Best Connectivit
y
www.LogiLink.
Art No. UA0149
com
USB3.0 4-Port Hub
The UA0149 is very well shielded owing to its metallic casing and as such is the
optimum solution for an industrial use. It can be mounted below the table or at
the wall. This creates order at the work place. The power pack contained in the
scope of supply provides for extra power with current hungry USB devices. Also,
diagnostic LEDs provide port status for each port and power status.
Features:
• Compliant to USB3.0/2.0/1.1
Specification
• Supports USB3.0 High-Speed up to
5Gbps
• 1 x up-stream port and 4 x down-stream
ports support
• Connects up to 127 USB devices
• Equipped with over-current Detection &
Protection
• With external power adapter (5V, 3.5A)
• Metal housing with mounting rack
• LED status indicator
• Plug & Play
• Supports Windows XP/Vista/7
Technical Specifications:
Dimensions (W×H×D) 117x20×45 mm
Weight 130g
Power Adapter 100-240V AC, 50-60Hz, 3500mA
Input Voltage Without Power Adapter 5V DC, 500 mA
With Power Adapter 5V DC, 3500 mA
Cable Length 1 m
Operating Temperature -5°C to 45°C
Storage Temperature -10°C to 60°C
Package Content:
• 1 x 4-Port USB HUB
• 1 x USB3.0 Cable
• 1 x Power Adapter
• 1 x User Manual
Packaging Information:
• Packing Dimension: 170x117x60 mm
• Packing Weight: 0.4kg
• Carton Dimension: 380x300x300 mm
• Carton Q'ty: 25pcs
• Carton Weight: 9kgs
*All trade names referenced are the registered namework of their respective owners.
* The specifications and pictures are subject to change without notice.
