Logos Imaging Digital Imaging System EPIX, EPIX User's Installation Manual

EPIX
Scanner
DIGITAL IMAGING SYSTEM
USB
U.S. Patent Number 5,635,728
User Manual
And Installation Guide
LOGOS IMAGING
1
INTRODUCTION
EPIX Digital Imaging System by LOGOS IMAGING
Congratulations on your purchase of the EPIX Digital Imaging System. The EPIX Digital Imaging System is a revolutionary new product designed to replace traditional x-ray film and film processors.
TECHNICAL SUPPORT
For technical support, call you Logos Imaging dealer or Logos Imaging directly.
SUPPLIES AND REPLACEMENT PARTS
To order supplies or replacement parts for your EPIX Digital Imaging System, call your Logos Imaging equipment dealer. If your dealer is unable to assist you, call Logos Imaging.
Logos Imaging EPIX Scanner User Manual
2
TABLE OF CONTENTS
Section 1: Use..............................................................................................................................3
Section 2: Safety Requirements.................................................................................................4
2.1. IMPORTANT INFORMATION..........................................................................................4
2.2. WARNINGS AND CAUTION STATEMENTS...................................................................4
Section 3: Pre-Installation Information and Recommendations............................................6
3.1. PURPOSE OF THE MANUAL...........................................................................................6
3.2. ABBREVIATIONS AND EXPLANATION OF SYMBOLS .................................................6
3.3. PHYSICAL DESCRIPTION...............................................................................................7
3.4. COMPUTER REQUIREMENTS...................................................................................... 10
3.5. ELECTRICAL REQUIREMENTS ....................................................................................10
3.6. COMPLIANCE TO STANDARDS................................................................................... 10
Section 4: Installation...............................................................................................................11
4.1. SITE SELECTION........................................................................................................... 11
4.2. UNPACKING THE UNIT................................................................................................ 12
4.3. LOADING THE EPIX SCANNER DRIVER SOFTWARE................................................. 13
4.4. HARDWARE SETUP AND CONNECTIONS................................................................... 13
Section 5: System Operating Instructions ..............................................................................14
5.1. PREPARING YOUR CURRENT X-RAY EQUIPMENT ...................................................14
5.2. ERASE THE IMAGING PLATE...................................................................................... 14
5.3. TAKING AN X-RAY....................................................................................................... 15
5.4. SCANNING THE IMAGING PLATE ...............................................................................16
5.5. TURNING OFF THE EPIX SCANNER SYSTEM............................................................. 16
Section 6: Software Operating Instructions ...........................................................................17
Section 7: Maintenance Procedures........................................................................................18
7.1. CLEANING THE SYSTEM............................................................................................. 18
7.2. OPERATOR MAINTENANCE........................................................................................ 19
7.3. TROUBLESHOOTING.................................................................................................... 20
7.4. DISPOSAL OF WASTE MATERIALS AND INOPERARTIVE PARTS............................ 22
Section 8: Storage and Shipment.............................................................................................23
8.1. STORAGE....................................................................................................................... 23
8.2. SHIPMENT..................................................................................................................... 23
Section 9: Technical Specifications .........................................................................................24
9.1. SPECIFICATIONS.......................................................................................................... 24
Section 10: Warranty Statement...........................................................................................25
Appendix A: Storage Phosphor Technology ………………………………………………....... 26
Appendix B: Lighting Conditions for Handling or Erasing Imaging Plates ……………..... 27
Appendix C: Optional Printer ………........................... ...............................................………. 29
Appendix D: Warranty Registration ..……………………………………………………........…. 30
Logos Imaging EPIX Scanner User Manual
3
SECTION 1: USE
The EPIX Digital Imaging System is intended for use as a general radiography system using x-ray recording media (phosphor imaging plates) for radiographic analysis providing interactive CRT retrieval, viewing and processing of stored computed radiographic images.
The EPIX SCANNER is not intended for medical imaging of humans.
The system includes reusable photostimulatable phosphor imaging plates, a laser diode scanner device and optical reader components, communications electronics and software, a workstation and various peripheral accessories.
Logos Imaging EPIX Scanner User Manual
4
SECTION 2: SAFETY REQUIREMENTS
2.1. IMPORTANT INFORMATION
It is important that all personnel who will operate the EPIX Digital Imaging System read and understand this manual before
follow all warnings and precautions as outlined in Section 2.2, for their safety and the safety of others around them.
operating the device. All personnel should
2.2. WARNINGS AND CAUTION STATEMENTS
In this manual, the following definitions apply for all WARNINGS and CAUTION statements:
Warnings: Any operation, procedure or practice, which, if not strictly observed, may result in injury or long-term health hazards.
Cautions: Any operation, procedure or practice, which, if not strictly observed, may result in destruction of equipment or loss of effectiveness.
Never chew or swallow the imaging plates
If the imaging plate is bitten or chewed, the plate and damages the protective barrier envelope, rinse the mouth with a large amount of water. If any of the blue surface of the plate is swallowed, contact a doctor immediately.
