Best Connectivit
y
www.LogiLink.
Art No. WL0037
com
Wireless 9dBi Omni Antenna
By connecting this wireless 9dBi Omni directional antenna on your wireless
router, access point or adapter etc., it extends transmitting distance of the
wireless signals and improves the wireless range in your garden, attic or
other places which had a low wireless signal before.
Specification:
• SMA male reverse connector
• Antenna type 9dBi Indoor Omni Antenna
• Frequency Range 2.4 ~ 2.4835GHz
• Gain 9 dBi
• V.S.W.R < 2.0
• Beam Width: H Plane 360° /E Plane 37.7°
• Polarization Vertical (Linear)
• Input Impedance 50 Ohms
• Usable for wireless Networks Specification: IEEE 802.11a/b/g/n
• Mini. System requirements: Wireless router, access point or adapter with detachable
reversed SMA antenna connection
Packaging Information:
• Packing Dimension: 31x410x31 mm
• Packing Weight: 0.055kg
• Carton Dimension: 330x330x450 mm
• Carton Q'ty: 100pcs
• Carton Weight: 7.5kgs
*All trade names referenced are the registered namework of their respective owners.
* The specifications and pictures are subject to change without notice.
WL0037
4 260113 565155
Made in Taiwan
