LOREX Technology LW2301 User Manual
MODELS:
LW2301 Series
Copyright © 2009 Lorex Technology Inc.
DIGITAL WIRELESS QUAD
SURVEILLANCE SYSTEM
WITH BUILT-IN VIDEO RECORDER AND
INDOOR/OUTDOOR MOTION CAMERA
Instruction Manual
www.lorexcctv.com
English Version 1.0
www.lorexcctv.com
Important Safeguards
panying
Thank you for purchasing the Digital Wireless Quad Video Recording System.
This manual refers to the following products:
• LW2301 Series
Please visit us on the web for the most current Manuals, Quick Start Guides and Firmware.
Additional Language Manuals may also be available at:
www.lorexcctv.com
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER (OR BACK).
NO USER SERVICABLE PARTS INSIDE.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the
products ‘ enclosure that may be of sufficient magnitude
to constitute a risk of electric shock
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accom
the appliance.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE
THIS UNIT TO RAIN OR MOISTURE.
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF
THE PLUG TO THE WIDE SLOT AND FULLY INSERT.
2
B E F O R E Y O U S T A R T
THIS PRODUCT MAY REQUIRE PROFESSIONAL INSTALLATION
LOREX IS COMMITTED TO FULFILLING YOUR SECURITY NEEDS
• We have developed user friendly products and documentation.
Please read the Quick Start Guide and User Manual before you
install this product.
• Consumer Guides and Video Tutorials are available on our web
site at www.lorexcctv.com/support
• If you require further installation assistance, please visit
www.lorexcctv.com/installation or contact a professional
installer.
• Please refer to the “Need Help” insert for technical support and
customer care information.
• Please note that once the components of this product have been
unsealed, you cannot return this product directly to the store
without the original packaging.
www.lorexcctv.com
AVANT DE
A N T E S D E
COMMENCER
CE PRODUIT POURRAIT EXIGER UNE
INSTALLATION PROFESSIONNELLE
LOREX S’ENGAGE À SATISFAIRE
VOS BESOINS SÉCURITAIRES
• Veuillez lire le guide de démarrage rapide et le
mode d’emploi avant d’installer ce produit.
• Les guides du consommateur et les séances
de tutorat vidéo sont disponibles sur l’Internet en
visitant www.lorexcctv.com/support
• Si vous avez besoin de l’aide pour l’installation,
E M P E Z A R
ESTE PRODUCTO PUEDE EXIGIR UNA
INSTALACIÓN PROFESIONAL
LOREX SE COMPROMETE A SATISFACER
SUS NECESIDADES EN SEGURIDAD
• Favor de leer la guía de instalación rápida y la
guía del usuario antes de instalar este producto.
• Puede conseguir las guías del consumidor y
los cursos en enseñanza video sobre el Internet
visitando www.lorexcctv.com/support
• Si necesita ayuda para la instalación, visite
veuillez visiter www.lorexcctv.com/installation
ou contactez un spécialiste en installation
• Veuillez référer à l’insert “Need Help” pour
ob¬tenir de l’information sur le service à la cli-
entèle et le support technique
• Veuillez constater qu’une fois que les
com¬posantes de ce produit ont été retirées de
l’emballage, vous ne pourrez plus retourner ce
produit directement au magasin.
www.lorexcctv.com/installation o contacte un
especialista en instalaciones
• Favor de referir al documento “Need Help” para
obtener información acerca del servicio al cliente
y al soporte técnico
• Favor de notar que una vez que los compo-
nentes de este producto han sido removidos del
embalaje, no podrá devolver este producto di-
rectamente a la tienda
w w w . l o r e x c c t v . c o m
NEED HELP?