The EPIX scanner is a Class 1 laser device per EN60825-1:2001 U.S. 21 CFR Chapter I Subchapter J. Caution: Use of controls or adjustments or
WARNINGS The EPIX Digital Imaging System should
be used only by trained professional.
performance of procedures other than those specified herein may result in hazardous radiation exposure. A fail-safe switch in the carousel well and cover keeps the laser
Do not open the device to service it.
None of the internal parts of t he scanner are user serviceable. The only user serviceable parts of the system are outlined in Section
7.2. If there is a service problem, call your qualified Logos Imaging dealer or Logos
inactive as long as the cover is open. Only a trained technician from a qualified Logos Imaging dealer should remove the cover from the scanner. Direct eye contact with the output beam from the laser may cause serious damage and possible blindness.
Imaging.
Use only fuses with the required current
Use only grounded electrical connections.
Connect the EPIX scanner to a grounded electrical outlet between 100-240 volts AC.
Imaging plates are toxic!
The blue colored substance in the imaging plate is toxic. If part/all of an imaging plate is swallowed, contact a physician immediately. The physician must remove
rating and of the specified type.
Make sure that only fuses with the required current rating and of the specified type are used for replacement. The use of incorrect or makeshift fuses or the short-circuiting of fuses holders creates a shock hazard for the operator and may damage the device.
the imaging plate. Do not use cracked, bent or chipped imaging plates.
Logos Imaging EPIX Scanner User Manual
5
CAUTION STATEMENTS Completely erase the imaging plates.
Before reusing an imaging plate, lay it blue or white surface up facing a bright light source for two (2) minutes as described in Section 5.2.
Mount the imaging plates under low light conditions.
Mount the imaging plates to the carousel under low light conditions as described in Section 5.4. Exposure to direct sunlight or direct indoor lighting will erase the information stored on the imaging plate.
Do not place scanner on or next to a radiator or water source.
Excessive heat or small amounts of water may damage the scanner’s electrical components.
Do not leave unscanned, exposed imaging plates in light.
Leaving unscanned, exposed imaging plates in light will cause loss of image quality.
Do not scratch the imaging plates
When handling the imaging plate, do not touch the active side (blue or white) with fingernails or any sharp object that might scratch the surface. Do not lay unprotected imaging plates face down.
Logos Imaging EPIX Scanner User Manual
6
SECTION 3: PRE -INSTALLATION INFORMATION AND
RECOMMENDATIONS
3.1. PURPOSE OF THE MANUAL
The instructions contained in this manual should be carefully followed for safe, trouble-free and effective equipment use. This manual provides the essential
operation and routine care of the EPIX Digital Imaging System. This manual is not to be used as a replacement for training in radiography.
information necessary fo r the installation,
3.2. ABBREVIATIONS AND EXPLANATION OF SYMBOLS
AC alternative current DC direct current Hz Hertz; cycles per second MHz Millions of hertz
CPU central processing unit (your
computer) in inch IEC International Electrotechnical
Commission
LED light emitting diode
| power on
mm millimeter
O power off
cm centimeter
green indicator, ready
kVp peak voltage in thousands of
volts IP imaging plates CD-ROM compact disc, read-only CCD charge-coupled device TIFF tagged image file format BMP bit-mapped JFIF joint photographic image
format
yellow indicator, scanning red indicator, error in scanning high voltage laser radiation RAM random access memory MB mega bytes GB giga bytes USB Universal Serial Bus
JPEG joint photographic expert
group LP/mm line pairs per mm D.P.I. dots per inch
Logos Imaging EPIX Scanner User Manual
The CE symbol ensures that
the product herein specified meets the applicable provisions of the European Council Directives.
7
3.3. PHYSICAL DESCRIPTION
The EPIX Digital Ima ging Systems consist of the following components:
Quantity
Description
1 EPIX SCANNER laser scanner 1 Carousel, 8 x 10 in and/or 8 x 17 in, depending on
configuration
2 Imaging Plates, 8 x 10 in and/or 8 x 17 in, depending on
configuration 2 8x10 in screen holders 2 8x17 in screen holders 3 8x10 light shields 3 8x17 light shields 1 Logos Imaging software package 1 User manual (this manual) 1 Software user manual 1 USB cable, 6ft 1 Power Cord 1 Tool kit 6 Spare carousel clips
Customer Supplied Components
Bottle of anhydrous isopropyl alcohol for cleaning imaging plates Computer system as described in Section 3.4.
Optional Equipment from Logos Imaging
Imaging plate, 8 x 17 in Imaging plate, 8 x 10 in Light box for erasing and storing imaging plates Carrying Case
Logos Imaging EPIX Scanner User Manual
8
EPIX SCANNER LASER SCANNER
1XXX
Figure 3-1 Scanner Front View
Carousel well and lid. The carousel, with imaging plates attached, is inserted into the carousel well for scanning. The carousel lid must be in the closed position prior to scanning. The scanner will not operate with the lid open.
