6955 VALJEAN AVE, VAN NUYS, CA 91406
PH: (818)994-6498 / FAX: (818)994-6458
/ www.louroe.com[email protected]
®
VERIFACT EGC
MICROPHONES
TECHNICAL DATA SHEET
DESCRIPTION
The Verifact EGC is an omni-directional, low
®
impedance, electret condenser microphone with built-in
preamp and automatic gain control. It can pick up
normal sounds approximately 25 ft. away, or within a 50
ft. diameter circle. It’s built-in limiter prevents the output
signal to be overdriven thus minimizing distortion.
Verifact E-AGC produces line level output (0 dB) and
®
can be located up to 1,000’ from the Louroe base
station. The gain of the microphone can be adjusted
through a potentiometer up to +10dB. The microphone
preamp is mounted inside a singe gang Bell Box
housing that is designed for outdoor use or in moist
environment. The Verifact EGC is compatible with all
®
Louroe Audio Base Stations or Louroe Audio Interface
Adapters.
APPLICATION
When part of a Louroe Audio System, the Verifact
EGC Microphones can be used in situations such
as:
Parking Structures
Secured Walkways
Booking Rooms
Docks
Maintenance Yards
Building Pheriperals
Entry gates
Any area requiring protections
from weather
®
R
U
T
E
D
C
A
I
F
U
N
A
M
N
SPECIFICATIONS
VERIFACT EGC
FEATURES
+
Has Automatic Gain Control/Limiter to
prevent overdriving the receiver
+
Weather Resistant Bell Box Housing
+
Microphone can pick up normal sounds 25'
away
+
Surface mount only
+
May be located up to 1000' from base station
+
T
H
Powered from Louroe Base Station or
E
external 12Vdc source
+
Microphone preamp contains output gain
control Potentiometer to increase the output
up to +10dB
®
Microphone Sensitivity
Frequency response
Output
Current drain
-45dB
50 Hz to 8 kHz
Line Level (0 dB, 1kW at 1 Khz )
10 mA
Supply voltage 12 Vdc
Output gain
+10dB
Microphone housing Single gang Bell Box
Dimensions
Weight
Shipping Weight
4 1/2”H x 2 3/4”W x 2 3/16”D
11.5 oz
1 lb
WIRING REQUIREMENTS
2 Conductor shielded cable, 22
gauge with a 24 gauge drain
wire.
NOTE: Unshielded cable is not
satisfactory for audio
systems.
Egc_mic_spec 12/14