CONTACT US FIRST
DO NOT RETURN THIS PRODUCT TO THE STORE
Please make sure to register your product at www.lorexcctv.com to receive product updates and information
3 EASy WAyS TO CONTACT US:
Online:
Pr od u ct S up por t is a v ai la bl e 2 4/ 7 in c lu di ng pr od uc t
in fo r ma ti on , u se r ma n ua ls , q ui ck s ta r t up g u id es a n d FA Q’ s
at w ww.lo rexcc tv.co m/sup port
To o r de r ac ces so ri es , v is it
www .lorexcct v.com
By Email:
Te ch n ic al S upp or t (f o r te ch n ic al /i ns t al la ti o n is su e s)
sup port@lore xcorp .com
Cu st o me r Ca re (f or w a rr an ty an d ac ce s so ry s a le s)
cus tomerserv ice@l orexc orp.c om
Cu st o me r Fe edb ac k
inf o@lorexco rp.co m
By Phone:
NOR TH AMERIC A: 1- 888-4 25-67 39 (1 -888- 42-LO REX)
MEX ICO: 1-80 0-514 -6739
INT ERNATIONA L: + 800-4 25-67 39-0
(Ex amp le: Fr om the UK , d ial 00 in ste ad of +)
Te ch n ic al S upp or t (f o r te ch n ic al /i ns t al la ti o n is su e s)
Pr es s o pt io n 1 f or E n gl is h, an d th en pr es s o pt io n 1
OR
Cu st o me r Ca re (f or w a rr an ty an d ac ce s so ry s a le s)
Pr es s o pt io n 1 f or E n gl is h, an d th en pr es s o pt io ns 2 to 5
NECESITA AYUDA
VOUS AVEZ BESOIN
D’AIDE?
COMUNÍQUESE PRIMERO
CON NOSOTROS
NO DEVUELVA ESTE PRODUCTO A LA TIENDA
Cerciór ese de p or favor colocar su producto en www.
lorexcc tv.com/r egistrat ion para recibir actu alizacio nes y l a inform ación de l produc to
3 maneras sencillas de comunicarse
con nosotros:
www
En línea:
apoyo al producto disponible 24/7 incluyendo información d el producto, manuales para el usuario , guías
de inici o rápido y preguntas más frecuentes e n
www.lorexcctv.com/support
Para col ocar pedidos de accesorios, visite
www.lorexcctv.com
NE RETOURNEZ PAS CE PRODUIT AU MAGASIN
Veuille z veille r à enre gistrer votre produit à www.
lorexcc tv.com/r egistrat ion pour recevoir des mises à
jour et l’infor mation d e produi t
3 façons faciles de nous contacter:
www
CONTACTEZ-NOUS
D’ABORD
En ligne:
le suppo rt des produits est disponible 24 heu res sur 24, 7
jours su r 7, y compris les informations sur l es produits, les
guides d e l’utilisateur, les guides de démarr age rapide et les
foires à questions
www.lorexcctv.com/support
Pour com mander des accessoires, visitez
www.lorexcctv.com
Por Correo Electrónico:
soporte técnico (para asuntos técnicos/la ins talación)
support@lorexcorp.com
O
servicio al cliente (respecto a la garantía y a la venta
de acces orios)
customerservice@lorexcorp.com
Comentar ios de cliente
info@lorexcorp.com
Por Teléfono:
L’AMÉRIQUE DU NORD: 1-888-425-6739 (1-888-42-lorex)
MEXICO: 1-800-514-6739
INTERNACIONAL: +800-425-6739-0
(Ejemplo: Desde el Reino Unido, marque el 00 en lugar del +)
soporte técnico (para asuntos técnicos/la ins talación)
oprima l a opción 1 para inglés y luego oprima la opción 1
O
servicio al cliente (respecto a la garantía y a la venta de
accesori os) oprima la opción 1 para inglés y luego oprima
las opci ones 2 A 5
sus opiniones son bienvenidas en
info@lorexcorp.com
para colocar pedidos de accesorios, visite
www.lorexcctv.com
Par Courriel:
support technique (pour les questions techniq ues et
d’instal lation) support@lorexcorp.com
OU
service à la clientèle (pour les questions de garantie
et les v entes d’accessoires)
customerservice@lorexcorp.com
Commenta ires des clients
info@lorexcorp.com
Par Téléphone:
NORTE AMÉRICA: 1-888-425-6739 (1-888-42-lorex)
MEXICO: 1-800-514-6739
INTERNATIONAL: +800-425-6739-0
(Exemple: À partir du Royaume-Uni, composez 00 au lieu de +)
support technique (pour les questions techniq ues et
d’instal lation) appuyez sur l’option 1 pour l ’anglais, et
ensuite sur l’option 1
OU
service à la clientèle (pour les questions de garantie
et les v entes d’accessoires) appuyez sur l’option 1 pour
l’anglais, et ensuite sur les options 2 à 5
nous serions heureux de recevoir vos
commentaires à info@lorexcorp.com pour
commander des accessoires, visitez
www.lorexcctv.com
Important Safeguards
Important Safeguards
In addition to the careful attention devoted to quality standards in the manufacture process of
your video product, safety is a major factor in the design of every instrument. However, safety is
your responsibility too. This sheet lists important information that will help to assure your
enjoyment and proper use of the video product and accessory equipment. Please read them
carefully before operating and using your video product
Installation
1. Read and Follow Instructions - All the safety
and operating instructions should be read
before the video product is operated. Follow
all operating instructions.
