Best Connectivity
www.LogiLink.
Art No. WL0225
com
WLAN 11ac USB adapter
11ac: Next-Generation Wi-Fi - Dual Band Gigabit
An ultra-fast wireless 11ac network is designed to stream flawless HD video to multiple
devices, play games, use Skype, and download large attachments in seconds.
By upgrading your current network to 11ac, you can immediately enjoy the benefits of faster
wireless speeds and increased home coverage so you can enjoy doing what you love most.
Easily Upgrade to Next Generation 11ac
Now you can have the world’s fastest WiFi technology, even on older laptops and desktops.
Just plug the adapter into a USB slot and surf, stream or game at blazing speeds.
Features:
• Easily upgrade your PC to the next generation 802.11ac WiFi
• Dual Band 2.4G or 5GHz
• Enjoy ultimate speed, range and performance
• Stream multiple HD videos simultaneously
• External Wi-Fi Protected Setup (WPS) button
• Works with standard 802.11 a/b/g/n and ac WiFi routers
Specification:
WiFi Technology
Chipset
WiFi Band Dual Band 2.4G or 5GHz
Standards IEEE 802.11 b/g/n 2.4 GHz
Operating Channels 13 for Europe
Data Rate (Mbps) 54, 48, 36, 24, 18, 12, 9, 6, 11, 5.5, 2, 1
802.11ac
MT7610
IEEE 802.11 a/ac 5.0 GHz
20 MHz BW: 150, 130, 117, 104, 78
40 MHz BW: 300, 270, 243, 216, 162, 108
80 MHz BW: <=433
*All trade names referenced are the registered namework of their respective owners.
* The specifications and pictures are subject to change without notice.
- 1 -
Best Connectivity
www.LogiLink.
Art No. WL0225
WLAN 11ac USB adapter
Security 802.1x, WEP 64/128, WPA/WPA2, TKIP
WiFi Range Large Homes
RF Output Power 18±1.5dbm@11b ,15±1.5dBm@2.4G,
14±1.5dBm@5G,13±1.5dBm@
System Requirements Intel® Pentium® class PC
Available USB 1.1, USB 2.0, or USB 3.0 port
Microsoft® Windows® 7, XP, Vista®: (32/64-bit)
Supports Windows® 8
MAC OS 10.7/10.8/10.9
Physical Specifications Dimensions: 80 x 25x 10 mm (L x W x H)
Weight: 0.016kg
The type of Connector USB
com
What is 11AC Wi-Fi?
The fifth generation of Wi-Fi technology, 11ac delivers incredible speed and
whole-home coverage -- up to three times as fast as the current "11n" Wi-Fi.
The Fastest Wireless Speed – 11ac is delivering the fastest wireless speed for
smooth gaming, high-quality HD video streaming and fast file transfers.
Enhance Your Connected Home – 11ac speed and coverage to your connected
home ensures that all your connected devices get the seamless performance they
deserve.
Whole Home Coverage – Dramatically improve the wireless range in your home
for true wall-to-wall, whole-home connectivity.
Dual Band – Provides up to 450Mbps (2.4GHz)
+1300Mbps (5GHz) speeds with less interference for maximum throughput.
*All trade names referenced are the registered namework of their respective owners.
* The specifications and pictures are subject to change without notice.
- 2 -
Best Connectivity
www.LogiLink.
Art No. WL0225
WLAN 11ac USB adapter
Backward Compatibility –
standards 11a/b/g/n, ensuring that your current networking devices do not
become obsolete.
Why do you need an 11ac network?
11ac is backward compatible with older wireless
com
The problem with current Wi-Fi: Interference & Congestion
Most mobile devices and wireless routers use the same 2.4 GHz frequency.
Interference and congestion occurs when too many devices are accessing the
router at the same time. When such unwanted traffic gets in your way, it slows down
overall speed. Data is forced to queue, resulting in slow-moving traffic.
Package Content:
• 1x WLAN 11ac USB Adapter
• 1x User Manual
• 1x Installation CD
Packaging Information:
• Packing Dimension: 184 x 120 x 20mm
• Packing Weight: 0.046 kg
• Carton Dimension:576 x 325 x 356 mm
• Carton Q'ty: 100pcs
• Carton Weight: 5.1 kg
*All trade names referenced are the registered namework of their respective owners.
* The specifications and pictures are subject to change without notice.
