Art No. PC0075
de
2-Port Gigabit LAN PCI-Express Card
This PCI-Express dual Gigabit Ethernet controller card is a high performance
10/100/1000 BASE-T Ethernet LAN controller, and is perfectly to convert the
PCI-Express interface into two Gigabit Ethernet ports.
Specification:
• Chipset: RTL8111F + Asmedia 1182E
• Two Gigabit Ethernet ports (RJ45 x 2)
• Complies with PCI-Express Base Specification Revision 2.0
(Backward compatible with 1.0a/ 1.1)
• A high performance 1000BASE-T Ethernet controller card
• Maximize your virtualized server's networking efficiency with dedicated ports
•10/100/1000Mbps data rate auto negotiation operation
• Fully compliant with IEEE 802.3, 802.3u and 802.3ab
• Supports full duplex flow control (IEEE 802.3x)
• Supports IEEE 802.1P layer 2 Priority Encoding
• Supports IEEE 802.1Q VLAN tagging
• Crossover Detection and Auto Correction operation
• Supports WOL (Wake-On-LAN) function
• Dimension: 120.0mm (L) x 92.6mm (W) x 21.5mm (T)
System Requirements
• Windows 8.1/8 32-/64-bit, Windows 7 32-/64-bit, Windows Server 2008 32-/64-bit,
Windows Vista 32-/64-bit, Windows Server 2003 32-/64-bit, Windows XP 32-/64-bit,
Windows 2000, ME, 98SE, Linux, MAC OS and DOS
• Computer with a free PCI-Express slot
Package Contents:
• 1 x 2-Port Gigabit LAN
PCI-Express Card
• 1 x User Manual
• 1 x Driver CD
* The specifications and pictures are subject to change without notice.
*All trade names referenced are the registered namework of their respective owners.
:
Packaging Information:
• Packing Dimension:
30 x 171 x 185mm
• Packing Weight: 0.14kg
• Carton Dimension:
640 x 400 x 190mm
• Carton Q'ty: 50pcs
• Carton Weight: 7.1kg
