Lorex Home Center
with Two 1080p Smart Outdoor Wi-Fi Cameras
Touch, Talk and View - a smart all-in-one home monitoring solution. This revolutionary home monitoring
solution puts the controls rmly in your hands with its simple touch screen interface. View and customize the two included Smart Indoor/Outdoor 1080p Wi-Fi Security Cameras using the Lorex Home Center or use our new "Lorex Voice™ Assistant" to conveniently access and control your cameras with just the sound of your voice. The Wi-Fi cameras are our rst Wi-Fi cameras featuring our Color Night Vision technology, and also include motion activated LED lights, two-way talk, and a siren you can trigger right from your Lorex Home Center if you see anything suspicious. The Lorex Home Center is a versatile hub designed to provide you with easy security while maintaining maximum privacy. This center also allows you to add further wireless cameras, devices and accessories to build the perfect security system for your home.
More than a security system, the center of your home.
The all-in-one Lorex Home Center simplies your home monitoring experience with its intuitive touch smart display. You can also use your voice to perform simple commands, such as:
"Lorex, show me all outdoor cameras" "Lorex, show me what happened yesterday at the 'front door' camera" "Lorex, show me all people* at the 'front door' camera between 2 and 3pm"
* Requires supported camera and setting to be turned on
Features
Secure Lorex Voice
Assistant
Touch Screen
Interface
1080p Full HD
Resolution
Warning Light &
2-Way Talk
Person and Vehicle
Detection
lorex.comL871T8-2CA2 Series
HOME CENTER
with Two 1080p Smart Outdoor Wi-Fi Cameras
The Center of Your Security
Easily control your cameras using the intuitive touch display1. Simply use your voice
to view and control your cameras using the secure Lorex Voice Assistant. Total and complete coverage – you can view up to 4 connected cameras at once or a specic
camera feed.
No hidden monthly fees
All video footage is safely stored on the security grade microSD card located
within the device. Upgrade the storage
to a maximum of 256GB microSD or a 1TB M.2 2280 SATA SSD M.
Extended wireless range
Use the included exible antenna to optimize the signal or add an optional
extender for hard to reach places (sold
separately, AX62TR).
Multi-Device Compatibility
Your security, your way. Add a variety of Lorex wireless devices of your choice to your Lorex Home Center for a customized system.
As you grow, so can your security
Additional Lorex devices and accessories to the Lorex Home Center to
Outdoor Wi-Fi Cameras Door/ Window Sensors
* Face unlock is limited to only 1 user and requires a well-lit area. ** An internet connection is required to use the Lorex Home App and to receive automatic device update notications.
expand and customize your system*.
Motion Sensors
*Additional devices and accessories are sold separately.
Enhanced Privacy Features
Secure Lorex Voice Assistant
As it runs on the device itself, there is no need to send audio to the Cloud unlike the competition.
Face Unlock
Login to the Lorex Home Center quickly with the Face Unlock* feature.
Camera Cover
The lens of the built-in camera can be covered if not using the Face Unlock feature.
Multiple Connection Options
Wired
Connect to your home router using the provided Ethernet cable.
Wireless
Connect to your home router wirelesly for exible
placement.
Ofine
An internet connection is not required for operating and connecting to different Lorex devices.**
lorex.comL871T8-2CA2 Series
HOME CENTER
with Two 1080p Smart Outdoor Wi-Fi Cameras
1080p Full HD Resolution
High quality 1080p resolution that
delivers enhanced clarity and detail.
2-Way Talk
With built-in mic and speaker, talk
directly through your camera to visitors
with the 2-way talk function.
Smart Deterrence
The motion activated warning light
and remote triggered siren adds an
additional layer of security. Customize your settings so the warning light is only activated when a person or vehicle is
detected.
Color Night Vision™
With help of external ambient lighting,
this camera features our revolutionary
Color Night Vision (CNV), which
produces full-colour video at night.
Person and Vehicle Detection
Avoid unwanted notications and alerts
as this camera distinguishes movement only from a person or vehicle.
Remote viewing from your mobile device with Lorex Home™
Your home will always be within reach with help from the Lorex Home App. This versatile app allows you to remotely access your Lorex Home Center so you can easily view live videos, customize your system settings, playback recorded motion events and more.
