Installation instruction for stove KOMEN / YUKON
Installation instruction stove KOMEN Creina d.d.
Kazalo:
1. Manufacturer/Model........................................................................................................................................3
1.1. Address:................................................................................................................................................3
1.2. Technical specifications........................................................................................................................3
2. Mounting instructions......................................................................................................................................5
2.1. Foreword...............................................................................................................................................5
2.2. Regulations...........................................................................................................................................5
3. Basic requirements.........................................................................................................................................5
3.1. Installation area.....................................................................................................................................5
3.1.1. Stove can be installed if:...................................................................................................................5
3.1.2. Stove must not be installed:.............................................................................................................5
3.1.3. Installation requirements..................................................................................................................5
3.1.4. Air combustion conduit.....................................................................................................................5
3.1.5. Floor protection.................................................................................................................................5
3.1.6. Fire-protection distances..................................................................................................................6
4. Transport.........................................................................................................................................................6
4.1. Packaging.............................................................................................................................................6
4.2. Handling of stove..................................................................................................................................6
5. General instructions (Air inlet is optional)..................................................................................................6
5.1. Air supply connection............................................................................................................................6
6. Repair advice............................................................................................................................................6
7. General warranty.......................................................................................................................................6
Installation instruction stove KOMEN Creina d.d.
1. Manufacturer/Model
1.1. Address:
LOKATERM Tel.: +386 (0)4 20 13 350
Creina d.d. Fax: +386 (0)4 20 13 363
Ulica Mirka Vadnova 8 E-mail: info@creina.si
4000 Kranj Website: www.lokaterm.com
SLOVENIJA www.creina.si
1.2. Technical specifications
Model KOMEN / YUKON
Model: Tip: Cabinet Pedestal
Standard: EN 13240
Nominal heat output: kW 5 kW
Average flue gas temperature (wood logs): °C 272
Flue gas mass flow (wood logs): g/s 5,4
Flue draught (wood logs; at nominal heat output): Pa 10
Weight: kg cca. 100 kg cca. 100 kg
Recommended fuels Beech wood
Logs lenght
mm max. 300
Height (lower part) ( H )
mm 427 414
Door height ( C )
mm 605
Width ( S )
mm 453 453
Glass visible area – width ( B ) mm 271
Glass visible area – height ( A ) mm 420
Stove height ( V )
mm 1080 1067
Rear flue spigot height ( Vd) mm 932 919
Air inlet connection height ( Vz ) mm 155
Air inlet connection diameter ( E )
mm 100
Depth ( G ) mm 405
Top flue spigot distance ( Gd ) mm 165
Flue spigot diameter ( R )
mm 150
Safety distances (from edge of the stove)
- front (floor/standing combustible elements) mm 500/800
- sides mm 200
- back mm 200
Installation instruction stove KOMEN Creina d.d.
Installation instruction stove KOMEN Creina d.d.
2. Mounting instructions
2.1. Foreword
Please read these instructions carefully and
pay attention to general safety instructions..
Before you start with the installation, of the
stove, check:
o If all parts are included (Notify supplier if
any of the parts are missing)
o The stove for potential damages (pay
special attention to glass, fire door and
coating protection; Notify hauler, if
damages are found)
o The functionality of all the movable parts
This manual is not a service handbook. Here
you won't find any instructions on how to
repair the stove.
2.2. Regulations
Following regulations and standards have to
be followed:
o EN 13240
o State building regulations and provisions.
o Fire-protection provisions.
o All other European, national and local
regulations and provisions that deal with
installation of the stove.
3. Basic requirements
3.1. Installation area
3.1.1. Stove can be installed if:
o Installation area is big enough to
ensure safe and normal use
(operating, cleaning …) of the stove.
o Within radiation area of the stove,
there are no load-bearing construction
elements (ex. pillars).
o Sufficient air supply is secured.
o There is at least one door or window
that leads out of the room where the
stove is installed.
o There is a direct or indirect air
connection with another room. .
