* The specifications and pictures are subject to change without notice.
*All trade names referenced are the registered namework of their respective owners.
Two-sectioned
Wall-mounted Cabinet
Technical Features
Material: 1-1.2 mm steel
Maximum Static Load: Up to 100 kg
Finish: Electrostatic powder paint
Color: RAL 7035 light grey or RAL 9005 black
Standard Configuration
- Steel frame
- Glass door with cylindrical lock
- Accessible from rear side with double hinged design
- 1 Pair of heavy duty 19” Mounting Rails
- RoHS compliant, UL and Gost-R certificated
* The specifications and pictures are subject to change without notice.
*All trade names referenced are the registered namework of their respective owners.
Two-sectioned Wall-mounted Cabinet - RAL 9005 Black
d1
W=600
D
HeightU Outer
Width
(W) mm
6U 600 300+150 366 266 530 260+120 110-205 20.23 W06D65B 8698800000768
6U 600 500+150 366 266 530 460+120 110-405 22.40 W06D67B 8698800000782
9U 600 300+150 500 400 530 260+120 110-205 29.93 W09D65B 8698800000805
9U 600 500+150 500 400 530 460+120 110-405 32.44 W09D67B 8698800000829
12U 600 300+150 632 532 530 260+120 110-205 38.67 W12D65B 8698800000843
12U 600 500+150 632 532 530 460+120 110-405 42.87 W12D67B 8698800000867
15U 600 300+150 766 666 530 260+120 110-205 46.34 W15D65B 8698800000881
15U 600 500+150 766 666 530 460+120 110-405 52.61 W15D67B 8698800000905
18U 600 300+150 900 800 530 260+120 110-205 55.46 W18D65B 8698800000928
18U 600 500+150 900 800 530 460+120 110-405 62.90 W18D67B 8698800000948
21U 600 300+150 1034 934 530 260+120 110-205 64.67 W21D65B 8698800000966
21U 600 500+150 1034 934 530 460+120 110-405 72.43 W21D67B 8698800000980
Outer
Depth
(D) mm
Outer
Height
(H) mm
Inner
Height
(h1) mm
Inner
Width
(w1) mm
Inner
Depth
(d1) mm
19" Rails Adjustable
Depth Range
(c) mm
Weight kgPart No. EAN Code
Two-sectioned Wall-mounted Cabinet - RAL 7035 Light Grey
HeightU Outer
Width
(W) mm
6U 600 300+150 366 266 530 260+120 110-205 20.23 W06D65G 8698800000751
6U 600 500+150 366 266 530 460+120 110-405 22.40 W06D67G 8698800000775
9U 600 300+150 500 400 530 260+120 110-205 29.93 W09D65G 8698800000799
9U 600 500+150 500 400 530 460+120 110-405 32.44 W09D67G 8698800000812
12U 600 300+150 632 532 530 260+120 110-205 38.67 W12D65G 8698800000836
12U 600 500+150 632 532 530 460+120 110-405 42.87 W12D67G 8698800000850
15U 600 300+150 766 666 530 260+120 110-205 46.34 W15D65G 8698800000874
15U 600 500+150 766 666 530 460+120 110-405 52.61 W15D67G 8698800000898
18U 600 300+150 900 800 530 260+120 110-205 55.46 W18D65G 8698800000911
18U 600 500+150 900 800 530 460+120 110-405 62.90 W18D67G 8698800000935
21U 600 300+150 1034 934 530 260+120 110-205 64.67 W21D65G 8698800000959
21U 600 500+150 1034 934 530 460+120 110-405 72.43 W21D67G 8698800000973
Outer
Depth
(D) mm
Outer
Height
(H) mm
Inner
Height
(h1) mm
Inner
Width
(w1) mm
Inner
Depth
(d1) mm
19" Rails Adjustable
Depth Range
(c) mm
Weight kgPart No. EAN Code
h1
w1
D
W=600
