19" Wall-mounted single
section box, disassembled
Technical Features
1.2mm steel
Maximum static load up to 30kg
Electrostatic powder paint
RAL 7035 light grey or RAL 7021 dark grey colors
Product dimensions are 6/9/12/15 U, 540mm width and 450mm depth
Glass door with cylindrical lock
Adjustable 19" profile rails
Cable entry from 3 sides
Disassembled flat pack delivery
Art-No.
Dark Grey = B
Light Grey = G
W06F64B 6U 540 450 330 110-350 14 4052792016321
W06F64G 6U 540 450 330 110-350 14 4052792016314
W09F64B 9U 540 450 460 110-350 17 4052792016345
W09F64G 9U 540 450 460 110-350 17 4052792016338
W12F64B 12U 540 450 595 110-350 20 4052792016369
W12F64G 12U 540 450 595 110-350 20 4052792016352
W15F64B 15U 540 450 725 110-350 25 4052792016383
W15F64G 15U 540 450 725 110-350 25 4052792016376
Made in China
Height UOuter
Width
(W)
mm
Outer
Depth
(D)
mm
Outer
Height
(H) mm
19“ Rails
Adjustable
Depth Range
(mm)
Weight
kg
www.logilink.com
EAN Code
Technical Drawings
D
H
W
Package Contents
1 x 19" Wall-mounted single section box
Packaging Informations
Packing Dimension
Packing Weight
575 x 490 x 210mm (W06F64x) / 590 x 500 x 215mm (W09F64x) / 655 x 570 x 210mm (W12F64x) /
790 x 570 x 210mm (W15F64x)
14kg (W06F64x) / 17kg (W09F64x) / 20kg (W12F64x) / 25kg (W15F64x)
Carton Dimension
Carton Q‘ty
Carton Weight
575 x 490 x 210mm (W06F64x) / 590 x 500 x 215mm (W09F64x) / 655 x 570 x 210mm (W12F64x) /
790 x 570 x 210mm (W15F64x)
1pc
14kg (W06F64x) / 17kg (W09F64x) / 20kg (W12F64x) / 25kg (W15F64x)
www.logilink.com
Made in China
