Art No. WC0020
1.3 Megapixel Network Camera
Feature:
• Powerful Remote Surveillance on Multiple Mobile Platforms
- For mobile device platforms, iPad®, iPod®, iPhone®, BlackBerry®, Nokia® Symbian,
Windows® Mobile & Android™ (with their built-in web browsers or EagleEyes)
- For web browsers, Internet Explorer®, Mozilla Firefox®, Safari®, Google Chrome™
and Opera
- For operating systems, Windows & Mac
- For multiple device control, our CMS software, Video Viewer, is provided for free
• 1.3 Megapixel live MOS sensor
• HDTV 720p quality, allowing users to notice minor details more easily
• Multiple video streams selectable: H.264 / MPEG4 / MJPEG
• Motion detection and event notification functions
• Digital pan / tilt / zoom for more details checking
• White LED application to illuminate the scene manually or scheduled by a timer
• Face detection function for human face detection and tracking
• Microphone built-in for audio recording
• Free CMS software with E-Map for multiple devices control & surveillance
• ONVIF standard supported to simplify system integration
Specification:
• Network
Network Compression H.264 / MPEG4 / MJPEG
Multiple Video
streaming (Encode
Modes, IPS, Resolution)
LAN Port YES
LAN Speed 10/100 Based-T Ethernet
Supported Protocols DDNS, PPPoE, DHCP, NTP, SNTP, TCP/IP, ICMP, SMTP, FTP,
ONVIF Compatible YES
Frame Rate NTSC: 30, PAL: 25
Number of Online Users 10
* The specifications and pictures are subject to change without notice.
*All trade names referenced are the registered namework of their respective owners.
3 (H.264, MJPEG, MPEG4)
HTTP, RTP, RTSP, UPnP
- 1 -
www.LogiLink.
com
Art No. WC0020
1.3 Megapixel Network Camera
Specification:
Security Multiple user access levels with password protection
Web management (1) Web browsers, such as Internet Explorer, Mozilla Firefox,
Google Chrome, Safari & Opera for single device access, or
(2) Free CMS software, Video Viewer, for up to 16 network
cameras control simultaneously
• Camera
Image Sensor 1/3" live MOS image sensor
Resolution SXGA to QVGA
Min Illumination 0.1 Lux / F1.5, 0 Lux (LED ON)
Shutter Speed 1 / 60 (1/50) to 1 / 100,000 sec.
S/N Ratio More than 48dB (AGC off)
Lens f4.0mm / F1.5
Viewing Angle 75°
White LED YES
White Balance ATW
AGC Auto
IRIS Mode AES
Microphone YES
Power Source (±10%) 5V / 1.2A
Operating Temperature 0°C~40°C
Dimensions(mm)** 95 x 59 x 41
• Others
Mobile Surveillance iPad, iPod, iPhone, BlackBerry, Windows Mobile, Symbian &
Android
RTC (real-time clock) YES
Mobile Surveillance iPad, iPod, iPhone, BlackBerry, Windows Mobile, Symbian &
Android
RTC (real-time clock) YES
Motion Detection YES
*All trade names referenced are the registered namework of their respective owners.
* The specifications and pictures are subject to change without notice.
- 2 -
www.LogiLink.
com
Art No. WC0020
1.3 Megapixel Network Camera
Specification:
Digital Pan/Tilt/Zoom YES
Face Detection YES
Event Notification FTP / Email / SMS
Minimum Web
Browsing Requirements
- Pentium 4 CPU 1.3 GHz or higher, or equivalent AMD
- 256 MB RAM
- AGP graphics card, Direct Draw, 32MB RAM
- Windows 7, Vista & XP, DirectX 9.0 or later
- Internet Explorer 7.x or later
Package Contents
• 1 x 1.3M Network Camera
• 1 x Power Supply
• 1 x CD + Manual
Packaging Information:
• Packing Dimension: 208x104x99mm
• Packing Weight: 0.5kg
• Carton Dimension: 514x440x345mm
• Carton Q'ty: 30pcs
• Carton Weight: 15.63kgs
* The specifications are subject to change without notice.
** Dimensional tolerance: (± 5mm)
*All trade names referenced are the registered namework of their respective owners.
* The specifications and pictures are subject to change without notice.
