Lorell 60504 Assembly Instructions Manual

Model Number 60504

Assembly Instructions

Carefully unpack all parts and identify them with parts list before attempting
to assemble the chair.

IMPORTANT: DO NOT TIGHTEN BOLTS AND SCREWS FULLY UNTIL
YOU HAVE COMPLETED THE FINAL ASSEMBLY.

1. Attach METAL TUBE (B) on both METAL FRAMES (A) by using 2
SCREWS (E).

2. Attach SEAT CUSHION(C) to both METAL FRAMES (A) by
using 8 SCREWS (F).

3. Attach BACK CUSHION (D) to both METAL FRAMES (A) by using 4

SCREWS (G).

4. Be sure that all the screws are fully tightened before using.

Parts List

Description Quantity

A. METAL FRAME

2
B. METAL TUBE

1
C. SEAT CUSHION

1
D. BACK CUSHION

1
E. SCREWS (1/4” x 1/2”)

F. SCREWS(1/4” x 1-1/4”)
G. SCREWS(1/4” x 1”)
H. ALLEN KEY

2
8
4
1