2. Retain Instructions - The safety and
operating instructions should be retained for
future reference.
3. Heed Warnings - Comply with all warnings
on the video product and in the operating
instructions.
4. Polarization - Do not defeat the safety
purpose of the polarized or grounding-type
plug.
o A polarized plug has two blades with
one wider than the other.
o A grounding type plug has two
blades and a third grounding prong.
o The wide blade or the third prong is
provided for your safety.
o If the provided plug does not fit into
your outlet, consult an electrician
for replacement of the obsolete
outlet
5. Power Sources - This video product should
be operated only from the type of power
source indicated on the marking label. If you
are not sure of the type of power supply to
your location, consult your video dealer or
local power company. For video products
intended to operate from battery power, or
other sources, refer to the operating
instructions.
6. Overloading - Do not overload wall outlets of
extension cords as this can result in the risk
of fire or electric shock. Overloaded AC
outlets, extension cords, frayed power cords,
damaged or cracked wire insulation, and
broken plugs are dangerous. They may result
in a shock or fire hazard. Periodically
examine the cord, and if its appearance
indicates damage or deteriorated insulation,
have it replaced by your service technician.
7. Power-Cord Protection - Power supply
cords should be routed so that they are not
likely to be walked on or pinched by items
placed upon or against them, paying
particular attention to cords at plugs,
convenience receptacles, and the point where
they exit from the video product.
.
8. Ventilation - Slots and openings in the case
are provided for ventilation to ensure reliable
operation of the video product and to protect
it from overheating. These openings must not
be blocked or covered. The openings should
never be blocked by placing the video
equipment on a bed, sofa, rug, or other
similar surface. This video product should
never be placed near or over a radiator or
heat register. This video product should not
be placed in a built-in installation such as a
bookcase or rack unless proper ventilation is
provided or the video product manufacturer’s
instructions have been followed.
9. Camera Extension Cables – Check the rating
of your extension cable(s) to verify
compliance with your local authority
regulations prior to installation.
10. Attachments - Do not use attachments
unless recommended by the video product
manufacturer as they may cause a hazard.
11. Water and Moisture - Do not use this video
product near water. For example, near a bath
tub, wash bowl, kitchen sink or laundry tub, in
a wet basement, near a swimming pool and
the like. Caution: Maintain electrical safety.
Power line operated equipment or
accessories connected to this unit should
bear the UL listing mark of CSA certification
mark on the accessory itself and should not
be modified so as to defeat the safety
features. This will help avoid any potential
hazard from electrical shock or fire. If in
doubt, contact qualified service personnel.
12. Accessories - Do not place this video
equipment on an unstable cart, stand, tripod,
or table.
The video equipment may fall,
causing serious damage to the
video product. Use this video
product only with a cart, stand,
tripod, bracket, or table
recommended by the
manufacturer or sold with the
video product.
Any mounting of the product should follow
the manufacturer’s instructions and use a
mounting accessory recommended by the
manufacturer.
3
Important Safeguards
Service
13. Servicing - Do not attempt to service this
video equipment yourself as opening or
removing covers may expose you to
dangerous voltage or other hazards. Refer all
servicing to qualified service personnel.
14. Conditions Requiring Service - Unplug this
video product from the wall outlet and refer
servicing to qualified service personnel under
the following conditions.
A. When the power supply cord or plug is
15. Replacement Parts - When replacement
16. Safety Check - Upon completion of any
17. Mounting - The cameras provided with this
18. Heat - The product should be situated away
damaged.
B. If liquid has been spilled or objects have
fallen into the video product.
