DIGITAL VIDEO SURVEILLANCE RECORDER
Instruction Manual
English Version 4.0
KEEP IN TOUCH
STAY CONNECTED
RETAIL
*8 Channel Model Shown
INDUSTRY
www.lorextechnology.com
Copyright © 2012 Lorex Technology Inc.
BUSINESS HOME
BUSINESS
OUTDOOR
LH330 EDGE2 Series
LH340 EDGE3 Series
Thank you for purchasing the Edge Series Digital Video Surveillance Recorder.
This manual refers to the following models:
• LH338 (8-channel EDGE2)
• LH336 (16-channel EDGE2)
• LH348 (8-channel EDGE3)
• LH346 (16-channel EDGE3)
For the latest online manual, downloads and product updates, and to learn about our
complete range of accessory products, please visit our website at:
www.lorextechnology.com
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RICK OF ELECTRIC SHOCK DO NOT
REMOVE COVER. NO USER SERVICABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an equilateral
triangle, is intended to alert the user to the presence of uninsulated
"dangerous voltage" within the products ' enclosure that may be of
sufficient magnitude to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is intended to
alert the user to the presence of important operating and
maintenance (servicing) instructions in the literature accompanying
the appliance.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT
EXPOSE THIS UNIT TO RAIN OR MOISTURE.
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE
OF THE PLUG TO THE WIDE SLOT AND FULLY INSERT.
NEED HELP?
CONTACT US FIRST
DO NOT RETURN THIS PRODUCT TO THE STORE
Please make sure to register your product at www.lorextechnology.com
to receive product updates and technical support.
2 Easy Ways to Contact Us
Online:
Product Support is available 24/7 including product information, user
manuals, quick start up guides and FAQ’s at
www.lorextechnology.com/support
For all other matters, visit www.lorextechnology.com
By Phone:
North America:
Customer Service (for warranty matters): 1-888-425-6739 (1-888-42-LOREX)
Tech Support (for technical/installation issues): 1-877-755-6739 (1-877-75-LOREX)
Mexico: 001-800-681-9263, 001-800-514-6739
SEP 12 2012 - R14
International: +800-425-6739-0
(Example: From the UK, dial 00 instead of +)
VIEW YOUR WORLD™
VOIR VOTRE MONDE
VEA SU MUNDO™
MD
¿NECESITA AYUDA?
COMUNÍQUESE PRIMERO
CON NOSOTROS
NO DEVUELVA ESTE PRODUCTO A LA TIENDA NE RETOURNEZ PAS CE PRODUIT AU MAGASIN
Por favor, registre su producto en www.lorextechnology.
com para recibir actualizaciones del producto y
asistencia técnica.
Hay 2 maneras fáciles de comunicarse
con nosotros:
En línea:
Apoyo al cliente está disponible 24/7, incluyendo
información del producto, manuales para el usuario, guías
de inicio rápido y preguntas más frecuentes en:
www.lorextechnology.com/support
BESOIN D’ASSISTANCE?
COMMUNIQUEZ D’ABORD
AVEC NOUS
Veuillez enregistrer votre produit sur le site
www.lorextechnology.com afin de recevoir des mises à jour
et le soutien technique pour votre produit.
2 façons simples de communiquer
avec nous :
En ligne :
À votre disposition 24/7, le soutien pour les produits comprend
les renseignements sur les produits, guides d’utilisation, guides
de départ rapide et FAQ :
www.lorextechnology.com/support
Para todo lo demás, visite
www.lorextechnology.com
Por teléfono:
Norte América:
Atención al cliente (para asuntos de la garantía):
1-888-425-6739 (1-888-42-LOREX)
Asistencia técnica (para asuntos técnicos o de instalación):
1-877-755-6739 (1-877-75-LOREX)
Mexico: 001-800-681-9263, 001-800-514-6739
Internacional: +800-425-6739-0
(Ejemplo: Desde el Reino Unido, marque el 00 en lugar del +)
Pour toutes les autres questions,
visitez www.lorextechnology.com
Par téléphone :
En Amérique du Nord :
Service à la clientèle (pour tout ce qui concerne la garantie) :
1-888-425-6739 (1-888-42-LOREX)
Soutien technique (pour les questions d’ordre technique ou relatives à
l’installation) : 1-877-755-6739 (1-877-75-LOREX)
Mexique : 001-800-681-9263, 001-800-514-6739
International : +800-425-6739-0
(par exemple : à partir du Royaume-Uni, composez le 00 au lieu de +)
SEP 12 2012 - R14
BEFORE YOU START
Please make sure to register your product at www.lorextechnology.com
to receive product updates and technical support
THIS PRODUCT MAY REQUIRE PROFESSIONAL INSTALLATION
LOREX IS COMMITTED TO FULFILLING YOUR SECURITY NEEDS
• We have developed user friendly products and documentation.
Please read the Quick Start Guide and User Manual before you
install this product.
• Consumer Guides and Video Tutorials are available on our web
site at www.lorextechnology.com/support
• If you require further installation assistance, please visit
www.lorextechnology.com/installation or contact a
professional installer.
• Please note that once the components of this product have been
unsealed, you cannot return this product directly to the store
SEP 6 2012 - R8
without the original packaging.
AVANT DE
ANTES DE
COMMENCER
Veuillez enregistrer votre produit sur le site
www.lorextechnology.com afin de recevoir
des mises à jour et le soutien technique pour
votre produit.
CE PRODUIT PEUT NÉCESSITER UNE
INSTALLATION PROFESSIONNELLE
LOREX S’ENGAGE À RÉPONDRE À VOS
BESOINS EN MATIÈRE DE SÉCURITÉ
• Nous avons conçu et développé une documentation
et des produits extrêmement conviviaux. Veuillez
lire le Guide de départ rapide et le Guide
d’utilisation avant d’installer ce produit.
• Des guides pour consommateurs et des tutoriels
EMPEZAR
Cerciórese de por favor colocar su producto
en www.lorextechnology.com para recibir
actualizaciones y la información del producto
y soporte técnico.
ESTE PRODUCTO PUEDE EXIGIR UNA INSTALACIÓN PROFESIONAL
LOREX SE COMPROMETE A SATISFACER
SUS NECESIDADES EN SEGURIDAD
• Favor de leer la guía de instalación rápida y la
guía del usuario antes de instalar este product.
• Puede conseguir las guías del consumidor y los
cursos en enseñanza video sobre el Internet
visitando www.lorextechnology.com/support
vidéo vous sont offerts sur notre site Web :
www.lorextechnology.com/support
• Si vous avez besoin de plus d’assistance pour
l’installation de ce produit, veuillez visiter le site
www.lorextechnology/installation ou communiquez
avec un installateur professionnel.
• Veuillez prendre note que lorsque vous avez déballé
les pièces et composantes de ce produit, vous ne
pouvez pas retourner celui-ci directement au
magasin sans son emballage original.
www.lorextechnology.com
• Si necesita ayuda para la instalación, visite
www.lorextechnology.com/installation o contacte
un especialista en instalaciones.
• Favor de notar que una vez que los componentes
de este producto han sido removidos del
embalaje, no podrá devolver este producto
directamente a la tienda.
VIEW YOUR WORLD™
VOIR VOTRE MONDE
VEA SU MUNDO™
MD
SEP 6 2012 - R8
Important Safeguards
In addition to the careful attention devoted to quality standards in the manufacture process of your
product, safety is a major factor in the design of every instrument. However, safety is your
responsibility too. This sheet lists important information that will help to ensure your enjoyment
and proper use of the product and accessory equipment. Please read them carefully before
operating and using your product.
General Precautions
1. All warnings and instructions in this manual should be followed.
2. Remove the plug from the outlet before cleaning. Do not use liquid aerosol detergents. Use a
water-dampened cloth for cleaning.
3. Do not use this product in humid or wet places.
4. Keep enough space around the product for ventilation. Slots and openings in the storage
cabinet should not be blocked.
5. It is highly recommended to connect the product to a surge protector to protect from damage
caused by electrical surges. It is also recommended to connect the product to an
uninterruptible power supply (UPS), which has an internal battery that will keep the product
running in the event of a power outage.
6.
Installation
1. Read and Follow Instructions - All the safety and
operating instructions should be read before the product
is operated. Follow all operating instructions.
2. Retain Instructions - The safety and operating
instructions should be retained for future reference.
3. Heed Warnings - Comply with all warnings on the
product and in the operating instructions.
4. Polarization - Do not defeat the safety
purpose of the polarized or
grounding-type plug.
A polarized plug has two blades with
one wider than the other.
A grounding type plug has two blades
and a third grounding prong.
The wide blade or the third prong are
rovided for your safety.
p
If the provided plug does not fit into your outlet, consult
an electrician for replacement of the obsolete outlet.
5. Power Sources - This product should be operated only
from the type of power source indicated on the marking
label. If you are not sure of the type of power supplied
to your location, consult your video dealer or local power
company. For products intended to operate from battery
power, or other sources, refer to the operating
instructions.
Overloading - Do not overload wall outlets or
extension cords as this can result in the risk of fire or
electric shock. Overloaded AC outlets, extension
cords, frayed power cords, damaged or cracked wire
insulation, and broken plugs are dangerous. They may
result in a shock or fire hazard. Periodically examine
the cord, and if its appearance indicates damage or
deteriorated insulation, have it replaced by your
service technician.
7. Power-Cord Protection - Power supply cords should
be routed so that they are not likely to be walked on or
pinched by items placed upon or against them. Pay
particular attention to cords at plugs, convenience
receptacles, and the point where they exit from the
product.
Surge Protectors - It is highly recommended that the
8.
product be connected to a surge protector. Doing so
will protect the product from damage caused by power
surges. Surge protectors should bear the UL listing
mark or CSA certification mark.
9. Uninterruptible Power Supplies (UPS) - Because
this product is designed for continuous,
24/7 operation, it is recommended that you connect
the product to an uninterruptible power supply. An
uninterruptible power supply has an internal battery
that will keep the product running in the event of a
power outage. Uninterruptible power supplies should
bear the UL listing mark or CSA certification mark.
Caution: Maintain electrical safety. Power line
operated equipment or accessories connected to this
product should bear the UL listing mark or CSA
certification mark on the accessory itself and should
not be modif ied so as to defeat the safety features. This
will help avoid any potential hazard from electrical
shock or fire. If in doubt, contact qualified service
personnel.
v
Installation (Continued)
10. Ventilation - Slots and openings in the case are
provided for ventilation to ensure reliable operation of
the product and to protect it from overheating. These
openings must not be blocked or covered. The
openings should never be blocked by placing the
product on a bed, sofa, rug, or other similar surface.
This product should never be placed near or over a
radiator or heat register. This product should not be
placed in a built-in installation such as a bookcase or
rack unless proper ventilation is provided and the
product manufacturer’s instructions have been
followed.
11. Attachments - Do not use attachments unless
recommended by the product manufacturer as they
may cause a hazard.
12. Water and Moisture - Do not use this product near
water — for example, near a bath tub, wash bowl,
kitchen sink or laundry tub, in a wet basement, near a
swimming pool and the like.
13. Heat - The product should be situated away from heat
sources such as radiators, heat registers, stoves, or
other products (including amplifiers) that produce
heat.
14. Accessories - Do not place this
product on an unstable cart,
stand, tripod, or table. The product
may fall, causing serious damage
to the product. Use this product
only with a cart, stand, tripod,
bracket, or table recommended by
the manufacturer or sold with the
product. Any mounting of the
product should follow the manufacturer’s instructions
and use a mounting accessory recommended by the
manufacturer.
15. Camera Extension Cables – Check the rating of
your extension cable(s) to verify compliance with your
local authority regulations prior to installation.
16. Mounting - The cameras provided with this system
should be mounted only as instructed in this guide or
the instructions that came with your cameras, using
the provided mounting brackets.
17. Camera Installation- Cameras are not intended for
submersion in water. Not all cameras can be installed
outdoors. Check your camera environmental rating to
confirm if they can be installed outdoors. When
installing cameras outdoors, installation in a sheltered
area is required.
Service
1. Servicing - Do not attempt to service this product
yourself, as opening or removing covers may expose
you to dangerous voltage or other hazards. Refer all
servicing to qualified service personnel.
2. Conditions Requiring Service - Unplug this product
from the wall outlet and refer servicing to qualified
service personnel under the following conditions:
A. When the power supply cord or plug is damaged.
B. If liquid has been spilled or objects have fallen into
the pr
oduct.
C. If the product has been exposed to rain or water.
D. If the product has been dropped or the cabinet has
been damage
E. If the product does not operate normally by
following the operating instructions. Adjust only those
controls that are covered by the operating
instructions. Improper adjustment of other controls
may result in damage and will often require extensive
work by a qualified technician to restore the product
to its normal operation.
F. When the product exhibits a distinct change in
performance. This indicates a need for service.
7. Replacement Parts - When replacement parts are
required, have the service technician verify that the
replacements used have the same safety
characteristics as the original parts. Use of
replacements specified by the product manufacturer
can prevent fire, electric shock, or other hazards.
8. Safety Check - Upon completion of any service or
repairs to this product, ask the service technician to
perform safety checks recommended by the
manufacturer to determine that the product is in safe
operating condition.
d.
Use
1. Cleaning - Unplug the product from the wall outlet
before cleaning. Do not use liquid cleaners or aerosol
cleaners. Use a damp cloth for cleaning.
2. Product and Cart Combination - When product is
installed on a cart, product and cart combination
should be moved with care. Quick stops, excessive
force, and uneven surfaces may cause the product and
cart combination to overturn.
Object and Liquid Entry - Never push objects of any
3.
kind into this product through openings as they may
touch dangerous voltage points or “short-out” parts
that could result in a fire or electric shock. Never spill
liquid of any kind on the product.
4.
Lightning - For added protection of this product
during a lightning storm, or when it is left unattended
and unused for long periods of time, unplug it from
the wall outlet and disconnect the antenna or cable
system. This will prevent damage to the product due
to lightning and power line surges.
WARNING: This product contains a button battery. If swallowed, it could cause
severe injury or death in just two hours. Seek medical attention immediately.
vi
FCC/IC Notice:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction, may cause harmful interference
to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception (which can be determined by
turning the equipment on and off), the user is encouraged to try to correct the interference by one or more
of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected
• Consult the dealer or an experienced radio or television technician for assistance
Modification:
Any changes or modifications not expressly approved by the grantee of this device could void the user's
authority to operate the device.
Toute modification non approuvée explicitement par le fournisseur de licence de l'appareil peut entraîner
l'annulation du droit de l'utilsateur à utiliser l'appareil.
RoHS:
This product is fully compliant with the European Union Restriction of the Use of Certain Hazardous
Substances in Electrical and Electronic Equipment ("RoHS") Directive (2002/95/EC). The RoHS directive
prohibits the sale of electronic equipment containing certain hazardous substances such as lead,
cadmium, mercury, and hexavalent chromium, PBB, and PBDE in the European Union.
NOTICES
This product has been certified and found to comply with the limits regulated by FCC, EMC, and
www.lorextechnology.com
Product Information
User Manuals
Quick Start Guides
Specification Sheets
Software Upgrades
Firmware Upgrades
LVD. Therefore, it is designated to provide reasonable protection against inter
cause interference with other appliance usage.
However, it is imperative that the user follows the guidelines in this
manual to avoid improper
usage, which may result in damage to the product, electrical shock and fire hazard injury.
In order to improve the features, functions, and quality of
this pr
oduct, the specifications are
subject to change without notice from time to time.
ference and will not
vii
EDGE2 Series Features
Digital Video Recorder Features
• HDMI output in full 1080p – simple connection to HDTVs
• Touch Screen navigation compatible
2
• 24x7 100% duty cycle HDD
• Pentaplex operation - View, Record, Playback, Backup & Remotely control the system
simultaneously
• Rec
ording options: Motion, schedule, or continuous
• Small form factor (11.6 x 6.5 x 1.3”)
• 3 x USB 2.0 ports (mouse, touch screen monitor, backup, firmware upgrade)
• VESA Mount (easily mounts to the back of an LCD monitor)
• “Flex” IR extender for remote control (line-of-sight not required)
1
3
• Swipe-to-Switch dynamic allocation of camera location in live viewing
• Scroll-to-Search through recorded event list with image preview
• PTZ cameras supported (RS-485)
Connectivity Features
• Instant Mobile Viewing on compatible Smartphones
4
5
• Exclusive LOREX Easy Connect Internet Set-up Wizard
• Lorex Edge Client Software:
• PC (Microsoft Windows™ 8 / 7 / Vista / XP c
ompatibl
e) using client software (included)
and web browser
• Mac remote client software (included)
• Free LOREX DDNS (Dynamic Domain Name Service) fo
r advanced remote connectivity at all
times
• Instant email alerts with snap shot attachments and web link
1. HDMI output 1080p (1920x1080) for high definition multi-channel live viewing only. High definition recording not
supported. Recording resolution is limited to a maximum of 704x480 per channel. Image quality and resolution
is dependent on the type of camera connected to the DVR.
2. Touch operation with Windows™ 7 Touch compatible touch screen monitor via USB connection.
3. Easily mounts to the back of an LCD monitor with VESA st
Requires clear access to the 100 x100 mm VESA mounting holes.