LED indicator lights with graphic symbols. The lights show the current status of the system. Green — Ready to scan
Yellow — Scanning Red — Error
Figure 3-2 Scanner REAR View
EPIX SCANNER power entry module with switch and fuses USB connectors. A USB cable (provided) connects the EPIX
SCANNER to the CPU’s USB port. ƒ Power cord socket. The power cord (provided) will be
connected from t his point to a grounded main outlet. Scanner label
Logos Imaging EPIX Scanner User Manual
DECEMBER 2002
9
Figure 3-4 8 x 17 in. and 8 x 10 in. IMAGING PLATES
8 x 17 in 8 x 10
Plastic mounting strips used to hold
Active imaging area, white color
imaging plate onto the carousel
Figure 3-5 CAROUSELS
Front (White)
Rear (Black)
8 x 10 8 x 17
Top of the carousel Imaging plate retaining device
Logos Imaging EPIX Scanner User Manual
10
3.4. COMPUTER REQUIREMENTS* Minimum Computer Requirements Recommended
CPU Speed 1.0 GHz or higher Operating system Windows 2000 and Windows XP operating systems RAM 256 MB Hard Drive 6 GB CD ROM Drive 4X 24X USB port Required Display 24-bit display (minimum 800x600 resolution) Backup Device Highly recommended Printer Recommended (see appendix C)
*See also the Imaging Software computer requirements.
3.5. ELECTRICAL REQUIREMENTS
Voltage 100-240 V AC 50/60 Hz power supply auto-senses the input voltage. Power 100 watts maximum Power Cord Standard line cord provided
3.6. COMPLIANCE TO STANDARDS The EPIX SCANNER Digital Imaging System conforms to the following standards:
EN61000-4-2: Electrostatic discharge EN61000-4-3: Radiated susceptibility EN61000-4-4: Electrical fast transient and
burst EN61000-4-5: Surge, AC 1 kV differential, 2 kV common EN61000-4-6: Conducted disturbances, 9
kHz to 30 kHz. 3 VRMS EN61000-4-8: Magnetic fields
EN61000-4-11: Voltage dips, interruptions, and voltage variation
Part 15 of the FCC Rules DHHS/CDRH: Radiation Performance
Standard, 21 CFR, Chapter I, Subchapter J EN61010-1 EN60825-1 EN50082-1 / EN55011 CAN/CSA-C22.2 No. 1010.1-92 UL 3101-1
Logos Imaging EPIX Scanner User Manual
11
4.1. SITE SELECTION
SECTION 4: INSTALLATION
The EPIX SCANNER can be located almost anywhere the operating conditions are met. The site you pick should have:
œ Subdued lighting conditions. You should
have the ability to turn down/off the lights and block sunlight with blinds. The area to be used for mounting imaging plates should not exceed 20 lux as measured on a light meter. This will give you about one minute to mount all of your imaging plates without encountering excess signal fading. If you cannot measure the light in the room where you wish to mount the imaging plates, you should turn off the room lights, close all blinds and leave the door open just enough so that you can see to mount the imaging plates. This should make the light level about 10-20 lux. If you need more than one minute, refer to appendix B.
œ A stable, flat countertop large enough to
hold the scanner plus provide a working area. We suggest a minimum of 18 x 36 in. (46 x 92 cm). The computer does not need to be on the countertop, but must
be within the length of the USB cable (6ft or 2m provided). If a longer cable is needed, it should not be longer than maximum 12 ft. (4 m). The countertop must be able to hold the weight of the unit or a minimum of 60 lbs (27 kg).
œ Access to a standard grounded electric
outlet.
œ Enough room to allow the operator to
mount imaging plates and use the computer effectively.
If you choose to put the system in your darkroom, please prepare the site by:
œ Removing all old film processing
equipment and plumbing.
œ Remove the safelight filter and adjust the
intensity of the light by lowering the bulb wattage until the intensity of the light around the scanner is 20 lux or less.
œ We recommend that you keep the light
off and the door open when mounting imaging plates to the carousel. The light from the open door will allow you to see enough to mount the imaging plates but will not adversely affect the image.
Logos Imaging EPIX Scanner User Manual
12
4.2. UNPACKING THE UNIT
The EPIX Digital Imaging System is shipped in two boxes. Completely unpack the boxes and save them in a safe, dry location. You may need to repack the unit for shipping if you ever encounter a maintenance outage, or relocate your office.
Fig. 4-1 Scanner, 1 each
Fig. 4-2 1 each 8 x 10 in
Carousel And/or 1 each 8 x 17 in
Carousel
Inventory the contents of the box and ensure that you have all of the following components. If any items are damaged or missing, contact your dealer immediately.