C. If the video product has been exposed to
rain or water.
D. If the video product does not operate
normally by following the operating
instructions. Adjust only those controls
that are covered by the operating
instructions. Improper adjustment of
other controls may result in damage and
will often require extensive work by a
qualified technician to restore the video
product to its normal operation.
E. If the video product has been dropped or
the cabinet has been damaged.
F. When the video product exhibits a distinct
change in performance. This indicates a
need for service.
parts are required, have the service
technician verify that the replacements used
have the same safety characteristics as the
original parts. Use of replacements specified
by the video product manufacturer can
prevent fire, electric shock or other hazards.
service or repairs to this video product, ask
the service technician to perform safety
checks recommended by the manufacturer to
determine that the video product is in safe
operating condition.
system should be mounted only as instructed
in this guide, using the provided mounting
brackets.
from heat sources such as radiators, heat
registers, stoves, or other products (including
amplifiers) that produce heat.
Use
19. Cleaning - Unplug the video product from the
wall outlet before cleaning. Do not use liquid
cleaners or aerosol cleaners. Use a damp
cloth for cleaning.
20. Product and Cart Combination - Video and
cart combination should be moved with care.
Quick stops, excessive force, and uneven
surfaces may cause the video product and car
combination to overturn
21. Object and Liquid Entry - Never push objects
for any kind into this video product through
openings as they may touch dangerous
voltage points or “short-out” parts that could
result in a fire or electric shock. Never spill
liquid of any kind on the video product
22. Lightning - For added protection for this
video product during a lightning storm, or
when it is left unattended and unused for long
periods of time, unplug it from the wall outlet
and disconnect the antenna or cable system.
This will prevent damage to the video product
due to lightning and power line surges. The
manufacturer’s instructions and use a
mounting accessory recommended by the
manufacturer.
4
General Precautions
General Precautions
1. All warnings and instructions in this manual should be followed
2. Remove the plug from the outlet before cleaning. Do not use liquid aerosol detergents. Use a water
dampened cloth for cleaning
3. Do not use this unit in humid or wet places
4. Keep enough space around the unit for ventilation. Slots and openings in the storage cabinet should not
be blocked
FCC NOTICE
This device complies with Part 15, subpart C, of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause
undesired operation.
The manufacturer is not responsible for any radio or TV interference caused by unauthorized
modifications to this equipment. Such modifications could void the user's authority to
operate the equipment.
However, it is imperative that the user follows the guidelines in this manual to avoid
improper usage which may result in damage to the unit, electrical shock and fire hazard
injury
In order to improve the feature functions and quality of this product, the specifications are
subject to change without notice from time to time.
www.lorexcctv.com
5
Features
Features
Technology
Ultra Digital Wireless technology features the latest advancements in wireless video surveillance
Minimizes interference with other devices such as wireless routers, cordless phones, Bluetooth
devices and is Wi-Fi friendly
100% Digital video and audio provides excellent image quality and crystal clear sound
Offers a secure connection between the receiver and camera for total privacy
Signal strength and out of range notifications help you find best possible installation location
Receiver
Built-in Video Recorder with SD memory card slot
Includes SD memory card and supports up to 16 GB size
Record when motion is detected by the camera or schedule a recording start and stop time
Record at VGA (640x480) resolution for excellent playback quality or QVGA (320x240) resolution to
maximize recording time
Viewing Options:
• Quad Mode Shows up to 4 Camera Views on Same Screen
• Auto Sequence Viewing Mode Shows each camera in Full Screen
On-screen menu system makes set-up and changing camera settings easy
Connects in minutes to any TV
System expandable up to 4 cameras
Includes IR extender so you can hide the receiver out of plain sight and still control all functions
using the included remote control
New recording / memory full indicators
Place on a flat surface or wall mount with included mounting kit
SMA connector allows for the usage of higher power antennas to extend wireless range
(antennas sold separately)
Camera
VGA (640x480) Resolution Camera
IR Night Vision 40 ft. / 12 m*
Built-in PIR motion sensor for accurate motion detection
Durable metal weatherproof housing ideal for indoor/outdoor use
Microphone for listen-in surveillance
* Stated IR Illumination range is based on ideal conditions. Actual range and image clarity depends on installation location, viewing
area and light reflection/absorption level of object
The Digital Wireless signal transmission type used by the Lorex LW2301 series is also known as FHSS –
Frequency Hopping Spread Spectrum. This type of signal is highly resistant to deliberate jamming as it
generates a channel hopping sequence using an algorithm generated by the receiver system.