4. Requires a high speed internet connection an
5. Instant Mobile Viewing on iPad™, iPhone™, and BlackBe
Android (v. 2.1). Selectable one channel live viewing. Mobile phone data plan is required (not included). Router
port forwarding required. For the latest smart phone compatibility list check www.lorextechnology.com as new
smart phone models become available in the market.
d a router (not included).
andard mounting holes and an independent stand.
rry (supported model numbers: 9000, 9700, 9800),
viii
EDGE3 Series Features
Digital Video Recorder Features
• 960H (960x480) recording resolution
• HDMI output in full 1080p – simple connection to HDTVs
• Touch Screen navigation compatible
• 24x7 100% duty cycle HDD
• Pentaplex operation - View, Record, Playback, Backup & Remotely control the system
simultaneously
• Rec
ording options: Motion, schedule, or continuous
• Small form factor (11.6 x 6.5 x 1.3”)
• 3 x USB 2.0 (mouse, touch monitor, backup, firmware upgrade)
• VESA Mount (easily mounts to the back of an LCD monitor)
• “Flex” IR controller (line-of-sight not required)
• Mirror Hard Drive Recording
4
• Expandable Hard Drive Storage
• PTZ cameras supported (RS485)
Connectivity Features
5
• Advanced Management Software
• Instant Mobile Viewing on compatible Smartphones
• Exclusive LOREX Easy Connect Internet Set-up Wizard
• PC (Microsoft Windows™ 8 / 7 / Vista / XP compatible) using Internet Explorer®
• Mac full function remote software
• Free LOREX DDNS (Dynamic Domain Name Service) fo
times
• Instant e-mail alerts with snap shot attachments and web link
1
2
3
6
r advanced remote connectivity at all
1. When used with 960H compatible cameras. DVR is backwards compatible and supports different camera inputs:
standard resolution and 960H.
2. HDMI output 1080p (1920x1080) for high definition multi-channel live viewing only. High definition recording not
supported. Recording resolution is limited to a maximum of 960x480 per channel. Image quality and resolution
is dependent on the type of camera connected to the DVR.
3. Touch operation with Windows™ 7 compatible
4. Hard drive mirroring and External storage expansion are se
both at the same time. The DVR supports a single external USB hard drive up to a maximum size of 2TB. The
external hard drive must be self-powered to work with the system; it cannot receive power from the DVR’s USB
port. Footage on the external hard drive can only be accessed using the DVR or a Windows PC. The footage cannot be accessed on a Mac.
5. Requires a high speed internet connection and a router (not included).
6. Instant Mobile Viewing on iPad®, iPhone®, BlackBerry (s
Android (version 1.5 & above). Mobile phone data plan is required (not included). Router port forwarding
required. For the latest smart phone compatibility list check www.lorextechnology.com as new smart phone
models become available in the market.
touch screen monitor via USB connection.
lectable options. You select one or the other, but not
upported model numbers: 8900, 9000, 9700, 9800),
ix
x
TABLE OF CONTENTS
Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Rear Panel (8-Channel) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Rear Panel (16-Channel) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Basic Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Step 1: Connect the BNC Cameras . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Step 2: Connect the Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Step 3: Connect the Mouse . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Step 4: Connect the Ethernet Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Step 5: Connect the Flex IR Extender (Optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Step 6: Connect the Power Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Step 7: Verify Camera Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Step 8: Set the Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Accessing System Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Default System Passwords . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Connecting Cameras . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Installation Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Installing Cameras . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Connecting BNC Cameras to your DVR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Connecting and Removing BNC Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Touch Screen Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Mouse Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Controls Quick Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
On-screen Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Using the On-Screen Keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Using the Split-Screen Selector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Flexible Camera Assignment (Swipe-to-Switch) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Using Sequence View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Setting the Date and Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Recording. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Event Recording . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Recording Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Event List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Channel Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Event Details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Searching for Recorded Data (Scroll-to-Search) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Playback. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
xi
The Playback Bar, Playback Markers, and Smart Search Markers . . . . . . . . . . . . . 25
Playback and Smart Search Markers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Taking Screenshots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Using Screenshots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Managing Passwords . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
User Accounts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Using the Password Wheel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Enabling and Disabling Passwords . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Changing Passwords . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Using the Main Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Configuring Camera Color Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Configuring the Covert Setting (Hidden Cameras) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Changing the Camera Title Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Changing the Sequence Dwell Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Changing the Camera Input Mode (EDGE3 Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Changing the Resolution and Video Output Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Accessing System Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Changing the Fan Speed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Selecting PAL or NTSC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Changing the System Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Adjusting HDMI Screen Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Resetting the DVR to Factory Default Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Saving your System Configuration to a USB Flash Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Loading a System Configuration from a USB Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Record . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Configuring Camera Frame Rate and Video Quality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Reading the Storage Calculator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Configuring the Recording Schedule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Viewing Hard Drive Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Changing the Record Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Formatting Hard Drives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
External Hard Drive Mirroring or Extension . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Configuring your External Hard Drive for HDD Mirroring or Extension . . . . . . . . . . . . . . . . . . . . . . . . . 39
Playing Back Video from the External Hard Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Enabling / Disabling System Buzzers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Enabling / Disabling Motion Detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Enabling / Disabling Video Loss Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Configuring Alarm Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Configuring the Motion Alarm Schedule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Configuring the DVR for Motion Recording Only . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Configuring Motion Detection Areas and Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Backup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Formatting the USB Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
xii
Backing up Video to a USB Flash Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Confirming Backup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Backup File Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Playing Backed-up Video on your Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Setting QuickTime Player as a Default Media Player (PC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
LAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Changing the HTTP Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Configuring Network Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Configuring Remote Access Passwords . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Configuring Dual Streaming Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Configuring DDNS Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Configuring Email Alerts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Enabling/Disabling UPnP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Setting up your DVR for Remote Connectivity. . . . . . . . . . . . . . . . . . . . . . . 51
System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Accessing your DVR Within a Local Network (LAN) . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Step 1 of 4: Connect your DVR to the Local Area Network (LAN) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Step 2 of 4: Obtain the DVR’s Local IP Address and HTTP Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Step 3 of 4: Install the Client Software on your PC or Mac . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Step 4 of 4: Configure the Client Software and Confirm Local Connection . . . . . . . . . . . . . . . . . . . . . . 53
Accessing your DVR Remotely Over the Internet . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Step 1 of 4: Port Forwarding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Step 2 of 4: Create a DDNS Account . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Step 3 of 4: Enable DDNS on the DVR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Step 4 of 4: Update the Client Software with your DDNS Information . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Advanced Networking Configuration (Optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
PC and Mac Client Software for Remote Viewing . . . . . . . . . . . . . . . . . . . . 62
Network User Accounts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Running the Client Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Client Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
DVR List: Managing DVRs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Adding a DVR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Changing DVR Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Deleting a DVR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Live Viewing Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Playback Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Using the Pop-Up Calendar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Backup Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67
Setup Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Changing Bitrate Speed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Enabling PPPoE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Enabling DDNS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Viewing System Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Configuring Email Alerts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Creating Custom Camera Titles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Taking Screenshots (PC Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
xiii
Manual Recording (PC Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Accessing Remote Speed Dome Settings (PTZ Controls) (PC Only) . . . . . . . . . . . . . 73
Using the HDD Reader (PC Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
DVR Netviewer: Viewing Your DVR Using a Web Browser . . . . . . . . . . . . 76
Connecting to your DVR Using a DDNS or IP Address . . . . . . . . . . . . . . . . . . . . . . . . . 76
Connecting to the DVR over a LAN Using UPnP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Internet Explorer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Internet Explorer 9 / 10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Mozilla Firefox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Google Chrome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Mobile Apps: Accessing your DVR Using a Mobile Device . . . . . . . . . . . . . 85
Compatible Devices and Platforms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
iPhone / iPad App . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Downloading the Lorex Live Application on iPhone / iPad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Connecting To Your DVR on the iPhone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
The Lorex Live Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
Connecting To Your DVR on the iPad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
Using the Address Book on the iPhone / iPad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
Accessing Backed up Video on the iPad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Android App . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Connecting to your DVR on Android . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Lorex Mobile Edge Viewing Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
Setup Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
Playback Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
PTZ Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Address Book . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Blackberry App . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Installing Mobile View on the Blackberry: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Connecting to your DVR on your Blackberry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
Viewing Your DVR on your Blackberry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
Enabling APN (Access Point Name) on Your Blackberry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
Appendix A: System Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
EDGE2 Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
EDGE3 Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Appendix B: Assigning a Fixed IP to your DVR . . . . . . . . . . . . . . . . . . . . . 104
What’s the difference between DHCP and Fixed IPs? . . . . . . . . . . . . . . . . . . . . . . . . 104
Setting up a Fixed IP Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
Appendix C: Connecting PTZ Cameras. . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
Controlling PTZ Cameras . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
Using PTZ Presets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
Appendix D: Recording and Playing Audio . . . . . . . . . . . . . . . . . . . . . . . . 111
xiv
Connecting an Audio-Capable Camera or Self-Powered Microphone . . . . . . . . . . 111
Playing Audio from your DVR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
Appendix E: Mounting the DVR to a VESA Mount . . . . . . . . . . . . . . . . . . . 113
Appendix F: Replacing the Hard Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
Removing the Hard Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
Replacing the Hard Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
Formatting the Hard Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
Appendix G: Upgrading Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118
If you do not see Buttons in DVR Netviewer After Upgrading the Firmware... . . . 119
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
Troubleshooting Remote Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
xv
xvi
Getting Started
12V DC POWER ADAPTER
QUICK START GUIDE
INSTRUCTION MANUAL
DOCUMENTATION CD
USB MOUSE ETHERNET CABLE
REMOTE CONTROLDVR (DIGITAL VIDEO RECORDER)*
FLEX IR EXTENDER 2 X OCTOPUS BNC
CONNECTOR
(16-channel only)
MOUNTING KIT
(Mounting Kit contents
may differ from image)
The system comes with the following components:
*HARD DRIVE SIZE, NUMBER OF CHANNELS, AND CAMERA CONFIGURATION MAY VARY
BY MODEL. PLEASE REFER TO YOUR PACKAGE FOR SPECIFIC DETAILS.
CHECK YOUR PACKAGE TO CONFIRM THAT YOU HAVE RECEIVED THE COMPLETE SYSTEM,
INCLUDING ALL COMPONENTS SHOWN ABOVE.
1
Front Panel
1 2 3 4 5 6 7 8 9
1 Playback Controls:
•
: In Playback mode, press to rewind video. Press repeatedly to increase rewind speed.
• While playback is paused, press to move back playback time or date.
• In menus, press to change settings.
: In Viewing mode, press to enter Playback mode.
•
• In Playback mode, press to play video. Press again to pause video playback.
•
: In Playback mode, press to fast forward video. Press repeatedly to increase fast forward
speed.
• While playback is paused, press to ad
ance playback time or date.
v
• In menus, press to change settings.
2 Quad/Split-screen View:
•
3 Channel Sele
• CH-:
• CH
4 Menu Contro
•
•
•
: Press to open the Split-Screen Selector. From Full Screen / Single-Channel view, press
to switch to Split-Screen view.
ction:
Press to select previous channel.
• While in Split-Screen view, press to open previously selected channel in full-screen view.
+: Press to select next channel.
While in Split-Screen view, press to open previously selected channel in full-screen view.
•
ls:
: Press to go back / exit menus.
• In Playback mode, press to return to Viewing mode.
• In Full Screen / Single-Channel mode, press to return to Split-screen view.
: Press to enter Main Menu.
: Press to confirm menu selections.
• In Viewing mode, press to access System Information.
• In Playback mode, press to create a Playback Marker.
2
5 Navigation Buttons:
1 2 3 4 5
6 7 8
9
•
: Press to move cursor up.
•
: Press to move cursor down.
: Press to move cursor left.
•
•
: Press to move cursor right.
6 Hard Drive / Power LED:
• Solid: Device is on / powering up.
• Flashing: Device is recording to hard drive.
7 IR Receiver:
8 Flex IR Extender Port: Connect the Fl
use the remote control without needing line of sight to the DVR (must have line of sight to Flex
IR Extender).
9 USB Ports:
flash drive (not included) for data backup and firmware updates.
Internal IR receiver for the remote control.
ex IR Extender to increase the remote control range or
Connect a USB mouse (included), touch screen monitor (not included), or a USB
Rear Panel (8-Channel)
1 DC 12V: Connect the included DC power adapter to power on the DVR.
2 LAN: Connect a CAT 5 RJ45 Ethernet cable for local and remote connectivity.
3 HDMI: Connect to an HDMI-compatible TV or monitor (not included). Note that the DVR
c
annot use a VGA and HDMI monitor at the same time.
4 RS485: Connect RS485 ca
5 VGA: Connect to a V
monitor at the same time.
6 USB: Con
mouse (included), USB flash drive (not included) for data backup and firmware updates), or
self-powered external hard drive (not included) for disk mirroring (PC required) or expansion.
NOTE: The DVR supports a single external hard drive up to a maximum size of 2TB. The
7 Audio Ou
8 Audio In:
9 BNC Video
bles for compatible PTZ cameras (not included).
GA monitor (not included). Note that the DVR cannot use a VGA and HDMI
to a Windows 7® Touch compatible touch screen monitor (not included),
nect
e
xternal hard drive must be self-powered to work with the system; it cannot receive
power from the DVR’s USB port.
t: Output for audio channel.
Input for audio channel.
In: Connect up to 8 BNC cameras.
3
Rear Panel (16-Channel)
1 2 3 4 5 6 7 8 9 10
1 DC 12V: Connect the included DC power adapter to power on the DVR.
2 LAN: Connect a CAT 5 RJ45 Ethernet cable for local and remote connectivity.
3 HDMI: Connect to an HDMI-compatible TV or monitor (not included). Note that the DVR
c
annot use a VGA and HDMI monitor at the same time.
4 RS485: Connect RS485 ca
5 VGA: Connect to a V
monitor at the same time.
6 USB: Connect a USB mouse (included), touch screen
(not included) for data backup and firmware updates, or self-powered external hard drive (not
included) for disk mirroring (PC required) or expansion.
NOTE: The
7 Audio O
8 Audio In:
9 Video IN 1~8CH: Con
cameras 1-8 to Octopus BNC connector.
10 Vi
deo IN 9~16CH: Connect
cameras 9-16 to Octopus BNC connector.
DVR supports a single external hard drive up to a maximum size of 2TB. The
e
xternal hard drive must be self-powered to work with the system; it cannot receive
power from the DVR’s USB port.
u
t: Output for audio channel.
Input for audio channel.
bles for compatible PTZ cameras (not included).
GA monitor (not included). Note that the DVR cannot use a VGA and HDMI
monitor (not included), USB flash drive
nect Octopus BNC connector here. Connect BNC connectors from
Octopus BNC connector here. Connect BNC connectors from
4
Basic Setup
Push and twist the BNC connector
clockwise to secure it to the BNC port.
Push and twist the BNC connector
clockwise to secure it to the
Octopus BNC connector
Connect this end to Video In port
on your DVR
NOTE: Do not connect to VGA port
Labels indicate
channel number
NOTE: This DVR features unique mounting options and can be mounted to back of LCD
monitors with a VESA mount. For mounting instructions, see “Appendix E: Mounting
the DVR to a VESA Mount” on page 113. If you intend to mount the DVR, it is
recommended to do so before completing setup.
Step 1: Connect the BNC Cameras
8-channel
• Connect the BNC cameras to the Video IN ports on the rear panel of the DVR.
16-channel
1 Connect the Octopus BNC connector for channels 1-8 (included) to the Video IN CH 1~8 port
on the rear panel of the DVR. Connect the Octopus BNC connector for channels 9-16
(included) to the Video IN CH9~16 port. The label at the end of each connector indicates the
channel number.
2 Connect the BNC ca
NOTE: For more information on installing cameras, see “Connecting Cameras” on page 9.
meras to the Octopus BNC connector(s).
5
Getting Started
HDMI
VGA
8-channel model shown
USB
8-channel model shown
Front USB ports
Rear USB port
Step 2: Connect the Monitor
NOTE: Lorex monitors and touch screen monitors include all the necessary cables and
adapters to connect to your DVR. Check your monitor documentation to see which
cables and adapters are included with your monitor.
1 If you are using a touch screen monitor, connect a USB cable (not included) from the monitor
the USB port on the rear panel of the DVR.
to
2 Connect a HDMI cable (not included) from the monitor to the HDMI port
(recommended) OR;
• Connect a VGA cable (not included) from the monitor to the VGA port.
3 Power on the monitor.
NOTE: If you have a monitor with a DVI input, you must use an HDMI to DVI adapter (not
included). Y
ou cannot use a DVI to VGA adapter.
NOTE: The DVR cannot use multiple monitors at the same time.
Step 3: Connect the Mouse
• Connect a USB mouse to one of the USB ports on the front or rear panel of the DVR.
6
Getting Started
Connect Ethernet cable
8-channel model shown
Flex IR
Extender
port
Flex IR
Extender
8-channel model shown
DC 12V port
Step 4: Connect the Ethernet Cable
• Connect the Ethernet cable to the LAN port on the rear panel of the DVR. Connect the other
end of the Ethernet cable to a router on your network.
Step 5: Connect the Flex IR Extender (Optional)
• Connect the Flex IR Extender to the Flex IR Extender port on the front panel of the DVR.
Position the Flex IR Extender near the front of the monitor or where it will receive a clear
signal from the remote control.
NOTE: The Flex IR Extender is not required to use the DVR. Use the Flex IR Extender to
Step 6: Connect the Power Adapter
• Before powering up the DVR, ensure the monitor is connected and powered on. This allows
the DVR to detect the best resolution for your monitor.