Fig. 4-3 2 each 8 x 10 in Imaging Plate And/or 2 each 8 x 17 in Imaging Plate
Fig. 4-4 Logos Imaging Software
package
Fig. 4-5 Power Cord, 1 each
Fig. 4-6 User Manual and Installation
Guide (this document), 1 each
Logos Imaging EPIX Scanner User Manual
13
4.3. LOADING THE EPIX DRIVER SOFTWARE
Power
Do not plug in or turn on the EPIX scanner before installing the Logos Imaging software. The EPIX system drivers are loaded automatically during Logos Software installation.
WARNING: THE EPIX SYSTEM MUST NOT BE INSTALLED ON THE NETWORK SERVER
4.4. HARDWARE SETUP AND CONNECTIONS
Before you start the hardware setup, ensure that you have an acceptable computer as outlined in Section 3.4. The computer must have a USB port available.
Step 1: Pick a location using the guidelines from 4.1. Step 2: Set up the computer and monitor per the manufacturer’s recommendations. Use an
ergonomic setup to minimize repetitive motion injuries.
Step 3: Turn the power on to the monitor and computer. Step 4: Connect the device end of the USB cable to the USB connector on the back of the EPIX
SCANNER. Connect the scanner to a grounded power outlet. Make sure the other end of the USB cable is connected to the USB port on the computer.
USB
Cable
Cable
Fig. 4-7
Step 5: Connect the computer to a network if desired. Refer to your Imaging Software User
Manual and Installation Guide for more information.
Step 6: Turn the power on to the scanner. The green light on the scanner should be lit at this
time. If it is not, follow the trouble shooting guidelines in Section 7.3.
Logos Imaging EPIX Scanner User Manual
14
SECTION 5: SYSTEM OPERATING INSTRUCTIONS
5.1. PREPARING YOUR CURRENT X-RAY EQUIPMENT
The EPIX Digital Imaging System produces x-ray images of high quality and low noise. More details on how this technology works can be found in appendix A. Almost any x­ray unit can be used with the EPIX system. There is no need to purchase a new one. The imaging plates can produce an excellent
5.2. ERASE THE IMAGING PLATE
Imaging plates should be erased just prior to use. Scanning an imaging plate does not erase all the image information. To completely erase the imaging plate, expose the front surface (blue or white in color) to direct, intense light for at least 2 minutes.*
An effective way to erase the imaging plate is to use a light box. Simply lay down the imaging plate active side up (blue or white face) facing the light box shining down. Expose the plates to light for about 2 minutes. To avoid scratching the imaging plates, refrain from lying the imaging plate active face down on a light box.
image over a wide range of exposures. With the EPIX system, it is possible to get high­quality images at the same exposure time you use for x-ray film. This is a great benefit to you because it means that it will be more difficult to over- or under-expose an image.
Alternatively, place the imaging plates within 8 inches of a lamp equipped with a lit 100-watt bulb for two minutes, minimum. The imaging plates are now completely erased and are ready for reuse. Avoid using sunlight since it contains UV light that can deeply stimulate the phosphor and leave artifacts in the image. Longer, non-UV light erasing may be required to rid the image plate of these artifacts.
*Note: Erasing time will vary depending on the quality and intensity of the erasing light. For more detailed information, see appendix B.
Logos Imaging EPIX Scanner User Manual
15
5.3. TAKING AN X-RAY
Fig. 5-1 Ensure the computer, monitor and EPIX
SCANNER are switched on and properly connected. The green LED indicates that the system is ready to scan
Fig. 5-2 Launch your imaging software. Refer to your
Imaging Software User Manual for details Fig. 5-3 Place the erased 8 x 10 in or 8 x 17 in imaging
plate into a screen holder or protective sleeve with the white side pointed toward the X-ray machine .
Place the screen holder/protective sleeve behind the item to be x-rayed and expose in the usual manner.
Fig. 5-4 In a semi-darkened room (see Section 4.1), open
the screen holder. With the white surface pointed away from the carousel, insert one side of the imaging plate under the edge of the imaging plate clip. Push with your thumbs until you hear a “click.” NOTE: If the image plate does not click into place, slide the image plate to one side then the other until it clicks into place.
8 x 10 in shown. Fig. 5-5 Wrap the imaging plate around the carousel and
push the free end under the edge of the other clip. Push until you hear a “click.”
8 x 10 in shown.
Logos Imaging EPIX Scanner User Manual
Fig. 5-6 Open the carousel well cover on the EPIX
SCANNER and insert the carousel. Close the cover. You are now ready to scan your 8 x 10 in or 8 x 17 in imaging plate.
16
5.4. SCANNING THE IMAGING PLATE
5.5. TURNING OFF THE EPIX SYSTEM
Fig. 5-7 Once the scanner has been loaded, click on the
EPIX Image button on the Logos Imaging Image Library toolbar. The software will automatically sense whether an 8 x 10 or 8 x 17 carousel is loaded.
Fig. 5-8 When the scan is complete, the image
thumbnail will appear in the Image Library window.
