Best Connectivity
www.LogiLink.
Art No. WL0151
com
Wireless N 150Mbps USB Adapter
The WL0151 is a highly integrated MAC/BBP and 2.4GHz RF/
PA/LNA single chip with 150Mbps PHY rate supporting. It fully
complies with IEEE802.11n and IEEE802.11b/g feature rich
wireless connectivity at high standards, delivers reliable, costeffective, throughput form an extended distance. The WL0151
is designed to support standard based features in the areas
of security, quality of service and international regulation,
giving end users the greatest performance anytime in any circumstance. The
very small and compact WLAN adapter design is good for wireless connectivity
when an external antenna needs.
Feature:
• Chipset: Ralink RT5370
• With 2dBi detachable antenna
• Complies with IEEE802.11b/g/n standards
• Supports 64/128-bit WEP, WPA, WPA2,
WPA-PSK and WPA2-PSK Encryption
• High transfer data rate – up to 150Mbps
• Supports WiFi Protection Setup (WPS)
• Supports USB 2.0/1.1 interface
• Supports Windows 2000/XP/Vista/7/8,
Linux 2.6.x and MAC OS
Software and System Information
Linux 2.4/2.6 ARM, MIPSII
Windows 2000/XP/Vista/7/8 X86 Platform
Mac OS X 10.3/10.4/10.5/10.6 N/A
*All trade names referenced are the registered namework of their respective owners.
* The specifications and pictures are subject to change without notice.
- 1 -
WL0151
Best Connectivity
www.LogiLink.
Art No. WL0151
com
Wireless N 150Mbps USB Adapter
Specification:
Hardware
Main Chipset Ralink RT5370
Host interface USB 2.0/1.1 Type A
LED Link/Activity
RF Performance
Standards IEEE802.11b/g & 802.11n (1T1R mode, 150Mbps)
Antenna 2dBi detachable antenna
Antenna Connector SMA Male Reverse
Operation Frequency 2412~2483.5 MHz (varies according to different regions).
Typical Tx Power
(E.R.I.P)
Receive Sensitivity 802.11b: -86±1dBm; 802.11g: -74±1dBm
Software Support
Operation System Windows 2000/XP/Vista/7/8; Linux 2.6.X; Mac OS X
Security WEP 64/128bit, WPA, WPA2, 802.1x, and 802.11i, Cisco CCS
Operation conditions
Voltage Range/
Current
Temperature Operation: -10°C ~ 60°C
Humidity(NonCondensing)
Physical Specification
Dimensions (Main body)16.4x14.7x58 mm
Net Weight 9.8g
802.11b (CCK)11Mbps: 19±1dBm; 802.11g (OFDM)
54Mbps: 16±1dBm
802.11n (HT20@MCS7), 15±1dBm; 802.11n (HT40@MCS7),
15±1dBm
802.11n (HT20), -70±1dBm; 802.11n (HT40), -70±1dBm
Compliant
DC 5.0V ± 5% <160mA
Storage:-20°C ~ 70°C
Operation: RH 95%
Storage: RH 95%
*All trade names referenced are the registered namework of their respective owners.
* The specifications and pictures are subject to change without notice.
- 2 -
WL0151