• Connect the power adapter to the DC 12V port on the rear panel of the sys
other end of the power adapter to a power outlet or surge protector.
NOTE: If the top or bottom of the screen is cut off on your HDTV, see “Adjusting HDMI
install the DVR where it will not have line of sight to the remote control, such as in
a cabinet or behind the monitor.
tem. Connect the
Screen Size” on page 33 to adjust the screen size.
7
Getting Started
button -
Press to access system information
button - Press to exit
system information
Level User ID Password
USER1 1 1111
USER2 2 2222
ADMIN 3 3333
Level User ID Password
USER1 7 1111
USER2 8 2222
ADMIN 9 3333
Local DVR Access: Remote/LAN Access:
Step 7: Verify Camera Image
• Power on the cameras, and then verify the camera video quality before permanently mounting
the cameras.
• Mount the cameras under a sheltered location. Always verify the environmental rating of your
ca
meras before permanent installation outdoors.
Step 8: Set the Time
• Set the system time for accurate video timestamps. Videos with inaccurate times may not be
valid as surveillance evidence.
• For details on setting the system time, see “Setting the Date and Time” on page 19.
Accessing System Information
• To quickly open a window that displays vital system information, press the button on the
front panel of the DVR.
Press to exit the System Information window.
Default System Passwords
• The DVR requires a user name (ID) and password to log in remotely using a computer or
mobile device.
• The HTTP port (default 80) must be port f
Internet or a local network.
Refer to the following tables for the default account user
DVR.
orwarded on your router to access the DVR over the
names and passwords
for the
8
Getting Started
ATTENTION: Cameras differ in terms of installation or mounting instructions. Please see
the documentation that came with your camera(s) for specific installation instructions.
Table Mount
Wall Mount
Ceiling Mount
Camera model not be exactly as shown.
Top t hre ad
(Ceiling mount, Wall mount)
Bottom thread
(Table mount)
Secure to camera
thread
Camera model may not be exactly as shown.
Connecting Cameras
Test the cameras before permanent installation. Plan where you will route the wiring for
the camera and where you will aim the camera.
Installation Tips
• Mount the camera where the lens is away from direct and intense sunlight.
• Plan your cable wiring so that it does not interf
• Ensure that the camera wiring is not exposed or easily cut.
• Mount the camera in an area that is visibl
• Avoid poi nting the camera at a glass windo w to see outside, as this may result in a
caused by glare from indoor / outdoor lighting conditions.
• Adjust the camera angle so that it covers an area with high traffic.
• In "high-risk" locations, have multiple cameras point in the same area. This provides camera
dundancy if a vandal attempts to damage the camera.
re
ere with power lines or telephone lines.
e, but out of reach.
poor image
Installing Cameras
1 Mount the camera(s) to the desired mounting surface according to the instructions that came
with the camera(s). Choose a firm mounting surface.
NOTE: If you wish to mount cameras to drywall,
(not included).
2 Adjust the camera stand to ensure that the camera has a satisfactory view of the area you
ould like to monitor. Stand configuration depends on the mounting surface you have chosen
w
(see below for suggested stand configurations).
NOTE: There are two connection points for certain cameras. Secure the stand to the top
thread for wall mounts or ceiling mounts. Secure the stand to the bottom thread
for table mounts or wall mounts.
it is recommended to use drywall plugs
9
Getting Started
BNC Extension cable
Female power connector
Digital Video Recorder
(8-channel model shown)
Male power connector
Connecting BNC Cameras to your DVR
1 Connect the male power connector on the BNC extension cable to the female power
connector on the camera.
• Connect the BNC connector to the camera.
2 Connect the female power connector on the BNC extension cable to the power adapter.
3 (8-channel) Connect the
BNC connector to one of the Video In ports on the rear panel of the
DVR.
• (16-channel) Connect the Octopus BNC connector for channels 1-8 (included) to the Video
IN CH 1~8 port an
d the Octopus BNC connector for channels 9-16 (included) to the Video IN
CH9~16 port on the rear panel of the DVR. Connect the BNC cameras to the Octopus BNC
connector(s). The label at the end of each connector indicates the channel number.
Plug the power adapter to a power outlet.
4
Connecting and Removing BNC Cables
BNC (Bayonet Nut Connector) is a special connector that locks on to the system port and
cannot be accidently removed.
To connect or remove a BNC connector:
• Push the BNC connector firmly into the BNC port and simultaneously twist the connector
clockwise t
• To remove a BNC connector from a BNC port, push and simultaneously twist the connector
count
10
o tighten.
er-clockwise to loosen the BNC connector.
Touch Screen Control
HDMI
VGA
USB
1
2
3
This DVR features unique touch screen navigation capabilities. It supports Windows 7®
Touch compatible touch screen monitors without needing any additional configuration.
To connect a touch screen monitor:
1 Connect the VGA or HDMI cable (not
included) from the monitor to the VGA or
HDMI port on the rear panel of the DVR.
2 Connect a USB cable (not included) from
the monitor to the USB port
panel of the DVR.
on the rear
Getting Started
To navigate the DVR using touch
screen
controls:
• T
ouch the icons on the display to access
/ nav
igate the menus.
• Touch
to go back / exit menus.
• Change menu settings by swiping your finger up and down.
• In Split-Screen mode, Touch a camera to view
that camera in full-screen. Touch to
return to Split-Screen mode.
• Swip
e-to-Switch: In Vie
wing or Playback
mode, you can switch cameras by swiping
your finger left or right. Release your finger
when the desired camera is highlighted to
select it.
NOTE: In Split-Screen view, this changes the
order of your cameras.
Mouse Control
The DVR can be controlled using a USB mouse.
To use a mouse with the DVR:
• Connect the mouse to one of the USB
ports on the fr
ont or rear panels of the DVR.
Use the mouse buttons to perform
the following:
1 Left-Button: Click to select a menu option. While in
Split-Scr
een mode (Viewing or Playback), click on a
camera to view the selected channel in full-screen.
2 Right-Button: Click to go back / exit menus.
3 Scroll-Wheel: Scr
oll up / down to change values in
selected menu options or select Playback Markers
in Playback Bar.
11
Getting Started
1
2
3
4
5
6
7
8
9
10
Remote Control
The DVR can also be controlled using the
included remote control.
To use the remote control:
1
2
3 Primary Contro
•
: Open the Event List.
: Opens the DVR Main Menu.
ls:
: Confirm menu selections; in Playback
mode, create Playback Marker; in Viewing
mode, view sys
: Move cursor in menus left; in Playback,
•
tem information.
increase rewind speed.
•
: Move cursor in menus right; in Playback,
increase fast-forward speed.
•
: Move cursor in menus up; channel up.
•
: Move cursor in menus down; channel down.
4
5
: Go back / exit menus.
: While in Event List, press to delete the selected event.
NOTE: Be careful when pressing the Trash button—there is no confirmation for deletion
ou cannot undo the action.
and y
6 Increase / Decrease Buttons:
•
•
7
8
9
: Increase the value of selected menu option.
: Decrease the value of selected menu option.
: Show / hide the On-screen Display.
: Enter Split-Screen mode; Open the Split-Screen Selector.
: Enter Playback mode; Play / pause playback; In Event List, select event for
playback.
10
: During Viewing and Playback, press to take a screenshot of the main display—USB
flash drive must be connected.
12
Controls Quick Reference
The following chart shows how to navigate the menus using the various control options
available on the DVR.
Getting Started
Using: Select
Change Setting: Go Back /
Option:
Mouse Left-click Scroll wheel up /
down
Touch Screen Tap Swipe up / down or
lef
t / right
Remote
Control
DVR Front
Panel
/
/
Exit Menu:
Right-click N/A
N/A
Move
Cursor
13
ATTENTION: The instructions in this manual describe how to operate the DVR
using a mouse (included). When using a touch screen monitor (not included),
simply touch the on-screen buttons when told to click, swipe your finger
horizontally or vertically to scroll up / down, and touch to right-click and exit
menus. All the features of this DVR can be accessed using a touch screen monitor.
On-screen Display
16-channel model shown
Tota l siz e of ha rd d rive
Percent full
On-screen Display
1 Display Screen: Shows live and recorded video in Full-screen / Single-Channel mode and
Split-Screen (16-way split on 16-channel model only) view.
2 Camera Number / Title: Y
3 Channels: Displays channels on the
4 Date / Time: Displays the date and time on the DVR.
5 HDD Status: Displays the size
recording space consumed on the hard disk (%).
NOTE: This reading is an approximation.
14
ou can set the DVR to show the camera number, title, or no title.
DVR. Icons flash red to indicate recording is in progress.
of the pre-installed hard drive (for example, 1000GB) and the
On-screen Display
NOTE: Additional buttons are shown in some screens.
6 Tool bar: Move the mouse to the bottom of the screen to view the toolbar. Click these buttons
to access the menus and control the DVR.
• : Click to open the Split-Screen Selector; In Full Screen / Single Channel mode, click to
open Split-screen view.
•
: Click to open the Main Menu. See “Using the Main Menu” on page 30.
•
: Click to move cursor left in menus.
•
: Click to move cursor right in menus.
: From Viewing mode, click to open Playback mode. Click to play / pause video.
•
: Click to rewind / increase rewind speed (only available during playback).
•
•
: Click to fast forward / increase fast forward speed (only available during playback).
: Click to open the Event List. See “Event List” on page 21.
•
•
: Click to begin Sequence view. In Sequence view, the DVR automatically switches
between connected cameras in Full Screen / Single Channel view. Click
view.
•
•
•
: Click to turn the On-Screen Display on / off.
: Click to go back / exit menus.
: Click to take a screenshot of the active display (live viewing or playback).
NOTE:
on page 26.
USB flash drive (not included) must be connected. For more details, see “Taking Screenshots”
• : From the Event List, click to delete a selected video file.
NOTE:
undo the action.
Be careful when clicking the Trash icon—there is no confirmation for deletion and you cannot
• : Click to access PTZ controls.
NOTE:
Cameras” on page 108.
PTZ camera(s) must be connected. For instructions, see “Appendix C: Connecting PTZ
• : Click to close the on-screen keyboard and cancel current entry.
to exit Sequence
15
On-screen Display
Shift
Numbers & Special
Characters
Space
Cancel
Entry
Confirm
entry
Delete
Using the On-Screen Keyboard
An on-screen keyboard appears when entering certain menu options that require text input
(for example, Email setup).
To use the on-screen keyboard:
1 Click on a
menu field that requires text.
• The on-screen keyboard appears.
• Click
for numbers or special characters (e.g. ".", "@", etc.). Click to go back
to letters.
NOTE: For additional special characters, click
• Click
• Click
• Click
to delete characters.
to confirm entry.
to cancel entry and exit keyboard.
from the numerical keyboard.
Using the Split-Screen Selector
The Split-Screen Selector allows you to choose the grid layout for Split-Screen view. Quad
(4-way), 9-way, and 16-way (16-channel only) split options are available.
To use the Split-screen Selector:
1 Cl
click
ick
to open the Split-Screen Selector. If you are in Full Screen / Single Channel view,
to go to Split-Screen view, and click again to open the Split-Screen Selector.
2 Click a grid configur
16
ation for live viewing or playback:
On-screen Display
Split-screen Selector (8-channel)
Split-screen Selector (16-channel)
Example: Channel 3 is reassigned to channel 5.
• 8-channel: Choose from quad (CH1~4, CH5~8) or 9-way split (the bottom-right square appears
blacked out).
• 16-channel: Choose from quad (CH1~4, CH5~8, CH9-12, CH13~16), 9-way split (CH1~9,
CH
10~2), or 16-way split (CH1~16).
Flexible Camera Assignment (Swipe-to-Switch)
In Split-Screen view, you can re-assign your cameras to different positions. For example,
you can duplicate the video feed from channel 1 onto channel 2. This is useful if you wish
to obscure the number or location of your cameras.
VR r
NOTE: The D
positions.
To re-assign camera positions using a mouse:
1 Select the channel you want to re-assign.
2 Click and hold the mouse.
• A camera menu appears.
ecords cameras to their designated channels even if you reassign camera
3 While holding, move the mouse to the left
or right t
o change the camera. Release
the mouse button when the desired
camera is highlighted to select it.
17
On-screen Display
Sequence Mode Selector
Single-channel Sequence
4-way Sequence
To re-assign camera positions using
a touch screen monitor:
1 Press and hold your finger on the
channel you want to re-assign.
• A camera menu appears.
NOTE: Tapping on the screen may
ause the DVR to switch to
c
Single-Channel / Full-Screen
mode. If it does this, press the
button to return to
Split-Screen view.
2 Move your finger from left to right to change the
channel. Release your finger when the
desired camera is highlighted to select it.
Using Sequence View
In Sequence view, the DVR automatically switches between camera channels every few
seconds (for instructions on changing the amount of time channels are shown before
switching, see “Changing the Sequence Dwell Time” on page 32). The following modes are
available for Sequence view:
• Single-channel Sequence: The D
automatically switches between connected
cameras in full-screen.
• 4-way Sequence: The DVR switches between
every channel, showing 4 channels at a time.
To enter / exit Sequence view:
• Click
to enter Sequence view. Sequence
view uses the last mode selected.
• Click
to exit Sequence view and return
to Split-Screen mode.
To change the Sequence mode:
VR
ick
1 Cl
2 Click
18
while viewing in Sequence view. The Sequence Mode Selector appears.
to select 4-way Sequence or for Single-channel Sequence.
Setting the Date and Time
It is highly recommended to immediately set the date and time
when first setting up your DVR.
Inaccurate time stamps may render your footage unusable as
court evidence.
Date/Time Setup Menu
To set the date and time:
1 Click
2 Click
3 Click Date/T
Setup Menu appears.
4 Configure the following:
• Date Mode:
date format you would like to use (Y/M/D,
D/M/Y, or M/Y/D). The Date field
automatically changes to the chosen
format when selected.
• Dat
select the date.
• Time Setup: Scr
NOTE: The DVR displays time in 24-hour format.
5 Click Ex
6 Right-click until all menus ar
corner of the screen.
to open the Main Menu.
to open the Setup Menu.
ime Setup. The Date/Time
Scroll up / down to select the
e Setup: Scr
it/Update to save your settings. The system returns to the Setup Menu.
oll up / down to manually
oll up / down to manually select the time.
e closed. The date and time are displayed on the bottom-left
NOTE: The syst
Remember to change the time one hour ahead, or one hour backward, according
to Daylight Savings Time. When the time is set backwards, the system will retain
recorded data with overlapping time stamps.
19
em does not automatically adjust the time for Daylight Savings Time.
Recording
By default, the system is set to immediately record video from all connected cameras in
Continuous Record Mode.
You can set the system to stop recording once the hard drive is full, or to continually record
by overwriting previously
Event Recording
The DVR includes the following modes of event recording:
recorded data. For more details, see “Record” on page 35.
•
•
The system employs a pre-record function to capture
Motion: The DVR records when motion is detected by the affected camera.
Video Loss: The DVR records when a camera is disconnected or suffers video loss.
video seconds before events occur.
Recording Audio
The system can record one audio channel. You must have an audio-enabled camera or
self-powered microphone connected to the system in order to use this function.
For details, see “Appendix D: Recording and Playing Audio” on page 111.
20
Event List
1
2
3
4
5
The system features an Event List to organize and search for recorded video on the system.
Events in the Event List are marked with Smart Search icons, which allows you to search
for recorded data on your system quickly and easily.
Event List
NOTE: The
To access the
• Click LIST or pr
NOTE: You cannot access the Event List using the buttons on the front panel of the DVR.
system can save a maximum of 8196 events.
Event List:
ess the LIST button on the remote control.
1 Channel Filter: View data from all cameras or from individual cameras.
2 Smart Search: Filt
3 Event Detail
4 Events: List
s: View details for the event, including date & time and event source.
of recorded events on the system.
er events through Smart Search icons, which indicate the type of event.
21
Event List
Event Number
Camera Number
OR Type of System
Event
Filter Type
Date & Time
Event Source
Event Details Bar
5 Active Toolbar Buttons: While in Event List, click to select events for playback, Trash
) to delete events (cannot undo), and to exit.
(
Channel Filter
Use the Channel Filter to sort the data from individual channels or all channels.
NOTE: Filters for channels 9~16 are shown in the Event List for the 8-channel model but
are not click-able.
Event Details
An event number, camera number, filter type, date & time, and event source are shown for
each event in the Event List. When you use the Channel Filter and Event Filter, the Event
Details Bar Helps you view event details at a glance.
Searching for Recorded Data (Scroll-to-Search)
Scroll-to-Search allows you to easily search through saved events and see a preview of the
recorded video. You can access the Event List from Viewing mode and Playback mode to
search for recorded data on your system.
To search for data:
1 From the main screen, click
2 Under Channel Filter, click
to view events from
22
individual
. The Event List opens.
to view events for
channels.
ALL
channels, or click the Channel icons
3 Click the Smart Search icons to sort the data according to the following:
Scroll-to-Search shows you a preview of your
recorded video when you select an event
Selected
event
Preview of
recorded
video
Event List
•
ALL: View all events chronologically.
NOTE: USB backups appear at the top of the lis
t if a USB flash drive with saved
backup data is connected.
•
•
Motion: Motion events from the selected camera(s).