If an error occurs during the scan or if the carousel lid is opened during the scan, the scanner will stop. Follow the troubleshooting guidelines to start scanning again. If the resulting image is not of high enough quality, erase the imaging plate and start again.
The EPIX SCANNER Digital Imaging System is designed to be left on continuously. The laser is only operational while the unit is actually scanning. If you wish to turn the system off, use the following procedure.
1. Wait until any scan in progress is
complete and the green light is on.
2. Save any changes you have made and
close down the imaging software. To
protect your data, frequently back-up your files.
3. Turn the power switch in the back of the
scanner to the “Off” position.
4. Turn off all computer components
following any instructions from the manufacturer.
If you live in an area of frequent thunderstorms or variable line voltages, you may want to turn the unit off on a more regular basis.
Logos Imaging EPIX Scanner User Manual
17
SECTION 6: SOFTWARE OPERATING INSTRUCTIONS
Logos Imaging software can capture digital x-ray images from the EPIX systems. Please refer to the Logos Imaging software user’s manual or online help file for detailed instructions.
Logos Imaging EPIX Scanner User Manual
18
SECTION 7: MAINTENANCE PROCEDURES
The EPIX Digital Imaging System is designed for many years of trouble-free operation. It is manufactured from the highest quality components to ensure excellent performance. Maintenance that can be performed by the operator is minimal.
7.1. CLEANING THE SYSTEM Cleaning the Scanner
Turn off the EPIX SCANNER, as described in Section 5.5, before cleaning. Wipe the outside surfaces with a paper towel dampened with a cold sterilant solution or household, non­abrasive cleaner (window cleaner works well). DO NOT SPRAY OR SOAK THE SCANNER. Wipe the inside of the carousel well with a very slightly damp cloth. Be careful not to allow running or dripping solvents into the EPIX SCANNER. This could cause damage to the electronics inside. Allow to air dry before plugging in or turning back on.
Cleaning Imaging Plates
Imaging plates should be handled carefully. For the best images, take care not to scratch
Cleaning the carousel:
Fig. 7-1 Spray the soiled surfa ces of the imaging plate holder
and carousel with a general household non-abrasive cleaner or soap and water. Do not use strong alkaline or ammonia based cleaners. Wipe clean and allow to air dry.
them and keep them dust-free. Use the following procedure to cle an them:
1. Use lint-free, 100% cotton gauze (not
cotton balls). Gently wipe the cotton gauze over the dry imaging plate surface. Wipe back and forth and then in a circular motion.
2. To clean any remaining stains, dampen the
gauze in anhydrous isopropyl alcohol and wipe using the same motion as above.
3. Completely dry the surface by wiping with
another piece of cotton gauze. Ensure that the imaging plate is completely dry before use.
Logos Imaging EPIX Scanner User Manual
19
7.2. OPERATOR MAINTENANCE Scanner Maintenance
The only operator serviceable part of the EPIX SCANNER is the fuse. If you experience any other maintenance problem, contact your local Logos Imaging dealer. Follow these directions to change the fuse.
Fig. 7-2 Turn the EPIX SCANNER off as per Section 5.5.
Unplug the power cord and USB cable. WARNING: To avoid possible electrical shock, ensure
that the power cord is unplugged. Fig. 7-3
Insert a small, flat tipped screwdriver into the top of the fuse cover on the back of the scanner. Pry the top of the connector open.
Fig. 7-4 Remove the fuse holder. Change both fuses. Ensure that
new fuses meet the following specifications: 250 V, 2 amp, Time Lag, High Breaking Capacity. Insert the fuses, REF 5101-0005, into t he fuse holder.
Fig. 7-5 Insert the fuse holder and close the cover. Plug the
power cord back in and turn the system on as outlined in Section 5.5
Carousel Maintenance
The carousel from the EPIX SCANNER can be maintained by the operator.
Imaging Plate Maintenance
The EPIX SCANNER imaging plates have no operator serviceable parts. The EPIX SCANNER Digital System might occasionally require lubrication. Please refer to the
EPIX SCANNER service manual or your service technician.
Logos Imaging EPIX Scanner User Manual
20
7.3. TROUBLESHOOTING
TROUBLE PROBABLE CAUSE CORRECTIVE ACTION
No power No green light
Scanner not plugged in Check power cord at outlet and at the
connection on the back of the scanner. Turn on the scanner and then turn on the
computer and monitor. Blown fuse See Section 7.2 Main power switch or power
Call your service representative.
supply is bad
Outlet does not have power Ensure that the outlet is grounded and
has power. Red, Green and/or Yellow
Defective LED Call your service representative LED(s) do not work; system operates normally
The Scanner does not initialize when the software is opened
The lid on the carousel well is
The scanner has not been
turned on
If the green power indicator light is off, switch on the EPIX SCANNER per Section 5.5.
