Wi-Fi 6E PCI Express Card
Art. No.: WL0248
Enjoy stable Wi-Fi performance and high speed wireless network with Wi-Fi 6E PCIe card.
Supports the speed of 2.4 Gbps on the 5 GHz/6 GHz and 574 Mbps on 2.4 GHz, you can enjoy viewing
HD multimedia while playing real-time online game at the same time. Also equipped with Bluetooth 5.2
function supporting connection to Bluetooth headset, Bluetooth stereo, Bluetooth keyboard/mouse and
others for more convenience and demands.
Features:
» Complies with IEEE802.11 ax/ac/a/b/g/n standards
» Data transfer rate up to 574 Mbps (2.4 GHz) or up to 2.4 Gbps (5 GHz/6 GHz)
» Supports Bluetooth 5.2
» Supports Windows, Mac OS and Linux
Specification:
Chipset Solution INTEL AX210
Interface Type USB 2.0 /1.1
Standard IEEE802.11 ax/ac /a/b/g/n
2.4 GHz: 574 Mbps
Data Rate
Interface PCI Express 1x slot and USB
Bluetooth Version 5.2
Antenna 2x 5dBi un-fixed
Dimension 6,5x4,45x0,16 cm
Supported OS
Environment
5 GHz: 2400 Mbps
6 GHz: 2400 Mbps
®
Windows
Mac OS® 10.x (Intel based, tested up to 10.9)
Linux 2.4.x and later (Tested up to 3.5)
Operating Temperature: 0°–70°C
Relative Humidity: 10–90% (non-condensing)
Storage Temperature: -10–80°C
Relative Humidity: 5–90% (non-condensing)
10 (32/64)
*The specifications and pictures are subject to change without prior notice.
*All trade names referenced are the registered trademarks of their respective owners.
Package Contents:
» 1x Wi-Fi 6E PCIe Card
» 2x High Gain Antennas
» 1x USB Cable
» 1x Low Profile Bracket
» 1x User Manual
Package Information:
» Packing Dimension: mm
» Packing Weight: kg
» Carton Dimension: mm
» Carton Q‘ty: pcs
» Carton Weight: kg