6
Table of Contents
Table of Contents
Getting Started ................................................................................................................................................ 8
Wireless Receiver ........................................................................................................................................... 9
Camera........................................................................................................................................................... 11
Remote Control ............................................................................................................................................. 12
Installing the Camera ................................................................................................................................... 13
Connecting the Wireless Receiver............................................................................................................... 14
LED Indicators on the Wireless Receiver .................................................................................................. 15
Using the System........................................................................................................................................... 16
On-Screen Display...................................................................................................................................... 16
Viewing Modes............................................................................................................................................... 18
Quad Mode.................................................................................................................................................. 19
Setting the Time ............................................................................................................................................ 20
Recording....................................................................................................................................................... 21
Recording Mode Summary......................................................................................................................... 21
Manual Recording ...................................................................................................................................... 22
Schedule Recording ................................................................................................................................... 23
Stopping Schedule Recording ................................................................................................................ 24
Motion Recording ....................................................................................................................................... 25
Viewing Recorded Video................................................................................................................................27
Viewing Video Using the System ................................................................................................................ 27
Controlling Playback .............................................................................................................................. 29
Viewing Video Directly From the SD Card.................................................................................................. 30
PC............................................................................................................................................................ 30
Mac.......................................................................................................................................................... 30
Using the Main Menu ..................................................................................................................................... 31
Camera On/Off............................................................................................................................................ 32
Record ........................................................................................................................................................ 33
Quality ..................................................................................................................................................... 34
VGA or QVGA? ......................................................................................................................................... 34
Trigger Record........................................................................................................................................ 35
Schedule Record..................................................................................................................................... 36
Overwrite ................................................................................................................................................ 37
Pairing ........................................................................................................................................................ 38
Settings....................................................................................................................................................... 40
Date & Time ............................................................................................................................................ 41
AV Out...................................................................................................................................................... 42
Zoom ....................................................................................................................................................... 43
Brightness .............................................................................................................................................. 44
Format .................................................................................................................................................... 45
Default .................................................................................................................................................... 46
Appendix A: System Specifications .............................................................................................................. 47
Appendix B: About Digital Wireless Technology......................................................................................... 48
Appendix C: Adding Cameras ....................................................................................................................... 49
Appendix D: Strengthening the Range of the Wireless Signal ................................................................... 50
Appendix E: Deleting Video Files on the System ......................................................................................... 52
Appendix F: Estimated Recording Times on SD Cards................................................................................ 53
Appendix G: Power Failure........................................................................................................................... 54
Troubleshooting ............................................................................................................................................ 55
FAQ................................................................................................................................................................. 56
7
Getting Started
Getting Started
The system comes with the following components:
1 x COLOR OUTDOOR
1 X WIRELESS ANTENNA
NIGHT VISION
*
1 x SD MEMORY
CARD
2 x WALL MOUNTING
KIT (FOR RECEIVER
AND CAMERA)
(FOR CAMERA)
*Camera configuration may vary by model
1 x CAMERA
MOUNTING STAND
1 x AUDIO/VIDEO
CABLE
2 x POWER ADAPTERS
(FOR RECEIVER &
1 x WIRELESS
RECEIVER
1 x REMOTE
CONTROL
1 x IR
EXTENDER
8
CHECK YOUR PACKAGE TO CONFIRM THAT YOU HAVE RECEIVED THE COMPLETE
SYSTEM, INCLUDING ALL COMPONENTS SHOWN ABOVE.
Wireless Receiver
Top Panel
2
1
Wireless Receiver
3
4
5
6
1. CHANNEL: Press M to change channels 1~4 manually; press A to enable Auto Sequence Viewing
Mode.
2. RECORD: Press M to start Manual Recording; press M again to stop. Press A to start Motion
Recording; press A again to stop.
NOTE: The date and time must be set on the system prior to using Schedule Recording. For
details, see “Setting the Time” on page 20.
