Best Connectivity
Art No. UA0021D
Art No. UA0021D
www.LogiLink.
de
USB Line Extender
over Cat 5/5e/6 Network Cable
The UA0021D USB Line Extender b the UNIQUE UIC 4102 chipset enables
you to extend USB devices up to 30 meters away over Cat5/Cat5e/Cat6 cable
without signal loss.
This LogiLink USB Line Extender consists of atransmitter and receiver unit
separately. The transmitter connects to the local USB 1.1 or 2.0 ports on your
PC and the receiver unit connects to the USB device. Use the Logilink USB Line
Extender to overcome the USB distance restriction and expand device and PC
locations and better organize productive office arrangements. The Logilink USB
Line Extender can help extend a USB keyboard and mouse during presentations,
operate a barcode scanner in retail point-of-purchase applications, access a
printer in another room and improve other USB applications without signal loss
or interference.
It's lightweight and portable with no external power supply or drivers required,
making it ideal for travel and use almostanywhere. Plug and Play capability
and Windows and Macintosh compatibility make installation easy and quick.
Specification:
• Compliant with USB 1.1 standard
• Allows a USB device to extend cable length up to 60m
• Embedded USB 1.1 Transceivers prevents signal loss
• Easy connected by a Cat5e/6 networking cable
• In comparison with extension of cable using USB device like Hubs, Printer, Scanner,
Mouse and Camera etc.
• Supports Windows 98SE/ME/2000/2003/XP/Vista/7/8/10, Mac OS
*All trade names referenced are the registered namework of their respective owners.
* The specifications and pictures are subject to change without notice.
- 1 -
Best Connectivity
Art No. UA0021D
Art No. UA0021D
USB Line Extender
over Cat 5/5e/6 Network Cable
Applications:
• WEB-Camera
• Surveillance Camera
• Printer
• Scanner
• Mouse
• Keyboard
• MP3..etc
www.LogiLink.
de
Package Contents:
• 1 x USB Extender Receiver
• 1 x USB Extender Transmitter
Packaging Information:
• Packing Dimension: 157 x 198 x 87mm
• Packing Weight: 0.15kg
• Carton Dimension: 300 x 480 x 320mm
• Carton Q'ty: 30pcs
• Carton Weight: 5.4kg
*All trade names referenced are the registered namework of their respective owners.
* The specifications and pictures are subject to change without notice.
- 2 -
