Copyright © 1998, Lucent Technologies. MERLIN LEGEND, MLX-10DP, MLX-16DP, MLX-20L, MLX-28D and
PassageWay are registered trademarks of Lucent Technologies in the U.S. and other countries. Mirage, StarSet, and
Supra are registered trademarks of Plantronics, Inc.
27
Programming Buttons & Settings
Programming Codes
Account Code ✻ 82
Alarm ✻ 759
Authorization Code ✻ 80
Auto Dial♦
inside ✻ 22 + extension
outside ✻ 21 + number
Callback
automatic callback off•
automatic callback on•
selective callback ✻ 55
Call Waiting•
off ✻✻ 11
on ✻ 11
Camp-On▲ ✻ 57
Coverage
Coverage inside on• ✻ 48
Coverage inside off• ✻✻ 48
Buttons for covering calls♦␣
Primary Cover ✻ 40 + sender’s
Secondary Cover ✻ 41 + sender’s
Group Cover ✻ 42 + sender’s
Buttons for sending calls♦␣
Coverage Off ✻ 49
Coverage VMS Off ✻ 46
(outside calls only)
Direct Voice Mail ✻ 56
Do Not Disturb♦␣ ✻ 47
Extension Status
ES Off ✻ 760
ES1 ✻ 761
ES2 ✻ 762
Forward ✻ 33
Headset/Handset Options♦
auto answer ✻ 780
hangup ✻ 781
mute␣ ✻ 783
status ✻ 782
▲ ✻✻ 12
▲ ✻ 12
extension number
extension number
group number
Last Number Dial ✻ 84
Messaging
leave message ✻ 25
send/remove message ✻ 38
Paging group or all ✻ 22 + group
extension
Paging loudspeaker ✻ 9 + line number
Park ✻ 86
Pickup
general pickup ✻ 9
group pickup ✻ 88
inside ✻ 9 + extension
outside ✻ 9 + line number
Privacy ✻ 31
Recall ✻ 775
Reminders
set reminder ✻ 81
cancel reminder ✻✻ 81
missed reminder♦✻ 752
Ringing Options•
abbreviated on ✻ 341
abbreviated off ✻ 342
delayed all lines ✻ 346
delayed one line ✻ 36
immediate all lines ✻ 347
immediate one line ✻ 37
no ring all lines ✻ 345
no ring one line ✻ 35
personalized ring ✻ 32 + ring(s) (1–8)
Saved Number Dial♦␣ ✻ 85
Signaling and Notify♦
signaling ✻ 23 + extension
notify receive␣ ✻ 758 + extension
notify send␣ ✻ 757 + extension
System Speed Dial ✻ 24 + code
(600–729)
Voice Announce•
on ✻ 10
off ✻✻ 10
◆ Must be programmed onto a line button.
• Sets up how your phone works. Use a line button to program (turn on or off). The setting is not
programmed onto a line button.
▲ See your system manager for details.
28
Feature Codes
Account Code Entry 82 + code + #
Authorization Code Entry 80 + code + #
Callback 55
Call Waiting
■
pick up call waiting call
87
Camp-On 57
Direct Voice Mail 56
Extension Status
ES Off 760 + extension
ES1 761 + extension
ES2 762 + extension
Follow Me 34 + extension
Forward
inside 33 + extension
outside 33 + dial-out code
+ number + #
Forward and Follow Me
■
cancel from all extensions
cancel from one extension
✻ 34 ✻
■
✻ 34 + extension
cancel from your phone 33 + your extension
Language
▼
English 790
French 791
Spanish 792
Last Number Dial 84
Messaging
cancel message
■
✻ 53 + extension
leave message 25
leave message without
■
calling
53 + extension
send/remove message 38 + extension
Night Service 39
Paging loudspeaker 9 + line number
+ zone
Pickup
group 88
inside 9 + extension
outside 9 + line number
Privacy
off ✻ 31
on 31
Recall 775
Reminders
set reminder
▼
81 + extension
+ time + 2 or 7
cancel reminder ✻ 81 + extension
System Speed Dial code (600–729)
■
Available only by using feature code.
▼
For time functions, English operates on 12-hour clock (2 or 7). French and Spanish operate on 24-hour clock.
␣ ␣ Special Characters ␣
Features that dial numbers automatically may need special characters to allow for correct dialing or
system response.
Press... See... Means...
Drop s Stop. Halts dialing sequence to allow for system response.
Hold p Pause. Inserts 1.5-sec. pause in dial sequence. Multiple consecutive pauses
Conf f Flash. Sends switchhook flash. Must be first entry in sequence.
## # For Extension Programming only (
##For dialing and Directory listings: End of Dialing. Use to signal end of dialing
allowed.
Ext Program [Prog
]): End of Dialing. Use to
signal end of dialing sequence or to separate grouped digits.
sequence or to separate grouped digits.
14
Loading...