3. Channels, OK: QUAD MODE ONLY—Press 1 to view camera 1, 2 to view camera 2, 3 to view
camera 3, and 4 to view camera 4; press OK to enter/confirm menu selections.
NOTE: The OK button serves the same function as the Enter button on the remote control.
4. Quad: Press to change display view to Quad (4-way); press again to exit.
5. MENU: Press to open the Main Menu, cancel/exit, or go to the previous page.
6. Del.: Press to delete files on the SD card
7. LED Indicators: LED indicators for camera and receiver operations. For details, see “LED
Indicators on the Wireless Receiver” on page 15.
7
9
Wireless Receiver
Left Panel
1
2
3
1. Antenna: Connection jack for the wireless antenna.
2. DC: Connect the included power adapter.
3. AV Out: Connect the included Audio/Video cable to display images from the receiver on your
TV/monitor.
4. Alarm Vol.: Adjust the volume of the motion alarm; will also adjust volume of system “beeps”
when you press buttons on the receiver and remote control.
Right Panel
4
1. IR Extension: Connect the included IR extender (optional).
2. Lock: Slide to lock the buttons on the wireless receiver.
3. SD Card: Insert an SD card (max 16 GB) as shown on the diagram.
10
1
2
VGA
/
QVGA
3
Pair
Camera
2
1
1. PIR Sensor: Passive IR motion sensor for more accurate motion recording.
2. Microphone: Built-in microphone underneath camera body.
3. Lens: Camera lens.
4. Night Vision IR: Night vision IR LEDs used for viewing in complete darkness.
5. Pair: Pairing button. For more details, see “Pairing” on page 38.
6. Antenna: Wireless antenna.
7. Power Cable: Connect the included power adapter to the cable extending from the camera.
3
5
4
6
Camera
7
11
Remote Control
Remote Control
ATTENTION: Before using the remote
1
control, remove the protective clear
plastic tab from the battery cover.
1. 1/
f: Move menu cursor UP;
play/pause playback; jump to
camera 1 while in Quad Mode.
2. Enter: Confirm menu selections
(same as OK on the wireless
receiver).
: Move menu cursor LEFT;
3. 4/
decrease values in certain menu
options; rewind playback; jump to
camera 4 while in Quad Mode.
4. MENU / Back: Press to open the
Main Menu; go back/close menu
windows.
5. Record: Press Motion to enable
motion recording – system will
ONLY record when motion is
detected; press
manual recording.
6. Volume: Press to
increase/decrease volume during
playback. Use the receiver to
change volume of buzzer and
motion alarm.
7. Quad: Press to change the display
view to quad (4-way) split-screen.
: Move menu cursor RIGHT;
8. 2/
increase values in certain menu
options; increase playback speed;
jump to camera 2 while in Quad
Mode.
: Move menu cursor DOWN;
9. 3/
decrease values in certain menu
options; stop playback; jump to
camera 3 while in Quad Mode.
10. Scan/Del: Press to delete
recorded video files.
11. Channel: Press “A” to enable/disable Auto Sequence Viewing Mode; press M to manually change
the channels (1~4).
12. AV: Not used.
to start/stop
2
3
4
5
6
Figure 1.0 Remote Control
7
8
9
10
11
12
12
NOTE: Unless otherwise noted, button names mentioned in steps in this manual will refer to
buttons on the remote control.
Installing the Camera
Before you install the camera, carefully plan where
and how it will be positioned, and where you will
route the cable that connects the camera to the
power adapter.
• Before starting permanent installation,
verify its performance by observing the
image on a monitor when camera is
positioned in the same location/position
where it will be permanently installed
Installation Warnings:
• Aim the Cameras to best optimize the
viewing area: Select a location for the
camera that provides a clear view of the
area you want to monitor, which is free
from dust, and is not in line-of-sight to a
strong light source or direct sunlight
• Avoid installing the cameras where there
are thick walls or obstructions between the
Cameras and the Receiver
• Select a location for the camera that has
an ambient temperature between
14°F~122°F (-10°C ~ 50°C)
Installing the Camera
Figure 2.0 Attach stand to mounting surface
To install the camera:
1. Use the included mounting screws to
mount the stand to the mounting surface:
• Mark the position of the screw holes on the
wall
• Drill holes and insert the drywall plugs as needed
• Firmly attach the stand to the wall using the provided screws
Figure 2.1 Attach the camera to the stand and
tighten thumbscrews
2. Screw on the wireless antenna to the rear panel of the camera.
3. Attach the camera to the mounting stand. Adjust the angle of the camera until the desired
view is set. Tighten the thumbscrews to secure the desired camera position.
