SWEET PEEK MINI
VIDEO BABY MONITOR
USER’S GUIDE
Version 1.0
ENGLISH
FRANÇAIS
ESPAÑOL
www.lorexbaby.com
Safety Precautions
• Adult assembly is required. Keep small parts away
from children when assembling.
• This product is not a toy. Do not allow children or
infants to play with it.
• This video monitor is not a substitute for responsible
adult supervision.
• Test the video monitor before use. Become familiar with
its functions.
• Keep the cords out of reach from children and infants.
• Never use extension cords with power adapters.
• Only use the chargers and power adapters provided.
Do not use other chargers or power adapters as this
may damage the device and battery pack.
• Only insert batteries/battery pack of the same type.
• Insert batteries with the correct polarity.
• Do not mix new and used batteries.
• Do not mix alkaline, standard, and rechargeable
batteries.
• Remove exhausted batteries from the product.
• Keep all batteries away from children and infants.
• Dispose or recycle batteries in accordance with local
laws, which may vary by location.
• Do not cover the video monitor with a towel or blanket.
• Do not use the video monitor near water.
• Do not install the video monitor near a heat source.
• Do not touch the plug contacts with sharp or metal
objects.
• Keep this user’s guide for future reference.
To Avoid Injury to
Children & Infants:
• MAKE SURE to keep the camera and all power
cords are least 3ft / 1m away from cribs and out of
reach of your child.
• Use the included cable clips to help keep power
cords away from your child.
3ft / 1m
ENGLISH
Table of Contents:
Product Includes ..............................2
Monitor Overview ...........................2
Camera Overview ...........................3
Getting Started ...............................4
Optional - Wall Mounting the Camera ....... 7
Using Your Baby Monitor ................8
Using the Menu ....................................... 8
Talking to Your Baby ................................ 9
Adjusting Volume .................................... 9
Adjusting Screen Brightness ...................... 9
Turning on the Night-Light ....................... 10
Changing Channels ............................... 10
Enabling VOX Mode (Voice Trigger) ........ 12
Video Off Mode (Audio Only Mode) ....... 13
Pairing Additional Cameras ..........14
Disabling Channels ............................... 16
Technical Specifications .................17
Camera ............................................... 17
Monitor ................................................ 17
Troubleshooting ............................18
Need Help? ...................................18
1
Product Includes
Camera
Screws & Anchors
x1
Monitor
x1*
x2*
x2*
Power Adapter
x1*
Power Adapter
Cable Clips
x1
Battery
x2*
x1
*Contents may vary by model
Monitor Overview
Antenna
Sound LEDs
Display
Power LED
Power on/off
Video on/off + VOX
ESC / night light
Speaker
Talk
Link LED
Volume up/down
Menu
2
ENGLISH
Belt clip
stand
Battery
compartment
Camera Overview
Antenna
Night-light
Power port
Nighttime LED’s
Power LED
Microphone
Power port
Speaker
Pairing
button
Lens
Mounting stand
On/off
switch
Light sensor
3
Getting Started
Connect the power adapter to the
1
camera.
Make sure all power cables are at
least 3ft / 1m away from the crib and
out of reach of your child.
Use the included cable clips to help
keep power cords away from your
child.
Slide the power switch to ON.
2
Power switch
Press down on the battery compartment
3
door and slide it off the monitor.
4
ENGLISH
Connect the battery cable to the monitor.
4
Battery cable
Battery
terminals
The battery cable only connects one
way. Do not force the battery cable.
Replace the battery compartment door.
5
Connect the power adapter to the monitor.
6
Press and hold the power button to turn on
7
the monitor.
Power button
5
