Portable power.
The Power-Tiny is the new battery-operated fog
generator from Look Solutions. It completes the
range of the off-mains operated machines (TinyFogger and Tiny Compact) perfectly and fills the
gap between high flexibility and powerful fog
output.
In the world of theatre, film, TV- and photographers, musicals and special effects, air flow and air
tightness testing – everywhere where fog is needed
quickly and efficiently, the Power-Tiny is the perfect
alternative to normal fog generators.
Features
• Minimal heat-up time
Due to the heat-up time of only one second the
Power-Tiny is ready-to-use on site.
• Light weight and small dimensions
The light weight (5.6 kg) and the small dimensions
(L=22.3, W=10, H=21 cm) makes the machine
useable for mobile uses.
• Adjustable output
The output of the Power-Tiny can be adjusted
with an adjusting knob. The release button is built
into the grip. Thus, a comfortable one-hand
operation is possible.
• Microprocessor controlled
The heart of this machine is a microprocessor which
controls and supervises all important functions.
This guarantees a continuous and safe running of
the generator.
• 250 hours stand-by time
Because of an intelligent control mechanism the
battery supplies energy only when necessary.
Thus the operation time is considerably increased
– the stand-by time is 250 hours.
With one battery 10 minutes of continuous output
or up to 150 x 5 seconds bursts can be produced.
When the battery is flat it has to be recharged
with the supplied charger.
As an option a batterypack is available (battery
complete with housing, PCB and fuses).
The fog generator can easily be disconnected from
the battery and can be connected to the new
battery quickly.
• Minimal fluid consumption
A special fluid ensures that dense fog is produced
with the lowest of fluid consumption.
• Control
The Power-Tiny is equipped with a 3pin-XLR-socket
for analog (0 - 10V) control. An XLR-remote as well
as a wireless radio remote can be connected (both
as an option).
With a DMX-converter (DMXit) the machine can
be controlled via DMX 512.
With the optional Timer (TIMEit) a fog and wait
time can be programmed in.
POWER -TINY
battery fog generator
small, quick, efficient
one-hand operation
made in Germany
Page 2
Technical data
Dimensions
Procedure
Vaporizing fog generator
Power requirement 400 Watt
Voltage 12 V with battery
Heat-up time 1 Second
Fluid tank capacity 250 ml
Fluid consumption 10 ml/Minute
at continuous output
Fog time 10 Min. continuous output
with battery or 150 x 5 Sec. bursts
Control
Start button
0-10V analog
Radio remote
(Option)
DMX 512 (Option)
Timer (Option)
Temperature control Microprocessor
Dimensions (L x W x H) 22.3 x 10.0 x 21.0 cm
Weight incl. battery 5.6 kg
21
cm
2.3 cm
Use original
Do not touch
vapour a nd
HOT
nozzle area !
Tiny-fluid only!
POWER-TIN Y
12VoltDC/400Watt
Remote
Pin1 - ground(-)
Pin2 - 0-10VDC in(+)
Pin3 - 12VDC/30mA
Serial no.
a Look Solutions
product
Advantages
• For portable uses
• Heat-up time 1 Second
• Small dimensions, light weight
• Output adjustable
• 250 hours Standby
• Continuous output
• Easy operation
• Control via start button or analog (0-10V) and
with XLR-remote, radio remote, DMX-converter,
Timer (options)
• Minimal fluid consumption
• Easy change of the batterypack
• Made in Germany
10 cm
Package includes
• Power-Tiny (fog generator + batterypack)
• Charger
• Fluid tank 250 ml
• 250 ml fluid
Accessories
• analog XLR-Remote
• Radio remote
• DMX-Converter (DMXit)
• Timer (TIMEit)
Service
Based on the strong partnership with the German
manufacturer OTTEC Technology GmbH, Look Solutions is able to provide a quick and easy service
which guarantees the high quality of all products
with the motto „innovation by communication“.