4. Connect the black power cable extending from the camera to the cable of the power
adapter; plug the power adapter to an outlet or surge protector.
NOTE: You can install additional cameras (maximum of 4 cameras). When adding cameras that
were not included in the original box, you will need to pair the cameras with the receiver. For
details, see “Appendix C: Adding Cameras” on page 49.
13
Connecting the Wireless Receiver
g
g
Connecting the Wireless Receiver
To set up the wireless receiver:
1. Connect the Black cable from the AV cable to AV Out port on the left panel of the receiver.
Connect the Yellow video cable and White audio cable (mono) to your TV, DVR, or
observation system.
2. Insert the included SD card into the SD Card slot on the right panel of the receiver until you
hear a “click.”
NOTE: The receiver is compatible with most major brands of SD card up to 16 GB. For recording
times on SD cards, see “Appendix F: Estimated Recording Times on SD Cards” on page 53.
3. Place the receiver in a place that will have a clear reception to your camera*.
4. Connect the cable from the power adapter to the 9V DC port on the left panel of the receiver,
and then connect the power adapter to an outlet or surge protector.
5. Change the video input on your TV or monitor to the corresponding input of the video cable
(i.e. Video 1, Video 2, Auxiliary, etc.).
OPTIONAL
6.
: Connect the included IR extender to the IR Extension port on the right panel of
the receiver. Use the IR extender to if you want to hide the receiver from plain sight. You can
conceal the sensor of the IR Extender in a bookcase, flowers, etc., and still fully control the
system using the included remote control.
POWER
ADAPTER
Fi
ure 3.0 Connect the power adapter, and AV cable
IR EXTENDER
Figure 3.1 Connect the IR extender (optional) and insert the SD card
*Avoid installing in a location which requires the wireless signal to pass through cement, concrete, and metal
structures. This will reduce the ran
RECEIVER (LEFT PANEL)
AV CABLE
RECEIVER (RIGHT PANEL)
SD CARD
e of transmission.
14
Connecting the Wireless Receiver
LED Indicators on the Wireless Receiver
Use the LED indicators on the wireless receiver to observe the status of the receiver, cameras,
and SD card.
Figure 3.2 LED indicators on wireless receiver
The blue LEDs indicate the following:
• MANUAL: Channel switching set to manual
•
AUTO: Channel switching set to Auto – Auto Sequence Viewing Mode enabled
NOTE: By default, Auto Sequence Viewing Mode is enabled when you first power on the wireless
receiver.
M: Manual recording enabled
•
•
A: Motion recording enabled
•
NEW: A new video file has been recorded to the SD card
•
FULL: The SD card is full
NOTE: The “Full” light will only appear if Overwrite is disabled. For details, see “Overwrite” on
page 37.
15
Using the System
Using the System
By default, the camera included with your system is automatically paired to the wireless
receiver. The camera and receiver will communicate with one another once they are powered
on.
On-Screen Display
With camera 1 properly connected and powered on, the system displays a single channel fullscreen live view of the camera.
NOTE: You should always power on the cameras before powering on the receiver.
1
RREECC
CCaamm11
4
2
3
160602-1.AVI
2009 07 17
16:32:05
1. Signal Indicator: Strength of the wireless signal between the camera and the wireless
receiver.
2. Recording Indicator: “REC” appears during manual, motion, and schedule recording.
Figure 4.0 Live viewing – single channel
5
6
7
8
3. File Name: Name of the file actively being recorded.
4. Camera indicator: Displays the camera you are presently viewing; position of camera
indicators shifts to the left side of the screen while in Quad mode.
5. File Icon: Flashing yellow icon indicates a new video file is on the SD card.
6. Power Failure icon: Flashing icon indicates a power failure occurred while the system was
recording.
7. SD Card icon: Icon appears when an SD card is present in the receiver; an SD card is required
for recording.
8. Time Stamp: The current date and time on the system.
16
