Single Wallmount Cabinet
with Openable Side Panels From Outside
Technical Features
Material: 1 / 1.2 / 1.5 mm steel
Maxi. Static Load: Up to 50 kg
Finish: Electrostatic Powder Paint
Color: RAL 7035 or RAL 9005
W1
AA
D1
19"
C
H1
H
W
» Steel frame
» Glass door with cylindrical lock
» Openable side panels from outside
» 1 Pair of 19” Mounting Rails
» RoHS compliant, UL Certificated
» Flat packed (disassembled)
450
44,50
8,50
145
D
45,50
72,80 60
Wallmount Cabinet - RAL 7035 Light Grey / RAL 9005 Black
Height
U
6 540 400 323 498 370 283 100– 340 13 W06A40X
6 540 550 323 498 530 283 100– 495 15 W06A54X
9 540 400 456 498 370 416 100– 340 15 W09A40X
9 540 550 456 498 530 416 100– 495 17 W09A54X
12 540 400 589 498 370 549 100– 340 17 W12A40X
12 540 550 589 498 530 549 100– 495 19 W12A54X
15 540 400 723 498 370 683 100– 340 19 W15A40X
15 540 550 723 498 530 683 100– 495 21 W15A54X
Outer width
(W) mm
Outer depth
(D) mm
Outer
height (H)
mm
Inner width
(W1) mm
Inner depth
(D1) mm
Inner height
(H1) mm
19“ rails
adjustable
depth range
(C)
Weight
kg
Part No.
X=B (Black)
X=G (Grey)
*All trade names referenced are the registered namework of their respective owners.
* The specifications and pictures are subject to change without notice.
