Page 1
Pull the crown OUT to the FIRST click and set the
time. Then push the crown IN.
Note: When you set the time, first set the minute
hand to a properly advanced time, then return
the minute hand to the correct time by turning it COUNTERCLOCKWISE.
Time setting for Cal. V516
Turn the hands counterclockwise to advance them
4 to 5 minutes ahead of the desired time. Then
turn them clockwise to set them to the exact time.
■HOW TO USE DAY/DATE MODEL
● The day of the week can be displayed
bilingually (English/another language) and you can
select either.
1. How to set the day and date
■HOW TO USE NON-CALENDAR MODEL
Normal position
First click
Pull out the
crown to the
first click position.
(The crown of
this watch can
be pulled out
to the second
click position.)
Turn the crown
and set the previous day and
date. (The day
and date can be
selected alternatively and
displayed in
English or the
other language.)
Pull out the
crown to the
second click
position and
set the present
day and date
by turning the
minute hand.
Day setting for Cal. V828 (Ladies' Day/Date)
Turn the hands clockwise and counterclockwise
repeatedly between 11:15 pm and 3:45 am to select
the desired day and language.
2. How to set the time
Pull out the crown
to the second
click position and
the second hand
stops. The second
hand should be
stopped on 12
o'clock position.
Turn the crown
and set the desired
time.
Push the crown in
to the normal
position in accordance with a
time signal.
• Be sure to check that the AM/PM is
correctly set. (The day and date are
designed to change once every 24 hours.)
• To adjust the correct time for a quartz
watch, it is necessary to advance the
minute hand 4 or 5 minutes ahead of the
correct time and then turn it
counterclockwise to set the designated
time.
■LUMIBRITE WATCH
（dial,hands,buttons,case,bezel,strapetc.）
☆If your watch is a LORUS LUMIBRITE watch, It
has following features.
LORUS LUMIBRITE watches absorb and store light
energy from natural and artificial light sources and
emit light in the dark. They are made of
environmentally friendly material, and therefore, are
harmless to human beings and the environment.
• With a full charge, LORUS LUMIBRITE watches
glow in the dark hours longer than conventional
luminous watches of this type. If exposed to a light
of more than 500 lux (i. e., the brightness of a typical
office) for approximately 10 minutes, or direct
sunlight for 2 minutes, they will glow for hours.
• Since LORUS LUMIBRITE watches emit the light
they store, the brightness will decrease gradually
over time. The length of time they will glow may
also differ slightly depending on such factors as the
brightness of and distance from the light source used
to charge the watch.
■LORUS LITE(RZA-SERIES)
While the button is kept depressed, the
electroluminescent light evenly illuminates the
entire watch dial for easy viewing in the dark.
Notes:
1. LORUS LITE watches work with one battery.
When the electroluminescent light begins to lose
its luminance, this is an indication that the
battery is depleted. We recommend that you
change the battery before the watch itself stops.
2. If the electroluminescent light is used
continuously for a long time, the battery life
may be less than the specified period.
Electroluminescent light button
Crown
Note:Do not attempt to set the day and date between
the times of 9:00 pm and 4:00 am as this may
cause the day and date displays to change out of
sequence.
■CARE AND SERVICE OF YOUR LORUS
WATCH
1. Care:
• BATTERY
CAUTION
Do not expose the old battery to fire or
recharge it. Keep it at a place beyond the
reach of children. If a child swallows it,
consult a doctor immediately.
NREAQ 07-98
Page 2
･ WATER RESISTANT
Condition
of use
Indication on
the dial/
case back
No indication
WATER
RESISTANT
WATER
RESISTANT
(50 M/5 BAR)*
( )
*
WATER
RESISTANT
100 M/
10 BAR or
above
Accidental
contact with
water, such
as splashes
and rain
Swimming
and taking
a shower
Skin
diving
Scuba
diving
NO NO NO NO
YES NO NO NO
YES YES NO NO
YES YES YES NO
* If your watch is 200 M/20 BAR, 100M/10 BAR
or 50 M/5 BAR water resistant, it is so indicated
on the dial/case back.
･ Do not operate the crown when the watch is wet.
･ If the watch is exposed to salt water, rinse it in
fresh water and then wipe it thoroughly dry.
Caution:
Leather straps are not water resistant except where
indicated, even if the watch head is water resistant.
･ALLERGIC REACTION
Because the case and band touch the skin
directly, it is important to clean them regularly.
If not, shirt sleeves may be stained and those
with delicate skin may develop a rash. Please
wear the watch with some play to avoid any
possible allergic reaction. If you develop a rash
on your wrist, stop wearing and consult a
physician.
･MAGNETISM
Your watch will not be affected by magnetism
generated by household electric appliances.
･SHOCKS AND VIBRATIONS
Your watch may be worn for normal sports
activities, but be careful not to drop it or hit it on
hard surfaces.
･TEMPERATURE
Your watch is preadjusted so that constant
accuracy may be insured at normal temperature.
2. Service:
When your LORUS watch requires repair or
servicing, please see the enclosed "WARRANTY/
GUARANTEE"
■BATTERY CHANGE
The miniature battery which powers your watch
should last as individually specified at right.
However, because it is inserted at the factory, the
actual life of the battery once in your possession
may be less than the specified period.
Be sure to replace the battery to prevent any
possible malfunction as soon as it runs down. To
replace the battery we recommend taking the watch
to a local watch retailer.
* The calibre number of your watch is inscribed on
the case back of the watch.
Calibre No.
BASE METAL BEZEL
STAINLESS STEEL BACK
Y573- □□□□
CAL. NO. BATTERY
BATTERY
LIFE
SEIKO/MAXELL/SONY
SR521SW
SEIKO/MAXELL/SONY/
MATSUSHITA SR626SW
Approx. two
(2) years
V401
V500
V501(JPN)
V501(HK)*
V506*
V507**
V515
Approx. four (4)
years
*Approx. two
(2) years
**Approx. one
and a half
(1.5) years
Approx. three
(3) years
*Approx. two
(2) years
V671
SEIKO/MAXELL/SONY
SR920W
Approx. two
(2) years
Y121
SEIKO/MAXELL/SONY/
MATSUSHITA SR626SW
Approx. four
(4) years
Y167
SEIKO/MAXELL/SONY
SR927SW
Approx. one
and a half
(1.5) years
V824*
V827*
V829
V732
V733
V739
V742
V744
V743
SEIKO/MAXELL/SONY/
MATSUSHITA SR920SW
Approx. five
(5) years
Approx. two
(2) years
V782
SEIKO/MAXELL/SONY/
MATSUSHITA SR621SW
SEIKO/MAXELL/SONY
SR527SW
SEIKO/MAXELL/SONY/
MATSUSHITA SR626SW
Approx. three
(3) years
V810
V811
V821
