6955 VALJEAN AVE, VAN NUYS, CA 91406
PH: (818)994-6498 / FAX: (818)994-6458
/ www.louroe.com[email protected]
®
VERIFACT CGC
MICROPHONES
TECHNICAL DATA SHEET
DESCRIPTION
The Verifact CGC is an omni-directional, low impedance, electret
condenser microphone with built-in preamp and automatic gain
control. It can pick up normal sounds approximately 25 ft. away, or
within a 50 ft. diameter circle. It’s built-in limiter prevents the
output signal to be overdriven thus minimizing distortion. Verifact
CGC produces line level output (0 dB) and can be located up to
1,000’ from the Louroe base station. Microphone has
potentiometer to adjust the output gain up to +10dB. It is designed
for mounting in a special or customized housing. The Verifact
CGC is compatible with all Louroe Audio Base Stations or Louroe
Audio Interface Adapters.
NOTE:
®
Verifact CGC Microphone is NOT recommended for
®
outdoor use or in areas with high moisture content.
®
®
APPLICATION
When part of a Louroe Audio System, the Verifact
CGC Microphones can be used in situations such
as:
Convenience Stores
Fast Food Restaurants
Booking Rooms
Interrogation Rooms
Sleep Disorder Centers
Therapy Labs
Cashier Booths
Gas Stations
Day Care Centers Anywhere CCTV
Cameras Are Installed
®
SPECIFICATIONS
VERIFACT CGC
®
FEATURES
+
Has Automatic Gain Control/Limiter to
prevent overdriving the receiver
+
Sturdy ABS housing
+
Microphone can pick up normal sounds 25'
away
+
Easy surface mount to wall or ceiling
+
May be located up to 1000' from base station
+
Powered from Louroe Base Station or
external 12Vdc source
+
Microphone preamp contains output gain
control Potentiometer to increase the output
up to +10dB
Microphone Sensitivity
Frequency response
Output
Current drain
-45dB
50Hz to 8kHz
Line Level (0 dB, 1 kW at 1 Khz )
10 mA
Supply voltage 12 Vdc
Output gain
Microphone housing
Dimensions
Weight
Shipping Weight
+10dB
High impact ABS
2 5/8”L x 2 1/8”W x 1 1/16”H
1.5 oz
1lb
WIRING REQUIREMENTS
2 Conductor shielded cable, 22
gauge with a 24 gauge drain
wire.
NOTE: Unshielded cable is not
satisfactory for audio
systems.
R
U
T
E
D
C
A
I
F
U
N
A
M
N
T
H
E
Cgc_mic 12/14
