LOREX Technology LBC5451 User Manual

SECURITY CAMERA

INSTRUCTION MANUAL

ENGLISH VERSION 1.0

LBC5451

www.lorextechnology.com

Contents

CHECK YOUR PACKAGE TO CONFIRM THAT YOU HAVE
RECEIVED ALL THE COMPONENTS SHOWN ABOVE.

• 1x Camera and mounting stand

• 1x Power adapter

• 1x Mounting kit

• 1x Allen key

• 1x Screw cap

• 1x 60 ft. (18m) BNC / power extension cable

• 1x BNC Female / RCA Male adapter

• 1x Instruction Manual

Features

• High resolution Sony Super HAD™ image sensor delivers
540TV lines of resolution.

• Dual infrared / white-light LEDs provide full-color night
vision in complete darkness for long-range monitoring and
close-up recognition.

• Capable of capturing images up to 60 ft. (18m) away in total

*

darkness in B/W and 30 ft. (9m) in color

• 4.3mm wide-angle lens for wide area coverage (80° FOV)

• IP67 rated housing for indoor / outdoor installations

* Illumination range under ideal conditions. Objects at or beyond this range may

be partially or completely obscured, depending on the camera application. Color

night vision only available once motion triggers white light LEDs to turn on.
† Field of view, diagonal.
‡ Not intended for submersion in water. Installation in a sheltered location recom-

mended.

.

‡

†

.

.

i

Safety Instructions

• Read this guide carefully and keep it for future reference.

• Follow all instructions for safe use of the product and handle

with care.

• Use the camera within given temperature, humidity, and

voltage levels noted in the Technical Specifications.

• Do not disassemble the camera.

• Do not point the camera directly towards the sun or a source

of intense light.

• Use only the supplied regulated power supply. Use of a

non-regulated, non-conforming power supply can damage
this product and voids the warranty.

• Periodic cleaning may be required. Use a damp cloth only.

Do not use harsh cleaners or aerosol cleaners.

• The supplied extension cable is rated for surface mounting

only. Cables for in-wall / floor-to-floor installations are sold
separately.

ii

TABLE OF CONTENTS

1. Camera Overview . . . . . . . . . . . . . . . . . . . . . . 1

2. Night Vision Features . . . . . . . . . . . . . . . . . . 2

2.1 Night Vision . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

2.2 Motion Detection / White Light LEDs . . . . . . . . . . . . . . . . . . .2

3. Installation Tips . . . . . . . . . . . . . . . . . . . . . . . 4

3.1 Suggested Install Locations . . . . . . . . . . . . . . . . . . . . . . . . . .5

4. Installing the Camera . . . . . . . . . . . . . . . . . . 6

4.1 Before Installing the Camera . . . . . . . . . . . . . . . . . . . . . . . . .6

4.2 To Install the Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

5. Positioning . . . . . . . . . . . . . . . . . . . . . . . . . . 10

6. Connecting the Camera . . . . . . . . . . . . . . . . 12

6.1 BNC to RCA Adapter (Optional) . . . . . . . . . . . . . . . . . . . . . .13

6.2 Setup Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

7. Technical Specifications . . . . . . . . . . . . . . . 14

7.1 Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

8. Cable Extension Options . . . . . . . . . . . . . . . 16

9. Troubleshooting . . . . . . . . . . . . . . . . . . . . . . 17

iii

iv

1. CAMERA OVERVIEW

1

2

3

4

5

6

7

8

9

1 Camera Module

2 Camera Holder

3 Camera Mount

4 Mounting Base

5 DC Power / BNC Video

Connector

“Connecting the Camera”
on page 12 for details.

6 Infrared LEDs: Enabl

s: See

e the

camera to see at night.

7 White Light LEDs:

o

Aut
when motion is detected

matically turn on

(during night vision only)
to deter criminals and
allow camera to view color
images at night

8 Camer

a Lens

9 Sensor: Dete

control night vision and

cts light to

trigger White Light LEDs.

1

Night Vision Features

How it Works: During nighttime, the camera’s night vision sees up to 60 ft. in black and white. When

an object comes within a 9 ft. range, the White Light LEDs turn on, and the Infrared LEDs turn off. White
light projects up to 30 ft., allowing the camera to view close by objects in color (depending on lighting
conditions). After 15 seconds, the White Light LEDs turn off, and the Infrared LEDs turn back on.

2. NIGHT VISION FEATURES

This camera is equipped with special features that make it
more effective at deterring and identifying nighttime
intruders.

2.1 Night Vision

This camera is equipped with IR (Infrared) LEDs, which
allow it to see at night up to a range of 60 ft. (18m). It has a
built-in light sensor that activates night vision when it is
dark. The camera sees in black and white when night
vision is on.

2.2 Motion Detection / White Light LEDs

This camera is also equipped with White Light LEDs. At
night, the White Light LEDs are set to turn on
automatically when the camera detects motion within a
range of 9 ft.

(3m).

2

This helps deter / identify intruders by:

The camera detects motion using a built-in
light sensor. Avoid installing the camera in
areas where the lighting conditions are likely
to change frequently, as lighting changes may
trigger the sensor even if there is no motion.

IMPORTANT:

Typical night-vision cameras
may be overlooked by intruders

White Light LEDs draw
attention to help identify faces

Night Vision Features

• Alerting them to the presence

of the camera, after they

have already been spotted.

• Providing a better view of the intruder’s face. The white

lights on the camera turn on instantly to surprise intruders,
drawing their eyes to the camera.

• Providing color images at night. When the white lights are

activated, the camera can view close by objects in color.
Color images help identify the intruder’s face and clothing.

NOTE: Whit

e Light LEDs r

the camera detects motion.

emain on for 15 seconds after

3
