Low Temp Industries 144-BT, CP BT Parts List

Item: __________________________

Quantity: ______________________

Beverage Table

Project: ________________________

Date: __________________________

MODELS

length

❑ 28-BT 28 3/8”
❑ 36-BT 36 3/8”
❑ 50-BT 50 3/8”
❑ 60-BT 60 3/8”
❑ 66-BT 66 3/8”
❑ 74-BT 74 3/8”
❑ 84-BT 84 3/8”
❑ 96-BT 96 3/8”
❑ 144-BT 144 3/8”

36-BT Beverage Table shown.

Top:

❑ 36” Counter Top Height
❑ Other Height (specify ___________)
❑ Top Extensions (width ___________)
❑ Top Extensions (length ___________ )
❑ Drop-Ins (specify ___________)
❑ Drain Trough length (specify _______)

Above the Top:

❑ Overshelf
❑ Sloped Front Protector
❑ Curved Front Protector

❑ Other Style Protector (specify _______)
❑ Buffet Shield Single Service
❑ Buffet Shield Double Service
❑ Lift-up Hinge for shield
❑ 2 tier Display Shelf, single service
❑ 2 tier Display Shelf, double service
❑ 3 tier Display Shelf, single service
❑ 3 tier Display Shelf, double service
❑ Curved Glass for Display Shelf
❑ Powder Coated nish (specify RAL #)
❑ Fluorescent Lights

Tray Slide:

Stainless Steel

❑ Solid “V” ridge
❑ Flat Surface

Solid Surface

❑ Corian

®

(specify ______________)

❑ Powder Coated brackets (specify RAL #)
❑ 34” Tray Slide Height
❑ Other Slide Height ___________

Base Options:

❑ Enclosed Base (specify EB after model #)
❑ Cam Operated Line-up Locks
❑ Hinged Doors
❑ Fiberglass Door Panels
❑ End Drop Shelf
❑ Custom Color (specify RAL #)
❑ 5” Diameter Casters
❑ Stainless Steel Legs
❑ Cashier Station
❑ Other ___________

Cutting Board:

❑ 8” wide Stainless Steel
❑ 8” wide Richlite

®

composite

❑ Other width ___________

Versatile counters, add

the options you need!

Durable, colorful, molded

fiberglass

East to clean, low maintenance

Electrical Options:

❑ Convenience outlet, ush
❑ Convenience outlet, pedestal
❑ Daisy chain
❑ Load center

Other Options:

❑ Canopy (specify style & color)
❑ Over-structure with signage & lights

(specify _____________________)

❑ Theme Package

❑ School Bus
❑ Train
❑ Space Shuttle
❑ Covered Wagon
❑ Circus Train
❑ Other (specify)

P.O. Box 795 • Jonesboro, GA 30237

Tel: [phone] • Fax: [phone]

www.lowtempind.com • [e-mail]

8

Item: _____________________________

Quantity: _________________________

Beverage Table

”

2

/

1

1

30”

4”

L

Plan View

APPROX. SHIP

MODEL L S WEIGHT

28-BT 28 3/8” N/A 205 lbs.

36-BT 36 3/8” 15” 220 lbs.

50-BT 50 3/8” 36” 260 lbs.

36”

S

”

4

/

1

5

Rear View

Project: ___________________________

Date: _____________________________

Drain Valve

End View

60-BT 60 3/8” 46” 300 lbs.

66-BT 66 3/8” 46” 320 lbs.

74-BT 74 3/8” (2) 28” 340 lbs.

84-BT 84 3/8” 28” & 36” 360 lbs.

96-BT 96 3/8” 28” & 46” 380 lbs.

144-BT 144 3/8” (2) 46” 750 lbs.

TOP: Top to be 30” wide and fabricated
from a minimum of 14 ga. stainless steel
with square turndown on all sides and cor­ners fully welded, ground and polished. Top
to have #4 satin finish and with all edges
having a #7 hi-lite finish.

BODY: Body to be seamless molded fiber­glass (F.R.P.) with smooth exterior surfaces
and rounded corners. To be constructed
by a hand lay-up process with four layers
of 1.5 oz continuous strand fiberglass mat,
plus a 24 oz layer of woven roving on the
bottom for added strength. Fiberglass to
be flame retardant per specification ASTM
E-162 having a flame spread of 25 or

less. Body interior to be reinforced at each
end with 4” wide, 12 gauge galvanized
channels welded to form integral “U” frame
for maximum stress relief.
Rear of body to have an open storage
base made from 18-gauge stainless steel.
Liner to have removable top panels to al­low for service access.

CASTERS: 4” diameter, ball bearing, swiv­el type casters to be non-marking and with
brakes on all wheels. Casters to be mounted
thru two 12 gauge channels for extra rigid­ity.

P.O. Box 795 • Jonesboro, GA 30237

Tel: [phone] • Fax: [phone]

www.lowtempind.com • [e-mail]

DRAIN TROUGH: 14 ga. stainless steel
drain trough welded into top and fitted with
a removable stainless steel anti-splash grid.
Trough to slope to 1” open brass drain
and extend to shut off valve located below
base.

We reserve the right to change specifications and product de­sign without notice. Such revisions do not entitle the buyer to
corresponding changes, improvements, additions or replace­ment for previously purchased equipment.

All equipment to be built in accordance with the Underwriters
Laboratories. Inc. and the National Sanitation Foundation, Inc.
standards and shall bear the Underwriters Laboratories, Inc.
listing label for safety and the Underwriters Laboratories clas­sification label for sanitation.

05/2006

U.L. SanitationClassified to NSF Standards