Video Loss: Camera(s) are disconnected or suffer video loss. The system employs
a pre-record function to capture video seconds before the loss of video occurred.
•
Shows D/T when the system date and tim
•
•
HDD/System: Hard drive connection / disconnection, power loss, or disk failure.
e has been changed.
Power ON/OFF: System ON/OFF.
Playback Mark: A personal marker set by the user during Playback Mode. For details,
see “The Playback Bar, Playback Markers, and Smart Search Markers” on page 25.
•
USB: USB backup performed by the user.
4 Scroll up / down to view the events on the list.
• With a t
inside the list
ouch screen monitor, touch
of events and move your
finger up / down to scroll.
5 Click an event. A preview of the
recorded video appears behind the
Event List window.
6 Click
. System switches to
Playback Mode.
NOTE: If the
appear, click
Playback t
oolbar does not
.
NOTE: You cannot begin playback after
clicking
7 To exit, right-click until you return to the main screen.
or
23
Playback
Playback display view
The playback time appears in the
bottom-right corner of the screen
Use the Playback Toolbar to select the time
and date for playback and create and search
through Playback Markers
Playback
Playback mode allows you to view video recordings saved on your DVR. You can playback
video from a single channel in Single-Channel / Full-Screen mode or from multiple
channels in Split-Screen view.
To begin playback:
1 From the main screen, click
NOTE: If the Playback Toolbar
2 Click and scroll up / down to select the date, month,
and click
3 During playback, y
: Click to pause playback; press again to resume playback.
•
: Click to rewind / increase rewind speed (5X, 15X, 60X).
•
: Click to fast forward / increase fast forward speed (5X, 15X, 60X).
•
•
: Click to open the Split-Screen Selector.
•
: Click to open the Event List. See “Event List” on page 21.
to begin playback.
ou have access to the following:
. Playback mode opens.
is not visible, click .
year, time, and / or frame for playback
4 Click any channel to view the selected channel in Full-Screen / Single-Channel mode.
5 Click inside the Playback Bar to set a Playback Mark
er. Playback Markers can be used for
faster searching in the Event List. See “The Playback Bar, Playback Markers, and Smart
Search Markers” on page 25.
NOTE: Y
24
ou can only create Playback Markers in Full-Screen / Single-Channel mode.
Playback
Playback Bar
Video not available
Video available
Search markers
1
6 Right-click anywhere on the screen to exit and return to Viewing mode.
The Playback Bar, Playback Markers, and Smart Search Markers
The Playback Bar shows recorded video data and events on the DVR based on the time they
were recorded. The Playback Bar is black when there is no video available for a given time,
and it is colored when video is available for a given time.
Playback and Smart Search Markers
Events on the DVR are represented by different colored markers (see the diagram below).
These markers are part of the Smart Search functionality of the system. For more details
on Smart Search, see “Event List” on page 21. You can also create your own Playback
Markers at any point during Playback mode.
1 Scroll up / down to position one of the colored markers in the Playback Target.
2 Click
To create Playback Markers:
• Click anywhere inside the Playback Bar. A Playback Marker appears at the Playback Target.
An e
vent is also added to the Event List with a
icon.
To use Smart Search and Playback Markers:
• Using
up / do
a touch screen monitor, touch any of the Time and Date Selectors and move your finger
wn.
.
1. Graphics simulated.
25
Taking Screenshots
ATTENTION: Video footage is preferable to screenshots when submitting surveillance
evidence in court. For instructions on how to backup or extract video footage from your DVR,
see “Backup” on page 43.
Screenshot being taken on the system
Filename
Screenshot
Taking Screenshots
You can take screenshots (screen captures) of the main display of your system at any time:
during live viewing, search, and playback, or in any system menu. Screenshots are useful
if you need to provide a still image of your security footage to the authorities.
NOTE: A USB flash
drive (not included) must be connected to the system and formatted
in order to take screenshots. For instructions on how to format USB flash drives,
see “Formatting the USB Drive” on page 43.
To take a screenshot:
1 Connect a USB flash
drive (not
included) to one of the USB ports on
the DVR. Format the USB flash drive
if you have not already done so.
2 If you want to capture a moment in
Viewing or Playback mode, select the
display view for the screenshot:
full-screen or split-screen.
3 Click
. The screenshot appears
in the center of the main display,
llowed by the file name.
fo
Screenshots are saved to the
folder on the USB flash drive.
NOTE: Screenshots are saved as
JPE
G files with the following
naming convention:
Filename Definition
N
mm
DD
x
26
System file marker
Month
Day
Numeral (e.g. 001, 002, 003, etc.)
Taking Screenshots
AutoPlay window
Using Screenshots
Once you have taken screenshots, connect the USB flash drive to a computer to view, print,
or archive the images.
To use screenshots (Windows):
1 Connect the USB flash drive to a USB port on
your computer. In the AutoPlay window, select
Open folder to view files.
NOTE: If AutoPlay does
computer for a
2 Double-click the Picture fo
3 Perform one of the following:
• View: Doubl
an image viewing or editing program, such as
Windows Picture Viewer or Adobe® Photoshop™
• Archive: Copy the
computer
• Print: Right-click
print it directly from Windows Explorer, or print
the screenshot from an image viewing or editing
program.
To use screenshots (Mac OS):
1 Connect the USB flash drive to a USB port on your computer. It appears on your desktop.
NOTE: If the USB driv
Devices.
2 Double-click the USB flash drive.
e-click the screenshot to view it in
not start, search your
Removable Disk
lder.
images to a folder on your
the image and select Print to
e does not appear, open Finder and locate the USB flash drive under
.
3 Double-click the Picture fo
4 Perform one of the following:
• View: Doubl
Preview or Adobe® Photoshop™
• Archive: Copy the
• Print: Print the scr
e-click the screenshot to view it in an image viewing or editing program, such as
images to a folder on your computer.
eenshot from an image viewing or editing program.
lder.
27
Managing Passwords
ATTENTION: By default, passwords are disabled on the system, which allows anyone to
access the menus and change DVR settings. It is recommended to enable passwords. See
“Enabling and Disabling Passwords” on page 29.
LEVEL ID PASSWORD
USER1 1 1111
USER2 2 2222
ADMIN 3 3333
LEVEL ID PASSWORD
USER1 7 1111
USER2 8 2222
ADMIN 9 3333
Local DVR Access:
Remote/LAN Access:
Login with your user ID and password using the
Password Wheel
Managing Passwords
Refer to the tables below for the user name (ID) and password required to log in to your
system:
User Accounts
The DVR has three user accounts: ADMIN, USER2, and USER1. The ADMIN account is the
system administrator. The ADMIN can access all the menus and can configure the DVR
both locally and from a remote computer. The ADMIN can also see covert cameras when
he is logged in from a remote computer or mobile device. For information on covert
cameras, see “Configuring the Covert Setting (Hidden Cameras)” on page 31.
USER2
for the Setup Menu. USER2 can view and backup recorded footage when logged into the
DVR from a remote computer or mobile device but cannot access the remote setup menu
or see covert cameras.
USER1 is a limited access user account that cannot access any menus on the DVR. USER1
can view
access the setup menus, view or backup recorded video, or see covert cameras.
is the standard user account. USER2 can access all the menus
cameras when logged in from a remote computer or mobile device but cannot
on the DVR except
Using the Password Wheel
The Password Wheel is used to input and change
user IDs and passwords.
To use the Password Wheel:
e
• Click 0~9 to
nter your user ID and password.
NOTE: You cannot select the options to the left of the Password Wheel (user ID, password)—
only
u can
yo
click
28
select the digits. If you make a mistake, simply right-click to exit or
and re-select the option to try again.
Managing Passwords
DVR Password Menu
Enter the new password twice to change passwords
Password change confirmation
Enabling and Disabling Passwords
By default, passwords are disabled. With passwords enabled, you need to enter your user
ID and password to access the system Main Menu, Event List, or Playback mode.
To enable/disable passwords:
1 Cl
ick
to open the Main Menu. Enter your
user ID and password if needed.
2 Click . The Setup menu opens.
3 Click D
VR Password. The DVR Password menu
opens.
4 Cl
ssword Enable and scroll up / down to
ick Pa
select O to enable passwords or X to disable.
5 Right-click until y
NOTE: When you
have exited all menus to save your changes.
ou
are logged in, this icon is shown at the top-left corner of the screen: .
The number represents your user ID. To l
Viewing mode.
Changing Passwords
If passwords are enabled, you must be
logged in as ADMIN in order to change
passwords.
To change passwords:
og out, right-click or click from
1 Click
2 Click
3 Click DV
to open the Main Menu.
. The Setup menu opens.
R Password. The Password Wheel
opens. Enter the ADMIN user ID and
password if needed.
4 Click the acc
5 Use the Password Wheel to enter a 4-digit
p
assword. Enter it again to confirm.
6 Right-click until y
ount you would like to change.
u have exited all menus
o
to save your changes.
NOTE: T
o change the Remote Access
swords see “Configuring Remote
pas
Access Passwords” on page 47.
29
Using the Main Menu
2
3
4
5
6
1
See the “Controls Quick Reference”
on page 13 for instructions on
navigating the menus with the
various control options available.
Tip!
Using the Main Menu
To open the Main Menu:
• Click
, OR press the button on the front panel of the DVR. Click on the icons below
to open sub-menus.
1 Camera: Adjust brightness, contrast, hue, and saturation for each camera. Configure camera
title display, sequence time, and Covert (hidden camera) settings.
2 Setup: Configur
system information.
3 Rec
ord: Configur
Configure recording mode and schedule. Configure
camera frame rate, video quality, resolution, and audio
settings. Format hard drive. View video information.
4 Alarm: Configure alarm, motion, and video loss settings.
Enable / disable system buzzers.
5 Backup: Backup rec
Select start time, stop time, and video channel for
backup. Format connected USB flash drive.
w
6 LAN: Vie
/ configure networking settings.
30
e date / time, language, video settings, passwords, and fan speed. View
e video parameters for recording.
orded video to a USB flash drive.
Using the Main Menu
Camera Menu
To access the Camera Menu, click then .
Camera color adjust settings
Camera
The Camera Menu allows you to
adjust the picture settings for
your cameras and configure camera
title display, sequence time, and Covert
(hidden camera) settings. Configure PTZ
cameras (RS-485 settings).
4 Scroll up / down to increase / decrease the
value for the selected option.
• For instructions on configuring PTZ
eras, see “Appendix C: Connecting
cam
PTZ Cameras” on page 108.
Configuring Camera Color Settings
1 From the Camera menu, select Adjust.
2 Select the camera you would like to
c
onfigure. The Camera Color Settings
Menu opens.
3 Configure the
• Brightness
• Contrast
• Hue
• Saturation
following:
5 Right-click t
return to the Camera menu.
save your settings and
o
Configuring the Covert Setting
(Hidden Cameras)
The Covert setting allows you to hide
cameras on the DVR, so users cannot
see them. Cameras that are hidden
using the Covert setting can only be
viewed remotely (i.e. through a local
network or the Internet) by the ADMIN
account.
NOTE: It is highly recommended to
enabl
e passwords when using
the Covert settings. If
passwords are not enabled, then
anyone can change Covert
settings and un-hide the
cameras. If passwords are
enabled, only the ADMIN and
USER2 accounts can change
Covert settings.
To configure Covert settings:
rom the Camera Menu, click Cov
1 F
under the camera you would like to hide /
un-hide.
ert
31
2 Move the cursor to the camera you would
e to hide / un-hide and scroll up / down
lik
to change the Covert settings.
• X - Visible (Covert OFF).
• O - Hidden (Covert ON).
Using the Main Menu
Select 960x480 for 960H cameras or
720x480 for non-960H cameras
3 Right-click until you have exited all menus
to save your settings.
Changing the Camera Title Display
1 From the Camera Menu, click Camera
Title Type.
2 Scroll up / down to select the type of label
tha
t you would like to appear above your
cameras:
•
camera. You can create custom titles for
ur cameras using the Client Software or
yo
DVR Netviewer. For details, see “Creating
Custom Camera Titles” on page 71.
: Displays the channel number.
•
•
: Displays no title.
3 Right-click to s
return to the Main Menu.
: Displays the name of the
ave your settings and
Changing the Sequence Dwell Time
Sequence time refers to the amount of
time a channel appears on the screen
before changing to a different channel
when the DVR is in Sequence view. For
example, when Sequence view is on,
channel 1 is shown for several seconds
before switching to channel 2.
Changing the Camera Input Mode
(EDGE3 Only)
The Video-In Mode is used to select if
your DVR inputs video from cameras in
wide-screen formats (such as 960H;
960x480) or standard formats (such as
720x480).
By default, the system is set to input all
0H
cameras in 96
enable larger, wide-screen formats, but
it will decrease the number of Frames
Per Second available for recording. It is
recommended to select 720x480 if you
do not have cameras that are
960H-capable.
To change the camera input mode:
rom the camera menu, click Adjus
1 F
2 Select the camera you would like to
c
onfigure.
3 Under Video-I
960H cameras (the DVR will use the wide
format resolutions for this camera) or
720x480 (the DVR will use the standard
resolutions for this camera) for non-960H
cameras.
format. 960H will
n Mode, sel
ect 960x480 for
t.
To change sequence time:
1 From the Camera Menu, click Sequence
Time.
2 Scroll up / down to adjust the sequence
ation.
dur
• To enter Sequence view, click
menu bar from Viewing mode.
3 Right-click to s
return to the Main Menu.
ave your settings and
in the
4 Right-click repeatedly to return to live
viewing.
32
Using the Main Menu
Setup Menu
To access the Setup Menu, click then .
Setup
The Setup Menu allows you to
configure system settings
including, the date / time, language,
video settings, passwords, and the
internal fan speed. You can also view
system information or reset the DVR to
factory settings
.
No, the DVR will return to the previous
resolution setting in 30 seconds.
5 Right-click to
return to the Setup Menu.
Accessing System Information
• From the Setup Menu, click Information.
Right-click to exit the Information window.
Changing the Fan Speed
Changing the fan speed affects the
internal temperature of the DVR.
1 From the Setup Menu, click Fa
Scroll up / down to select High, Medium, or
Low.
2 Right-click to
return to the Main Menu.
save your settings and
n Speed.
Selecting PAL or NTSC
1 From the Setup Menu, click NTSC/PAL
Select. Scroll up / down to select NTSC (for
North America), PAL (for Europe), or Auto
(the system automatically detects the
format of the connected cameras,
recommended).
• To change the date and time, see “Setting
the Date and Time” on page 19.
• To enable or configure DVR passwords, see
“Managing Passwords” on page 28.
Changing the Resolution and Video
Output Mode
1 From the Setup Menu, click Video-Out
Setup. The Video-Out Setup Menu opens.
2 Click Vide
down to select your video output type (VGA
or HDMI) and resolution or select Auto for
the DVR to automatically detect the best
resolution for your monitor
(recommended).
3 Click Video-Out Update.
4 Click Yes to
discard them. If you do not select Yes or
o-Out Resolution. Scroll up /
save your changes or No to
2 Right-click to
return to the Main Menu.
save your settings and
Changing the System Language
1 From the Setup Menu, click Language.
Scroll up / down to select the language.
2 Right-click to
return to the Main Menu.
save your settings and
Adjusting HDMI Screen Size
On some HDTV’s, the top or bottom of
the screen may be cut off by the display.
If this happens, follow the steps below.
To adjust HDMI Screen Size:
1 Click
the DVR to open the Main Menu.
2 Click
or press on the front panel of
to open the Setup Menu.
33
Using the Main Menu
Click HDMI Screen Size and scroll up / down to adjust
the screen size
ATTENTION: Resetting to Factory Default
Settings will not erase your recordings,
but it will erase all event and playback
markers in the Event List.
This cannot
be undone.
Click to save DVR configuration to a
USB flash drive (not included)
3 Click Video-Out Setup. The Video-Out
Setup Menu opens.
4 Clic
k HDMI Screen Size,
and scroll up /
down to adjust the screen size.
NOTE: Adjusting the HDMI Screen Size
setting has no effect if the
monitor is connected with a VGA
cable.
5 Right-click until y
ou hav
e exited all menus
to save changes.
Resetting the DVR to Factory
Default Settings
does not save or backup any
video.
To save your system configuration to a
USB flash dr
ive:
1 Connect a USB flash drive (not included) to
one of
the USB ports.
2 Format the USB flash drive with the DVR if
ou have not done so already. For
y
instructions, see “Formatting the USB
Drive” on page 43.
3 From the Setup Menu, click Config Set
4 Click Sav
e Config to USB and then click
up.
Yes to confirm.
1 From the Setup Menu, click Config Setup.
2 Click Load Factory Default.
3 Click Yes t
o confirm or No to cancel.
Please allow a few moments for the
system to
reset.
Saving your System Configuration
to a USB Flash Drive
You can save your current system
configuration to a USB flash drive (not
included). This allows you to save all of
your current settings for backup
purposes.
NOTE: This function only saves settings
cr
eated in system menus. It
5 Wait until the save is completed.
Loading a System Configuration
from a USB Drive
1 Insert a USB flash drive (not included) with
a saved configuration file into one of the
USB ports.
2 From the Setup Menu, click Config Set
3 Click L
oad Config from USB and then click
Yes to confirm.
4 Wait for the system to finish restoring the
onfiguration. Do not pull the power plug
c
or power off the DVR during while the
configuration is restored. The DVR will
restart once it is finished.
up.