Lorex Home
lorex.comL871T8-2CA2 Series
Product Specications
Lorex Home Center
HOME CENTER
with Two 1080p Smart Outdoor Wi-Fi Cameras
Screen Size 7" Diagonal
Screen Type LCD Touch Screen
Audio
Microphone
Speakers 3 x Speakers
Camera Built-in
Wireless Camera Support
Wireless Sensor Support Up to 32
Simultanous Camera Viewing
Voice Assistant
Privacy Features Local Voice Assistant, Microphone
Digital Zoom Camera Dependent
Log-in Options Password or Face Unlock
*Devices stream by default using substream at lower resolution
Full Duplex 2-way Audio
2 x Noise Cancelling Microphones
Up to 8x1080p or 4x2K
Up to 4 channels
Lorex Voice Assistant
Circuit Cut Switch, Camera Cover
Wi-Fi Cameras
Sensor
Image Sensor 1/2.8" CMOS
Sensor Resolution 2 MP
Optical
Lens Type Fixed
Focal Length 2.8 mm
Aperture F1.6
Shutter Speed 1/3–1/10,000 s
Video
Video Resolution 1920×1080
Aspect Ratio 16:9
Frame Rate 1080p FHD @30fps
HDR No
White Balance Auto
Gain Control Auto
Noise Reduction 3D Temporal
Signal-Noise Ratio (SNR)
Video Codec H.265, H.264
Diagonal Field of View (DFOV)
≤ 50dB
129°
LEDs
White LED Yes
Infrared Wavelength 850 nm
Night Vision Range 50ft / 15m
Low Light
Color Night Vision™ Yes
Miniumum Colour Illumination
Minimum B&W IR Illumination
Wi-Fi
WLAN Protocols IEEE 802.11 b/g/n/ac
Wi-Fi Frequency Bands
Audio
Microphone Yes
Speaker Yes
Siren Yes
Two Way Talk Yes
Audio Codec AAC
Status LED Multi-color LED status bar indicator
Sensors Ambient Light
Storage Type microSD (up to 256GB)
Internet Recommendation 2 cameras ~4Mbps / 4 cameras
Home Router Connectivity 100Mbps Ethernet or 5GHz Wi-Fi
Device Connectivity 2.4/5GHz Wi-Fi / BLE 5.0
Ports Power, Ethernet, 1 x USB
Weather Rating Indoor only
Operating Temp. Range 32~104°F / 0~40°C
Languages English
Power 12V DC / 2A
Available Color White
Unit Dimensions (W × D × H)
Unit Weight 1.81lb / 0.92kg
0.02 Lux
0 Lux
2.4 GHz, 5.0 GHz
or M.2 2280 SATA SSD M (up to 1TB)*
~10Mbps @1080p upload speed*
7.5 x 3.6 x 7.0” /
19.0 x 9.1 x 17.7 cm
Storage
Capacity Up to 256 GB microSD
Electrical
Max Power 8W
Max Voltage
Max Current 1.5 A
Connectivity
Remote Viewing Lorex Home
General
Camera Dimensions (W×D×H)
Camera Weight
Storage Temperature
Storage Humidity ≤95% RH
Operating Temperature
Operating Humidity ≤95% RH
Environmental Rating
12 VDC
3.07 × 3.5 × 3.07” / 78 × 89 × 78 mm
0.73 lb / 0.33 kg
-22°F–140°F /
-30°C–60°⁰C
-22°F–140°F /
-30°C–60°⁰C
IP65 (Indoor/Outdoor)
6
lorex.comL871T8-2CA2 Series
Model Information
HOME CENTER
with Two 1080p Smart Outdoor Wi-Fi Cameras
L871T8-2CA2-E Lorex Home Center
6-95529-02791-3 with Two 1080p Smart Outdoor Wi-Fi Cameras
L871T8-2CA2-F Lorex Home Center
6-95529-02799-9 with Two 1080p Smart Outdoor Wi-Fi Cameras
Package Information
Package Retail Box
Package Weight 11.9lb / 5.3kg
Package Dimensions (W × D × H)
12.2 × 10.7 × 10.4” / 309 × 271 × 264mm
Package Cube 0.785 cbf / 0.002cbm
What’s in the box
Lorex Home Center
2 x Wi-Fi Cameras 2 x Wall Mounts
Lorex Home Center Disclaimers:
1. Video is captured and can be exported in full resolution based on the maximum resolution supported by the camera and the resolution settings the user has set.
2. Compatible with certain Lorex devices only. For a list of compatible devices please visit www.lorex.com/compatibility
3. Accessing your security system remotely requires a high-speed Internet connection. Ensure your recorder has a connection to a router (not included). An upload speed of atleast 5 Mbps is recommended for remote video viewing.
4. Image quality and frame rate are dependent on the distance and types/locations of objects between the devices and the Lorex Home Center. An optional Range Extender (model # AX62TR) is available to further extend the range (not included).
5. The Lorex Home Center can be connected to your home router wired (using included CAT5E cable) or wireless. Lorex always recommends using a wired connection whenever possible. For a wireless connection, you will need a home router supporting dual band (2.4/5Ghz) and the 5GHz network needs to be accessible.
6. The Lorex Home Center supports offline use which does not require a home router. It does mean that you will not be able to access it remotely using the Lorex Home App.
* Requires a dual-band router (2.4GHz/5GHz) with 5GHz Wi-Fi network enabled. ** Devices stream by default using substream at lower resolution.
Wi-Fi Camera Disclaimers:
1. Accuracy of Person and Vehicle Detection will be influenced by multiple factors, such as the object’s distance from the camera, the size of the object, and the height and angle of the camera. Night vision will also impact the accuracy of detection.
2. Color nighttime video typically switches to black & white IR night vision when there is not sufcient ambient light to ensure optimal low-light image quality.
3. Stated IR illumination range is based on ideal conditions in typical outdoor nighttime ambient lighting (up to 50ft/15m in total darkness). Actual range and image clarity depends on installation location, viewing area and light reflection/absorption.
4. Audio recording is disabled by default. Audio recording without consent is illegal in certain jurisdictions. Lorex Technology does not assume liability for any use of its product that fails to conform with local laws.
5. Not intended for submersion in water. Installation in a sheltered area recommended.
Local Storage
Ethernet Cable
2 x Tabletop Stand /
Ceiling Mounts
Lorex Home Center
Power Adapter
2 x Camera
Power Adapters
Quick Setup Guide
Quick Setup Guide
2 x Camera
Mounting Kits
L871T8-2CA2 Series
lorex.com
999 Corporate Blvd. Suite 110
Linthicum, MD, 21090, United States
As our product is subject to continuous improvement, Lorex Technology & subsidiaries reserve the right to modify
product design, specications & prices without notice and without incurring any obligation. E&OE.
Lorex Corporation
© 2021 Lorex Corporation
(20-0103-LOR) 03032021-2