3.1.2. Stove must not be installed:
o In rooms, where highly inflammable
and explosive substances or their
mixtures are being manufactured,
processed or stored.
o In rooms that are ventilated and have
safety devices that prevent negative
pressure.
o In rooms that have no adequate air
supply for stove to work properly.
3.1.3. Installation requirements
o Stove has to be installed in a way, that
connection parts (chimney flue, air
conduit), when needed of cleaning,
are easily accessible.
o Walls in installation area of the stove,
must be free of electrical and gas
installations..
3.1.4. Air combustion conduit
o Air connection for additional air supply
to the room, where stove will be
installed, has to have a cross-section
of at least 100 cm2.
o Fresh air conduit has to have an inbuilt
closing flap, where positions »open« »close«, must be clearly visible.
o When calculating the necessary air
conduit cross-section, local (elbows,
filters etc.) and line (conduit length)
resistances have to be taken into
consideration.
o When air travels through operating
combustion chamber, it heats up.
o Air conduit's overflow resistance must
not exceed 4 Pa.
3.1.5. Floor protection
o If floor, where stove will be located, is
not fire resistant, it has to be protected
by a layer of fire-resistant material (ex.
6 mm thick glass plate).
o Area where the stove will be installed,
must withstand the weight of the stove
and chimney.
o Incombustible floor area in front of the
stove has to be at least 50 cm long,
while on the sides the distance must
not be less then 20 cm. (measured
from stove walls).
Installation instruction stove KOMEN Creina d.d.
3.1.6. Fire-protection distances
Minimum distance between charging door
and combustible objects must be at least
80 cm, while for sideplates; the distance
must be greater then 20 cm.
3.1.7. Chimney
Effective height of the chimney should be
at least 4 meters (measured from the
hearth of the stove). For detailed
calculations, please refer to standard EN
13384-2.
4. Transport
Transport should be handled by experts with
appropriate equipment.
4.1. Packaging
o Stove it tightly fixed onto a palette.
o Please check the stove for possible
damages and that is contains all
ordered parts.
o If you do find any damages, please
report them to your stove supplier
immediately.
4.2. Handling of stove
o Stoves should be moved with a palette,
standing upside-down. Move it carefully
so it does not tip over!
o Avoid shocks and vibrations.
o Once in place, dismount it and proceed
with the installation.
o When transporting, do not physically
overload the top cover of the stove.
5.
General instructions (Air inlet is
optional)
o Please do not overload the stove.
o All the packing material should be removed
from hearth and ash pan.
o Check out functionality of movable parts
(front door etc.)
o Build outer air flaps into facade
o Mount smoke flap onto chimney funnel
o Connect chimney funnel. Chimney
thickness and insulation must be in
accordance with country's and EU
construction regulations.
o Chimney must not apply additional
pressure on the stove.
o Minimum diameter of the chimney should
be taken into consideration.
o Measured values, gathered in this
document, corresponds to the calculations
of chimney with the following dimensions 4 m height; diameter 150mm.
5.1. Air supply connection
o For stove to work properly, continuous
air supply is required.
o If upper requirement is not met,
additional air supply can be provided
through air tube connection (Ø100mm)
(accessory), which is inserted at the
back of the stove's pedestals onto the
stove.
o
Airflow is being regulated with air taps,
which are built-in, into air supply
conduit. These parts are not supplied
with the stove, nor they are part of the
stove.
o Please note that during winter times,
cold air surges can generate condense
on stove parts and thus compromise its
functionality. Don't expose stove to
water.
6. Repair advice
o Glass frame and most of the movable parts
can be removed once the stove is installed.
o Repairs can only be performed by a
professional in agreement with the
supplier/manufacturer
o Repair instructions are not part of this
document
o If necessary, refer to your local dealer of
service agent.
7. General warranty
For details on warranty, please look at the user
manual.
