LSI PCI to USB Host Adapter 60800 User Manual

USER’S

GUIDE

LSI60800
PCI to USB
Host Adapter

Version 1.1

November 2000

®

S14000.A

Electromagnetic Compatibility Notices

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

1. This device may not cause harmful interference, and

2. This device must accept any interference received, inc luding interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15

of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause har mful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and the receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Shielded cables for SCSI connection external to the cabinet are used in the compliance testing of this Product. LSI
Logic is notresponsible for anyradio or televisioninterference caused byunauthor ized modification of this equipment
or the substitution or attachment of connecting cables and equipment other than those specified by LSI Logic. The
correction of interferences caused by s uch unauthorized modification, substitution, or attachment will be the
responsibility of the us er.

The LSI Logic LSI60800 is tested to comply with FCC standards for home or office use.

This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.
Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur le matériel brouilleur du

Canada.

This is a Class B product based on the standard of the Voluntary Control Council for Interference from Information
Technology Equipment (VCCI). If this is used near a radio or television receiver in a domestic environment, it may
cause radio interference. Install and use the equipment according to the instruction manual.

LSI Logic Corporation
North American Headquarters
Milpitas, CA

408.433.8000

ii

LSI60800 PCI to USB Host Adapter

User’s Guide

Version 1.1

1 What is Covered in This Guide

This User’s Guide provides instructions and illustrations to help you
install a LSI Logic LSI60800 PCI to USB Host Adapter. It covers the
following topics:

• Ensuring USB support is available in Windows 98

• Installing the LSI60800 Board

• Installing the LSI60800 software

• Connecting USB devices

®

The LSI60800 provides a low-cost USB solution for attaching USB
devices (digital video cameras, digital audio speakers, page scanners,
photo scanners, photo printers, etc.) to PCI computer systems. Figure 1
shows the major components and connections of the LSI60800 Board.

The LSI Logic LSI60800 is based on the industry standard OpenHCI
specification. Therefore, no vendor-specific driver is needed. It is
supported by Microsoft in Windows 98, and the upcoming
Windows NT 5.0.

November 2000 1

Copyright © 1998–2000 by LSI Logic Corporation. All rights reserved.

Figure 1 LSI60800 Board

External

USB Cable

.

2 Hardware Installation

Before you begin the board installation, switch off the power to the
computer and any peripheral devices and disconnect all power cords.

PCI to USB

Controller

J2

J1 PCI
Mainboard
Connector

Important:

1. Remove the cover on your computer to access the PCI slots. Refer
to your computer documentation if necessary.

2. Locate an unused PCI expansion slot for installing the LSI60800
Board. Refer to your computer documentation if necessary to locate
the expansion slots.

3. Remove the blank bracket panel on the back of the computer that
covers the slot you intend to use. Save the bracket screw.

2 LSI60800 PCI to USB Host Adapter

Before handling the LSI60800 board, ground yourself using
a ground strap attached to the computer metal frame. Static
charges on your body can damage electronic components.
Handle plug-in boards by the edge; do not touch board
components or gold connector contacts.

4. Remove the LSI60800 Board from the antistatic bag and insert the
edge connector into the PCI slot, as pictured in Figure2. Make sure
the edge connector is properly aligned before pressing the board into
place. Apply even pressure to both ends of the board while inserting it.

5. Visually check to make sure the LSI60800 Board is properly seated,
and is all the way down in the PCI slot.

6. Screw the bracket down with the screw from step 3.

Figure 2 Inserting the LSI60800 Board

LSI60800 PCI to USB Host Adapter 3

3 LSI60800 Software Installation

The LSI60800 Host Adapter is supported by Microsoft embedded drivers
for Windows 98.

After installing the LSI60800 Board, restart the computer.
A sequence of windows will appear briefly one after the other.
First the New Hardware Found window will appear.
Then the next window will indicate that the LSI Logic LSI61C102 USB

Host Controller is the device that was found.
Then a window will indicate that the Controller is an unknown device.
Then the New Hardware Found Root Hub window will be displayed.
The System Properties window will be the last window to be displayed

and will remain on screen.

3.1 Verifying the Installation

To check for correct installation, open the Device Manager using the
following procedure, and verify that the LSI60800 PCI to USB Host
Adapter is working correctly.

1. From the Windows 98 Start menu, select Settings, then Control Panel.

2. From the Control Panel window, double-click the System icon. The System Properties menu displays.

3. Select the Device Manager tab.

4. Click on the “+” box next to “Universal Serial Bus Controller”.
Figure 3 shows a properly installed USB card.

4 LSI60800 PCI to USB Host Adapter

Figure 3 System Properties Window - Device Manager Tab

5. Click on Close.

4 Connect the USB Devices

1. Load the USB device driver supplied by the USB device
manufacturer following the procedure provided with the USB device.

2. Plug in the USB device using the correct cable (see below). There
is no need to turn off the computer power. The USB devices can be
hot-plugged.

3. The device driver should load automatically without any user interaction.

LSI60800 PCI to USB Host Adapter 5

4.1 Cabling

4.2 Hubs

The LSI60800 PCI to USB Host Adapter supports type A cable
connectors only.

The USB specification provides for two types of cables. For full-speed
devices like scanners, cameras, printers, and speakers, a full-speed
cable must be used. For low-speed devices like keyboards, mice,
joysticks, and other game devices, a sub-channel or low-speed cable can
be used.

The USB specification supports two types of hubs; cable-powered and
self-powered. A self-powered hub can support all USB devices,
independent of the USB device power requirements. A cable-powered
hub can support only devices which use 100 mA or less. Also, a hub
must be connected using only a high-speed cable.

6 LSI60800 PCI to USB Host Adapter

Notes

LSI60800 PCI to USB Host Adapter 7

Notes