Close the lid.
open The USB cable between the
scanner and computer is loose
or defective. The computer does not
recognize that the scanner is
connected or the scanner has
not been added to the Device
Reconnect the cable. Check for tightness. Swap with a known good cable if possible.
Turn off the scanner and re -install the EPIX SCANNER systems software driver (see section 4.3).
Turn the unit on.
Manager There is a hardware problem
Contact your service representative
with the EPIX SCANNER. After scan ning, no image
appears on the monitor The imaging plate is mounted
There are no imaging plates on
the carousel.
backwards on the carousel.
Ensure that the exposed imaging plate is properly mounted for scanning
The imaging plates are to be mounted with the white or blue surface visible. Turn incorrectly mounted plates around and rescan
The imaging plate was erased
prior to scanning.
Ensure that imaging plates are mounted under low light conditions as outlined in
Section 4.1. Hardware failure. Call your service representative. X-ray source failed. Call your service representative.
Logos Imaging EPIX Scanner User Manual
21
TROUBLE PROBABLE CAUSE CORRECTIVE ACTION
Image is too dark Imaging plate has been
overexposed
Image contains ghost images or shadows.
Imaging plate was not completely erased.
Imaging plate was exposed
with the back of the IP facing the X-ray machine You may notice the writing from the back of the plate on the image.
Imaging plates have been
stored in protective envelopes for too long a period.
Partial erasure of the image
due to exposure to light during handling of the imaging plates.
Image shows artifacts. The imaging plate surface is
not clean and has dirt or stains on it. The surface may be scratched.
The imaging plate was
removed from the cassette too quickly, which resulted in a static discharge.
A cosmic event occurred and
deeply exposed the image plates with cosmic rays. This may occur during shipment.
Imaging plates fall out into the EPIX SCANNER carousel well
The imaging plates have not been loaded properly. See Section 5.3 for more information.
The red light stays on and the scanner stops
The lid to the carousel well has been opened.
Hardware failure Call your service representative
Adjust brightness with software. If this is
not possible, retake image at lower
exposure. See exposure guidelines
Section 5.1.
Increase the amount of time that is used
to erase plates. Alternatively, increase the
intensity of the light source. To test if an
imaging plate is completely erased,
simply mount an erased plate on a
carousel and scan it. If no image is
obtained, your procedure is effective at
completely erasing imaging plates.
Insure the imaging plates are inserted
properly into the protective envelope and
the proper orientation to the x-ray source
is maintained
Do not store imaging plates in protective
envelopes for more than one week.
Do not leave exposed imaging plates in
well-lit areas. Even in the protective
envelope, some light penetrates and can
partially erase the imaging plates.
Transfer imaging plates from their
protective sleeve to the EPIX SCANNER
as quickly as possible (within one hour
of exposure).
Clean the imaging plate as outlined in
Section 7.1. If the plate is scratched or
stained, do not use the plate again.
Clean the imaging plate with anhydrous
isopropyl alcohol AND remove from
cassette more slowly.
Erase the image plate and rescan until the
artifacts are no longer present.
Practice loading erased imaging plates in
full light until you become familiar with
the loading procedure. You will hear a
“click” when the panoramic screen is
loaded properly.
Do not raise the lid while the unit is
scanning.
Logos Imaging EPIX Scanner User Manual
22
7.4. DISPOSAL OF WASTE MATERIALS AND INOPERARTIVE PARTS
Disposal regulations vary from country to country. Therefore, it is difficult to give specific instructions on the disposal of EPIX
Material Items Recycle? Comments
Plastic Carousel Latches No Dispose of with other non-recyclable plastic
Aluminum Housing, Optic
Module Carousels Yes Scan Engine Frame Yes Carriage, Optic
Module Storage
Phosphors
Other Materials
I/O Imaging Plates No
All Others No All other materials should be land filled.
SCANNER waste materials and inoperative parts. In general, we believe the following guidelines to be true.
items.
Yes Remove all non-aluminum parts before
recycling.
Yes
Contain barium, which may be regulated. No No
Contact your local Logos Imaging location
for more information and instructions on
what to do with damaged imaging plates.
Logos Imaging EPIX Scanner User Manual
23
8.1. STORAGE
SECTION 8: STORAGE AND SHIPMENT
The EPIX Digital Imaging System has been designed for long -term operation in a normal office environment. The system must be protected from adverse conditions such as excessive moisture, cold or heat. If the system is to be stored for a long period of time, pack the unit in its original carton.
8.2. SHIPMENT
The EPIX Digital Imaging System is designed to be shipped in its original shipping container by normal commercial carriers. Ensure that the carousel has been removed from the scanner and that the carousel well is empty.
If the system is to be moved long distances or under adverse conditions, it should be
While in storage, keep at moderate temperatures and protect against moisture and humidity. When you are ready to use the system again, unpack it and allow the scanner to come back to room temperature. Then, follow the guide lines outlined in Section 5.
protected. This can be accomplished by wrapping the EPIX scanner in a plastic bag before putting it in the original packing materials.