34
Using the Main Menu
Record Menu
To access the Record Menu, click then .
Record
The Record Menu allows you to
configure video recording
parameters, including recording mode,
schedule and camera video settings.
Camera video settings include the video
frame rate, image quality, resolution,
and audio settings. It also allows you to
format hard drives or configure your
external hard drive (not included) for
disk mirroring or expansion.
• Working Rate:
This determines the frame
rate used during working hours. Click
under each camera, and select 0 (DVR will
not record during working hours), 2, 3, 5,
7.5, 10, 15, 30 (FPS).
• Non-w
orking Rate:
This determines the
frame rate used during non-working
hours. Click under each camera, and
select 0 (DVR will not record during
non-working hours), 2, 3, 5, 7.5, 10, 15, 30
(FPS).
• Real Rate: Th
e system will automatically
calculate and allocate a Real Rate when
you set the working rate.
• Quality: Click under each
camera and
select 1, 2, 3, 4, 5.
• Resolution: Click and scr
oll up / down to
select the resolution for all cameras.
Available resolutions are:
• EDGE2: 352x2
40, 704x240, 704x480.
• EDGE3: 360/480x240, 720/960x240,
72
0/960x480.
To configure camera audio settings, see
“Appendix D: Recording and Playing
Audio” on page 111.
Configuring Camera Frame Rate
and Video Quality
1 From the Record Menu, click Video Frame
Rate. The Video Frame Rate Menu opens.
2 Configure the
• Alarm/Motion Rate: This determines the
fr
ame rate that is used during alarms or
motion events. Click under each camera,
and select X (DVR will not record during
alarms / motion events or will use working
rate), 2, 3, 5, 7.5, 10, 15, 30 (FPS
NOTE: Motion Detection mus
enabled to record motion
events.
following:
t be
1
).
NOTE: The slashes in
the EDGE3
resolution options show both
the wide or non-wide options.
The DVR determines which
option to use for each camera
based on the Video-In Mode
setting under
MENU>CAMERA>ADJUST.
For example, if the Video-In
Mode for channel 1 is 960x480,
and the resolution on the system
is set to 720/960x480, the DVR
will record channel 1 at 960x480.
ight-click to save your changes and
3 R
r
eturn to the Record Menu.
NOTE: As y
ou change the frames, the
torage calculator at the bottom
s
of the screen calculates the
remaining space on the hard
drive.
1. Frames Per Second
35
Reading the Storage Calculator
Storage calculator
Range Selectors
Recording Schedule
HDD Information
A storage calculator shows the
approximate maximum continuous
recording time available on the hard
drive based on your settings. Use the
storage calculator to help maximize
your hard drive space.
NOTE: The estimation from the Storage
only
Calculator is based
on
Continuous Recording, not
motion or alarm recording.
Configuring the Recording
Schedule
The Recording Schedule allows you to
configure an hourly or daily schedule for
recording. The Recording Schedule is a
grid featuring the days of the week and
hours 0~23.
Using the Main Menu
3 Right-click to save your changes and
return to the Record Menu.
To configure the Recording Schedule:
1 From the Record Menu, click Sch
edule.
The Schedule window opens.
2 Click the bo
xes to switch each half-hour
between Working and Non-working hours.
Use the Range Selectors below to switch
multiple boxes at once.
• Working Hour (Yellow):
DVR will record
according to the working hour frame rate.
• Non-working Hour (Green): D
VR will
record according to the non-working hour
frame rate.
Viewing Hard Drive Information
The HDD Information sub-menu allows
you to view information about your hard
drives, format your internal or external
hard drive (not included), configure
overwrite settings, or configure your
external hard drive for hard drive
extension or mirroring.
To view hard drive information:
• From the Record Menu, click HDD
Info
rmation.
36
Using the Main Menu
ATTENTION: Formatting the HDD erases
all data on the hard disk.
This step cannot be undone.
The HDD Information menu shows the
following information about your hard
drives:
o
7 Right-click until y
to save changes.
u have exited all menus
Formatting Hard Drives
If you want to use an external hard drive
(not included) for hard drive expansion
or mirroring, or if you replace the
pre-installed hard drive, it
formatted in order to function properly
with the system.
must
be
ord Mode: C
• Rec
selected.
• HDD Mode: Current external hard drive
mode sel
• Vendor: V
hard drives.
• Size: The ca
the percentage of space used.
• Start: The earlies
hard drive.
• Stop: The most recent recording saved on
the har
NOTE: Depending on y
ected.
endor information about your
d drive.
settings and capacities the
Start/Stop time may be different
for your internal and external
hard drives.
urrent recording mode
pacity of your hard drives and
t recording saved on the
our hard drive
Changing the Record Mode
4 From the Record Menu, click HDD
Information.
5 Click Reco
6 Scroll up / down to change the record
mode:
•
recording when the internal hard drive is
full.
•
recording when the hard drive is full by
ov
erwriting the oldest recorded data.
•
record.
rd Mode.
Single-way: The system stops
Overwrite: The system continues
No Record: The system
does not
To format the hard disk:
1 From the Record Menu, select HD
Information.
2 Click Sele
3 Scroll up / down to select Internal HDD to
format the hard drive installed in the DVR,
External HDD to format your external hard
drive (not included), or All to format all
connected hard drives.
4 Click For
5 Click Yes t
No to cancel.
Please allow a few seconds for
formatting to occur and
to reset.
ct Format HDD.
mat HDD.
o format the hard drive or click
for the system
D
External Hard Drive Mirroring or
Extension
You can connect a single self-powered
external hard drive (not included) to the
rear panel of the DVR. You can use an
external hard drive either to expand the
total storage capacity of the DVR (HDD
Extension) or to have the DVR record to
both hard drives simultaneously for
backup purposes (HDD Mirroring). You
cannot use both HDD Extension and
HDD Mirroring at the same time.
37
NOTE: The DVR supports a single
external hard drive up to a
maximum size of 2TB. The
external hard drive must be
self-powered to work with the
system; it cannot receive power
from the DVR’s USB port.
Using the Main Menu
NOTE: F
ootage on the external hard
driv
e can only be accessed using
the DVR or a Windows PC. The
footage cannot be accessed on
a Mac.
HDD Extension allows you to expand the
total storage
capacity of your
DVR, so
you can record longer durations of
video. When HDD extension is enabled,
the DVR will first record until the
internal hard drive is full before it
begins to record to the external hard
drive. Once the internal and external
hard drives are full, it will begin to
overwrite the oldest available
recordings on the internal hard drive
(first in, first out).
The external hard drive you use for
mirroring must be the same size or
larger than the internal hard drive to
maintain a complete backup of your
internal hard drive.
NOTE: HDD Mirroring does not backup
ta fr
da
om before HDD
mirroring is enabled. The DVR
begins parallel recording to
both hard drives when HDD
mirroring is enabled.
If the external hard drive is larger than
in
ternal hard drive, the DVR will do
the
the following:
1 Record in parallel to both hard drives until
the in
ternal hard drive is full.
HDD Mirroring is useful if you want to
create an automatic backup of your
video footage on your external hard
drive. This allows you to secure your
external hard drive in a locked box or
cabinet. This way, if an intruder
removes or damages the DVR, you will
have a secure backup of the saved
footage.
2 Begin to ov
erwrite the oldest recordings
(first in first out) on the internal hard drive,
while continuing to record on the
additional capacity of the external hard
drive.
3 When the e
ternal hard drive is full,
x
overwrite the oldest recordings on the
external hard drive.
This allows you to keep a backup of your
most recent footage as well as a
single
copy of your oldest available footage on
the external hard drive.
38
Using the Main Menu
ATTENTION - Formatting the external hard
drive will erase all data on the drive. You must
connect the external hard drive to a Windows
PC and use Lorex Client 12 to access the video
on the hard drive.
For details, see “Using the HDD Reader (PC
Only)” on page 74. The footage cannot be
accessed on a Mac.
Select Mirror, Extended REC, or Read only
Total size of hard drive(s) Percent full
Hard drive status indicator
Footage on external hard drive (yellow)
Configuring your External Hard
Drive for HDD Mirroring or
Extension
You can connect a single self-powered
external hard drive (not included) to the
USB port on the rear panel of the DVR
for HDD Mirroring or Extension (see
“External Hard Drive Mirroring or
Extension” on page 37 for details).
To configure external HDD mirroring
or extension:
1 Connect an ex
port on the rear panel of the system.
ternal hard drive to the USB
NOTE: The DV
R supports a single
self-powered external hard
drive up to a maximum size of
2TB.
2 If y
ou have not done so already, you must
f
ormat the external hard drive with the
DVR to use it with the system. To format
the hard drive:
• From the Record Menu, select HD
Inf
ormation.
• Click Select Format HDD and sel
External HDD.
• Click For mat H DD and cli
Wait a few seconds for formatting to
complete.
3 Return to the HDD Information menu and
click External HDD Mode. Scroll up / down
to select one of the following:
• Mirror: HD
• Extended REC: HDD Extension.
• Read Only: Disabl
external hard drive and use it to playback
recorded footage only.
39
D Mirroring.
e recording on the.
D
ect
ck Yes to confirm.
4 Right-click and then click Ye s to confirm
your change. Right-click repeatedly to
return to live viewing.
NOTE: If y
ou select Extended REC, the
har
d drive status indicator at the
bottom of the screen will
indicate the combined size of
both the internal and external
hard drives. If you select Mirror,
the disk full indicator will
display the size of the internal
hard drive only.
Playing Back Video from the
External Hard Drive
When an external hard drive is
connected to the DVR, you can playback
video from it the same way that you
playback video from the internal hard
drive. For instructions on using
Playback Mode, see “Playback” on
page 24.
On the Playback Bar, times with video
that are stored on
drive are shown as yellow.
the external hard
Using the Main Menu
Alarm Menu
To access the Alarm Menu, click then .
Alarm Setup Menu
Alarm
The Alarm Menu allows you to
configure settings for alarms
and motion detection. It also allows you
to enable and disable the system
buzzers.
Enabling / Disabling System
Buzzers
The DVR has two buzzer options, a
system buzzer and a key buzzer. The
system buzzer beeps during alarms,
motion events, and system events. The
key buzzer beeps when buttons are
pressed.
To enable / disable system buzzer:
rom the Alarm Menu, click Buz
1 F
up / down and select O to enable the
system buzzer or select X to disable it.
zer. Scroll
Enabling / Disabling Motion
Detection
1 From the Alarm Menu, click Motion Enable
under the camera that you wish to
configure.
2 Scroll up / down and select O to ena
motion detection or X to disable it.
3 Rig
ht-click to save your changes and
eturn to the Main Menu.
r
ble
Enabling / Disabling Video Loss
Alarms
Video loss alarms occur when cameras
are disconnected or suffer a loss of
video. The DVR employs a pre-record
function to capture video from seconds
before the video loss occurred.
To enable / disable video loss alarms:
rom the Alarm Menu, click Vide
1 F
Alarm under the camera you wish to
configure.
2 Scroll up / down and select O to enabl
video loss alarm or X to disable it.
3 Right-click to save your changes and
eturn to the Main Menu.
r
o Loss
e the
Configuring Alarm Settings
1 From the Alarm Menu, click Alarm Setup.
The Alarm Setup Menu opens.
2 Right-click to save your changes and
eturn to the Main Menu.
r
To enable / disable the key buzzer:
rom the Alarm Menu, click Ke
1 F
Scroll up / down and select O to enable the
key buzzer or select X to disable it.
2 Right-click to save your changes and
r
eturn to the Main Menu.
y Buzzer.
40
Using the Main Menu
Motion Alarm Schedule
Range Selectors
2 Configure the following:
• Vloss Response Time: Sel
seconds) that the buzzer and on-screen
message will turn on after a Video loss
event.
• Response Dura
seconds) for the DVR to record after a
motion event. This also controls the
duration of the buzzer and on-screen
message.
NOTE: When the buzzer is
press any button or right-click
to stop it. This does not disable
the buzzer for future events.
• Alarm F
the DVR to display events (for example,
when motion is detected or video loss
occurs) in full screen; select X to have the
DVR remain in its current view when events
occur.
3 Right-click t
return to the Alarm Menu.
ull Screen: Se
tion: Select the time (in
o s
ave your settings and
ect the time (in
activated,
lect O if you want
Configuring the Motion Alarm
Schedule
The Motion Alarm Schedule allows you
to enable or disable motion events at
certain times. This can be useful if you
want to set up your DVR to record
continuously during business hours and
record motion events only outside of
business hours.
To configure the Motion Schedule:
rom the Alarm Menu, click Alarm Setup.
1 F
The Alarm
Setup Menu opens.
2 Click Moti
Alarm Schedule opens.
3 Click the boxes to switch each half-hour
between Working and Non-working hours.
Use the Range Selectors to switch multiple
boxes at once.
• Enabled (yellow): Motion
enabled during these hours.
• Disabled (green): Motion e
disabled during these hours.
4 Right-click until
menus to save your changes.
on Alarm Schedule. The Motion
events will be
vents will be
you have existed all
Configuring the DVR for Motion
Recording Only
Use the steps below to configure the
DVR to disable continuous recording
and only record footage that has motion.
This allows you to record for a much
longer time before the hard drive is full.
You can do this on one, some, or all of
your cameras.
41
NOTE: By default, the DVR will
o
verwrite the oldest recordings
when the hard drive is full. It can
also be configured to stop
recording when the hard drive is
full. For details, see “Changing
the Record Mode” on page 37.
Using the Main Menu
Set the Working Rate and Non-working rate to 0 to
disable continuous recording
Step 1 of 3: Enable Motion Detection on
your cameras:
1 While viewing, click
to open the Main
Menu.
2 Click
3 Under ca
to open the Alarm Menu.
meras that you wish to enable for
motion detection, click Motion Enable and
select O.
ight-click to save your changes and
4 R
r
eturn to the Main Menu.
Step 2 of 3: Configure the Motion Alarm
dule for 24/7
Sche
1 From the Main Menu, click
motion recording:
to open
the Alarm Menu.
2 Click Alarm S
etup>Motion Alarm
Schedule to open the Motion Alarm
Schedule.
e
3 Configur
the Motion Alarm Schedule to
enable motion events at all times. The
schedule will be solid yellow when motion
events have been enabled on a 24/7 basis.
NOTE: Use the r
ange selectors below
the Motion Alarm Schedule to
configure multiple boxes at a
time.
til y
4 Right-click un
ou have returned to the
Main Menu to save your changes.
Step 3 of 3: Disable Continuous
Recording (Working and Non-working
Hours):
1 From the Main Menu, click
to open
the Record Menu.
2 Click Video Frame Rate.
The Video Frame
Rate Menu opens.
3 Set both the Wo
king Rate and
r
Non-working Rate to 0 for cameras that
you want to configure for motion recording
only. This disables continuous recording on
these cameras.
NOTE: Ensure that the Alarm/Motion
R a t e i s h i g h e r t h a n 0 o n c a m e r a s
that you want to configure for
motion recording only.
r
4 Right-click
epeatedly to save your
changes.
Configuring Motion Detection Areas
and Sensitivity
You can configure the DVR to detect
motion only in certain areas. This can be
helpful if you want to only detect motion
in an important area (for example, the
entrance or driveway of your house) or if
normal traffic or movement (for
example, from a public street or a tree)
in an area is triggering the motion
detection.
You can also adjust the motion detection
to be more or
motion detection sensitivity means that
smaller amounts of motion will trigger
motion events. Lower motion detection
sensitivity means that it will take more
motion to trigger a motion event.
To configure motion detection
and sensitivity:
1 From the Alarm Menu, select Mo
Setup.
less sensitive. Higher
areas
tion
42
Using the Main Menu
Motion detection
is off
Motion Detection configuration window
Motion detection
is on
Area Selectors
Sensitivity bar
Backup Menu
To access the Backup Menu, click then .
ATTENTION: Formatting erases
all data
on the USB flash drive. This step
cannot
be undone.
2 Select the camera you wish to configure.
The Motion Detection configuration
window opens.
Backup
The Backup Menu allows you to
backup recorded video to a USB
flash drive (not included) and format a
connected USB flash drive.
You must format your USB flash drive before
u can backup video from your DVR.
yo
NOTE:
USB flash drives from 1~ 16GB.
The system supports most brands of
3 Click the area or areas where you would
like to disable / enable motion detection.
Areas covered by motion detection are
indicated by yellow dots. Use the Area
Selectors to enable or disable a larger
area.
4 Click the Sensitivity bar and scroll up /
wn to adjust the motion detection
do
sensitivity. A higher sensitivity means that
motion events will be triggered by smaller
movements. A lower sensitivity means
motion events require larger movements
to trigger.
For firmware upgrade instructions, see
“Appendix G: Upgrading Firmware” on
page 118.
Formatting the USB Drive
Prior to backing up data, you must
format the USB flash drive so it will
work properly with the DVR.
To format the USB drive:
1 Connect a USB flash drive to one of the
US
B ports on the front or rear panel of the
DVR.
2 From the Backup Menu, click Fo
Device.
3 Click Yes to format
the USB flash drive or
click No to cancel.
Please allow a few moments for
rmat
43
Using the Main Menu
formatting to take place. The DVR will
display "USB Check OK" when
formatting is completed.
