Best Connectivity
www.LogiLink.
Art No. PC0059
com
USB3.0 + SATA 6Gb/s Combo PCI
Express Card
2-Port external USB3.0 + 2-Port internal SATA 6G/s
Features:
• True SATA 6Gb/s & USB 3.0 support: Native support PCIe Gen2 bandwidth
• PCI Express Base Specification Rev. 2.0
• PCI Express Card Electromechanical Rev. 2.0
• Serial ATA AHCI Spec. Rev.1.3
• Serial ATA Revision 3.0
• One lane PCI Express for 2.5 and 5GHz signaling
• Single virtual channel
• ECRC and Advanced Error Reporting capability
• 2 ports Serial ATA PHY for 1.5, 3.0 and 6.0GHz signaling
• Supports IDE/AHCI mode
• Supports Native Command Queue (NCQ)
• Supports Gen1m and Gen2m SATA PHY
• Supports Port Mult Compliant with Universal Serial Bus 3.0 specification Revision 1.0.
• Compliant with xHCI (eXtensible Host Controller Interface) specifications Revision 1.0.
• Supports simultaneous operation of multiple USB 3.0, USB 2.0 and USB 1.1 devices.
• Expands two external USB3.0 Super-Speed ports on the system
• Hot-swapping feature allows you to connect/disconnect devices without powering
down the system
*All trade names referenced are the registered namework of their respective owners.
* The specifications and pictures are subject to change without notice.
- 1 -
Best Connectivity
www.LogiLink.
Art No. PC0059
com
USB3.0 + SATA 6Gb/s Combo PCI
Express Card
2-Port external USB3.0 + 2-Port internal SATA 6G/s
Specification:
Bus Type PCI Express
Chipset ID ASMEDIA ASM1061& AS1042
Number of Ports 2 external USB3.0 &2 Port Internal SATA III
Transfer Rate SATA III transfer rate of 6.0Gbps,3.0Gbps,1.5Gbps
Data Transfer rate of 1.5/12/480/5000 Mbps.
Dimensions 69(W) x 130(L)mm
Environment Operating Temperature: -0°C to 50°C (32°F to 122°F)
Storage Temperature: -20°C to 60°C (-4°F to 140°F)
OS Compatibility Windows 2000/XP/Vista/7/8(32/64-bit)
Windows Server 2003/2008
Bracket Standard 121mm
Product Dimension 130 x 120 x 22mm
Product Weight 172g
The type of Connector USB3.0 A type x 2 port + SATA III 2 port
Package Content:
• 1 x PCI Express USB3.0 & SATA III card
• 1 x Driver CD
• 1 x User Manual
Packaging Information:
• Packing Dimension: 210x143x40 mm
• Packing Weight: 0.19kg
• Carton Dimension: 600x300x400 mm
• Carton Q'ty: 45pcs
• Carton Weight: 9.4kg
*All trade names referenced are the registered namework of their respective owners.
* The specifications and pictures are subject to change without notice.
- 2 -