If you are shipping the scanner, it is necessary to park the optics module in the center of travel prior to shipment. Contact your Logos Imaging dealer for details.
Logos Imaging EPIX Scanner User Manual
24
SECTION 9: TECHNICAL SPECIFICATIONS
9.1. SPECIFICATIONS
EPIX Scanner
Height 39.4 cm 15.5 in Width 49.3 cm 19.4 in Depth 27.4 cm 10.8 in Weight (empty) 15 kg 32 lbs Interface Cables USB cables Voltage 100-240 V AC Frequency 50/60 Hz Power 100 watts max. Laser Classification Compliance per DHHS Radiation Performance
Standards 21 CFR, Ch I, Subch. J+EN60825 Class 1 Laser Device
Storage and Shipping Conditions -40° to 70°C (-40° to 158°F)
EPIX Imaging Plates
Dimensions: 8 x 10 in (20.3 cm x 25.4 cm) and 8 x 17 in (20.3 x
43.2 cm) Resolution at 300 DPI: 85 micron square pixels, approximately 4 lp/mm Resolution at 150 DPI: 170 micron square pixels, approximately 2 lp/mm Recommended Dose : Equal to standard systems equipped with rare-earth
intensifying screens (400 speed)
Storage: Store in their clear plastic shipping envelope
Logos Imaging EPIX Scanner User Manual
25
EPIX Scanner
SECTION 10: WARRANTY STATEMENT
The scanner and carousels are warranted against defects arising from faulty materials or workmanship for one (1) year from date of purchase. Parts will be repaired or replaced at our option. The EPIX Scanner and Carousels must be installed and
EPIX Imaging Plates
The EPIX Imaging Plates are designed expressly for us e with the EPIX scanner. EPIX Imaging Plates will be replaced if defective in manufacturing or packaging only. With proper handling, EPIX Imaging
operated in accordance with the Logos Imaging written instructions furnished with the unit. Please fill out the warranty registration card (appendix D) and mail to Logos Imaging as instructed.
Plates are designed for years of effective use. They can, however, be damaged if folded, creased, scratched or dented, and, therefore no additional warranty is provided.
Logos Imaging EPIX Scanner User Manual
26
Appendix A: Storage Phosphor Technology
State
Unstable Excited
Blue light emitted
Expose to Red Laser
Expose IP to X
-
Rays
The EPIX SCANNER Digital Imaging System produces high quality x-ray images at very low doses. The imaging plates in the EPIX SCANNER system are much more efficient at capturing x-ray energy than x-ray film.
as molecules return
Stable Excited
Imaging Plates Ground
State (Erased Imaging
to ground state
How Storage Phosphor Imaging Plates Work
Each EPIX SCANNER Imaging Plate is made up of a very thin layer of tiny storage phosphor crystals that are bonded together and coated on a flexible sheet of plastic. These storage phosphor crystals have the ability to capture
the energy of x-rays and store the pattern as a latent image (see diagram).
In essence, they act as an “energy trap,” storing x-ray energy. The amount of energy stored is directly proportional to the amount of x-ray energy the crystal was exposed to.
The EPIX SCANNER further excites the phosphor crystals to an unstable state by exposing them to a red laser. The phosphor crystals then release a blue light and return to their stable ground state. The EPIX SCANNER reads this blue light and, with the imaging software, produces an image.
This process does not completely erase the imaging plate. Some crystals remain as “energy traps.” This information can be erased by exposing the imaging plate to light. A few seconds of low levels of light will usually not effect the image quality. Once erased, the imaging plate can be re-exposed and the process can begin again. With proper handling, EPIX SCANNER Imaging Plates can be continually reused.
Logos Imaging EPIX Scanner User Manual
27
Appendix B: Lighting Conditions for Handling or Erasing Imaging Plates
Without light, storage phosphor imaging would not work. The red light from the laser scanner excites the exposed imaging plates, causing them to emit blue light. After your computer interprets the blue light and changes it into a digital image, light is used to erase the residual information from the imaging plate.
Between x-ray exposure and scanning, however, one must be careful handling the imaging plates. An imaging plate should never be removed from its protective sleeve or cassette and exposed to a strong source of light. This act would erase the latent image from the plate. Therefore, you must load imaging plates onto the carousel under controlled light ing conditions. The recommendations below have been developed to ensure that you obtain excellent image quality.
Recommendations on Lighting Conditions for Loading Carousels
œ Fluorescent Lights
If loading can be accomplished in less than 60 seconds, the fluorescent lighting in the
area should not exceed 20 lux. If loading will take longer than 60 seconds, the room conditions need to be darker. At 10 lux, the operator has about 5 minutes to accomplish loading.
œ Incandescent Lighting
Incandescent lighting is about half as efficient as fluorescent lighting at fading imaging plates. Here, again, we recommend lighting conditions of around 20 lux. Under incandescent lighting, however, you have about 2 minutes to complete the loading process. If it takes longer than 2 minutes, decrease the amount of light to 10 lux.
