Welcome!

Congratulations on your purchase of the Logitech® io™2 Digital Pen with Bluetooth® wireless technology.

This manual provides valuable information about your digital pen, its features and functionality, as well as information
about how to obtain additional support from Logitech.

After you have become familiar with the Logitech’s digital pen with Bluetooth, be sure to visit www.logitechio.com
to learn more about what other customers have done to maximize the benefits of this unique data capture device.

Features

Ink cartridge removal hole

Memory/Bluetooth status

LED

Battery status LED

1. Pen Cap. Acts as the on/off switch for the digital pen. The hole in the clip also serves as the ink cartridge remover.

2. Battery and Memory/Bluetooth Status LEDs. Provides battery and memory level, as well as Bluetooth®

connectivity status information.

3. Reset Button. Resets the digital pen. (See Troubleshooting for more information.)

4. USB Cradle. Charges the digital pen.

Page - 1

Logitech® io

™

2 Digital Pen with Bluetooth®

Connecting and Charging the Digital Pen

You must charge the digital pen before using it. Battery charging takes up to two hours.

Note In order for the digital pen to charge, the USB cradle must be plugged into a USB port on your computer

and your computer must be running. The digital pen draws the power it needs from the computer through
the USB port. Additionally, the digital pen can be charged using a wall or car charging adapter, which
connects to the USB cradle. (For more information, see Recharging the Digital Pen.)

1. Turn on your computer.

2. Open the USB cradle by pulling the top of the cradle stand away from its bottom.

Cradle stand

3. Place the USB cradle on a flat surface.

4. Connect the cradle’s USB connector to the computer’s USB port.

5. Remove the pen cap. The Battery and Memory/Bluetooth Status LEDs flash red,

yellow, and then green. The digital pen will vibrate once to indicate it is on.
The Memory/Bluetooth Status LED will flash blue to indicate the pen is in
Bluetooth discoverable mode. The discoverable mode (with cap off) lasts for
two minutes.

6. Insert the digital pen into the USB cradle. The Microsoft® Windows® operating
system will detect the new hardware and a dialog box will launch asking if you
would like to load the appropriate drivers.

Page - 2