Backing up Video to a USB Flash
Drive
1 Connect a formatted USB flash drive (not
included) to a USB port. See above for
instructions on how to format a USB flash
drive to work with the DVR.
2 From the Backup Menu, click Se
Channel and select the channel you would
like to backup.
3 Click Start Time, and s
month, year, and time to begin the backup.
Event Markers will appear in the Time Bar
as you scroll through the date and time.
4 Click Stop Time,
month, year, and time to end backup.
NOTE: Ev
ent Markers will appear in the
me Bar as you select the Start
Ti
and Stop times.
elect the date,
and select the date,
lect
video files, c
your computer. For instructions, see
“Playing Backed-up Video on your
Computer” on page 44.
3 To exit, right-click until you return to the
screen.
main
onnect the USB flash drive to
Backup File Information
Backup files are saved as MOV files to
Movie
the
drive. These files can be played on the
system using Event List or on your PC
using QuickTime Player. See “Event
List” on page 21.
Backup files are labeled, using the start
time specified, according to
following naming convention:
ch##_YYYYMMDD_hhmmss.mov:
Filename Definition
ch## Channel number (1~16)
YYYY Year
folder on your USB flash
the
ick Save to
5 Cl
on-screen counter displays the progress of
the transfer based on the start and stop
times selected.
6 To cancel Backup, right-click until you
eturn to the main screen. Please allow a
r
few moments for the system to exit.
NOTE: Backup may t
minutes, depending on the
amount of data being
transferred.
Device. Backup begins—the
ake several
Confirming Backup
To verify that the file has been
properly backed up:
rom Viewing or Playback mode, click
1 F
to open the Event List.
2 Cl
ick
to show backup files only. To view backup
from the Smart Search icons
MM Month
DD Day
hh Hour
mm Minute
ss Second
Playing Backed-up Video on your
Computer
View your saved backup video files
using QuickTime Player. You must have
QuickTime Player installed to view
backup files.
NOTE: For the latest version of
QuickTime Play
www.apple.com/quicktime/
download/
er, go to
44
Using the Main Menu
Click Choose
Default program
To access backed-up video recordings
(PC):
1 Connect your USB flash drive to a USB
port
on your computer. An Autoplay
window appears.
2 Select Op
3 Double-click the
en Folder to View Files.
Movie
folder to open it.
4 Double-click files to open them in
QuickTime, or
move them to a folder on
your computer to save them on your
computer’s hard drive.
i
To access backed-up v
deo recordings
(Mac):
1 Connect your USB flash drive to a USB
port on
your computer. The USB drive
appears on your desktop.
2 Doubl
e-click the USB drive icon (
open your USB thumb drive.
2 Click Open With>Choose Default
Program.
3 Under Recommended Programs, select
QuickTime Player and then click OK.
) to
Movie
3 Double-click the
folder to open it.
4 Double-click files to open them in
QuickTime, or
move them to a folder on
your computer to save them on your
computer’s hard drive.
Setting QuickTime Player as a
Default Media Player (PC)
It is recommended to set QuickTime
Player as your default media player.
This allows you to double-click on a
backed up video file and have the file
play automatically.
To set QuickTime Player as your
ult media player:
defa
1 Click on the back
to view, and right-click.
ed-up video file you wish
45
Using the Main Menu
LAN Menu
To access the LAN Menu, click then .
If you change the default port on the system from 80
to a different value, you MUST enter http:// and a
colon and the port number after the DDNS or IP
address when connecting to the DVR using a web
browser.
For example, if you change your port number from
80 to 85, you MUST enter a colon and port 85 after
the DDNS address (for example,
http://
tomsmith.lorexddns.net:85
).
Scroll up / down to
change HTTP port
LAN
The LAN Menu allows you to
view and adjust the networking
settings for the DVR, including the
Remote Access user IDs and
passwords. Changing settings in the
LAN Menu is not necessary to set up
your DVR for remote access. For
instructions on how to set up the DVR
for remote access, see “Setting up your
DVR for Remote Connectivity” on
page 51.
NOTE: For advanced users, tips that
wi
ll help keep your DVR secure
and accessible at all times, even
in the event of a power failure
are available in “Advanced
Networking Configuration
(Optional)” on page 61.
service provider (ISP).
NOTE: Pl
ease contact your ISP for
omplete information on
c
available ports.
Example
Let’s say you want to change the HTTP
port on your system from 80 to
To change the port number:
1 Click
to open the Main Menu, and
85
.
• It is highly recommended to set your DVR
up to use a fixed IP address. For more
information, see “Appendix B: Assigning a
Fixed IP to your DVR” on page 104.
Changing the HTTP Port
For added security, we strongly
recommend changing HTTP port 80 on
the system to
not blocked by your Internet
must
46
any desired port
—the port
then click
2 Click HTTP Port and
. The LAN Menu opens.
scroll up / down to
change the port number to 85.
3 Right-click to exit and save your settings.
4 Disconnect the power adapter from the
r
ear panel of the system. Let the system
power-down for 15~20 seconds and then
Using the Main Menu
HTTP Port
LAN Password Menu
reconnect the power adapter to the DC 12V
port.
5 To confirm that the new port number is
ed on your system, press the
sav
button on the front panel or remote control
to v
iew System Information.
• IP: Configure
DVR. This address will only be used if
DHCP is disabled.
• Mask: Configure a custom subnet mask
r your DVR.
fo
• Gateway:
address for your DVR.
• DNS Server: Configur
server for your DVR.
• DHCP Enab
O to enable DHCP or X to enable a fixed IP
address.
2 Right-click t
return to the Main Menu.
a custom IP address for your
Configure a custom gateway
e a custom DNS
le: Scroll up / down and select
o sav
e your changes and
Configuring Remote Access
Passwords
Use the LAN Password Menu to control
Remote Access passwords for USER1,
USER2, and ADMIN profiles. The
Remote Access password is required
when accessing the DVR over the
Internet or a local network.
You must update your DVR List in the
Client Software to use the new port.
Also, when logging into your DVR with
an Internet browser you must include a
colon and the HTTP port in the URL
after the DDNS address or IP address
(for example,
http://tomsmith.lorexddns.net:85
If you have already completed router
port forwar
re-configure your router to forward the
newly selected port.
ding, you will need to
Configuring Network Settings
The following steps are only required if
you need to enter a custom IP address,
subnet mask, gateway address, or DNS
server for your DVR. Consult your
router’s user guide for details.
1 Configure the following:
To change Remote Access passwords:
rom the LAN Menu, select LAN Password
1 F
and ent
password if needed (By default, ID: 9;
Password: 3333).
).
2 Select a user account, and use the
Password Wheel to enter the new Remote
Access password. Enter it again to
confirm.
er the ADMIN user ID and
47
Using the Main Menu
Dual Stream Setup
DDNS Setup
• USER1: Lowest level network user, with
access to remote live viewing only. By
default: ID 7; password: 1111.
• USER2: Normal
evel network user, with
l
access to remote live viewing,
playback, and backup only. By default,
ID 8; password: 2222.
• ADMIN (Administrato
r): Highest level
user, with access to remote live
viewing, playback, and setup. By
default, ID 9; password: 3333
3 To save your settings, right-click until you
e exited all menus.
hav
NOTE: After changing the LAN
swords, you must clear your
pas
browser’s cache to connect to
the DVR using a web browser.
Configuring Dual Streaming
Settings
Dual Streaming settings control the
quality and frame rate of video when you
connect to the DVR using a computer,
smart phone or tablet. Increasing Dual
Streaming settings will provide a better
image, but requires more bandwidth.
Performance may be impacted if
insufficient bandwidth is available.
To configure Dual Streaming settings:
1 From the LAN Menu, select Adv
Then select Dual Stream Setup.
2 Under Bitrat
e, select your Internet
connection speed between 28.8/36.6kbs
(lowest) and Intranet (highest). The Sub
Stream Frame Rate and Sub Stream
Quality adjust automatically based on your
selection.
anced.
3 (Optional) You may adjust the Sub Stream
Frame Rate and Sub Stream quality
manually. The Bitrate settings adjusts
automatically based on your selection.
4 Right-click repeat
edly to save your
changes and exit all menus.
Configuring DDNS Settings
Configure DDNS settings. You must
create a DDNS account before you can
configure DDNS settings. See “Step 2 of
4: Create a DDNS Account” on page 55.
To configure DDNS settings:
1 From the LAN Menu, select Adv
Then Select DDNS.
2 Under DDNS Select, select LOREX.
3 Click DDNS User Name and
on-screen keyboard to enter the DDNS
User Name from the confirmation email
that was sent to you after registering for
DDNS. Click
4 Click DDNS Pa
to confirm.
ssword and enter the DDNS
Device Password from the confirmation
email that was sent to you after registering
for DDNS. Click
to confirm.
5 Click DDNS Domain Name
Domain name/URL Request from the
confirmation email that was sent to you
after registering for DDNS. Click
confirm.
anced.
use the
and enter the
to
48
Using the Main Menu
Select Default under Send Mail Status to use
Lorex’s email server (recommended)
Enter the Sender’s email address and up to 3 receivers
NOTE: If the Domain name/URL
request is
tomsmith
, the
address to access your video will
tomsmith.lorexddns.net
be
using Client Software, or
http://
tomsmith.lorexddns.net:80
using a compatible Internet
browser.
6 Rig
ht-click repeatedly to save your
ch
anges and exit all menus.
Configuring Email Alerts
You can configure email notifications
when an event occurs (for example,
when motion is detected by one of your
cameras). You must enable motion
detection on your cameras to receive
email alerts. For instructions, see
“Enabling / Disabling Motion Detection”
on page 40.
To configure email alerts:
rom the LAN Menu, click Adv
1 F
select Mail Setup.
2 Under Send Mail Status
, select Default
(recommended) to use the Lorex email
server or select On to use a custom email
server. See the instructions below
depending on your selection.
anced. Then
2 Click Sender’s
E-mail and use the
on-screen keyboard to enter the sender’s
email address. This can be any email
address of your choice. Click
confirm.
3 Under Rece
iver’s Email, enter up to 3
to
email addresses to receive notifications
using the on-screen keyboard. Click
to confirm each entry.
4 Right-click t
o return to Mail Setup.
5 (Optional) Click Subject &
.
Location. Enter
a custom email subject and location using
the on-screen keyboard. Click
to
confirm each entry. Right-click to return to
Mail Setup.
6 Click Tes
7 Right-click repeat
t Mail to send a test notification.
edly to save your
changes.
To use the Lorex email server
(recommended):
1 Click E-m
ail Address.
To use a custom email server:
1 Under Send Mail Status, sel
2 Click SMTP Server
3 Click SMTP Server a
& Port.
nd use the on-screen
ect On.
keyboard to enter the email server
address. Click
4 Click SMTP Po
to confirm.
rt and select the email
server port number.
5 Right-click t
6 Click SMTP User & P
o return to Mail Setup.
assword.
7 Click SMTP User Name and enter the
SMTP user
name. Click
to confirm.
49
Using the Main Menu
Enter the Sender’s email address and up to
3 receivers
Enable/disable UPnP
8 Click SMTP Password and enter the SMTP
password. Click
to confirm.
9 Right-click to return to Mail Setup.
10 To enable secure authentication (such as
SS
L), click Log on using Secure and select
O.
ick E-m
11 Cl
12 Under Sender’s
ail Address.
E-mail, enter the sender’s
email address using the on-screen
keyboard. This can be any email address of
your choice. Click
13 Under Rece
iver’s Email, enter up to 3
to confirm
email addresses to receive notifications
using the on-screen keyboard. Click
to confirm each entry.
Enabling/Disabling UPnP
The DVR features UPnP compatibility to
allow a PC to automatically detect the IP
address. For details on how to connect
to your DVR using UPnP, see
“Connecting to the DVR over a LAN
Using UPnP” on page 77.
To enable/disable UPnP:
1 From the LAN Menu, click Adv
2 Click UPnP Enable. Scroll up / down to
select O to enable UPnP or X to disable.
anced.
14 Right-click to return to Mail Setup.
15 (Optional) Click Subject &
Location. Enter
a custom email subject and location. Click
to confirm each entry. Right-click to
return to Mail Setup.
16 Click Te
st Mail to send a test notification.
17 Right-click repeatedly to save your
anges.
ch
3 Right-click repeat
changes.
edly to save your
50
Setting up your DVR for Remote Connectivity
To complete the steps
below, your computer must
be on the same network as
the DVR.
!
Setting up your DVR for Remote Connectivity
The DVR supports two options for remote viewing over a local network (LAN) or the
Internet: Client Software (provided on the CD) for PC and Mac and DVR Netviewer, a
built-in, browser-based surveillance viewing software.
NOTE: Ex
cept where noted, the instructions in this section are the same for PC and Mac.
System Requirements
Prior to using the Client Software or DVR Netviewer, make sure your system meets the
following minimum system requirements:
Description Requirement
®
CPU Intel Pentium
Operating
System
Memory 128 MB RAM
Video 16 MB of video memory
Network (LAN) 10/100 BaseT Network
Network (WAN) 384 Kbps upstream
Browser
1
1 For the latest compatibility list, visit www.lorextechnology.com.
Windows™ XP / Vista
Mac OS 10.5 or above
*High-speed Internet service is recommended when using remote viewing.
Internet Explorer
you need to install the IE Tab plug-in.
4 3.0ghz or above (PC) / Intel Pentium Core Duo, 1.66 Ghz or above (Mac)
/ 7 / 8
®
6 (or later); Mozilla Firefox and Google Chrome are also supported, but
NOTE: If a user connects to the DVR remotely, there may be slow performance when
Accessing your DVR Within a Local Network (LAN)
You can connect to your DVR through the local area
network (LAN). It is recommended to confirm
connectivity over a local network before setting up
your DVR for Internet connectivity.
Step 1 of 4: Connect your DVR to the Local
Area Network (LAN)
1 Power off your DVR by disconnecting the power adapter from the rear panel.
2 Connect an Ethernet cable (included) to the LAN port on the rear panel of the system.
Connect the other end of the Ethernet cable to an empty LAN port (usually numbered 1~4) on
your router.
accessing the DVR locally. This is normal and is not a malfunction.
51
Setting up your DVR for Remote Connectivity
ROUTER
(Not Included)
Computer
(Not Included)
(not required for
local viewing)
INTERNET
Ethernet Cable
LAN port
8-channel model shown
HTTP Port
DVR IP address
3 Reconnect the power adapter to the DC 12V port on the rear panel to power the system back
on.
Step 2 of 4: Obtain the DVR’s Local IP Address and HTTP Port
1 Wait at least 5 minutes after powering up your DVR.
2 Press the
button on the front panel to bring up the System Information window.
3 Write down the IP address and HTTP Port number of the DVR.
52
• A local IP address looks something lik
e this: 192.168.50.220.
• Write down the port number beside the HTTP P
ort field
Setting up your DVR for Remote Connectivity
Run Lorex.exe
Edge Client
Software (Mac)
Step 3 of 4: Install the Client Software on your PC or Mac
Edge Client Software allows you to view and configure Edge Series DVR‘s over a local
network or the Internet. It is included on the software CD that came with your DVR, or
available as a free download from www.lorextechnology.com.
To install the Client Software on a PC:
1 Insert the softwar
The Autoplay window opens.
2 Click Run Lorex.exe.
e CD into your computer.
3 Click DV
R Software then Lorex Edge Client
Software - PC.
4 Follow the on-screen instructions to install.
install Edge Client Software on Mac:
To
1 Insert the softwar
e CD into your computer. The Lorex CD icon ( ) appears on your
desktop.
2 Double-click the Lor
3 Open the Mac fol
ex CD icon ( ).
der.
4 Double click the installer file.
5 Follow the on-screen instructions to install.
Step 4 of 4: Configure the Client Software and Confirm Local Connection
1 (PC) Double-click the Lorex Client 12 icon ( ) on the desktop. If a security warning
appears, click Yes. Th
e client window opens.
• (Mac) Double-click Edge Client
Softwar
e in your Applications
folder. The client window opens.
53
Add/ Configure
DVR
Open/refresh
connection
Close
connection
Select DVR
Client window
Setting up your DVR for Remote Connectivity
DVR List
2 Click DVR List. The DVR List window opens.
3 Click Add.
4 Configure the following:
• Name: Enter the name you
would like to use for
your DVR. You can use your name, your company
or business name, or anything of your choice.
• IP / DDNS: Enter the IP addr
ess from the System
Information window.
• Port:
Enter the HTTP port (default: 80) from the
System Information window.
• ID: Enter the ADMIN ID for remote viewing
(def
ault: 9).
• Password: Enter
the ADMIN password for
remote viewing (default: 3333).
5 Cl
ick Change. Then click Cl
ose to return to the
main client window.
6 Select your DVR from the drop-down menu at the top of the screen and click
Live video from your cameras will appear when the connection is successful.
to connect.
NOTE: If it does not
the connection.
54
connect within 30 seconds, click and click again to refresh
Setting up your DVR for Remote Connectivity
Accessing your DVR Remotely Over the Internet
Setting up remote connectivity allows you to view your DVR from any computer or
compatible mobile device with internet access.
To set up remote connectivity
1 P
ort forward the HTTP port (default: 80) on your router to your DVR’s IP address.