œ Sunlight
Sunlight is the most efficient light for fading imaging plates. Additionally, it is very difficult to judge the intensity of sunlight. Loading carousels under sunlight is not recommended.
If you cannot darken your mounting area to 20 lux or less, contact your local Logos Imaging representative for suggested mounting times.
Logos Imaging EPIX Scanner User Manual
28
Recommendations on Lighting Conditions for Erasing Imaging Plates
In order to completely erase imaging plates,
99.5% of the image information must be removed. Scanning only removes part of the information. To completely erase imaging plates, follow the guidelines given below. It is important that you measure the light intensity with a light meter at the point where the imaging plate will be positioned. The intensity of light changes dramatically as you move away from the source. Erasing the imaging plates for periods of time longer than suggested does not harm them. A good place to store your imaging plates is under the erasing light source.
œ Fluorescent Lights
A light box typically gives off between 1000 and 5000 lux. Measure your light box and use the lowest value to determine the erasing time. At 1000 lux, an imaging plate will be erased in 1 minute. At 2000 lux or more, 30 seconds is sufficient.
œ Incandescent Lighting
At 1000 lux, an imaging plate will be erased in about 2 minutes. At 2000 lux or more, erase for 1 minute.
œ Sunlight
Full sunlight on a bright day can be as strong as 70,000 lux. At this intensity, it takes less than 10 seconds to erase imaging plates. However, sunlight is too variable, and we do not recommend using it.
If you are unable to directly measure the light output from your erasing light source, or do not have an erasing light source greater than 1000 lux, use the practical test, below, to determine your erasing time.
Practical Test
1. Completely erase an imaging plate by
subjecting it to direct, intense light for about 20 minutes.
2. Scan the imaging plate. No image should
appear on the monitor. If an ima ge does appear, repeat step 1 with a more intense light source.
3. Place the imaging plate in a sleeve or
cassette.
4. Expose the imaging plate using normal
exposure conditions. If possible, place an object, in the path of the x-ray beam.
5. Turn on your erasing light source. We
recommend a light box or a minimum l00­watt incandescent light bulb (see Section
5.2).
6. Remove the imaging plate from its sleeve
or cassette and place it with the blue side toward the light for 2 minutes.
7. Scan the imaging plate. If an image
appears, the plate was not completely erased. Repeat step 6, adding a minute to the exposure time. Continue to repeat until no image appears on the monitor. Record the erasing time that resulted in no image. This is the time required to erase an unscanned imaging plate.
8. Repeat steps 1-4. This time, under low
light conditions, remove the imaging plate from the sleeve or cassette and mount it on the carousel. Scan the imaging plate.
9. Remove the scanned imaging plate and
place it, in the dark, into a light-protected area (such as a light-tight drawer.
10. Now repeat steps 6 and 7, exposing one
plate (blue side toward light) to the erasing light for 2 minutes, the next plate for 3 minutes, etc., until you find the point where no image appears on the monitor. This is the time required to erase a scanned imaging plate.
The time required to erase an imaging plate will vary depending on the quality and intensity of the erasing light source. It should be fairly easy to find a light source that will erase imaging plates in 2-3 minutes.
Logos Imaging EPIX Scanner User Manual
29
Appendix C: Optional Printer
Because the EPIX SCANNER system can be interfaced with different applications software, and printer technology is constantly evolving, we can only suggest a list of suitable technical requirements for printers.
œ To interface with the PC, the printer must
have a digital input and not a video (analog) input.
Inkjet printers
Black and white or color hard copy. Printers should have a minimum of 600 dpi resolution and pseudo-randomic dithering. Using the standard Windows® drivers allows the use of the same printer for all other Windows applications (word processing, etc.).
The Epson Stylus Photo product line is suitable for printing moderate to good quality images. We recommend using the photographic quality glossy paper and printing on the highest resolution setting available.
Dye Sublimation printers
Advised whenever the EPIX SCANNER System is used when high printing quality is required.
Application software
Please refer to the instructions in the application software for special information about printers.
Logos Imaging EPIX Scanner User Manual
4
Appendix D: Warranty Registration
It is important that you register your new EPIX SCANNER Digital Imaging System with Logos Imaging, so that we will be able to inform you directly of any changes or upgrades to the system. As with any software product, there will be continuous improvements to imaging software, and you may be interested in some of the upgrades.
Name Address City, State Country, Postal Code Phone Serial Number
Registering your system with Logos Imaging ensures that you will be promptly notified of any new offerings.
Please return this registration to:
Logos Imaging Customer Service P.O. Box 765 Richmond, IN 47375 USA
Date of Purchase Comments
Suggested Improvements
I o am o am not satisfied wit h my purchase of the EPIX SCANNER Digital Imaging System.
Logos Imaging EPIX Scanner User Manual
Loading...
