Table of contents
1 Safety Precautions .............. .. ..................................... .. .. .. ................... 1
2 What is included with my FLIR FX camera?.. ..................................... .. .. .. 2
3 How do I set up my FLIR FX camera? ............................. .. .. .. ..................3
4 What are the parts of my FLIR FX camera? ...... .. ..................................... 5
4.1 Front ................................... .. .. .. ................................. .. .. .. ........5
4.2 Top ............... ....................................... .. .. ................................5
4.3 Left........ .. .. .. ................................. .. .. .. ..................................... 6
4.4 Right.. .. .. ................................. .. .. .. ..................................... .. .. .. 6
4.5 Back .......... .. .. .. ................................. .. .. .. ................................. 7
4.6 Indoor Stand ............................. .. .. .. ..................................... .. .. .. 7
5 How do I activate manual recording? . .. ....................................... .. .. .......8
6 How do I view recordings on my computer?............. .. .. .. ......................... 9
7 How do I wall mount my FLIR FX camera? ...................... .. .................... 11
8 FLIR FX Specifications ..... .. .. .. ..................................... .. .. .. ................. 13
9 Notices...... .. .. .. ..................................... .. ..................................... .. .. . 14
DRAFT
#LX400034; r.16787/16787; en-US
v
DRAFT
1
Safety Precautions
• Camera is not weatherproof. Use the appropriate outdoor accessory if using the camera outdoors or where it will be exposed to moisture.
• Make sure that outdoor power outlets and cable connections are properly sheltered
from the elements.
• Do not use the camera below 32°F / 0°C or above 104°F / 40°C.
• Only use the camera with approved FLIR accessories.
• Do not use or install the camera near a radiator or heat source.
• Do not cover the camera with a towel or blanket.
• Do not point the camera directly towards the sun or a source of intense light.
• Aiming the camera through a window will cause the nighttime LEDs to reflect off of the
glass, causing a bright spot in the image.
• Keep the cables at least 3ft / 1m away from baby cribs and out of reach of children and
infants.
• Use the included cable clips to help keep cables away from children.
• Do not disassemble the product. No user serviceable parts inside.
• Do not disassemble or do a modification to the battery. The battery contains safety and
protection devices which, if damage occurs, may cause the battery to become hot, or
cause an explosion or an ignition.
• If you are not using the product for a prolonged time, charge the battery every 6 months
to keep the battery in working condition.
• Dispose or recycle the product and batteries in accordance with local laws, which may
vary by location.
• If using an accessory with replaceable batteries, only use replacement batteries specified by FLIR. Use of other types of batteries may damage the product.
• The camera makes a clicking noise when changing between day and night modes. This
clicking is normal and indicates that the camera filter is working.
• Do not connect more than one USB cable to the product at once.
DRAFT
#LX400034; r.16787/16787; en-US
1
2
What is included with my FLIR FX camera?
The standard model FXV101–H comes with the following components:
• Camera with indoor stand.
• microUSB cable.
• 8GB microSD card pre-installed in the camera.
• Power adapter.
• Power points for European and UK use.
• Mounting screws and drywall anchors.
• Extra mounting / camera ID plate for convenience.
• Quick start guide and safety information.
Note
Other models or configurations may come with slightly different components or accessories.
DRAFT
#LX400034; r.16787/16787; en-US
2