2 Create a DDNS account.
3 Enabl
4 Upd
e DDNS on the DVR.
ate the Client Software with your DDNS information.
with your DVR, you must:
Step 1 of 4: Port Forwarding
You must port forward the HTTP port (default: 80) on your router to your DVR’s IP address
before you can remotely connect to your system. There are several methods to port
forward your router:
• Use the Lor
the required ports. For instructions on how to use the Easy Connect Wizard, see the Easy
Connect manual on the CD.
• Manually port forward the required ports on your router to your DVR’s IP address by
f
ollowing your router manufacturer’s instructions. For more information on port
forwarding, see the reference guides on www.lorextechnology.com.
NOTE: If
NOTE: Cert
the HTTP port is not forwarded on your router, you will not be able to access your
system remotely.
check with your ISP and change the HTTP port. see “Changing the HTTP Port” on
page 46. If you change your HTTP port, you must
Software for the newly selected port.
ex Auto Port Forwarding Wizard (PC only, provided on the CD) to port forward
ain ISPs (Internet Service Providers) block port 80. If you are unable to connect,
update your DVR List in the Client
Step 2 of 4: Create a DDNS Account
Lorex offers a free DDNS service for use with your system. A DDNS account allows you to
set up a web site address that points back to your local network. This allows you to connect
to your system remotely. You must create a DDNS account in the same network as your
DVR.
55
Setting up your DVR for Remote Connectivity
Click Step 1
Enter your account Information
and click Create Account
Click Create Account
Click Warranties
To setup your free Lorex DDNS account:
1 In your browser, go to http://www
.lorexddns.net and click Step 1.
2 The My Lorex account login screen opens (if you are already logged in, skip to step 4). Create
a new account or log into an existing account. To create a new account, fill in the required
fields on the right and click Create Account.
3 Click Warranties to register your product for warranty.
NOTE: Warranty registration is required to register for DDNS.
4 The Warranty page opens. Click A
56
ctivate Warranty to register your product for warranty.
Setting up your DVR for Remote Connectivity
Enter your address
information
Click Create Address
Select your address or
enter a new address
Enter your product and
purchase details
Click Save Warranty
5 Under Your Address, select an address or click Enter a New Address to create a new address.
Fill in your address information and click Create Address.
6 Fill in the warranty registration form with your product and purchase details. Check the
sticker underneath your DVR for the Product Model Number and Serial Number. Click Save
Warranty.
57
Setting up your DVR for Remote Connectivity
Click Set Up a New DDNS
Select your product
warranty
Enter a Device Name
of your choice
Enter the product’s
MAC address
Enter the web site
address that will be
used to connect
Click Save
MAC Address
7 A page pops up to prompt you to register your product for Lorex DDNS. Click Set Up a New
DDNS.
8 Configure the following:
58
• Product Warranty: Select the product warranty you created in the previous steps.
• Device Name: Ent
er a name for your device. You can enter your name, business name, or
anything of your choice. This is used to identify this device in your list of activated DDNS
accounts that appears anytime you visit the DDNS page.
• MAC Address:
Enter the MAC address of your Lorex product. Press the button on the
front panel to find your MAC address. A MAC address is a permanent, unique 12-digit address
used to identify
a device on a network.
Setting up your DVR for Remote Connectivity
Domain name/URL Request:
DDNS User Name:
DDNS Device Password:
DDNS setup in Edge Client Software
ATTENTION: You
MUST
enter your DDNS information
over the local
network
before attempting remote access.
Setup button
DDNS tab
• URL Request: Enter the web site address that will be used to connect to your Lorex product.
For example, if you enter
tomsmith.lorexddns.net
tomsmith
using Client Software or
, the address to access your video will be
http://tomsmith.lorexddns.net
using a
compatible web browser.
9 Click Sav
e to register your product for DDNS. A confirmation email will be sent to the email
address used to register for My Lorex.
You will need this information to enable
remote access to your system. Record your
information below:
Step 3 of 4: Enable DDNS on the DVR
Once you have registered for free DDNS service, use the information in the confirmation
email to configure DDNS settings on your system.
To enable DDNS on your system:
1 Open the Cl
2 Click the Setup butt
3 Open the DDNS ta
4 Under DDNS Select, select http://l
ient Software and sign into your DVR.
on.
b.
orexddns.net from the drop-down.
59
Setting up your DVR for Remote Connectivity
5 Configure the following:
• DDNS User Name: Enter
you after you created your DDNS account.
• DDNS Password: Ent
• DDNS Domain Name: Ent
the DDNS User Name from the confirmation email that was sent to
er the DDNS Device Password from the confirmation email.
er the Domain name/URL Request from the confirmation email.
6 Click A
7 Reset the DVR by disconnecting and reconnecting the power cable from the rear panel.
NOTE: Please allow 10~15 minutes for the DDNS servers to update with your new DDNS
pply to save your changes.
addr
ess before attempting to connect.
Step 4 of 4: Update the Client Software with your DDNS Information
Finally, you must configure your DVR List with the DDNS information for your DVR by
adding a new DVR entry to the DVR List with your DDNS address. You will use the DDNS
address whenever you want to connect to your DVR over the Internet.
If you are performing the steps below on a computer on the same ne
this allows you to keep a separate entry for your DVR on the local network. Connecting to
the DVR will be faster on the local network and will allow you to save bandwidth.
To add a new entry to your DVR list us
1 Open the Client Softwar
2 Click Ad
3 Configure the following:
• Name: Ente
company or business name, or anything of your choice.
• IP/DDNS: Enter the Do
the Domain name/URL request is
• Port: Ent
• ID: Enter the ADMIN ID f
• Password: En
d.
r the name you would like to use for your DVR. You can use your name, your
er the HTTP port (default: 80) from the System Information window.
ter the ADMIN password for remote viewing (default: 3333).
e and click DVR List. The DVR List window opens.
main name/URL Request followed by .lorexddns.net. For example, if
or remote viewing (default: 9).
ing the DDNS address:
tomsmith
, enter
tomsmith.lorexddns.net
twork as your DVR,
.
4 Click Change t
5 Select your DVR’s DDNS address from the drop-down menu (e.g.
the top of the screen and click
when the connection is successful.
NOTE: If it does
the connection.
Congratulations! Your DVR is now connected to the Internet. For instructions on us
Client Software to view live video, playback and backup recorded footage, and configure
your DVR, see “PC and Mac Client Software for Remote Viewing” on page 62.
You can now access your DVR using a compatible web browser (for details, se
Netviewer: Viewing Your DVR Using a Web Browser” on page 76) or mobile device (for
details, see “Mobile Apps: Accessing your DVR Using a Mobile Device” on page 85).
60
o save your settings. Then click Close to return to the client window.
tomsmith.lorexddns.net
to connect. Live video from your cameras will appear
connect within 30 seconds, click and click again to refresh
not
e “DVR
) at
ing the
Setting up your DVR for Remote Connectivity
Advanced Networking Configuration (Optional)
The following steps are recommended to ensure your DVR is secure and accessible at all
times, even in the event of a power failure. Please note that some of the steps below
require you to reconfigure the settings for your DVR in the Client Software.
• As
sign a fixed IP address to your DVR. A fixed IP address will allow your DVR to keep the
same IP address in the event of a power failure or if you restart your router. If your DVR’s IP
address changes, you may lose your port forwarding rules. See “Appendix B: Assigning a Fixed
IP to your DVR” on page 104.
hange your system passwords and remote access passwords to something other than the
• C
defaults. See “Managing Passwo
you must update your DVR List in the Client Software to use the new password(s).
hange your HTTP Port to
• C
by your Internet service provider. For details, see “Changing the HTTP Port” on page 46. If you
change your HTTP port, port forward the newly selected port and update your DVR List in the
Client
• Connect y
A UPS has an internal battery that will keep your equipment running in the event of a power
failure. The amount of time that a UPS can keep your equipment running will depend on the
model of UPS and the devices connected.
Software for the newly selected port.
our DVR, router/modem, and cameras to an Uninterruptible Power Supply (UPS).
rds” on page 28. I f y o u c h a n g e y o u r r e m o t e a c ce s s p a s s w o r d s ,
any desired port
other than port 80. The port must not be blocked
NOTE: In
must also connect your router and modem to the UPS.
order to maintain remote connectivity to your DVR during a power failure, you
61
PC and Mac Client Software for Remote Viewing
Level User ID Password
USER1 7 1111
USER2 8 2222
ADMIN 9 3333
Remote/LAN Access:
Edge Client
Software (Mac)
PC and Mac Client Software for Remote Viewing
Client Software is available that allows you to access your system from any PC or Mac with
an Internet connection. The Client Software is compatible with any Edge Series DVR, and it
can save the device information for multiple DVRs. This means you can easily switch
between multiple DVRs located in your home, business, or properties without having to
re-enter the address or password.
as
NOTE: This section
to enable your DVR for remote viewing.
NOTE: Check www.lorextechnology.com for software updates.
Network User Accounts
In order to login to the DVR remotely, you need a
Remote Access user ID and password. See the
table on the right for the default Remote Access
user IDs and passwords. For a detailed
description of user accounts, see “User
Accounts” on page 28.
sumes that you have completed all the steps in the previous section
Running the Client Software
NOTE: For installation instructions, see “Step 3 of 4: Install the Client Software on your PC or
Mac” on page 53.
• (PC) Double-click the Lor
appears, click Yes. Th
• (Mac) Double-click Edge Client
appears.
ex Client 12 icon ( ) on the desktop. If a security warning
e client window opens.
Software in your Applications folder. The client window
62
Client Window
Client Window (PC version / 8-channel model shown)
NOTE: The appearance of the client window differs before you connect to your DVR.
1
2
7
4
5
6
10
9
3
8
PC and Mac Client Software for Remote Viewing
1 DVR List: Click to configure the connection information for your DVRs. Can save multiple
Edge Series DVRs for quick access.
2 Status Bar: Show
s connection status. When connected to DVR, presents the date and time on
the connected DVR.
3 Display screen:
4 DVR Selector:
5 Connect/Refre
6 Disconnect
7 Utilities: Onl
Displays video from your cameras.
Select DVRs from your DVR list.
sh : Click to connect to DVR.
: Click to disconnect from your DVR.
y available on the PC version; not available on Mac or via browser. Items are
grayed out when they are not currently available.
C
• Speed Dome:
• Full Screen:
lick to access PTZ camera controls when PTZ camera is selected.
Click to view the display screen in full-screen. Press ESC to exit full-screen.
63
PC and Mac Client Software for Remote Viewing
DVR List
• Capture: Click to take a screenshot of the display screen.
• HDD Reader: Clic
connected to the computer using a USB cable (not included). This allows you to quickly backup
long segments of video, such as hours or days.
• REC: Click t
• Large: Click t
in its original proportions.
8 Modes:
• Live: Click to view live, streaming video; view c
• Playback: Click t
• Backup: Click to save recorded video data to your computer.
• Setup: Click to
k to playback / backup video from an external hard drive (not included)
o record live video onto your computer hard drive.
o stretch the video to the edge of the gray area. Click Small to show the video
ameras in full-screen or split-screen.
o view recorded video from the system.
open Setup Mode.
9 Views: Click
10 Channels: Click t
to view in Quad, 9-split, or 16-split (16-split available on 16-channel only).
o view channels in full-screen.
DVR List: Managing DVRs
DVR List is used to save the connectivity
information for your DVR or DVRs. You can use it
to add a new DVR or modify or delete an existing
DVR.
You can also have multiple entries in your DVR
List for the same DVR. For example, on
computers on
can have one entry for the local IP address of your
DVR and one entry for the DDNS address of your
DVR. This can be useful if you have a laptop. When
you are at home, you can view the DVR using the
local IP address, which saves bandwidth and
provides a faster connection. When you are out,
you can connect over the Internet using the DDNS
address.
Adding a DVR
1 From the Client window, click DVR List. The DVR List appears.
the same network as your DVR, you
2 Click Ad
3 Configure the following:
64
d.
PC and Mac Client Software for Remote Viewing
Click DVR
to select
• Name: Enter the name you would like to use for your DVR. You can use your name, your
company or business name, or anything of your choice.
• IP / DDNS: Enter the DDNS addr
ess or IP address of your DVR. For the DDNS address, enter
the Domain name/URL Request sent to you in the confirmation email, followed by
.lorexddns.net (for example,
• Port:
Enter the HTTP port (default: 80) for your DVR.
tomsmith.lorexddns.net
)
• ID: Enter a user ID for remote viewing.
• Password: Enter
the corresponding password for remote viewing.
4 Click Change. Then click Cl
ose to return to the client window.
5 To test your settings, select your DVR from the drop-down menu at the top of the screen and
click
to connect. Live video from your cameras will appear when the connection is
successful.
NOTE: If it does
connect within 30 seconds, click and click again to refresh
not
the connection.
Changing DVR Settings
Change the settings for an existing DVR. You will need to do this if you change the
passwords or port configuration of your DVR.
To change settings for an existing
DVR:
1 From the Client window, click DVR
List. The DVR List window opens.
2 Click the DVR y
change.
3 Change the c
needed.
ou would like to
onfigur
ation as
4 Cl
ick Change t
o save your changes.
Then click Close to return to the
client window.
Deleting a DVR
1 From the Client window, click DVR List. The DVR List window opens.
2 Click the DVR y
3 Click De
4 Click Cl
lete. Then click Yes to confirm.
ose to return to the client window.
ou would like to delete.
65
PC and Mac Client Software for Remote Viewing
Channel
View
buttons
Channel
buttons
8-channel model shown
Playback controls
Live Viewing Mode
By default, the Client Software
launches in Live Viewing
mode.
To use Live Viewing:
1 Cl
ick
.
2 Click the View buttons (for
example,
) to view in
Quad, 9-way split, or 16-way
split (16-way sp
lit available on
16-channel only).
ick the Channel buttons
3 Cl
to
view channels in full-screen.
NOTE: Audio is not ava
Playback
Mode
ilable in Live Viewing.
Use the Playback mode to view recorded video from
your DVR. Use the Pop-up Calendar to select recorded
video from a specific date and time.
NOTE: Only the ADMIN and USER2 accounts may access
Playback mode.
To
use remote playback:
1 Click
NOTE: Depending on
.
your network connection, please allow a few moments for the system
to switch to playback mode.
2 Click the Channel buttons t
3 Click
4 Click
to open the Pop-up Calendar to select the date and time.
, , , to control playback.
o select the channel you want to view.
NOTE: When a channel with audio is sel
Audio-enabled camera (not included) or self-powered (not included) microphone
be connected and configured. For details, see “Appendix D: Recording and
must
Playing Audio” on page 111.
66
ected, click to mute / un-mute audio.
Using the Pop-Up Calendar
Pop-Up Calendar
Drag slider to
adjust time
Backup controls
Set Start Time
Set Stop Time
Select Channel
for Backup
Start Backup
1 Click to open the Pop-up Calendar to
select the date and time.
ick
2 Cl
3 Click to select a date.
to change the month.
PC and Mac Client Software for Remote Viewing
4 Click
to set the time or drag the slider to
adjust time in 30 minute increments.
5 Click SET.
6 Click
Backup
The pop-up calendar closes.
, , , to control playback.
Mode
Use Backup mode to copy recorded video data
from your DVR to your PC or Mac.
NOTE: Onl
y the ADMIN and USER2 accounts
se Backup mode.
may u
NOTE: If you are accessing your DVR using a
owser, you may be prompted to install
br
the ActiveX plug-in before Backup will
function properly. When prompted, click
the bar to install ActiveX to your browser.
DVR Netviewer will reset. You may need
to log in again with your user ID and
password.
To use Backup:
1 Cl
ick the
button.
2 Click the Channel buttons t
o select the channel you want to back up.
67
PC and Mac Client Software for Remote Viewing
Backup controls
Expanded
calendar view
Run as administrator
System tab in Setup Mode
3 Under Start Time, click to open the
pop-up calendar and select a date and time.
Click the
SET button.
4 Under Stop Time, click to open the
pop-up calendar and select a date and time.
Click the
SET button.
5 Click Start to begin
backup. It may take
several minutes to complete the backup,
depending on the length of video selected.
The file is saved to:
• PC - Client Software or Browser:
C:\DVR_Backup
• Mac:
HD>Applications>Edge Client
Software>DVR_Backup
NOTE: Backup files carry the file extension .mov. You can use QuickTime Player to view
back up video files.
NOTE: If
an error message appears while trying to create a
backup thr
ough your web browser, close the
browser. Then, right-click on the browser desktop or
Start Menu icon and select Run as administrator. If
a security warning appears, click Yes. Re-connect to
your DVR. You should now be able to create backups
as normal.
Setup Mode
Use Setup Mode to configure your
network settings and video streaming
options. You can also use Setup mode
to create custom names for your
cameras.
NOTE: Only the ADMIN account can
To open Setup Mode:
• From the main screen, click
68
access Setup mode.
. By default, the System tab opens.
Changing Bitrate Speed
Bitrate tab
Select bitrate
speed
Click Apply
PPPoE tab
ATTENTION: You
MUST
enter your
DDNS information
on the local network
before attempting remote access.
Enter only the first portion of your domain name
1 Click the Bitrate tab from Setup Mode.
2 Under Bitrate, select a bitrate speed. A
higher bitrate speed improves the quality of
the video stream but requires more
bandwidth. If the video is taking a long time
to update or is choppy, it is recommended to
select a lower bitrate.
PC and Mac Client Software for Remote Viewing
3 Click A
pply to save your settings to the
system.
Enabling PPPoE
1 Click the PPPoE tab from Setup Mode.
2 Under the PPP
oE Status, select ON.
3 In the corresponding text fields, enter your
PPPoE Username and
4 Click A
pply to save your settings.
password.
Enabling DDNS
Lorex provides a free DDNS service for use
with your DVR. A DDNS account allows you to
set up a permanent web-site address for your
DVR.
Visit http://www.lorexddns.net to register for Lorex’s free DDNS service. For more details
on setting up a free Lorex DDNS account, see “Step 2 of 4: Create a DDNS Account” on
page 55.
NOTE: Y
o change DDNS settings:
T
ou must register for Lorex’s free DDNS service prior to configuring DDNS settings.
1 Click the DDNS tab from Setup Mode.
2 Under DDNS Sel
ect, click the drop-down
menu and select http://lorexddns.net
3 Configure the following:
• DDNS User Name: Enter
Name from the confirmation email that
was sent to you after you created your
DDNS account.
• DDNS Password: Ent
Password from the confirmation email.
• DDNS Domain Name: Ent
the DDNS User
er the DDNS Device
er the Domain name/URL Request from the confirmation email.
69
PC and Mac Client Software for Remote Viewing
System tab
Email tab
To setup email alerts, you must be logged into
your DVR using Edge Client Software. Once you
are logged in, click and then
Mail to
access the Email tab.
You must enable motion detection on your
cameras to receive email alerts. For
instructions, see “Enabling / Disabling Motion
Detection” on page 40.
IMPORTANT
4 Click Apply to save your settings or click Clear to exit without saving.
5 To ensure your DDNS settings are saved on your system, disconnect the power adapter from
rear panel of your system. Allow the system to power down for 15~20 seconds. Reconnect
the
the power adapter.
NOTE: Pl
NOTE: Y
ease allow 10~15 minutes for the DDNS servers to update with your new DDNS
addr
ess. This is normal for the DDNS system.
ou will have to reconfigure your DVR’s connection settings in DVR List to connect
t
o the DVR using DDNS. For instructions, see “Changing DVR Settings” on page 65.
Viewing System Status
By default, Setup Mode opens to the System
tab. However, you can view this screen at any
time when navigating Setup Mode.
To view system status:
• Click the System ta
b from Setup Mode. The
System Status screen appears.
NOTE: You cannot edit the IP address or port number.
Configuring Email Alerts
Use the Mail tab to configure email alerts for triggered events (such as when motion is
detected by one of the cameras) on your DVR. By default, email alerts use Lorex’s email
server (recommended). However, you can also use your own SMTP server.
To configure email alerts:
1 Click the Mail t
ab from Setup Mode.
2 Under Send Mail Status, select Default.
3 Under the Sender’
70
s Email field, enter the sender’s email address.
PC and Mac Client Software for Remote Viewing
Title tab
4 In the Interval drop-down menu, select the minimum interval between event notification
emails. For example, if you set the interval to 5 minutes, the DVR will only send alerts every 5
minutes when an event occurs.
5 Under the Rec
eiver Email fields, enter the email address or addresses you would like alerts
to be sent to. You can enter up to 3 email recipients.
must
NOTE: You
6 (Optional) Ent
enter a sender and receiver email address for email alerts to work.
er a subject for the notification and a location (of the DVR) in the respective
fields.
7 Click A
pply to save your settings, or click Clear to exit without saving. Click OK to close the
confirmation window.
8 Click Te
st Mail to send a test notification. Click OK to close the confirmation window.
NOTE: If you have made a mistake with either email addresses, you will not receive the
te
st notification.
9 Restart the DVR by disconnecting the power adapter from the rear panel of the DVR and
econnect it.
r
NOTE: If you want to use your own SMTP server, select ON
from the Send Mail Status
drop-down menu. Enter the address of your SMTP Server, port, user name, and
password. Check the Log on using secure authentication checkbox to log on using
secure authentication. Enter the sender’s email address and recipient’s email
address or addresses. Click Apply to save your settings and Test Mail to test the
notification.
Creating Custom Camera Titles
Use the title tab to create custom titles
for your cameras. Custom titles are
displayed on the DVR but are not shown
while viewing remotely. You can also
save custom title configurations to your
computer and restore them later or
apply them to other DVRs.
To change camera names/titles:
lick the Title tab from Setup Mode.
1 C
2 Under the Channel fields, ent
title for the camera. For example,
Parking Lot 1, Front Door, etc.
3 (Optional) (PC) Click Font Size
dr
op-down menu to change the size of
your camera titles. You can also drag
the slider to adjust the font size or
manually enter the font size.
er a new
71
PC and Mac Client Software for Remote Viewing
Save As
Cancel
NOTE: The Capture button takes a snapshot
of the entire display area. To take a
snapshot of a single camera, you
must switch to it before clicking
Capture.
• (Mac) Click the Font Option button and use the menu to change the font and font size.
• (PC only) Use the Language drop-down menu to sele
ct the language for the camera titles.
4 Click A
pply to save the new titles to your DVR.
5 Return to your DVR and refresh your screen by changing the display mode (single, quad,
split-scr
To save a camera title configuration (PC
1 Click Sav
2 Select a save location, enter a file name, and click Sav
een) to see the new titles.
only):
e File.
e.
To load a camera title configuration (PC only):
1 Click Load Fil
e.
2 Select the configuration file and click Open.
3 Click A
pply to update your DVR with the saved configuration.
4 Return to your DVR and refresh your screen by changing the display mode (single, quad,
split-scr
een) to see the new titles.
Taking Screenshots (PC Only)
You can use the Capture button to take
screenshots of the display area at any
time during live viewing or playback.
NOTE: Screenshot function is not
available on Mac or via browser.
To take screenshots:
ick the Capture but
1 Cl
ton ( ). The
Capture window opens with a preview of
your scr
2 Click Sav
eenshot.
e As. A Save As window
appears. Select the folder where you
would like to save the screenshot. In the
File Name field, enter a name for your
snapshot. Click Save.
72
PC and Mac Client Software for Remote Viewing
You must connect and configure PTZ cameras locally on the DVR before you
can use remote PTZ controls. For instructions on connecting PTZ cameras,
see “Appendix C: Connecting PTZ Cameras” on page 108.
!
Select the channel for
the PTZ camera
Speed Dome
Manual Recording (PC Only)
You can use the REC button to create a manual recording of the display area anytime
during live viewing.
NOTE: Manual
To take a manual recording:
ick the REC but
1 Cl
2 Click the REC butt
NOTE: Manual recordings are saved to
NOTE: The REC button tak
a single camera, you must select it before clicking REC.
ecording is not available on Mac or via browser.
r
ton ( ). The REC button flashes to indicate manual recording is on.
on again to stop recording.
C:\DVR_Backup
es a recording of the entire display area. To take a recording of
.
Accessing Remote Speed Dome Settings (PTZ Controls) (PC Only)
Using the Speed Dome menu, you can control your PTZ cameras (not included) remotely.
NOTE: Remote Speed Dome settings are not available on Mac or via browser.
To access Speed
1 Click the channel number that the PTZ c
Dome
Settings on Client Software:
amera is connected to.
73
PC and Mac Client Software for Remote Viewing
Speed Dome Controls
Click the Arrows to change the
camera Pan and Tilt
Click X to close Speed Dome
controls
ATTENTION - When removing the hard drive, it is VERY IMPORTANT to follow the
instructions in “Appendix F: Replacing the Hard Drive” on page 114 to avoid
damaging your DVR.
2 Click Speed Dome. Speed Dome controls open.
NOTE: The Speed Dome controls are identical to the controls available through the DVR.
For details, see “Controlling PTZ Cameras” on page 109.
Using the HDD Reader (PC Only)
The HDD Reader is used to backup and playback video saved on an external hard drive (not
included). This allows you to quickly backup long segments of video, such as hours or days.
It is also useful if the DVR is damaged or removed by an intruder, and you need the video
data that is stored on the external hard drive. For details on setting up an external hard
drive with the DVR for HDD extension or mirroring, see “Configuring your External Hard
Drive for HDD Mirroring or Extension” on page 39.
It may also be used to access the footage on your DVR’s internal
hard drive when it is
connected to your computer using a 3.5" SATA external hard drive enclosure (not included)
using a USB cable (not included). This requires you to remove the hard drive from your DVR
and install it in the external hard drive enclosure.
To use the HDD Reader:
1 Connect the external hard drive (not included) to y
our computer using a USB cable (not
included).
NOTE: The hard drive may not be visible if you try to locate it using Windows Explorer or
My Computer
. This is normal. The DVR stores data in a format that is incompatible
with Windows.
2 Open the Client Softwar
e and click the HDD Reader button ( ). The HDD Reader
opens to Playback Mode.
74
To playback video using the HDD Reader:
Click to select
Playback time
Click to select
channel
Click to begin
Playback
Click to Start
Backup
Click to select
channel
Click to select
Start Time
Click to select
End Time
PC and Mac Client Software for Remote Viewing
1 Under Play Time, clic
k and use the pop-up
calendar to select a date and time to play back.
2 Select the channel you would like to playback and
to begin playback.
click
3 Click
to pause playback and select another
playback time.
To backup video using the HDD Reader:
1 Click the
button.
Under Start Time, click and use the pop-up
2
calendar to select a date and time.
3 Under Stop
Time, click and use the pop-up
calendar to select a date and time.
4 Select the channel you would like to back up.
5 Click Start t
o begin the back up. Back up may
take several minutes to complete, depending on
the length of video specified.
NOTE: Back up files are saved to
C:\DVR_Backup
.
75
DVR Netviewer: Viewing Your DVR Using a Web Browser
Domain Name/URL Request
HTTP port number
Colon
Example of a DDNS address
http://tomsmith.lorexddns.net:80
Domain Name/URL Request
Colon
HTTP port number
Internet Explorer connected to a DDNS address
http://
DVR Netviewer: Viewing Your DVR Using a Web
Browser
DVR Netviewer is a built-in, browser based software for remotely connecting to your DVR.
This section only covers how to connect to your DVR using compatible browsers. It
assumes that you have completed all the steps in the section “Setting up your DVR for
Remote Connectivity” on page 51 to configure your DVR for remote viewing over the
Internet.
NOTE: The interface for DVR Netviewer is identical t
not support certain features, such as DVR List. For instructions on how to navigate
the remote viewing interface to access and control your DVR, see “PC and Mac Client
Software for Remote Viewing” on page 62.
o the Client Software, except it does
Connecting to your DVR Using a DDNS or IP Address
When you connect to your DVR using a web browser, enter the DDNS address of your DVR.
A DDNS address is a permanent, web site address that will allow you to connect to your
DVR over the Internet from any compatible browser or mobile device. To connect using a
DDNS address, you must register for a free Lorex DDNS account and configure your DVR
with your DDNS account information. For instructions, see “Accessing your DVR Remotely
Over the Internet” on page 55.
Use the following format to connect to your DVR using a DDNS address: http://, the
main Name
Do
.lorexddns.net, colon, and the HTTP port number (default: 80). See below for an example.
/URL Request you created when you made your DDNS account, followed by
You can also connect to the DVR using an internal or external IP address; however, it is
recommended to use the DDNS address, because it is a text address that is easy to
remember and will not change. Using an internal, or local IP, address is only available on
computers on the same network as your DVR.
76
DVR Netviewer: Viewing Your DVR Using a Web Browser
Internet Explorer connected to a local IP address
IP Address
Colon
HTTP port number
http://
Network
Double-click the DVR’s IP address to
open it in your default browser
Use the following format to connect to your DVR using an IP address: http://, the IP
address, and then colon and the HTTP port number (default: 80). See below for an
example.
Connecting to the DVR over a LAN Using UPnP
This DVR features UPnP for easy connection over a local area network (LAN). UPnP allows
a PC on the same network to automatically locate the DVR’s IP address.
NOTE: The foll
owing method only works over a local network. You must complete DDNS
and port forwarding setup to connect to your DVR over the Internet. For instructions,
see “Accessing your DVR Remotely Over the Internet” on page 55.
To connect to your DVR on the local network using UPnP:
1 On a PC c
onnected to the same router as the DVR, open Windows Explorer
(Start>Computer) and click Network. The DVR’s IP address appears.
2 Double-click the DVR’s IP address to connect to the D
VR. The DVR will open in your default
browser.
You will need to complete additional steps to connect to the DVR in your web browser. See
below for details.
77
DVR Netviewer: Viewing Your DVR Using a Web Browser
You must port forward
your router before you can
connect to your system
using a web browser (e.g.
Internet Explorer)
!
Run as administrator
Login screen
Click the ActiveX attention bar
Select Install this Add-on for All Users on
This Computer...
Click Install
Internet Explorer
Remote viewing using Internet Explorer is supported on
Internet Explorer versions 6 and higher. The instructions
below describe how to connect to your DVR on Internet
Explorer 6 through 8. See page 79 for instructions
specific to Internet Explorer 9 and 10.
To view your DVR using Inter
1 Open Internet Explorer and enter your DV
address or IP address in the address bar.
NOTE:
2 In the ID and Password fields, enter your re
access ID (default: 9) and password (default:
3333) and click Login.
• If you enter the incorrect ID or password, the
3 Y
Netviewer to function. Click the attention bar at
the top of the main page and select Install this
Add-on for All Users on This Computer.... DVR
Netviewer will reset.
When opening Internet Explorer, it is
recommended to right-click the Internet
Explor
and select Run as administrator. This will allow
you to use the remote back up feature to save
video files from your DVR on your computer hard
drive.
login page will refresh and the fields will clear.
ou must install the ActiveX
er icon from your Start Menu or Desktop,
net Explorer:
®
plug-in for DVR
R’s DDNS
mote
4 Re-enter your ID and password and click Login. An installation window opens.
78
DVR Netviewer: Viewing Your DVR Using a Web Browser
32-bit Internet
Explorer
Run as administrator
Blue icon
Click Allow
5 Click Install. DVR Netviewer launches.
Internet Explorer 9 / 10
You must use compatibility mode to connect to your DVR using Internet Explorer 9 or 10.
To view your DVR using Inte
1 Open Internet Expl
orer. On Windows 8, you must use the Desktop version of Internet Explorer.
rnet Explorer 9 or 10:
NOTE: You must use the 32-bit version of Internet Explorer. From the Start Menu, click
Internet Expl
orer. Do not click Internet Explorer (64-bit).
NOTE: When opening Internet Explorer, it is recommended to right-click the Internet
Explorer icon, and select Run as administrator. This will allow you to use the remote
back up feature to save video files from your DVR on your computer hard drive.
NOTE: On Window
s 8, right-click the Internet Explorer taskbar icon, then right-click
Internet Explorer and select Run as Administrator. You must run Internet Explorer
from the Desktop to access your DVR.
2 Ent
er your DV
3 In the ID and Password fields, enter your re
R’s DDNS address or IP address in the address bar.
mote access ID (default: 9) and password
(default: 3333) and click Login. An attention bar appears at the bottom of the screen asking if
you want to install an add-on.
e
• An attention bar may appear at the bottom of the scr
en asking if you want Internet Explorer
to remember the password for your DVR. Click either Yes or No, depending on your preference.
NOTE: If you see a white page with t
ext, you will need to enable compatibility mode. Click
the broken page icon in the address bar. The icon will turn blue.
4 Click Allow in the attention bar. The page refreshes.
5 Re-enter your remote access ID and password and click Login. Another attention bar
appears.
79
DVR Netviewer: Viewing Your DVR Using a Web Browser
Click Install
Click Install
You must port forward
your router before you can
connect to your system
using a web browser (e.g.
Internet Explorer)
!
Add-ons
Search for:
ie tab
6 Click Install in the attention bar.
7 Re-enter your re
8 Click In
stall. DVR Netviewer launches.
mote access ID and password and click Login. An install window appears.
The page refreshes.
Mozilla Firefox
You must download an extension called IE Tab before
Firefox can connect to your DVR.
NOTE: The inst
guideline only. Mozilla may change their browser
interface without prior notice.
To connect to your DVR using Firefox:
1 Open Firef
2 In the search bar, enter ie tab and then press Enter.
ructions and illustrations below serve as a
ox, and then click Firefox>Add-ons.
80
DVR Netviewer: Viewing Your DVR Using a Web Browser
View page in IE Tab
Click Install
3 Next to the add-on called IE Tab V2, click Install to install the extension.
4 Click Re
5 Enter your DVR’s DDNS a
6 Right-click anywhere on
start now or restart Firefox manually.
ddress or IP address into the address bar.
the page, and then click View Page in IE Tab. The page refreshes.
7 In the ID and Password fields, enter your remote access ID (default: 9) and password
(default: 3333) and click Login. An install window appears.
8 Click In
stall. DVR Netviewer launches.
81
DVR Netviewer: Viewing Your DVR Using a Web Browser
You must port forward
your router before you can
connect to your system
using a web browser (e.g.
Google Chrome)
!
browse the gallery
Search for:
ie tab
Google Chrome
You must download an extension called IE Tab before
Chrome can connect to your DVR.
NOTE: The ins
guideline only. Google may change their browser
interface without prior notice.
To connect to your DV
1 Open the Chr
ome browser and then click on >Tools>Extensions.
ructions and illustrations below serve as a
t
R using Ch
rome:
2 Click browse the gallery or Get more Extensions. The Chrome Web Store opens (IE Tab is a
free download).
3 In the search field, search for ie tab.
82
Loading...
